Axio Lab.A1
The ergonomic design elements of the Axio Lab.1 are:
Vertically adjustable, swivel-type and swivel/vertically adjustable ergo tubes
Skin-friendly surfaces on binocular section of the tubes, control elements and stand
Ergo table with fixed stage drive
Vertical and friction adjustable stage drives
Optional use of fine focusing knobs in standard form or as a jog/shuttle knob
Special, ergonomic arrangement of the three main control elements: focusing drive, stage drive and
brightness control
A TÜV certificate of ergonomics was prepared for the light microscope in cooperation with occupational
health physicians and the TÜV Rhineland and granted for the following basic configuration:
Transmitted light brightfield stand with ergo table and comfortable ergo tube
