Foundry IronPoint 200 Installation Guide

Features and Benefits

Connectivity

◆ 54 Mbps wireless interface supports up to 64 mobile users
◆ Local network connection via 10/100 Mbps Ethernet port
◆ IEEE 802.11a, 802.11b, and 802.11g compliant on the wireless interfaces
◆ IEEE 802.3 and IEEE 802.3u compliant on the Ethernet interface
◆ Ethernet port supports Power over Ethernet based on the IEEE 802.3af standard
◆ Provides seamless roaming within the IEEE 802.11a, 802.11b, and 802.11g WLAN environment
◆ Scans all available channels and selects the best channel for each client based on the signal-to-
noise ratio
◆ Optional high-gain 2.4 GHz external antenna can be attached to extend the service area
◆ Advanced security through 64/128/152-bit Wired Equivalent Protection (WEP) encryption, IEEE
802.1x port authentication, Wi-Fi Protected Access (WPA), SSID broadcast disable, remote
authentication via RADIUS server, and MAC address filtering
◆ Auto-negotiation enables the Ethernet port to automatically select the optimum communication
mode (half or full duplex) if this feature is supported by the attached device; otherwise the port
can be configured manually

Management

◆ "At-a-glance" LEDs for easy troubleshooting
◆ Network management agent:
Supports Telnet, SSH v2, SNMP v2 and v3, and Web-based HTTP and HTTPs interface
•
• Supports out-of-band RS-232 console port (VT100)
2-6 © 2007 Foundry Networks, Inc. September 2007
