OM NIS T OR AW N IN G
footboard and the arms (with screwdriver
and wrench S10).
• Slide out the footboard.
• Reinstall the front plate.
Current drawn
• Working current: 5 A
• Blocking current, when fully extended or
retracted: 14 A
Fig. 1 Front plate

Omnistor Awning

General remarks:
• An awning is a sun and not a rain protection.
The awning should be in closed position in
case of storm, snowfall or heavy rainfall.
• The awning can not be used without putting
out the support arms.
• The fabric may not be rolled up wet for a
longer period.
• Clean the awning only by using water or
OMNI CLEANER.
Users instructions:
1. Adjust the crank to the required height.
1
136
2. Introduce the crank arm into the
bayonet joint.
2
3. Unroll the awning while keeping the crank
down. The awning will only open after a
couple of turnings.
3
