Summary of Contents for CyberView KD1 Series

  • Page 1: User Manual

    User Manual Rackmount Keyboard Drawers KD1 Series - Optional KVM KD2 Series - Shallow Depth - Single Console Only...
  • Page 2 blank page...
  • Page 3: Table Of Contents

    Connect to KVM via USB Interface........5 1.10 Connect to Server via PS/2 Interface........6 1.11 Connect to KVM via PS/2 Interface........6 Chapter 2 Keyboard and Mouse ..........7 Chapter 3 Optional Specification KVM Options for KD1 Series..........8 Environmental..............8 Chapter 4 Dimensions ................8...
  • Page 4: Package Contents

    Chapter 1 1.1 Package Contents Keyboard drawer x 1 pc Fasteners for rear L-bracket x 4 pcs 330mm rear mounting L-bracket x 1 pair * RK-1 series mounting depth-adjustable from 210 to 800mm * RK-2 series maximum mounting depth is 645mm Combo keyboard cable x 1 pc User manual (As of Sept 2011, all user manuals will be download-only.
  • Page 5: Before Installation

    If anything is missing, or damage, contact the supplier immediately. 1.4 Optional Accessories 1. Extended rear mounting L-bracket 1.1 430mm (16.9") extended rear L-bracket for : KD1 series up to 900mm (35.4") KD2 series up to 745mm (29.3") *Extended rear L-bracket can be tailor-made to length upon request...
  • Page 6: Peripheral Products

    Chapter 1 1.5 Peripheral Products Item Model No. Description 16-Cat6-M2X / M3X / M4X Matrix Cat 6 16-Port KVM 16-Cat6-M3X-IP / M4X-IP / M4X-2IP Matrix IP Cat 6 16-Port KVM Matrix Cat 6 KVM 32-Cat6-M2X / M3X / M4X Matrix Cat 6 32-Port KVM 32-Cat6-M3X-IP / M4X-IP / M4X-2IP Matrix IP Cat 6 32-Port KVM 8-M2X / M3X / M4X...
  • Page 7: Installation

    Chapter 1 1.7 Installation ■ Install each rear L-bracket using two fasteners shown in Figure 1. ■ Leave the fasteners slightly loose Figure 1. Install the rear L-bracket to the keyboard drawer. ■ Measure the front and rear mounting depth of the rack.
  • Page 8: Connect To Server Via Usb Interface

    Chapter 1 1.8 Connect to Server via USB Interface Figure 4. Example of connecting EKC-3 keyboard cable to server via USB interface 1.9 Connect to KVM via USB Interface Figure 5. Example of connecting EKC-3 keyboard cable to KVM via USB interface Please Note: ■...
  • Page 9: Connect To Server Via Ps/2 Interface

    Chapter 1 1.10 Connect to Server via PS/2 Interface Figure 6. Example of connecting EKC-3 keyboard cable to server via PS/2 interface 1.11 Connect to KVM via PS/2 Interface Figure 7. Example of connecting EKC-3 keyboard cable to KVM via PS/2 interface Please Note: ■...
  • Page 10: Chapter 2 Keyboard And Mouse

    Chapter 2 2.1 Keyboard & Mouse Supporting layouts B keyboard integrated with N keyboard integrated with track ball touch pad Supporting layouts only Supporting layouts only Compact keyboard integrated Compact keyboard integrated with touch pad mouse with track ball...
  • Page 11: Kvm Options For Kd1 Series

    Chapter 3 for KD1 Series 3.1 KVM Options Our KVM is designed to seamlessly integrate into the rear of our full range of keyboard drawer solutions: ■ For KVM operation, please refer to the "All KVM" user manual ■ Options available for multiple consoles via Matrix KVM ■...
  • Page 12 The company reserves the right to modify product speci cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2010 Austin Hughes Electronics Ltd. and Eclipse Rackmount, Inc. All rights reserved.
