- Page 1 Operating Instructions Ryeco RMM2010 - CNC Operation Instructions CNC Toolmaker Microscope RMM2010-CNC...
- Page 2 • Failure to complete or incorrect maintenance work • Unauthorized technical changes • Use of spare parts and accessories that have not been approved by Ryf Ltd. Switzerland • Use of unsuitable or unauthorized operating materials • Operation using faulty, non-functional or bypassed safety and monitoring equipment •...
- Page 3 The measurement device is designed for stationary applications Any use of a RMM2010 that is not in accordance with the specified provisions and/or parameters is deemed to be contrary to the intended use for which Ryf Ltd. shall not assume any liability for damage or malfunctions.
- Page 4 • Bear responsibility for the operation of the measurement device. • Ensure that all employees have read and understood the parts of this documentation that are relevant to their work. Provide personnel by Ryf with safety training at regular intervals; at least once per year (1x / year).
- Page 5 Assembling the measurement device: Specialized staff with relevant vocational training. Experience of assembling similar measurement devices. Initial commissioning: Initial commissioning must be carried out by specialized staff at Ryf. Operating the measurement device: Trained person with relevant specialist knowledge. Instructions on operating the measurement device.
- Page 6 • The positioning laser must not be used for any other purpose than to position measurement objects. • The positioning laser should only be switched on when actually required. • Any work, that requires the protective housing of the laser system to be removed, must only be completed by qualified specialized staff from Ryf Ltd.
- Page 7 Operating Instructions Ryeco RMM2010 - CNC Damaged or ineffective safety equipment and damaged components Risk of death or serious injuries caused by ineffective safety equipment or damaged components. • Never operate the measurement device with damaged, ineffective or bypassed safety equipment. •...
- Page 8 Operating Instructions Ryeco RMM2010 - CNC Hazard caused by the measurement device falling down or tilting during transport and assembly: Risk of squashing, shearing or collision. • Only use the specified attachment points for transport purposes. • Heavy vibration and shock loads and point loads on the housing of the measurement device must be avoided.
- Page 9 Operating Instructions Ryeco RMM2010 - CNC Emergency Stop button (CNC model) In the event of a hazardous situation, press the Emergency Stop button on the joystick immediately to stop the axis motion of the measurement device. "CLICK" 4.2 Structure of measurement device RMM2010-CNC (CNC model) NOTICE Measurement device RMM2010-CNC is designed according to the latest technology and...
- Page 10 Operating Instructions Ryeco RMM2010 - CNC 4.3.1 Joystick (CNC model) The joystick is used to control the axes. The following figure illustrates an example of the standard scope of supply: POSITION DESIGNATION 1 Connection socket 2 Button to switch between "creep speed – normal speed" 3 Axis interlock button 4 Emergency Stop button 5 "GoTo position"...
- Page 11 Operating Instructions Ryeco RMM2010 - CNC...
- Page 12 Operating Instructions Ryeco RMM2010 - CNC 4.6.1 Measurements using transmitted light and incident light All models of the WM1 series can be used for transmitted light and/or incident light measurements.The following figure provides a schematic overview of both measurement options:...
- Page 13 Operating Instructions Ryeco RMM2010 - CNC 5 Installation location, ambient conditions, transport 5.1 Installation location NOTICE The measurement device must be installed on a level, sufficiently load-bearing and sufficiently wide surface. The installation location for the measurement device must be selected so that no direct light from windows or lights can penetrate the measurement table of the measurement device.
- Page 14 Operating Instructions Ryeco RMM2010 - CNC 6.0 Connections on the rear of the device (CNC model) NOTICE All USB devices should always be connected to the same connection to prevent any driver conflicts. The following figure shows an example of the connections on the rear of a CNC-controlled RMM2010;...
- Page 15 Operating Instructions Ryeco RMM2010 - CNC 7.0 Activation and startup 1. Connect the multiple socket extension lead 2. Switch on the measurement computer ►► The measurement computer and Windows operating system start up 3. Log in to Windows using the "User" account 4.
- Page 16 Only specialised staff is authorised to complete maintenance work on the measurement device. Maintenance work must be completed in the presence of a person who is trained at Ryf Ltd. to operate the measurement device. All of the work must be completed in accordance with applicable provisions and protective regulations to safeguard any warranty claims.
- Page 17 Operating Instructions Ryeco RMM2010 - CNC...
- Page 18 Operating Instructions Ryeco RMM2010 - CNC Lubricating the X-axis and Y-axis spindles 12. Clean the X-axis spindle (7c) with a lint-free cloth: move up and down the X-axis several times so that any remaining grease residue is easier to remove. 13.
- Page 19 Operating Instructions Ryeco RMM2010 - CNC 18. Clean both of the X-axis guide rails (7a, 7b) with a lint-free cloth: move up and down the X-axis several times so that any remaining grease residue is easier to remove. 19. Slightly grease both of the X-axis guide rails (7a, 7b) with a brush. 20.
-
Page 20: Troubleshooting And Fault Elimination
8.2 Troubleshooting and fault elimination Any "Service" work must be completed by the Customer Services team at Ryf Ltd. as additional alignment or calibration work and special tools are required. The following faults can occur on manual and/or CNC models:... - Page 21 Operating Instructions Ryeco RMM2010 - CNC...
- Page 22 The installation and/or use of such components may therefore change the specified characteristics of your product. Ryf Ltd. is not liable for any damage caused by the installation and/or use of non-original parts. We recommend that you always consult Ryf Ltd first if you...
- Page 23 Operating Instructions Ryeco RMM2010 - CNC...
- Page 24 Operating Instructions Ryeco RMM2010 - CNC www.ryfag.ch...
