  • Page 1 CT series User Manual www.barco.com...
  • Page 2 User’s Guide – Getting to know the projector CT series User Manual...

  • Page 3: Table Of Contents

    Contents Introduction Thank you Training Symbols used in this documentation Safety and compliance General safety considerations Information/Warning - Potential Mercury Vapour Health Issues FCC compliance Disposal information 2.4.1 Statement WEEE (Waste Electrical and Electronic Equipment) 2.4.2 Disposal of batteries in the product 2.4.3 Turkey RoHS compliance Service...
  • Page 4 Overview Keypad and indicator Wireless remote control Connectors 5.3.1 Signal connectors 5.3.2 Control connectors Menu system 5.4.1 Top menu 3D main menu 5.5.1 3D > Dual head setup sub menu Picture main menu 5.6.1 Picture > RealColor sub menu 5.6.2 Picture >...
  • Page 5 6.10 PIN code 6.11 Disabling the wireless remote control (IR) receivers 6.12 Software upgrades Optimising the image Calibration data 7.1.1 Updating RealColor™ calibration data 7.1.2 RealColor™ modes Setting a white point or color temperature 7.2.1 Defining the system color gamut Gamma Technical specifications Lamp change...
  • Page 6 User Manual - Introduction CT series User Manual - Introduction...

  • Page 7: Introduction

    Active Stereo 3D. 1.2 Training To get the best performance out of the projector as well as the system, training at Barco is highly advised, in addition to studying this user guide. Various courses are available. At the University, skilled trainers will teach you basic projector use as well as more advanced set-up and configuration across multiple application areas.
  • Page 8 User Manual - Introduction CT series User Manual - Introduction...

  • Page 9: Safety And Compliance

    2 Safety and compliance 2.1 General safety considerations • Use only the cables and cords supplied with the projector or original replacement cables. Using other cables or cords may lead to malfunction and permanent damage to the unit. • Always use 3-prong (grounded) power cord to ensure proper grounding of the unit. Never use 2-prong power cords, as this is dangerous and could lead to electrical shock.

  • Page 10: Information/Warning - Potential Mercury Vapour Health Issues

    2.2 Information/Warning - Potential Mercury Vapour Health Issues This projector uses a very powerful UHP™ lamp for illumination to produce an extremely bright image. This technology is similar to other high-pressure discharge lamps that are extensively used in cars, street lights and other lighting appliances today. These lamps, like fluorescent lighting, contain small amounts of mercury.

  • Page 11: Disposal Information

    For more information about recycling of this product, please contact your local city office or your municipal waste disposal service. For details, please visit the Barco website at: http://www.barco.com/en/AboutBarco/weee. 2.4.2 Disposal of batteries in the product This product contains batteries covered by the European Directive which must be collected and disposed of separately from municipal waste.
  • Page 12 User Manual - Introduction CT series User Manual - Safety and compliance...

  • Page 13: What Is In The Box

    3 What is in the box? The following components are standard delivery: Projector Power Cable (Country Dependent) Remote Control User Documentation Additional accessories available for the projector: Exhaust air kit (for ceiling mount) A: Air-inlet filter (also sold separately) B: Side cover/Air-inlet C: Ceiling mount cover/Air-outlet (also sold separately) D: Exhaust air duct*...
  • Page 14 User Manual - Introduction CT series User Manual - What’s in the box?

  • Page 15: Installation

    4 Installation 4.1 System considerations Please refer to Chapter 5 Overview for an explanation on the various features of the projector. Installation should only be performed by trained and skilled personnel in order to achieve the desired results. Safety first: Projectors and other equipment that are not mounted properly represent a potential danger to people and may result in injury or death! Creating a successful system installation requires proper skills, competencies and knowledge of the particular system requirements.

  • Page 16: Ventilation Accessories

    A set of optional accessories is available for this projector, covering anything from cables and lenses to air flow parts and lens control. For information on availability, specifications and pricing, please refer to our web site: www.barco.com User Manual - Introduction...

  • Page 17: Ceiling And Rig Mounting

    4.3 Ceiling and rig mounting Use the three mounting holes provided in the bottom part to securely fix the projector to a ceiling or rig mount. Use M6 screws that protrude maximum 9mm into the projector body. Figure 4-2. Ceiling/rig mounting mounting holes 4.4 Locking the projector The projector can be locked physically by using a so called Kensington lock.

  • Page 18: Selecting A Lens

    4.6 Selecting a lens The projector is delivered without a lens, enabling you to select a lens according to your desired image size and projection distance. The projector uses a bayonet mount system to precisely fix the lens in place. The lenses are manual, meaning zoom, focus and iris adjust- ments are done by hand manually.

  • Page 19: Inserting A Lens

    Note that the lens positioning when using lens shift may affect the accessibility of the lens button. If so, reposition the lens to gain access. 4.6.3 Lens range The table shows a selection of lenses available. Please see www.barco.com for more information about lens availability. ITEM TYPE...

  • Page 20: Lens Lock

    Using the remote control, press the OK key to center the lens or arrow keys to position it (restricted downwards movability). • Using the RS-232 or LAN control interfaces, please refer to the relevant SIS (Simplified Instruction Set) commands available for download on www.barco.com User Manual - Introduction CT series User Manual - Installation...

  • Page 21: Lens Planarity (Scheimpflug Adjustment)

    4.9 Lens planarity (Scheimpflug adjustment) This adjustment is rarely needed, do not apply it unless it is required. Certain applications require fine adjustment of the lens planarity in order to obtain an image that is focused. The projector is fitted with three adjustment screws (Allen key 3mm/5mm) around the bayonet mount that facilitate such adjustment, a so called Scheimpflug adjust- ment.

  • Page 22: Making The Connections

    Please see the relevant SIS (Simplified Instruction Set) commands available for download on www.barco.com for easy access to more information. Power up the projector and the source! 4.14 Source format integrity – EDID...

  • Page 23: Image Sizes

    7.00 7.50 3.50 6.00 6.25 3.00 5.00 2.50 5.00 4.00 2.00 3.75 3.00 1.50 2.50 2.00 1.00 1.25 1.00 0.50 0.00 Projection distance Lens types and specifications may change without prior notice. For correct lens information please refer to www.barco.com...
  • Page 24 1.50 2.50 2.00 1.00 1.00 1.25 0.50 0.00 Projection distance Lens types and specifications may change without prior notice. For correct lens information and other resolutions please refer to www.barco.com User Manual - Introduction CT series User Manual - Installation...

  • Page 25: Overview

    5 Overview Remote Control Receiver Interchangeable Projection Lens Projection Lens Release Button Figure 5-10. Projector front Remote Control Receiver Hot Air Exhaust Signal and Control Connector Panel Mains Power Connector Figure 5-11. Projector rear Keypad Figure 5-12. Projector top...
  • Page 26 Accessory Mounting Features Ceiling/Rig Mounting Features Figure 5-13. Mounting features Lamp Door Air Inlet Figure 5-14. Projector left and right hand side CT series User Manual - Overview...

  • Page 27: Keypad And Indicator

    5.1 Keypad and indicator Figure 5-15. Projector top key pad VALUE POWER Power on or power off (standby) MENU Activate or deactivate on-screen menu system UP, DOWN, LEFT, RIGHT Select source when not in Shift or Menu mode Shift lens when not in Menu and after SHIFT/OK pressed Navigate when in Menu system SHIFT/OK Shift lens when not in menu system...

  • Page 28: Wireless Remote Control

    5.2 Wireless remote control INFO POWER SHIFT BACK MENU SOURCE Batteries can be replaced by end-user. To replace the 2 standard AAA-batteries for this remote control, slide the lid at the back of the control downwards. Lift it off and remove the batteries. Replace with new batteries and slide the lid back in place.

  • Page 29: Signal Connectors

    5.3 Connectors Figure 5-17. Connector panel (see technical data for details) 5.3.1 Signal connectors CONNECTOR CONNECTOR FUNCTION NAME TYPE HDBaseT RJ45 Video over twisted pair DVI-I*) dual link Digital video (dual-link) HDMI HDMI type A Digital video DP (DisplayPort) Digital video (2) 9 pin mini DSUB Analog RGBHV video 3G-SDI BNC 75 Ω...

  • Page 30: Menu System

    5.4 Menu system The various projector-settings can be controlled via the on-screen menu system. The menu system is accessed by the keypad on the projector or using the wireless remote control. Press the MENU key to enter or leave the menu system. Navigate the options using the arrow-keys.

  • Page 31: Main Menu

    5.5 3D main menu The 3D menu contains settings for turning 3D on and off, in addition to defining various aspects of setup using Dual Head and specifying the types of glasses to be used. 3D : Offers the possibility to switch the 3D function off and to chose between the following alternatives for setup: off, side by side (<60Hz only), frame sequential and dual head (<60Hz only) dual head setup:...

  • Page 32: Dual Head Setup Sub Menu

    5.5.1 3D > Dual head setup sub menu source 1: Choice of source. Alternatives are SDI1, SDI2, DVI, HDMI, VGA, HDBaseT, DisplayPort1, DisplayPort 2. For possible setup combinations, see Figure 5-18. Dual head setup possibilities. source 2: Choice of source. Alternatives are SDI1, SDI2, DVI, HDMI, VGA, HDBaseT, DisplayPort1, DisplayPort 2.

  • Page 33: Picture Main Menu

    If the profile is marked by an asterisk (*), this indicates that the original settings have been changed. RealColor: Barco’s proprietary color management suite. See description in RealColor sub menu. gamma: 10 predefined gamma curves: Film 2.2: Exponential 2.2 curve Film 2.4: Exponential 2.4 curve...

  • Page 34: Picture > Realcolor Sub Menu

    5.6.1 Picture > RealColor sub menu BrilliantColor™: Texas Instruments DLP™ color processing. 3 settings*: Bright: Max brightness, boosted color profile for highest perceived brightness. In this mode all segments and spokes of the color wheel are in use. Color: Max brightness, balanced color profile for better color performance. In this mode all segments and spokes of the color wheel are in use.

  • Page 35: Picture > Advanced Sub Menu

    5.6.2 Picture > Advanced sub menu horizontal position: Shifts the image sideways (VGA only) vertical position: Shifts the image up or down (VGA only) phase: Adjust for stable image. A jittery image may appear with certain VGA sources. You may also press the AUTO button on the keypad or remote control to optimize.

  • Page 36: Installation Main Menu

    5.7 Installation main menu image orientation : Rotate the image on the imaging device in desktop front, desktop rear, ceiling front, ceiling rear. source scan : Search through all input connectors for an active signal or stay on one connector. IR front Enable or disable front IR-receiver.

  • Page 37: Installation > Edid Sub Menu

    5.7.1 Installation > EDID sub menu VGA : Define the detailed timing descriptor in the EDID data for VGA connector. Select between auto, WUXGA, 1080@60Hz, SX+, SXGA, 1366x768, 720@60Hz, 720@50Hz, XGA, SVGA, VGA. DVI : Define the detailed timing descriptor in the EDID data for DVI connector. Select between auto, WQXGA@60Hz, WUXGA@120Hz, WUXGA@60Hz,1080 @120Hz, 1080@60Hz, SX+, SXGA, 1366x768, 720@60Hz, 720@50Hz, XGA, SVGA, VGA.

  • Page 38: Installation > Synchronization Sub Menu

    5.7.2 Installation > Synchronization sub menu 2D frame lock : Selects the 2D frame lock sync signal. Options for 2D frame lock: source, SYNC 1, SYNC 2, SYNC 3. SYNC 1: Selects usage of SYNC1 connector in 2D mode. Options for SYNC 1: input, display sync, SYNC 2, SYNC 3 SYNC 2: Selects usage of SYNC2 connector in 2D mode.

  • Page 39: Settings Main Menu

    5.8 Settings main menu PIN code: Protect the projector from usage with a PIN. If enabled the projector will ask for the PIN at every start up. network : Set IP address, Subnet mask and default gateway TCP/UDP port number. DHCP is supported and is enabled by default, but can be disabled.

  • Page 40: Settings > Pin Code Sub Menu

    5.8.1 Settings > Pin Code sub menu PIN code enable: The PIN code is disabled by default. If you want to enable/disable the PIN code you have to enter the current PIN (Default PIN: 1234). When completed you can enable or disable the use of PIN code. If PIN is entered incorrectly 3 times, it will ask for a PUK code, which is provided in printed form in the box.

  • Page 41: Settings > Network Sub Menu

    5.8.2 Settings > Network sub menu change LAN settings: In this sub-menu you can switch the DHCP enabled function on or off. If off you can set a fixed IP-address. LAN DHCP: DHCP is supported and is enabled by default, but can be disabled under change LAN settings LAN IP address: Info field stating the current LAN IP address.

  • Page 42: Settings > Factory Reset Sub Menu

    5.8.3 Settings > Factory Reset sub menu picture: Restores picture settings to factory default. Restores 3D settings to factory default. communication: Restores communication settings to factory default. RealColor Restores RealColor settings to factory default. other: Restores other settings of your choice to factory default. 5.8.4 Settings >...

  • Page 43: Languages Main Menu

    5.9 Languages main menu Select the desired menu language. • Supported languages: English, French, German, Spanish, Norwegian, Swedish, Russian, Korean, Japanese,Chinese Traditional, Chinese Simplified, Portuguese, Italian. • Default: English...

  • Page 44: Status Main Menu

    5.10 Status main menu source information: Simple and advanced source information. synchronisation information: Displays the current synchronization information. Includes 2D framelock, 3D source sync and 3D display sync. part number: Projector part number. serial number: Projector serial number. manufactured (y): Year of manufacturing.

  • Page 45: Status > Source Information Sub Menu

    5.10.1 Status > Source Information sub menu advanced: Access to sub menu for more settings depending on source used. See 4.10.2 Status > Source Information > Advanced sub menu source 1: Info on which source is in use. format: Displays resolution and frequency for the source in use. source 2: Info on which source is in use.

  • Page 46: Status > Source Information > Advanced Sub Menu

    5.10.2 Status > Source Information > Advanced sub menu resolution: Info on current source resolution. total image size: Info on current horizontal and vertical image size. sync frequency : Info on current horizontal and vertical sync frequency for the projector. pixelclock: Week of manufacturing.

  • Page 47: Status > Source Synchronisation Sub Menu

    5.10.3 Status > Source Synchronisation sub menu Indicates which 3D mode is used. 2D frame lock: Indicates what the projector locks to in 2D Shows the current frequency of the locking signal frequency: status: Indicates the locking status phase: Indicates phase between the source and the locking signal 3D source sync: Indicates where the source L/R sync is connected source has in-band sync: Indicated if the source has embedded L/R sync, only...
  • Page 48 CT series User Manual - Overview...

  • Page 49: Functionality

    6 Functionality The various functions of the projector are described in detail in the following chapters. 6.1 Powering On and Off 6.1.1 Manual power control Switch the projector between On and Standby using the POWER switch on the keypad or the wireless remote control.

  • Page 50: Language

    6.3 Language The menu system has a total of 11 user-selectable languages available. The default language is English. The available languages are: • English • French • German • Spanish • Russian • Norwegian • Swedish • Korean • Japanese •...

  • Page 51: Lamp Power

    • Using the RS232 or LAN control interfaces, please see the relevant SIS (Simplified In- struction Set) commands available to download on www.barco.com 6.7 On screen display (OSD) messages When detecting sources and using the various features of the projector, OSD messages will appear on the screen.

  • Page 52: Picture By Picture (Pbp)

    6.8 Picture by Picture (PbP) You may choose to view two sources simultaneously as a picture by picture. The PbP-function allows viewing of two images side by side or on top of each other. Certain restrictions apply to how sources combine when using PbP. To view PbP: •...

  • Page 53: Software Upgrades

    You will need a USB memory stick set up with a FAT-file system to perform this upgrade Access the upgrade software from the following web-address; www.barco.com Download and save the firmware.zip-file to your PC desktop Download and save the firmware_<version>.tar file to the root of a memory stick It is important that the USB is safely removed from computer, using the eject function on your PC.
  • Page 54 User Manual - Introduction CT series User Manual - Functionality...

  • Page 55: Optimising The Image

    7.1 Calibration data All Barco projectors are measured and calibrated with high precision equipment at the factory for the best out-of-box experience. Over the lifetime of the lamps the characteristics of the projector might change slightly. The same applies when replacing lamps.

  • Page 56: Realcolor™ Modes

    7.1.2 RealColor™ modes Before any color correction is applied to the image, RealColor™ must be enabled. Go to menu PICTURE > REALCOLOR > COLOR CORRECTION to enable RealColor™. RealColor™ can operate in 3 modes: • Color temperature/white point correction only. •...

  • Page 57: Setting A White Point Color Colcolor Temperature

    7.2 Setting a white point or color temperature After enabling RealColor™ set the color temperature in the menu PICTURE > REALCOLOR > TEMPERATURE. Values between 3200K and 9300K can be selected. These color temperatures are tracking the “black body curve”- the black curved line in the center of CIE Chart in Figure 7-1.

  • Page 58: Gamma

    7.3 Gamma The projector features a set of 6 built in gamma curves: Film 2.2, Film 2.4, Film 2.6, Film 2.8, Video 1, Video 2, Computer 1, Computer 2, Dynamic and DICOM 180. The different gamma curves are displayed below. The names of the curves are descriptive for their recommended use.
  • Page 59 Figure 7-4. Film 2.8 gamma Figure 7-5. Video 1 gamma Figure 7-6. Video 2 gamma...
  • Page 60 Figure 7-7. Computer 1 gamma Figure 7-8. Computer 2 gamma Figure 7-9. Dynamic gamma User Manual - Introduction CT series User Manual - Optimising the image...
  • Page 61 Figure 7-10. DICOM 180 Lux* (example HB color wheel: other shapes with other alternatives) * Several DICOM settings (10, 60, 180, 250, 400 Lux - The higher Lux number (ambient light), the steeper the curve.
  • Page 62 User Manual - Introduction CT series User Manual - Optimising the image...

  • Page 63: Technical Specifications

    8 Technical specifications Please see www.barco.com for more technical information.
  • Page 64 User Manual - Introduction CT series User Manual - Technical specifications...

  • Page 65: Lamp Change

    9 Lamp change The indicator on the keypad will turn RED when lamp life is expired. Change the lamp when lifetime expires. Always replace lamp with the same type and rating. USE ORIGINAL LAMPS ONLY. The lamp holder employs an electronic lamp timer that is tracking the life time of the lamp. Always disconnect the power cord and wait until the projector has cooled down (60 minutes) before opening the lamp cover.
  • Page 66 User Manual - Introduction F50 User Manual - Lamp change...

  • Page 68: Production Address

    601-0363-01 © 2014 Barco nv. All rights reserved. All brands and trade names are the property of their respective owners. Specifications subject to change without prior notice. All values are typical and may vary. Please visit our website for latest specifications and product offerings.
