Page 1: Installation Guide
AT-FS7016 AT-FS7024 Fast Ethernet Smart Switches Installation Guide PN 613-50469-00 Rev A... - Page 2 Copyright 2003 Allied Telesyn, Inc. 960 Stewart Drive Suite B, Sunnyvale, CA 94085, USA All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesyn, Inc. Ethernet is a registered trademark of Xerox Corporation. All other product names, company names, logos or other designations mentioned herein are trademarks or registered trademarks of their respective owners.
-
Page 3: Electrical Safety And Emissions Compliance Statement
Electrical Safety and Emissions Compliance Statement Standards: This product meets the following standards. U.S. Federal Communications Commission Radiated Energy Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 4 Electrical Safety and Emissions Compliance Statement Tärkeää: Liite B sisältää tämän laitteen asentamiseen liittyvät käännetyt turvaohjeet. Kun näet -symbolin, katso käännettyä turvaohjetta liitteestä B. Importante: l’Appendice B contiene avvisi di sicurezza tradotti per l’installazione di questa apparecchiatura. Il simbolo , indica di consultare l’Appendice B per l’avviso di sicurezza nella propria lingua.
-
Page 5: Table Of Contents
Table of Contents Electrical Safety and Emissions Compliance Statement ....iii Welcome to Allied Telesyn ................. vii Where to Find Web-based Guides ..............vii Document Conventions ...................viii Contacting Allied Telesyn ................viii Online Support ..................viii E-mail and Telephone Support..............viii Returning Products ..................viii For Sales or Corporate Information ............ - Page 6 Table of Contents Chapter 3 Troubleshooting ................... 21 Appendix A Technical Specifications ................23 Physical ......................23 Environmental ....................23 Electrical Rating ....................24 Agency Compliance................... 24 Pinout Assignments..................25 Appendix B Translated Safety and Emission Information ........27...
-
Page 7: Welcome To Allied Telesyn
You can view the documents online or download them onto a local workstation or server. Once you have installed your AT-FS7016 and AT-FS7024 switch, refer to the following guide for instructions on how to manage and configure your unit: ❑... -
Page 8: Document Conventions
Welcome to Allied Telesyn Document Conventions This guide uses the following conventions: Note Notes provide additional information. Caution Cautions informs you that performing or omitting a specific action may result in equipment damage or loss of data. Warning Warnings informs you that performing or omitting a specific action may result in bodily injury. -
Page 9: For Sales Or Corporate Information
AT-FS7016 and AT-FS0724 Installation Guide For Sales or Corporate Information You can contact Allied Telesyn for sales or corporate information at our web site: www.alliedtelesyn.com. To find the contact information for your country, select “Contact Us” then “Worldwide Contacts”. Obtaining Management Software Updates... -
Page 11: Chapter 1 Overview
Chapter 1 Overview The AT-FS7016 and AT-FS7024 are Layer 2, Fast Ethernet Smart Switches. These switches offer a range of features and capabilities, including limited management that simplifies the task of creating or expanding an Ethernet or Fast Ethernet network. - Page 12 24 Port Fast Ethernet Smart Switch RS-232 TERMINAL PORT POWER AUTO MDI / MDI-X LINK/ACT 100M RS-232 Status LEDs Terminal Port Figure 2 AT-FS7024 Front Panel Figure 3 illustrates the back panel of the AT-FS7016 and AT-FS7024 switches. Power Receptacle Figure 3 Back Panel...
-
Page 13: Key Features
100 m (328 ft) AT-FS7024 RJ-45 100 m (328 ft) Key Features The AT-FS7016 and AT-FS7024 Smart Switches have the following key features: LEDs for power and port status Fixed 16 or 24 10/100Base-TX twisted pair ports Auto MDI/MDI-X on all ports... -
Page 14: Status Leds
Overview Status LEDs Table 2 lists the status LEDs for the AT-FS7016 and AT-FS7024 switches. Table 2 Status LEDs Color Description POWER Green Power is applied to the switch. LINK/ACT Green A valid link has been established on the port. -
Page 15: Port Speed
Each twisted pair port on the AT-FS7016 and AT-FS7024 switch can operate in either half- or full-duplex mode. The twisted pair ports are IEEE 802.3u- compliant and will Auto-negotiate the duplex mode setting. -
Page 16: Auto Mdi/Mdi-X
MDI to MDI, you would use a crossover cable. When a port on the AT-FS7016 or AT-FS7024 switch is set to Auto-negotiation, the switch enables the auto MDI/MDI-X feature. The RJ-45 port automatically determines the configuration of the port on the device to which it is connected and then configures itself appropriately. -
Page 17: Power Requirements
Allied Telesyn ships power cords with these units to the U.S., Continental Europe, and the U.K. The AT-FS7016 switch requires input of 100 - 240 V AC, 0.8A, 50/60 Hz. The AT-FS7024 switch requires input of 100 - 240 V AC, 0.5A, 50/60 Hz. -
Page 18: Network Topologies
Overview Network Topologies The AT-FS7016 and AT-FS7024 Fast Ethernet Smart Switches can be used in a variety of network topologies. Three types of topologies are described below. Power Workgroup Topology A power workgroup topology, shown in Figure 4, allows each end-node to directly connect to a 10/100Base-TX twisted pair port on an AT-FS7016 switch. -
Page 19: Collapsed Topology
AT-FS7016 and AT-FS7024 Installation Guide Collapsed Topology In the topology illustrated in Figure 5, an AT-FS7016 switch connects together 10/100 Mbps Ethernet hubs. This type of topology is often referred to as a collapsed backbone topology. The switch functions as the focal point of the network by acting as a bridge between the different workgroups. -
Page 20: Mixed Topology
Overview Mixed Topology Figure 6 illustrates a network of three AT-FS7024 switches. The workstations and servers are connected either directly to a switch or indirectly through an Ethernet hub. The switches are connected together through 10/100Base-TX twisted pair ports. AT-FS7024 AT-FS7024 24 Port Fast Ethernet Smart Switch RS-232 TERMINAL PORT... -
Page 21: Chapter 2 Installation
Make sure the following items are included in your package. If any item is missing or damaged, contact your Allied Telesyn sales representative for assistance. ❑ One AT-FS7016 or AT-FS7024 Fast Ethernet Smart Switch ❑ Four protective feet (AT-FS7016 only) ❑... -
Page 22: Planning The Installation
Installation Planning the Installation Be sure to observe the following guidelines when planning the installation of your switch. ❑ The end-nodes connected to the twisted pair ports can operate at either 10 Mbps or 100 Mbps and half- or full-duplex mode. Refer to “Port Speed”... -
Page 23: Selecting A Site
AT-FS7016 and AT-FS7024 Installation Guide Selecting a Site Be sure to observe the following guidelines when selecting a site for your switch. ❑ Select a site that is dust-free and moisture-free. ❑ Select a site that will allow you to easily access the switch’s power and data cables. -
Page 24: Reviewing Safety Guidelines
Installation Reviewing Safety Guidelines Please review the following safety guidelines before you begin to install the switch. Warning Electrical Shock Hazard: To prevent electrical shock, do not remove the cover. There are no user-serviceable parts inside. The unit contains hazardous voltages and should only be opened by a trained and qualified technician. -
Page 25: Installing The Switch On A Table Or Desktop
In the event a problem occurs and you need to return the unit, please use as much of the original shipping material as possible. 2. For the AT-FS7016 switch, attach the four protective feet to the bottom of the unit. See Figure 7. - Page 26 Installation ❑ Since the ports on the switch are auto MDI/MDI-X, you can use either a straight-through or crossover twisted pair cable to connect any type of network device to a port on the switch. Refer to “Auto MDI/MDI-X” on page 6 for additional information. ❑...
-
Page 27: Rackmounting The Switch
AT-FS7016 and AT-FS7024 Installation Guide Rackmounting the Switch The AT-FS7016 and AT-FS7024 switches can be used on a desktop or installed in a rack. For desktop installation, refer to “Installing the Switch on a Table or Desktop” on page 15. - Page 28 Installation 2. Attach the rackmounting brackets to each side of the switch using the screws provided. See Figure 10. Figure 10 Attaching the Rackmounting Brackets to the Switch 3. Secure the switch to the rack using two screws (not provided) for each side, as shown in Figure 11.
-
Page 29: Warranty Registration
AT-FS7016 and AT-FS7024 Installation Guide Note The switch performs a self-diagnostic test upon power up. This takes about 20 seconds to complete. 6. Connect the twisted pair cables to a twisted pair ports on the switch and on the end-nodes. When connecting a twisted pair cable to a port on the switch, observe the following: ❑... -
Page 31: Chapter 3 Troubleshooting
Chapter 3 Troubleshooting Follow the guidelines below to test and troubleshoot the installation in the event a problem occurs. If the POWER LED is OFF, do the following: Check to be sure that the power cord is securely connected to a power outlet and that the other end of the power cord is securely connected to the back of the switch. - Page 32 Troubleshooting If you are unable to establish a local management session with the switch through the RS-232 terminal port, do the following: Check to be sure that the RS-232 cable is securely connected to the RS-232 terminal port on the switch and to the RS-232 port on the terminal or PC.
-
Page 33: Technical Specifications
Appendix A Technical Specifications Physical Dimensions: W x D x H AT-FS7016 330 mm x 155 mm x 44 mm (13.0 in x 6.1 in x 1.73 in) AT-FS7024 440 mm x 174 mm x 41 mm (17.32 in x 6.85 in x 1.61 in) -
Page 34: Electrical Rating
Technical Specifications Electrical Rating Internal Universal Power Supply: Input AT-FS7016 100 - 240 V AC, 0.8A, 50/60 Hz AT-FS7924 100 - 240 V AC, 0.5A, 50/60 Hz Power Consumption: 27W maximum Agency Compliance EMI/RFI: FCC Class A, EN55022 Class A,... -
Page 35: Pinout Assignments
AT-FS7016 and AT-FS0724 Installation Guide Pinout Assignments Figure 12 shows the pin assignments of the RJ-45 connector. Pin 8 Pin 1 Figure 12 RJ-45 Connector Table 4 lists the 10/100Base-TX connector pins and their signals when the port is operating in either MDI or MDI-X configuration. -
Page 37: Translated Safety And Emission Information
Appendix B Translated Safety and Emission Information Important: This appendix contains multiple-language translations for the safety statements in this guide. Wichtig: Dieser Anhang enthält Übersetzungen der in diesem Handbuch enthaltenen Sicherheitshinweise in mehreren Sprachen. Vigtigt: Dette tillæg indeholder oversættelser i flere sprog af sikkerhedsadvarslerne i denne håndbog. - Page 38 Translated Safety and Emission Information Standards: This product meets the following standards. U.S. Federal Communications Commission Radiated Energy Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 39 AT-FS7016 and AT-FS7024 Installation Guide Electrical—Auto Voltage Adjustment This product will automatically adjust to any voltage between the ranges shown on the label. Electrical—Type Class 1 Equipment THIS EQUIPMENT MUST BE EARTHED. Power plug must be connected to a properly wired earth ground socket outlet. An improperly wired socket outlet could place hazardous voltages on accessible metal parts.
- Page 40 Translated Safety and Emission Information Betriebstemperatur: Dieses Produkt wurde für den Betrieb in einer Umgebungstemperatur von nicht mehr als 40° C entworfen. Alle Länder: Installation muß örtlichen und nationalen elektrischen Vorschriften entsprechen. Standarder: Dette produkt opfylder følgende sikkerhedsstandarder. Radiofrekvens forstyrrelsesemission EN55022 Klasse A Advarsel: I et hjemligt miljø...
- Page 41 AT-FS7016 and AT-FS7024 Installation Guide Normen: Dit product voldoet aan de volgende veiligheidsnormen. RFI Emissie EN55022 Klasse A Waarschuwing: Binnenshuis kan dit product radiostoring veroorzaken, in welk geval de. Immuniteit EN55024 Electrische Veiligheid TUV-EN60950, UL60950 ( Veiligheid Waarschuwingen Met Betrekking Tot Elektriciteit Waarschuwing: GEVAAR VOOR ELEKTRISCHE SCHOKKEN Verwijder het deksel niet, teneinde ELEKTRISCHE schokken te voorkomen.
- Page 42 Translated Safety and Emission Information Normes: ce produit est conforme aux normes de sécurité suivantes. Emission d’interférences radioélectriquesEN55022 Classe A Mise En Garde: dans un environnement domestique, ce produit peut provoquer des interférences radioélectriques. Auquel cas, l’utilisateur devra prendre les mesures adéquates.
- Page 43 AT-FS7016 and AT-FS7024 Installation Guide Normit: Tämä tuote on seuraavien turvallisuusnormien mukainen. Radioaaltojen häirintä EN55022 Luokka A Varoitus: Kotiolosuhteissa tämä laite voi aiheuttaa radioaaltojen häiröitä, missä tapauksessa laitteen käyttäjän on mahdollisesti ryhdyttävä tarpeellisiin toimenpiteisiin. Kestävyys EN55024 Sähköturvallisuus TUV-EN60950, UL60950 ( Turvallisuus Sähköön Liittyviä...
- Page 44 Translated Safety and Emission Information Standard: questo prodotto soddisfa i seguenti standard di sicurezza. Emissione RFI (interferenza di radiofrequenza) EN55022 Classe A Avvertenza: in ambiente domestico questo prodotto potrebbe causare radio interferenza. In questo caso potrebbe richiedersi all’utente di prendere gli adeguati provvedimenti.
- Page 45 AT-FS7016 and AT-FS7024 Installation Guide Sikkerhetskrav: Dette produktet oppfyller følgende sikkerhetskrav. RFI stråling EN55022 Klasse A Advarsel: Hvis dette produktet benyttes til privat bruk, kan produktet forårsake radioforstyrrelse. Hvis dette skjer, må brukeren ta de nødvendige forholdsregler. Immunitet EN55024 Elektrisk sikkerhet...
- Page 46 Translated Safety and Emission Information Padrões: Este produto satisfaz os seguintes padrões de segurança. Emissão de interferência de radiofrequência EN55022 Classe A Aviso: Num ambiente doméstico este produto pode causar interferência na radiorrecepção e, neste caso, pode ser necessário que o utente tome as medidas adequadas.
- Page 47 AT-FS7016 and AT-FS7024 Installation Guide Normas: este producto cumple con las siguientes normas de seguridad. Emisión RFI EN55022 Clase A Advertencia: en un entorno doméstico, este producto puede causar radiointerferencias, en cuyo caso, puede requerirse del usuario que tome las medidas que sean convenientes al respecto.
- Page 48 Translated Safety and Emission Information Normer: Denna produkt uppfyller följande säkerhetsnormer. Radiostörning EN55022 Klass A Varning: Denna produkt kan ge upphov till radiostörningar i hemmet, vilket kan tvinga användaren till att vidtaga erforderliga åtgärder. Immunitet EN55024 Elsäkerhet TUV-EN60950, UL60950 ( Säkerhet Tillkännagivanden Beträffande Elektricitetsrisk: RISK FÖR ELEKTRISK STÖTFör att undvika ELEKTRISK...
