Lighting
If the door is open for more than 2 minutes,
the sensor-controlled interior lighting is
automatically cut off (except for models with
battery igniter).
Note: Please contact the authorized
Dometic Service if a failure occurs.
Positioning the storage racks
The storage racks may be pulled out by
smoothly lifting them and may be positioned
as desired.
Removable freezer compartment
(where applicable)
To enlarge the cooling compartment, just
remove the freezer compartment.
1. Unlock the freezer compartment on both
sides.
2. Pull the freezer compartment out.
Store the freezer compartment safely in order
to prevent damage.
Once the freezer compartment is removed, an
additional storage rack (3.) may be installed.
The storage rack is a piece of extra equipment
and may be obtained by Dometic.
Winter operation
In winter, check that the ventilation grilles and
the exhaust duct system (1) have not been
blocked by snow, leaves, etc.
When the outside temperature falls below
+10°C, the winter covers should be fitted.
This protects the unit from excessively cold
air which could have adverse effects on the
performance of the unit.
Covers may be supplied as part of the
specification of your motorhome or
alternatively are available through most
Swift Group dealers
Note: You should also attach the winter
covers if the vehicle is taken out of service
for a longer period of time or while it is being
cleaned from the outside.
1
Fig. 35
2
Fig. 36
105
