- Page 1 RYF AG Zürich Showroom,/Sales office Im Hanselmaa 10 CH-8132 Egg / Uster Tel 043 277 59 99 Manual for: RyecoCam 4000 Digital-Microscope R-FHD-4000-1001 Instruction Manual (mode d’emploi)
- Page 2 RYF AG Zürich Showroom,/Sales office Im Hanselmaa 10 CH-8132 Egg / Uster Tel 043 277 59 99 Manual for: RyecoCam 4000 Digital-Microscope Before starting the turn key system system pleas resde the software manual. 1. Press ON/OFF Button to start the camera and the LED Indicator will turn into blue;...
- Page 3 RYF AG Zürich Showroom,/Sales office Im Hanselmaa 10 CH-8132 Egg / Uster Tel 043 277 59 99 Manual for: RyecoCam 4000 Digital-Microscope Brief Introduction of Ryecocam UI and Its Functions RyecoCam 4000 UI shown in Fig. 2 includes a Camera Control Panel on the left side of the video window, a Measurement Toolbar on the upper side of the video window, a System Camera Control Toolbar on the bottom of the video window.
- Page 4 RYF AG Zürich Showroom,/Sales office Im Hanselmaa 10 CH-8132 Egg / Uster Tel 043 277 59 99 Manual for: RyecoCam 4000 Digital-Microscope The Camera Control Panel on the Left Side of the Video Window The Camera Control Panel controls the camera to achieve the best image quality according to the specific applications;...
- Page 5 RYF AG Zürich Showroom,/Sales office Im Hanselmaa 10 CH-8132 Egg / Uster Tel 043 277 59 99 Manual for: RyecoCam 4000 Digital-Microscope Icons and Functions of the Synthesis Camera Control Toolbar at the Bottom of the Video Window: Setting function is relatively more complicated than the other functions. Here are more info about Global：...
- Page 6 RYF AG Zürich Showroom,/Sales office Im Hanselmaa 10 CH-8132 Egg / Uster Tel 043 277 59 99 Manual for: RyecoCam 4000 Digital-Microscope Figure: Comprehensive Magnification Calibration Management Settings Page Name: Names such as 10X, 40X, 100X are based on magnification of the microscopes. For continuous zoom microscopes, ensure that the selected magnification coincides with the scale alignment line on the microscope zoom knob;...
- Page 7 RYF AG Zürich Showroom,/Sales office Im Hanselmaa 10 CH-8132 Egg / Uster Tel 043 277 59 99 Manual for: RyecoCam 4000 Digital-Microscope Figure Rycocam FHD Comprehensive Setting of Language Selection Setting Page English: Set language of the whole software into English (only in English / August 2022;...
- Page 8 RYF AG Zürich Showroom,/Sales office Im Hanselmaa 10 CH-8132 Egg / Uster Tel 043 277 59 99 Manual for: RyecoCam 4000 Digital-Microscope The Measurement Toolbar on the Upper Side of the Video Window The Measurement Toolbar will pop up when moving mouse cursor to any place near the upper side of the video window.
- Page 9 RYF AG Zürich Showroom,/Sales office Im Hanselmaa 10 CH-8132 Egg / Uster Tel 043 277 59 99 Manual for: RyecoCam 4000 Digital-Microscope When user left-clicks Display/Hide button on the Measurement Toolbar, the Measurement Toolbar will be fixed. In this case the Camera Control Panel will not pop up automatically even if moving mouse cursor to the left side of the video window.
-
Page 10: Lcd Screen
Full HD camera with HDMI output, resolution 1920x1080P, sensor 1/2.8", image rate 60 fps, interface 2x USB and 1x SD slot, stand with focus drive (Nikon), 15" LCD color monitor, LED ring light Ryf NKL- 12 LED, including SD card and Wi-Fi mouse.
