- Page 1 SAT2510U2F Instruction Manual SATA Hard Drive Enclosure 2.5” USB, FireWire to SATA External Hard Drive Enclosure...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question.
-
Page 3: Table Of Contents
Table of Contents Introduction ..............1 Packaging Contents..............1 System Requirements ..............1 Installation ............... 2 Hardware Installation ..............2 Driver Installation .................3 Using the Enclosure ............3 Specifications ..............5 Technical Support ............6 Warranty Information ............6... -
Page 4: Introduction
Introduction The SAT2510U2F External Hard Drive Enclosure supports both USB 2.0 and FireWire 400 (IEEE1394a) host connections in a slim, lightweight aluminum design. Packaging Contents • 1 x SAT2510U2F hard drive enclosure • 1 x USB “Y” split cable •... -
Page 5: Installation
Installation WARNING: Hard drives require careful handling, especially when being transported. If you are not careful with your hard disk, lost data may result. Always handle your hard drive and storage device with caution. Hardware Installation Remove the two small screws from either side of the rear panel of the enclosure and then pull the rear panel out. -
Page 6: Driver Installation
Connect the enclosure to the host computer system via FireWire or USB cable. OPTIONAL: if additional power is required by the hard drive, connect the USB power cable from the DC plug on the enclosure to an available USB port on the host computer system. Driver Installation Windows 2000/XP/Vista/7, Mac OS 9.2/10.x, or Linux/Unix No driver installation is required for these operating systems, as this... - Page 7 Locate the Disk that says it is “Unallocated” (check hard drive capacity to confirm it’s the correct hard drive) and then right-click in the section that says “Unallocated” and select “New Partition”. The New Partition Wizard will appear. Follow the instructions in the wizard to complete setting up the drive.
-
Page 8: Specifications
Specifications USB 2.0 Bus Interface FireWire400 (IEEE1394a) 1 x USB mini-B Connectors 1 x 6-pin FireWire 1 x DC power connector LEDs 1 x Power/Activity Chipset Oxford OXUF934SSA 2.5” SATA 1.5/3.0Gbps, Hard Drive Support 9.5mm height, up to 500GB in capacity USB: 480Mb/s Maximum Data Transfer Rate... -
Page 9: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or... - Page 10 StarTech.com has been making “hard-to-find easy” since 1985, providing high quality solutions to a diverse IT and A/V customer base that spans many channels, including government, education and industrial facilities to name just a few. We offer an unmatched selection of computer parts, cables, A/V products, KVM and Server...
