Foundry IronPoint 200 Installation Guide

Wiring Map for Serial Cable

Signal (access point serial port)
Unused
TXD (transmit data)
RXD (receive data)
Unused
GND (ground)
Unused
CTS (clear to send)
RTS (request to send)
Unused
Note: The left hand column pin assignments are for the male DB-9 connector on the access point. Pin 2
(TXD or "transmit data") must emerge on the management console's end of the connection as RXD
("receive data"). Pin 7 (CTS or "clear to send") must emerge on the management console's end of the
connection as RTS ("request to send").
The serial port's configuration requirements are as follows:
• Default Baud rate—9,600 bps
• Character Size—8 Characters
• Parity—None
• Stop bit—One
• Data bits—8
B-4
Pin
1
2
3
4
5
6
7
8
9
© 2007 Foundry Networks, Inc.
Signal (management console port)
Unused
RXD (receive data)
TXD (transmit data)
Unused
GND (ground)
Unused
RTS (request to send)
CTS (clear to send)
Unused
April 2007
