Safety
UL/cUL (UL 60950 & CSA 60950)
Ü
EN60950 (T V/GS), IEC60950 (CB)
LVD/EN 60950
Standards
IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX,
IEEE 802.11a, b, g

Sensitivity

IEEE 802.11a
Modulation/Rates
BPSK (6 Mbps)
BPSK (9 Mbps)
QPSK (12 Mbps)
QPSK (18 Mbps)
16 QAM (24 Mbps)
16 QAM (36 Mbps)
64 QAM (48 Mbps)
64QAM(54 Mbps)
IEEE 802.11g
Data Rate
6 Mbps
9 Mbps
12 Mbps
17 Mbps
24 Mbps
36 Mbps
48 Mbps
54 Mbps
IEEE 802.11b
Data Rate
1 Mbps
2 Mbps
5.5 Mbps
11 Mbps
May 2007
Sensitivity (GHz - dBm)
5.15-5.250 5.25-5.350
-88 -88
-87 -87
-86 -86
-84 -84
-82 -81
-80 -79
-73 -73
-70 -70
© 2007 Foundry Networks, Inc.
Specifications
5.50-5.700 5.725-5.825
-88
-87
-86
-84
-81
-78
-73
-69
Sensitivity (dBm)
-88
-87
-86
-85
-81
-77
-72
-70
Sensitivity (dBm)
-93
-90
-90
-87
-88
-87
-86
-84
-81
-78
-73
-67
C-3
