How to Setup RAID functions
Installation
1.
Use a screw driver to loosen the two screws and slide in the 2.5"
HDDs.
Note: If you want to build RAID functions, you must install two hard
drives at the same time.
2.
Set the RAID mode on the DIP SW
Display
a) To set the operating mode according to the above table:
i) Connect the USB or eSATA data and power cable to your system,
then, turn on the power from the RAID box rear panel. Wait until both
hard drives are powered on.
ii) Press the RAID Change Mode SW once to finish setting the RAID
mode. [*Note: If you want to use the default model setting (or re
place HDDs), you still must press the RAID Model Change SW
once].
3.
Once the selected RAID mode is ready, you may partition/format the
RAID-built HDDs. After the HDDs have been formatted, they are ready
to use.
RAID Status
0
BIG (span)
1
JBOD (single)
2
FAST (strip)
3
SAFE (mirror)
4
SAFE33
5
SAFE50
6
RESERVED
7
GUI ONLY
Instruction Manual
10
RAID Configuration
4
2
OFF
OFF
OFF
OFF
OFF
ON
OFF
ON
ON
OFF
ON
OFF
ON
ON
ON
ON
1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
