Axio Lab.A1
2.3.1

Viewing height and tube angle

Order No. Binocular tube
425522-9000-000 Binocular tube 30°/20
425522-9010-000 Binocular photo tube 30°/20 (50:50)
425522-9020-000 Binocular ergo tube 8-38°/20
425522-9030-000 Binocular ergo photo tube 838°/20
(50:50)
425522-9040-000 Binocular ergonomic tube 8-38°/22
425520-9000-000 Binocular tube 30°/23
425520-9010-000 Bin. photo tube 30°/23 (50:50)
425520-9020-000 Bin. photo tube 30°/23 (100:100) Bio
425520-9030-000 Binocular photo tube 20°/23 (100:100)
425520-9040-000 Bin. ergo tube (100/100), angle-
adjustable, upright image
425520-9050-000 Bin. ergo tube 15°/23 (50/50),
telescopic, height, upright image
425520-9090-000 Binocular tube 20°/23
425520-9100-000 Bin. photo tube 20°/23 Pol (100:100)
425511-0000-000 Binocular ergo tube 20°/23,
44 mm height
425512-0000-000 Bin. ergo tube 20°/23 (100/100), reverse
image, 44 mm height
425514-0000-000 Bin. ergo tube 20°/23 (100/100),
upright image, 44 mm height
Viewing heights:
*
Tubes with fixed viewing angle without ergo function:
Binocular part lower/upper
Angle- and vertically adjustable ergo tubes:
Binocular part lower/upper
All specifications are for an interpupillary distance of 65 mm.
04/2013
DESCRIPTION OF THE INSTRUMENT
Technical data
e.g. 442 / 481 442 to 481 mm
e.g. 457 / 574 457 to 574 mm
430037-7144-001
Viewing Adjustment
angle
30° - none -
30° - none -
8-38° Angle
8-38° Angle
8-33° Angle
Height
30° - none -
30° - none -
30° - none -
20° - none -
5-30° Angle
15° Height
telescopic
20°
20°
20° Height
20° Height
20° Height
Carl Zeiss
Viewing
height* in mm
434 / 470
434 / 470
407 - 534
407 - 534
412 - 603
449 / 485
449 / 485
449 / 485
442 / 481
395 - 537
410 - 509
442 / 481
442 / 481
457 - 574
457 - 574
457 - 574
23
