Grandhall XS08ALP Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Liquid Propane Gas (LPG) Grill
Model XS08ALP
Natural Gas (NG ) Grill
Model XS08ANG
FREE HELP
FROM THE GRILL EXPERTS
Grand Hall is the expert on this product
and trained to help you with:
Ÿ
Assembly Questions
Ÿ
Grill Operation
Ÿ
Replacement of Damaged or Missing parts
visit www.grandhall.com or call:
1-877-934-7455
Monday - Friday 8:00am-4:30pm CST
IMPORTANT:
Ÿ
NOTE TO ASSEMBLER / INSTALLER:
Leave this manual with the consumer.
Ÿ
NOTE TO CONSUMER:
Keep this manual for future reference.
Ÿ
RECORD YOUR SERIAL # __________________
(see silver CSA label on main body of grill)
Operator's Manual
WARNING
!
Ÿ
Failure to comply with these instructions could
result in a fire or explosion that could cause
serious bodily injury, death or property dam-
age.
Ÿ
Whether this grill was assembled by you or
someone else, you must read this entire manual
before using your grill to ensure the grill is
properly assembled, installed and maintained.
Ÿ
Use your grill at least 3 feet away from any
wall or surface. Use your grill at least 3 feet
away from combustible objects that can melt or
catch fire such as vinyl or wood siding, fences
and overhangs or sources of ignition including
pilot lights on water heaters and live electrical
appliances.
Ÿ
THIS GAS APPLIANCE IS DESIGNED FOR OUT-
DOOR USE ONLY.
Ÿ
Never use your gas grill in a garage, porch,
shed, breezeway or any other enclosed area.
Ÿ
Never obstruct the flow of ventilation air
around your gas grill housing.
Ÿ
Never disconnect the gas regulator or any
gas fitting while your grill is lit. A lit grill can ignite
leaking gas and cause a fire or explosion which
could result in property damage, personal injury
or death.
Manual # P80134003A - Date:2008/12/15
!

Advertisement

Table of Contents
loading

Related Manuals for Grandhall XS08ALP

Summary of Contents for Grandhall XS08ALP

  • Page 1: Primary Safety Warnings

    Replacement of Damaged or Missing parts before using your grill to ensure the grill is visit www.grandhall.com or call: properly assembled, installed and maintained. Ÿ Use your grill at least 3 feet away from any 1-877-934-7455 wall or surface.

  • Page 2: Table Of Contents

    Table of Contents WARNING Primary Safety Warnings ......1-3 Pre-Assembly Instructions ......3 Do not store or use gasoline or other Part Diagrams and Lists ......4-7 flammable liquids or vapors in the Assembly Instructions........8-9 vicinity of this or any other appli- Use &...

  • Page 3: Pre-Assembly Instructions

    Pre-Assembly Instructions For Your Safety Congratulations on your selection of one of the finest outdoor PRE-ASSEMBLY kitchen appliances available. Your Grill is equipped with the Read and perform the following pre-assembly instruc- unique Crossray infrared cooking system by Grand Hall (patent tions: pending) which offers restaurant style grilling performance.

  • Page 4: Part Diagrams And Lists

    & XS08ANG PART # PART DESCRIPTION PURPOSE OF PART P06030001A Hardware Pack For use in as sembly of Models XS08ALP/NG S182G04061 Pan Head Screw 1/4"x3/8" Install Side Shelves P05515128Y Wrench/M5 For use in rem oving/installing the replacement part for Lid Hinge...
  • Page 5 Parts Diagram for Models XS08ALP & XS08ANG 8b (optional) 8b (optional) 8a (optional)
  • Page 6 Parts List for Models XS08ALP & XS08ANG DESCRIPTION PART# Lid Assem bly Outer P0014513PK Protective Pad P05518002I Tem perature Gauge P00601375A Lid Handle P00215034D Lid Assem bly Inner P0014514E5 Lid Hinge P05547004D Lid Bracket P033031165 Cooking Rack/Secondary P015160275 Cooking Grid...
  • Page 7 P05507140M Charger P05384001B Tem perature Probe P05385001B Grate Handle Hook P05514135G Operator's Manual P80134003A Optional Parts to Purchase for Models XS08ALP & XS08ANG DESCRIPTION PART# Griddle (optional) P057050035 Griddle Handle (optional) P055151255 Cover (optional) P07007052A For the repair or replacement parts you need: Call 1-877-934-7455 M-F 8AM-4:30 PM CST To obtain the correct replacement parts for your gas grill, please refer to the part numbers in this parts list.

  • Page 8: Assembly Instructions

    Assembly Instructions CAUTION : While it is possible for one person to assemble this grill, obtain assistance from another person when handling some of the larger, heavier pieces. Install Side Shelves Raise Lid and remove all packing materials. Insert the Left Side Shelf Brackets into the holes on the Left Bowl Panel. Align the 4 holes on the Left Side Shelf with the 4 holes on the Left Bowl Panel, insert 4 Phillips Head Screws 1/4"x3/8"...
  • Page 9 Install Cooking Components Install Ignitor Battery Place Cooking Grids on bowl ledge. Remove Ignitor Cap from the inside of the Cart. Place the Secondary Cooking Rack into the Place supplied AA battery into the Ignitor Slot with slots on Grill Bowl Side Panels. positive pole out.

  • Page 10: Gas Safety And Leak Tests

    LP Gas Tank Installation CORRECT LP GAS TANK USE Never allow children to operate your grill. Do not allow children or pets to play near your grill. Always supervise LP Gas grill models are designed for use with a standard children and pets if they are in the vicinity of the unit 20 lb.

  • Page 11: Use & Care Instructions

    USE AND CARE INSTRUCTIONS NOTE about LP Gas Tank Exchange Programs Secure a 20lb LP Gas Tank to Gas Grill Ÿ Many retailers that sell grills offer you the option of replacing your empty LP Gas tank through an exchange service. Use Turn your LP Gas Tank Valve clockwise to the closed only those reputable exchange companies that inspect, pre- or OFF positon.
  • Page 12 USE AND CARE INSTRUCTIONS LP Gas Model only: Check all connections for LP Gas Leaks Connect Regulator with Hose to your LP Gas Tank Never test for leaks with an open flame. Prior to first use, at the beginning of each season, or every time Turn all Burner Valves to the OFF position.

  • Page 13: Natural Gas Connection

    Natural Gas Connection Natural Gas Model only: Connecting Natural Gas To Your Grill Fig.1 Connect the Swivel nut of the 12' Natural Gas Hose to the horizontal fitting of NG Regulator as shown in Fig.1. Connect the other hose end (male Vertical fitting plug) to the gas supply line from your home.

  • Page 14: Use & Care Instructions/Lcd

    USE AND CARE INSTRUCTIONS - LCD LCD Functions: 1. Cooking Timer (shows cooking time remaining) 2. Grill Temperature Display (indicates temperature of grill) 3. Flame Level Detector (indicates flame level) 4. Battery Power Display (indicates how much battery power is remaining) 5.
  • Page 15 USE AND CARE INSTRUCTIONS - LCD Using the Temperature Probe Insert the plug of the Temperature Probe into the Temperature Control Outlet of the LCD Panel. When appears, select whether you want the temperature displayed in Celsius or Fahrenheit. After you have selected the unit of measurement, you can stick the probe into your food.

  • Page 16: Lighting Instructions

    USE AND CARE INSTRUCTIONS Grill Lighting Instructions Before each use, check all hoses for cracks, nicks, If ignition does not occur in 5 seconds, turn gas off cuts, burns or abrasions. If a hose is damaged in any at source and turn Control Knobs OFF. Wait at least 5 minutes for gas to clear, then retry.

  • Page 17: Troubleshooting

    USE AND CARE INSTRUCTIONS Troubleshooting To purge air from your gas line and/or reset the regulator excess gas flow device: If the grill fails to light : Turn Control Knobs to the OFF position. Turn the gas off at the source and turn Control Knobs to OFF.
  • Page 18 USE AND CARE INSTRUCTIONS CORRECT ROTISSERIE USE CAUTION Read all instructions before initial use. IMPORTANT: When using electrical appliances, basic To protect against shock hazard risk, connect only safety precautions should always be used. to properly Grounded Outlet. The Rotisserie Motor is set for 12V, 5W DC. The Rotisserie is for outdoor use only.

  • Page 19: Rotisserie Instruction

    Rotisserie Instructions 1. Remove all components from the carton. Slide a Holding Fork onto each end of the Rotisserie Spit. Adjust spacing between Holding Forks to accommodate your food, then turn clockwise until the screw stops. Holding Forks Clockwise to Tighten Spit Note: In order to avoid damaging the holding fork, do not tighten unless it is assembled on the spit rod.
  • Page 20 Check if the Motor Socket Wire has been connected to the LCD Plug Wire. (The Motor Socket Wire was connected by the manufacturer. The wire connection may have loosened if your grill has been frequently shifted.) If the wire connection is loose, reconnect the wire and socket. Make sure that you have completed installation step 2 on page 8 before testing the rotisserie or turning it on.

  • Page 21: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Cleaning Exterior Stainless Steel Surfaces: Routine care and maintenance is required to preserve Proper care and maintenance will keep your grill in top operat- the appearance and corrosion resistance of stainless ing condition and prolong its life. Follow these cleaning proce- steel.
  • Page 22 Infrared Grill Cooking Instructions Burn-Off Indirect Cooking Before cooking on your gas grill for the first time, you To cook indirectly, the food should be placed on the should "burn off" the grill to eliminate any odor or foreign left or right side of your grill (or Secondary Rack) with matter.
  • Page 23 Guide to Infrared Grilling using the Direct Cooking Method Cut of Meat Approx. Total Cooking Times Grilling Steak and Ribs Fill Grease/Water Tray half-full. Turn the grill Burners on T-bone steak Rare: 4-6 minutes , close the Lid and preheat your grill 3 to 5 minutes.Open Sirloin steak Medium: 6-8 minutes Lid and place food on the mid section of a Cooking Grid.
  • Page 24 Guide to Roasting & Baking using the Indirect Cooking Method HIGH and close Lid for approximately 2 minutes. An Important Note About Infrared Heat Settings Food preparation The suggested heat settings and cooking times shown are approximate. Unlike the controlled environment inside your Trim meat of excess fat.
  • Page 25 Guide to Smoking Infrared Rotisserie Cooking Preparing to Smoke Balancing the Food Smoking gives food a distinctive, delicious flavor. You will find In rotisserie cooking, balancing the food is of utmost a variety of wood chips available for use in smoking grilled importance.
  • Page 26 Guide to Stir-Frying and Deep-Frying DEEP-FRYING TECHNIQUES STIR-FRYING TECHNIQUES A wide variety of foods can be deep-fried outdoors on your This method of cooking is popular around the world and can grill, from potatoes, to seafood and chicken. Deep-frying be easily accomplished outdoors on your gas grill. It's a quick uses a large portion of oil, preferably saturated.
  • Page 27 Question: Question: Sometimes I hear a humming sound coming from my Can I convert my grill from one fuel type to another in regulator. What causes this? And - My grill has a low other words from LPG to NG or vice versa? flame and sometimes will not light.
  • Page 28 Question: After every use (after your grill has cooled down), wipe The Regulator and Hose supplied with my gas grill stainless surfaces with a soft, soapy cloth or sponge does not fit the older LP Gas tank I’ve used for years. then rinse with water.
  • Page 29 All Other Grill Parts- 5 Year Limited Warranty Grand Hall will require reasonable proof of your date of purchase. Therefore, you should send in the owner registration card or register online at www.grandhall.com. Save your receipt in case it is required as proof of purchase.
