Foundry IronPoint 200 Installation Guide

Radio Characteristics

The IEEE 802.11a/g standard uses a radio modulation technique known as Orthogonal Frequency
Division Multiplexing (OFDM), and a shared collision domain (CSMA/CA). It operates at the 5 GHz
Unlicensed National Information Infrastructure (UNII) band for connections to 802.11a clients, and at
2.4 GHz for connections to 802.11g clients.
IEEE 802.11g includes backward compatibility with the IEEE 802.11b standard. IEEE 802.11b also
operates at 2.4 GHz, but uses Direct Sequence Spread Spectrum (DSSS) modulation technology to
achieve a communication rate of up to 11 Mbps.
The access point also supports a 54 Mbps half-duplex connection to Ethernet networks for each
active channel (up to 108 Mbps in turbo mode on the 802.11a interface).

Management Options

The IronPoint 200 contains LEDs for "at-a- glance" monitoring of wireless and network port status. It
also includes a built-in network management agent that allows the access point to be managed in-
band using SNMP, with a Web browser, or remotely via Telnet and SSH. The access point provides
an RS-232 DCE serial port (DB-9 connector) on the front panel for out-of-band management. A PC
may be connected to this port for configuration and monitoring out-of band via a straight-through
serial cable. (See "Console Port Pin Assignments" on page B-3 for wiring options.)
For a detailed description of the access point's management features, refer to the Foundry
IronPoint 200 User Guide.
2-2 © 2007 Foundry Networks, Inc. September 2007
