6. Press the access point against the bracket until it snaps into place. The clip locks the access
point in place. Install the 2-56 screws on the sides of the access point.
7. For best coverage, position the antennas along different axes, such as 45 to 90 degrees apart
from each other.
Figure 4-5. Attaching the Bracket to a Suspended Ceiling
September 2007
© 2007 Foundry Networks, Inc.
Installing the IronPoint 200 Access Point
Suspended Ceiling T-rail
Fastener
Mounting Bracket
Lock Nut
4-7
