Foundry IronPoint 200 Installation Guide
5. Configure the TCP/IP address. The default IP address for the access point is 169.254.1.1 with a
255.255.0.0 subnet mask and a default gateway of 169.254.1.254. To change the access point's
IP address, for example, to 192.168.1.10 with a 24-bit subnet mask and a default gateway of
192.168.1.254, enter:
Foundry AP#configure
Foundry AP(config)#interface ethernet
Foundry AP(if-ethernet)#ip address 192.168.1.10 255.255.255.0 192.168.1.254
Foundry AP(if-ethernet)#end
Foundry AP #
Syntax: interface ethernet
ip address <ip-address> <subnet-mask> <default-gateway>
6. Confirm the Country Code and TCP/IP settings with the show system command. Do not
proceed unless the information displayed is correct. For example, to confirm the country code of
the United Kingdom and the TCP/IP address of 192.168.8.10/24, enter:
Foundry AP # show system
Syntax: show system
The command displays the following information:
Foundry AP # show system
System Information
============================================================
Serial Number
System Up time
System Name
System Location
System Contact
System Country Code
MAC Address
IP Address
Subnet Mask
Default Gateway
VLAN State
Management VLAN ID(AP): 1
IAPP State
DHCP Client
HTTP Server
HTTP Server Port
HTTPS Server
HTTPS Server Port
Slot Status
Software Version
SSH Server
SSH Server Port
Telnet Server
============================================================
7. Power down the access point.
8. Connect one end of the Ethernet cable to the RJ-45 connector on the access point.
4-12
: SACC1200KA
: 0 days, 0 hours, 5 minutes, 25 seconds
: Foundry AP
:
: Contact
: GB - UNITED KINGDOM
: 00-0C-DB-813-882
: 192.168.8.10
: 255.255.255.0
: 192.168.8.254
: DISABLED
: ENABLED
: DISABLED
: ENABLED
: 80
: ENABLED
: 443
: Dual band(a/g)
: 01.2.03.00Tw8
: ENABLED
: 22
: ENABLED
