Site Planning
Table 3-2
Environmental Characteristic
Thermal shock nonoperating with change over time
of 3 minutes
Thermal Shock - Operating at 2.5 degree C per
minute

Physical Characteristics

Be familiar with the physical characteristics of the Cisco ASR 1001-X Router to assist you in placing
the system at a proper location.
Note For information regarding rack widths supported for the Cisco ASR 1001-X Router, see the following
sections:
•
•
Table 3-3
Table 3-3
Characteristic
Height
Width
Depth
Weight
The following list describes additional Cisco ASR 1001-X Router characteristics:
•
•
•
•
Cisco ASR 1001-X Router Hardware Installation Guide
3-10
Cisco ASR 1001-X Router Environmental Tolerance (continued)
19 in.—"General Rack-Selection Guidelines" section on page 3-15
23 in.—"Guidelines for 23-in. (Telco) Racks" section on page 3-16
shows the weight and dimensions of the Cisco ASR 1001-X Routers.
Physical Characteristics of Cisco ASR 1001-X Router
Chassis height meets EIA-310 rack spacing 1RU (1.71 in. or 43.43 mm), universal rack mount
Chassis width meets EIA-310 19 in. (17.3 in. or 439.42 mm) wide with rack brackets
Cable-management brackets allow a bend radius of 1.5 in. (38.1 mm) for cables
Ships with forward rack-mount brackets installed and an extra set included in the accessory kit
Minimum
–25° C
0° C
Cisco ASR 1001-X
1.71 in. (43.43 mm) —1RU; rack-mount per
EIA RS-310
17.3 in. (439.42 mm)
22.50 in. (571.5 mm) Depth includes
cable-management brackets; card and
power-supply handles for mounting in a 600
mm enclosed cabinet.
25 lb (11.35 kg) fully loaded
Chapter 3 Preparing Your Site for Installation
Maximum
+70° C
+50° C
OL-32376-02
