Foundry IronPoint 200 Installation Guide
Connecting to a Switch, Hub, PC, or Server
1. Attach one end of a twisted-pair cable segment to the network device's RJ-45 connector.
Figure 5-1. Connecting to a Network Device
RJ-45 Connector
2. Attach the other end of the cable segment to the Ethernet port on the access point.
Note: Make sure the twisted pair cable does not exceed 100 meters (328 ft) in length.
3. As the connection is made, the access point's Link LED should light indicating a valid network
connection. If the Link LED fails to light, see Appendix A for troubleshooting information.
5-2
© 2007 Foundry Networks, Inc.
April 2007
