Page 1: Installation Guide
AT-FH705E Dual Speed Hub Installation Guide PN 613-10803-00 Rev. A... - Page 2 Copyright ”1999 Allied Telesyn International, Corp. 960 Stewart Drive Suite B, Sunnyvale CA 94086, USA All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesyn International, Corp. Ethernet is a registered trademark of Xerox Corporation. All other product names, company names, logos or other designations mentioned herein are trademarks or registered trademarks of their respective owners.
-
Page 3: Fcc Statement
408-730-0950 Declares that the product: Model Number: AT-FH705E This product complies with FCC Part 15B, Class B Limits: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device must not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 4: Safety Warnings
Safety Warnings Safety Warnings STANDARDS: This product meets the following standards RFI Emmission EN55022 Class B Immunity EN50082-1, 1997 SAFETY Power to the hub must be sourced only from the adapter. USA/CANADA Use a UL Listed/CSA Certified AC adapter of DC 5 V, 2.5 A. EUROPE - EU Use TÜV licensed AC adapter of DC 5 V, 2.5 A. -
Page 5: Table Of Contents
Technical Specifications ïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïï ä Physical Characteristics......................9 Agency Compliance ......................10 100Base-TX Cable .........................11 100Base-TX Connector Pinouts...................12 Appendix B Technical Support Fax Order ïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïï ìê Incident Summary.........................13 Appendix C AT-FH705E Switch Installation Feedback ïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïï ìè Appendix D Where To Find Us ïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïï ìæ... -
Page 7: Product Description Ïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïï Ì
Chapter 1 Product Description The AT-FH705E Mini Hub is an 5-port 10/100 Mbps dual speed hub that offers a cost-effective solution to today’s growing need of network speed integration. With five 10/100 Mbps plug-and-play dual speed ports equipped in its compact body, it is possible to achieve the coexistence of 10 Mbps and 100 Mbps devices in a single network now and step to 100 Mbps network in the future. -
Page 8: Package Contents
Product Description Package Contents The package should include the following items: ‰ One 5-port Dual Speed Mini Hub ‰ One Power Adapter ‰ This Installation Guide If any item is missing, please contact your dealer immediately. Front Panel The front panel contains the hub LED indicators. The LEDs help monitor the hub’s operating status and overall network performance. -
Page 9: Installing The Mini Hub
Chapter 2 Installation Installing the Mini Hub Place the Hub on a smooth and horizontal surface. 2. Establish network connection by plugging one end of the Category 5 UTP/STP cable RJ45 connector into the hub port, the other end to the Ethernet/Fast Ethernet adapter installed in the workstation computers. -
Page 10: Application
10BASE-T / 100BASE-TX 5 PORT ETHERNET HUB COLLISION 100M LINK/ACTIVITY 100M POWER Set to Uplink 100 m (328 ft) 100 m (328 ft) 100 Mbps 10 Mbps 100 Mbps 100 Mbps Workstation Workstation Workstation Workstation Figure 2 AT-FH705E Mini Hubs Connected to Workstation... -
Page 11: Connectivity Testing
Chapter 3 Troubleshooting This chapter describes the procedures to test and troubleshoot the hub. Connectivity Testing In the following procedure, you will test each port for a valid connection and to confirm the correct operation of the network. Start with Ports 1 and 2. Connect these two ports of a single hub to two nodes or workstations and turn on the hub’s power supply. -
Page 12: Problem Solving
Troubleshooting Problem Solving Is the unit receiving power? Check the Power LED on the front of the hub. This green LED should be lit. If the Power LED is not on: Check the back of the unit. Make sure the power cord is attached securely. - Page 13 AT-FH705E Installation Guide Problem 3: Port 1 does not operate properly. Solution 3: The Uplink slide switch may be in the wrong position. Check the following: ‰ When using the cascade port of the hub (Port 1), you should set the slide 8SOLQNý...
-
Page 15: Technical Specifications Ïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïï Ä
Appendix A Technical Specifications Physical Characteristics 10/100Base-TX Port 5 auto-negotiate ports Uplink Port Port 1 Cabling UTP/STP Category 5 for 100 Mbps; UTP Category 3, 4, or 5 for 10 Mbps Maximum of 100 m (328 ft) between the hub and a network node Operating Temperature 0 ~ 40... -
Page 16: Agency Compliance
Technical Specifications Agency Compliance Standard IEEE 802.3 (10Base-T) and IEEE 802.3u (100Base-TX) Class I and II Repeater EMI/RFI FCC Part 15 Class B, EN55022 Class B Immunity EN 50082-1 Safety Complies with safety standards UL 1950, cUL, EN60950 CE Compliant UTP (RJ45) Connector Figure 3 shows an RJ45 connector. -
Page 17: 100Base-Tx Cable
AT-FH705E Installation Guide Cabling Specifications Table 2 provides an overview of IEEE 802.3 and 802.3u cabling specifications for 10Base-T, and 100Base-TX network configurations using twisted-pair cable. Table 2 IEEE 802.3 and 802.3u Cabling Specifications 10Base-T 100Base-TX Media Unshielded/Shielded Twisted Unshielded/Shielded Twisted... -
Page 18: 100Base-Tx Connector Pinouts
Technical Specifications 100Base-TX Connector Pinouts Straight-through Cable Crossover Cable 4#7;. 7;.#4 4#7;. 7;.#4 5#7;0 7;0#5 5#7;0 7;0#5 6#5;. 5;.#6 6#5;. 5;.#6 9#5;0 5;0#9 9#5;0 5;0#9... -
Page 19: Technical Support Fax Order Ïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïïï Ìê
Appendix B Technical Support Fax Order Name ___________________________________________________________________ Company ________________________________________________________________ Address _________________________________________________________________ City ________________________ State/Province ________________________________ Zip/Postal Code ___________________ Country _________________________________ Phone _______________________________Fax _________________________________ Incident Summary Model number of Allied Telesyn product I am using ______________________________ Network software products I am using _________________________________________ BBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB Brief summary of problem __________________________________________________ BBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB... - Page 21 Appendix C AT-FH705E Switch Installation Feedback Please tell us what additional information you would like to see discussed in the guide. If there are topics you would like information on that were not covered in the guide, please photocopy this page, answer the questions and fax or mail this form back to Allied Telesyn.
-
Page 23: For Sales Or Corporate Information
Appendix D Where To Find Us For Technical Support or Service Location Phone Americas 1 (800) 428-4835 1 (918) 628-3222 United States, Canada, Mexico, Central America, South America Asia (+65) 3815-613 (+65) 3833-830 Singapore, Taiwan, Thailand, Malaysia, Indonesia, Korea, Philippines, China, India Australia (+61) 2-943-5111 (+61) 2-9438-4966...
