Attaching the Access Point to a Wall Using the Mounting Bracket

Do the following to attach the access point to the wall using the mounting bracket:
1. Use the template in Figure 4-2 to mark the holes for the mounting screws on the wall.
2. Install the mounting screws for the two slotted key mounting holes on the wall, but leave
approximately 1/4 inch of clearance between the wall and the screw head.
3. Install the mounting bracket on the wall by aligning the slotted key mounting holes on the
mounting bracket with the screws on the wall (Figure 4-3).
4. Slide the mounting bracket across the screws to move the screws into the narrow part of the
mounting holes.
5. Tighten the screws to secure the mounting bracket in place.
6. Install the mounting screw at the bottom of the bracket.
7. Install the access point into the mounting bracket by aligning the two rear tabs on the mounting
brackets with the two rear rectangular holes on the access point (Figure 4-4). For safety reasons,
make sure ventilation holes on the access point are positioned horizontally, not vertically.
8. Press the access point into the mounting bracket until it snaps into place. The clip locks the
access point in place.
9. For best coverage, position the antennas along different axes, such as 45 to 90 degrees apart
from each other.
