D OM ET IC AB SOR PTI ON REF RI GE R AT OR
Manual energy selection /
automatic ignition (RM 8xx1) MES
1 2
1. Power ON/OFF switch
2. Energy selector button 230V ~
3. Energy selector button GAS
4. Energy selector button 12V =
6. Temperature level selection
7. Temperature level display
8. Indicator LED failure /
Reset button GAS FAILURE
Switching ON/OFF
• Switch ON by pressing button (1), 2s
• Switch OFF by pressing button (1), > 2s
230V AC operation
• Select "Mains voltage" by pressing
button (2)
• Set temperature step by pressing button (6)
12V DC operation (vehicle's battery)
• Select "Battery voltage" by pressing
button (4)
• Set temperature step by pressing button (6)
Gas operation
• Select "Gas" by pressing button (3)
• Set temperature step by pressing button (6)
102
3
4 6
Electrical operation
To start the refrigerator, press button (1) for 2
seconds.
The refrigerator starts with the last selected
type of energy.
230V operation :
7 8
Press button (2) :
Fig. 8 12V operation :
Press button (4) :
Gas operation
Gas operation :
Press button (3) :
The ignition process is activated automatically
by means of an automatic igniter.
Note: The flame extinguishes after
reaching the preset cooling compartment
temperature and ignites again if the cooling
compartment temperature increases again.
If the flame is not lit after the first ignition
attempt, the automatic igniter repeats the
ignition twice (duration 30 s) at time intervals
of 2 minutes. If the flame is not lit afterwards,
a fault is indicated.
3
Fig. 17
