Change Mode Button
Backup Button
HDD-1 Access & Failure LED
Green: HDD-1 working. Red: HDD-1 failed.
Green/Red twin lights blinking means that RAID(1) is being built,
or rebuilt.
HDD-0 Access & Failure LED
Green: HDD-0 working. Red: HDD-0 failed.
Green/Red twin lights blinking means RAID(1) is being built, or
rebuilt.
System Ready/Backup LED
Green: System ready. If there is no indication, the system or hard
drive health may have a problem.
Red : Red blinking means data backup is in operation. (optional
function)
Instruction Manual
HDD-1 LED
HDD-0 LED
HDD Eject Buttons
2
System Ready/
Backup LED
eSATA Port
Mini USB Switch
RAID Mode
Configuration Switch
DC Input (5V)
Power Switch
