Table of Contents

Advertisement

Quick Links

Download this manual See also: Admin Manual, System Manual
480i, 480i CT, 9112i, 9133i
SIP IP PHONE
41-001129-00
Rev 09
Administrator Guide
Release 1.4.1
DFW Phone 972-992-4600

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 480i and is the answer not in the manual?

Questions and answers

Related Manuals for Aastra 480i

Summary of Contents for Aastra 480i

  • Page 1 480i, 480i CT, 9112i, 9133i SIP IP PHONE 41-001129-00 Rev 09 Administrator Guide Release 1.4.1 DFW Phone 972-992-4600...
  • Page 2 WWW.DFWPHONE.COM SALES@DFWPHONE.COM Aastra Telecom will not accept liability for any damages and/or long distance charges, which result from unauthorized and/or unlawful use. While every effort has been made to ensure accuracy, Aastra Telecom will not be liable for technical or editorial errors or omissions contained within this documentation. The information contained in this documentation is subject to change without notice.

  • Page 3: Software License Agreement

    Software in object form solely with the Equipment for which the Software was intended. This Product may integrate programs, licensed to Aastra by third party Suppliers, for distribution under the terms of this agreement. These programs are confidential and proprietary, and are protected as such by copyright law as unpublished works and by international treaties to the fullest extent under the applicable law of the jurisdiction of the Customer.
  • Page 4 DFW Phone 972-992-4600...

  • Page 5: Table Of Contents

    Installing the Firmware/Configuration Files ..............1-8 Chapter 2 Configuration Interface Methods About this chapter ......................2-1 IP Phone UI ........................2-2 Options Key ......................2-2 Aastra Web UI ........................2-5 Description .......................2-5 Accessing the Aastra Web UI ..................2-5 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...
  • Page 6 Status ........................2-6 Operation .........................2-7 Basic Settings ......................2-7 Advanced Settings ....................2-8 Enabling/Disabling the Aastra Web UI ..............2-9 ..........................2-9 Chapter 3 Administrator Options About this chapter ......................3-1 Administrator Level Options ...................3-3 Description .......................3-3 IP Phone UI Options ....................3-3 Aastra Web UI Options ....................3-4 Configuration File Options ..................3-4...
  • Page 7 Administrator Passwords ..................5-8 Hard Keys ........................5-9 Softkeys/Programmable Keys ................5-12 Suppressing DTMF Playback .................5-24 Busy Lamp Field (BLF) (480i/480i CT/9133i only) ..........5-26 Directed Call Pickup (BLF Call Interception) (480i/480i CT/9133i) ....................5-32 BLF Subscription Period (480i/480i CT/9133i) ............5-35 Do Not Disturb (DND) ....................5-37 Bridged Line Appearance (BLA) (480i/480i CT/9133i only) ........5-39...
  • Page 8 SIP Message Sequence for Blind Transfer ..............6-5 Update Caller ID During a Call .................6-6 Boot Sequence Recovery Mode ................6-7 Auto-discovery Using mDNS ..................6-8 Single Call Restriction (480i CT only) ..............6-9 Chapter 7 Encryption and the IP Phone About this chapter ......................7-1 Encryption and the IP Phone ..................7-2...
  • Page 9 Operational, Basic, and Advanced Parameters ............. A-5 Network Settings ..................... A-5 Password Settings ....................A-8 Aastra Web UI Settings ..................A-10 Configuration Server Settings ................A-10 Type of Service (ToS)/DSCP Settings ..............A-17 Virtual Local Area Network (VLAN) Settings ............A-18 Network Address Translation (NAT) Settings ............
  • Page 10 BLF Subscription Period Settings ................. A-89 Hard Key Parameters ....................A-90 Softkey/Programmable Key Parameters ..............A-93 Softkey Settings for 480i and 480i CT ..............A-94 Programmable Key Settings for 9112i and 9133i ..........A-100 Advanced Operational Parameters ................A-103 MAC Address/Line Number ................A-103 Blind Transfer Setting.
  • Page 11 Sample Configuration Files About this appendix ....................... D-1 Sample Configuration Files ................... D-2 480i Sample Configuration File ................D-2 480i CT Sample Configuration File ............... D-12 9112i Sample Configuration File ................D-29 9133i Sample Configuration File ................D-36 Appendix E Sample BLF Softkey Settings About this appendix .......................
  • Page 12 Directory Object (Directory List Screen) (480i only) ..........G-12 Status Message Object (Idle Screen) ..............G-14 Execute Commands Object (for executing XML commands) .......G-17 HTTP Post ......................G-19 XML Schema File ....................G-22 Limited Warranty 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...

  • Page 13: Preface

    This SIP IP Phone Administrator Guide provides information on the basic network setup, operation, and maintenance of the IP phones, Models 480i, 480i Cordless (480i CT), 9112i, and 9133i. It also includes details on the functioning and configuration of the IP phones.

  • Page 14: Other Documentation

    Included with the phone. • Model 480i, 480i CT, 9112i, 9133i SIP IP Phone Administrator Guide – explains how to set the phone up on the network, as well as advanced configuration instructions for the SIP IP phone. This guide contains information that is at a technical level more suitable for a system or network administrator.
  • Page 15 Software License Agreement About this guide Chapters and appendixes in this guide This guide contains the following chapters and appendixes: Go to An overview of the IP Phone firmware installation information Chapter 1 IP Phone interface methods Chapter 2 Administrator option information Chapter 3 Configuring the IP Phone Chapter 4...
  • Page 16 DFW Phone 972-992-4600...

  • Page 17: Overview

    Chapter 1 Overview About this chapter Introduction This chapter briefly describes the IP Phone Models, and provides information about installing the IP phone firmware. It also describes the firmware and configuration files that the IP phone models use for operation.. Topics This chapter covers the following topics: Topic...

  • Page 18: Ip Phone Models

    IP Phone Models IP Phone Models Description The IP Phone Models 480i, 480i CT, 9112i, and 9133i communicate over an IP network allowing you to receive and place calls in the same manner as a regular business telephone. All phone models support the Session Initiation Protocol (SIP). The 480i additionally supports the Media Gateway Control Protocol (MGCP).

  • Page 19: Firmware Installation Information

    Phone keypad menu (Phone UI) • Aastra Web-based user interface (Aastra Web UI) When the IP phone is initialized for the first time, DHCP is enabled by default. Depending on the type of configuration server setup you may have, the IP phone may download a firmware version automatically, or you may need to download it manually.

  • Page 20: Installation Requirements

    Power over Ethernet (PoE) power supply (optional accessory – necessary only if no inline power is provided on the network). (Not applicable to 9112i) • Power adapter (included for certain models of 9112i, 9133i, and 480i CT). 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...

  • Page 21: Configuration Server Requirement

    Overview Firmware Installation Information Configuration Server Requirement A basic requirement for setting up the IP phone is to have a configuration server. The configuration server allows you to: • Store the firmware images that you need to download to your IP phone. •...

  • Page 22: Firmware And Configuration Files

    The firmware consists of a single file called: • <phone model>.st The configuration files consist of two files called: • aastra.cfg • <mac>.cfg The following table provides the firmware for each Aastra IP phone model. IP Phone Associated Model Firmware 480i 480i.st 480i CT 480i Cordless.st...

  • Page 23: Configuration File Precedence

    Aastra Web UI • Configuration files Models 480i and 480i CT have 20 softkeys available to configure the IP phone. Model 9133i has 7 programmable keys. Model 9112i has 2 programmable keys. 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...

  • Page 24: Installing The Firmware/Configuration Files

    IP phone. Note: The <phone model> attribute is the IP phone model (i.e., 480i.st, 9133i.st) Copy the Aastra configuration files (aastra.cfg and <mac>.cfg) to the root directory of the configuration server.

  • Page 25: Configuration Interface Methods

    IP phone model are indicated where required in this guide. Topics This chapter covers the following topics: Topic Page IP Phone UI page 2-2 Aastra Web UI page 2-5 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...

  • Page 26: Ip Phone Ui

    IP Phone UI The IP phone UI provides an easy way to access features and functions for using and configuring the IP phone. Hardkeys include Hold (480i/480iCT), Swap (9112i), Redial, Options, Xfer, Conf, Icom (480i/480iCT), and Services (480i/ 480iCT). Specific keys are also programmed to access the Directory List and the Callers List.
  • Page 27 Save Delete Save Swap Delete PQRS WXYZ Conf Xfer Mute 9112i PQRS WXYZ Mute 9133i Options Key Hold Redial Goodbye Options PQRS WXYZ Xfer Icom Conf Services 480i CT Handset 480i/480i CT 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...
  • Page 28 Press the Done softkey at any time to save the changes and exit the current option. Press the Cancel softkey, press or press at any time to exit without saving changes. From the 480i CT handset: Step Action  Press the key to enter the Options List when the phone is not in use.

  • Page 29: Aastra Web Ui

    Aastra Web UI Aastra Web UI Description An administrator can setup and configure the IP phone using the Aastra Web UI. The Aastra Web UI supports Internet Explorer and Gecko engine-based browsers like Firefox, Mozilla or Netscape. Accessing the Aastra Web UI Use the following procedure to access the Aastra Web UI.

  • Page 30: Status

    IP Phone Administrator Guide Aastra Web UI The following illustration is an example of a Network Status screen for the 480i IP phone. IP address or host name 480i Network Status Window Logout button The following categories display in the side menu of the Aastra Web UI: Status, Operation, Basic Settings, Advanced Settings.

  • Page 31: Operation

    9112i and up to 7 on the 9133i. Softkeys and XML Allows you to configure up to 20 softkeys and load XML (480i and 480i CT only) applications. Handset Keys Allows you to configure up to 15 softkeys on the handset.

  • Page 32: Advanced Settings

    Allows you to manually perform a firmware update on the IP phone from the configuration server Troubleshooting Allows you to perform troubleshooting tasks whereby the results can be forwarded to Aastra Technical Support for analyzing and troubleshooting 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...

  • Page 33: Enabling/Disabling The Aastra Web Ui

    Note: A value of zero (0) disables the Web UI on the phone. A value of 1 enables the Web UI. Save the changes and close the <mac>.cfg or the aastra.cfg file. Restart the phone to apply the changes. The Aastra Web UI is disabled for a single IP phone or for all phones.
  • Page 34 DFW Phone 972-992-4600...

  • Page 35: Administrator Options

    The IP phones provide specific options on the IP Phone UI that allow an administrator to change or set features and configuration information as required. For all models, you can also use the Aastra Web UI and the configuration files to enter and change values.

  • Page 36: Topic Page

    IP Phone Administrator Guide About this chapter Topic Page Configuration Server Settings page 3-21 Firmware Update Features page 3-22 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...

  • Page 37: Administrator Level Options

    Appendix A, the section “Password Settings” page A-8. For the Aastra Web UI, you can access the Administrator options by entering a user name and password. The default user name is "admin" and the default password is "22222". IP Phone UI Options The following are administrator options in the "Options List"...

  • Page 38: Aastra Web Ui Options

    Troubleshooting Reference For information about all other user options, see your model-specific SIP IP Phone User Guide. For procedures on configuring the IP phone via the Aastra Web UI, see Chapter 4, “Configuring the IP Phones.” Configuration File Options A system administrator can enter specific parameters in the configuration files to configure the IP phones.

  • Page 39: Configuration Files

    Save the changes and close the configuration file. If the parameter requires the phone to be restarted in order for it to take affect, use the IP Phone UI or the Aastra Web UI to restart the phone. 41-001129-00 Rev 09, Release 1.4.1...

  • Page 40: Phone Status

    In the IP phone UI, the Phone Status options are available to the user and the administrator and do not require a password entry. However, the “Restore Defaults” option (9112i/9133i) and the "Factory Default" option (480i/480i CT) are for administrator use only.

  • Page 41: Factory Default

    Also displays the IP and MAC address of the phone. These fields are read-only. • Network Status (480i and 480i CT only) Displays the network status of the Ethernet ports at the back of the phone. You can also view the phone’s IP and MAC addresses. These fields are read-only.
  • Page 42 In the Aastra Web UI, the "Network Status", "Hardware Information", and "Firmware Information" options are read only and available for viewing by the user and administrator. Resetting the IP phone to factory defaults using the Aastra Web UI (Operation->Reset->Current Settings) is available to the administrator only.
  • Page 43 Administrator Options Administrator Level Options The following information displays for phone status in the Aastra Web UI at the location Status->System Information. This information is available to the user and the administrator as read-only. • Network Satus Displays the network status of the Ethernet ports at the back of the phone. You can also view the phone’s IP and MAC addresses.

  • Page 44: Basic Preferences (Aastra Web Ui)

    Basic Preferences (Aastra Web UI) An administrator can configure the following basic preferences using the Aastra Web UI: • Idle Display Name 1 and 2 The names that display on the idle screen rather than the user name and phone number.
  • Page 45 Administrator Options Administrator Level Options • Key Mapping Allows you to set the Redial and/or Conf keys as speedial keys. • Priority Alerting Enabling/disabling priority alert by setting specific ring tones for types of calls (Group, External, Internal, Emergency, Priority). •...

  • Page 46: Network

    • Basic network settings • Advanced network settings Note: Specific parameters are configurable using the Aastra Web UI only and are indicated where applicable. Basic Network Settings If Dynamic Host Configuration Protocol (DHCP) is enabled, the IP phone automatically configures all of the Network settings. If the phone cannot populate the Network settings, or if DHCP is disabled, you can set the Network options manually.
  • Page 47 Administrator Options Administrator Level Options • Primary DNS Primary Domain Name Service. A service that translates domain names into IP addresses. To assign static DNS addresses, disable DHCP. • Secondary DNS Secondary Domain Name Service. A service that translates domain names into IP addresses.
  • Page 48 • RTP Settings Note: Specific parameters are configurable using the Aastra Web UI only and are indicated where applicable. If you have a proxy server or have a SIP registrar present at a different location than the PBX server, the SIP parameters may need to be changed.
  • Page 49 (not configurable via IP phone UI) Phone number that you assign to BLA lines that is shared across all phones (global configuration) or shared on a per-line basis (per-line configuration). For more information about BLA, see Chapter 5, the section, “Bridged Line Appearance (BLA) (480i/480i CT/ 9133i only)” page 5-39. •...
  • Page 50 IP Phone Administrator Guide Administrator Level Options Basic SIP Network Settings • Proxy Server (Proxy IP in the configuration files). IP address of the SIP proxy server. Up to 64 alphanumeric characters. Configurable on a global and per-line basis. • Proxy Port SIP proxy server’s port number.
  • Page 51 IP Phone. You can enable and disable MWI by setting this parameter to 0 (disable) or 1 (enable) in the configuration files or by checking the box for this field in the Aastra Web UI. Default is disabled. •...
  • Page 52 IP Phone Administrator Guide Administrator Level Options • BLF Subscription Period Specifies the time period, in seconds, that the BLF feature becomes active again after a software/firmware upgrade or after a reboot of the IP phone. RTP Settings You can configure the following RTP settings: •...

  • Page 53: Line Settings

    480i CT 9112i 9133i A user or administrator can then assign the line to a specific softkey (480i/480i CT) or programmable key (9112i/9133i). The available softkeys also depends on the IP phone model as shown in the following table. Program...
  • Page 54 IP Phone Administrator Guide Administrator Level Options The functions you can configure are: • line (480i, 480i CT, 9133i) • speeddial • do not disturb • BLF (480i, 480i CT, 9133i) • BLF/List (480i, 480i CT, 9133i) • • flash •...

  • Page 55: Configuration Server Settings

    Note: Any changes made using the Aastra Web UI or the IP phone UI are not overwritten by an auto-resync update. Auto-resync affects the configuration files only. However, the settings in the Aastra Web UI take precedence over the IP phone UI and the configuration files.

  • Page 56: Firmware Update Features

    IP phone UI or the Aastra Web UI). • Automatic update of firmware, configuration files, or both at a specific time in a 24-hour period (via the Aastra Web UI or configuration files) Reference For more information about firmware update, see Chapter 8, “Firmware...

  • Page 57: Configuring The Ip Phones

    This chapter provides the information required to configure the administrative options on the IP phones. It includes procedures for configuring via the configuration files, the IP Phone UI, and the Aastra Web UI where applicable. Topics This chapter covers the following topics:...
  • Page 58 IP Phone Administrator Guide About this chapter Topic Page Network Time Servers page 4-32 Session Initiation Protocol (SIP) Settings page 4-38 Real-time Transport Protocol (RTP) Settings page 4-50 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...

  • Page 59: Overview

    UI, from the Aastra Web UI, or the configuration files. Administrator level options are password protected in both the IP phone UI and the Aastra Web UI. Note: An administrator has the option of enabling and disabling the use of password protection in the IP phone UI.

  • Page 60: Basic Network Settings

    IP Phone Administrator Guide Basic Network Settings Basic Network Settings This section describes the basic network settings on the IP phone. DHCP The IP phone is capable of querying a DHCP server, allowing a network administrator a centralized and automated method of configuring various network parameters for the phone.
  • Page 61 Basic Network Settings Configuring DHCP You can enable and disable DHCP using the configuration files, the IP phone UI, or the Aastra Web UI. Configuration Files For specific parameters you can set in the configuration files, see Appendix A, the section, “Network...
  • Page 62 IP Phone Administrator Guide Basic Network Settings Aastra Web UI Step Action Click on Advanced Settings->Network->Basic Network Settings. Enable the "DHCP" field by checking the check box. (Disable this field by unchecking the box). Click to save your settings. 41-001129-00 Rev 09, Release 1.4.1...

  • Page 63: Configuring Network Settings Manually

    If you disable DHCP on your phone, you need to configure the network settings manually. You can configure the Network settings using the configuration files, the IP phone UI, or the Aastra Web UI. Configuration Files For specific parameters you can set in the configuration files, see Appendix A, the section, “Network...
  • Page 64 Select DNS and enter a Primary and/or Secondary DNS server. For 9112i/9133i: Press Set to save the changes. For 480i/480i CT: Press Done to save the changes. The IP phone is manually configured. You can now continue configuring the IP phone if required using the IP Phone UI.
  • Page 65 Enter a Primary DNS in the Primary DNS field, and/or a secondary DNS in the Secondary DNS field. Click to save your settings. The IP phone is manually configured. You can now continue configuring the IP phone if required using the Aastra Web UI. 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...

  • Page 66: Configuration Server Protocol

    TFTP, FTP, HTTP. The TFTP setting is the default download protocol. You can configure the type of protocol that the IP phone uses by setting it in the configuration files, the IP phone UI, or the Aastra Web UI. Note: For DHCP to automatically populate the IP address or domain name for the TFTP server, your DHCP server must support Option 66.
  • Page 67 For 9112i/9133i: Press Set to save the changes. For 480i/480i CT: Press Done to save the changes. From the Network Settings menu, select TFTP Server, FTP Server, or HTTP Server (depending on which protocol you configured in Step 4).
  • Page 68 IP Phone Administrator Guide Configuration Server Protocol IP Phone UI Step Action Enter the IP address of the protocol server (in dotted decimal format). Use the following table to configure the applicable server. TFTP - Select TFTP. - Select Primary. - Select Primary TFTP.
  • Page 69 Action For 9112i/9133i: Press Set to save the changes. For 480i/480i CT: Press Done to save the changes. Press Done to finish configuring the configuration server protocol for the IP phone. Note: The session prompts you to restart the IP phone to apply the configuration changes.
  • Page 70 IP Phone Administrator Guide Configuration Server Protocol Aastra Web UI Step Action Select the protocol from the "Download Protocol" list box. The IP phone uses the protocol you select to download new firmware and configuration files from the configuration server. Use the following table to configure the applicable server.

  • Page 71: Advanced Network Settings

    You can set advanced network settings on the IP phone such as, Network Address Translation (NAT), Nortel NAT, Network Time Protocol (NTP) Time Servers, Virtual LAN (VLAN), and Quality of Service (QoS) using the Aastra Web UI or the configuration files.
  • Page 72 IP Phone Administrator Guide Advanced Network Settings Nortel Proxy/Registrar The phone at IP address 10.10.10.10 is configured to register with the proxy at 63.251.195.10. Because it is a Nortel proxy, the configuration must additionally include the "sip nortel nat support" and "sip nortel nat timer" settings, telling the firmware to enhance the protocols with Nortel specific content.

  • Page 73: Configuring Nortel Nat (Optional)

    SIP ping requests to the Nortel proxy. Configuring Nortel NAT (optional) You can configure Nortel NAT using the configuration files, the IP phone UI, or the Aastra Web UI. Configuration Files For specific parameters you can set in the configuration files, see Appendix A, the section, “Network...
  • Page 74 Action For 9112i/9133i: Press Change to set Yes (enable) or No (disable) for NAT on a Nortel network. For 480i/480i CT: Press Change to set Yes (enable) or No (disable) for NAT on a Nortel network. For 9112i/9133i: Press Set to save the changes.

  • Page 75: Configuring Nat Address And Port (Optional)

    Configuring NAT Address and Port (optional) You can also configure a specific NAT address and port on the IP phone using the configuration files, IP Phone UI, or Aastra Web UI. Configuration Files For specific parameters you can set in the configuration files, see Appendix A, the section, “Network...
  • Page 76 Select NAT Port. Enter the public SIP signalling port number of your NAT device. For 9112i/9133i: Press Set to save the changes. For 480i/480i CT: Press Done to save the changes. 4-20 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...
  • Page 77 Configuring the IP Phones Advanced Network Settings Aastra Web UI Step Action Click on Advanced Settings->Network->Advanced Network Settings. Enter a NAT IP address in the "NAT IP" field. Enter a NAT port in the "NAT Port" field. Click to save your settings.

  • Page 78: Virtual Lan (Optional)

    VLAN parameters. If you choose to change these parameters, you can configure them using the configuration files, the IP Phone UI, or the Aastra Web UI. The following sections describe the VLAN features you can configure on the IP phones.

  • Page 79: Type Of Service (Tos), Quality Of Service (Qos), And Diffserv Qos

    Configuring the IP Phones Advanced Network Settings Type of Service (ToS), Quality of Service (QoS), and DiffServ QoS ToS is an octet as a field in the standard IP header. It is used to classify the traffic of the different QoSs. QoS provides service differentiation between IP packets in the network.
  • Page 80 IP Phone Administrator Guide Advanced Network Settings Notes: In order for the software to successfully maintain connectivity with a network using VLAN functionality, the IP phone reboots if you modify the "tagging enabled" (VLAN enable in the Web UI), "VLAN id", or "VLAN id port 1"...
  • Page 81 Configuring the IP Phones Advanced Network Settings DSCP Range/VLAN Priority DSCP Range VLAN Priority 8-15 16-23 24-31 32-39 40-47 48-55 56-63 The following table identifies the default DSCP of protocols. Protocol Default DSCP Name Values in the ToS Field rtcp Configuring Type of Service (ToS)/DSCP (optional) Use the following procedures to configure ToS/DSCP on the IP phone.
  • Page 82 Action For 9112i/9133i: Press on the phone to enter the Options List. For 480i/480i CT: Press % on the phone to enter the Options List. Select Network. Select Type of Service. Select SIP, RTP, and/or RTCP and enter a value from 0 to 63.
  • Page 83 Configuring the IP Phones Advanced Network Settings Aastra Web UI Step Action Click on Advanced Settings->Network->Type of Service,DSCP. Choose a Protocol (SIP, RTP, and/or RTCP), and enter a value from 0 to 63. Note: If you change the ToS/DSCP setting for a Protocol, and VLAN is enabled, you will need to map the applicable priority to the Protocol setting as shown in the table “DSCP Range/VLAN Priority”...
  • Page 84 Step Action For 9112i/9133i: Press on the phone to enter the Options List. For 480i/480i CT: Press % on the phone to enter the Options List. Select Network. Select VLAN. To globally enable/disable VLAN and set priority for non-IP packets: Select VLAN Enable, and press Change to set VLAN Enable to Yes (or No to disable) Press Done to save the changes.
  • Page 85 Configuring the IP Phones Advanced Network Settings IP Phone UI Step Action Select VLAN ID and enter a value from 1 to 4094 to specify the VLAN ID of Port 0. Press Done to save the change. Select Priority. Select a VLAN Protocol (SIP, RTP, and/or RTCP). Enter a VLAN priority value from 0 to 7 for the associated Protocol.
  • Page 86 IP Phone Administrator Guide Advanced Network Settings Aastra Web UI Step Action Click on Advanced Settings->Network->VLAN. To globally enable/disable VLAN and set priority for non-IP packets: Enable VLAN by checking the VLAN Enable field check box. (Disable this field by unchecking the check box).
  • Page 87 Configuring the IP Phones Advanced Network Settings Aastra Web UI Step Action Click to save your changes. Note: The session prompts you to restart the IP phone to apply the configuration settings. Select Operation->Reset and click 41-001129-00 Rev 09, Release 1.4.1...

  • Page 88: Network Time Servers

    Network Time Protocol (NTP) is a protocol that the IP phone uses to synchronize the phone clock time with a computer (configuration server) in the network. To use NTP, you must enable it using the configuration files or the Aastra Web UI. You can specify up to three time servers in your network.
  • Page 89 Press Set to save the change. For 480i/480i CT: Press Done to save the change. Use the following procedure to enable/disable and configure the NTP Servers using the Aastra Web UI.. Aastra Web UI Step Action Click on Advanced Settings->Network->Advanced Network Settings.
  • Page 90 IP phones. You configure these features using the configuration files, the IP Phone UI, or the Aastra Web UI. The following table identifies which method of configuration applies to each feature.
  • Page 91 Step Action For 9112i/9133i: Press on the phone to enter the Options List. For 480i/480i CT: Press % on the phone to enter the Options List. Set Time and Time Format: Select Time and Date. Select Set Time. Using the keys on the keypad, enter a time to set on the IP phone.
  • Page 92 IP Phone UI Step Action For 9112i/9133i: Press Set to save the date you entered. For 480i/480i CT: Press Done to save the date you entered. Select Date Format. Select a date format from the list of options. Valid values are: •...
  • Page 93 Note: The default for Daylight Savings is Automatic. For 9112i/9133i: Press Set to save the Daylight Savings value you selected. For 480i/480i CT: Press Done save the Daylight Savings value you selected. 41-001129-00 Rev 09, Release 1.4.1 4-37 DFW Phone 972-992-4600...

  • Page 94: Session Initiation Protocol (Sip) Settings

    You configure and modify these parameters and associated values using the configuration files, the IP phone UI, or the Aastra Web UI. The Aastra Web UI and configuration file methods configure global and per-line SIP settings on the IP phone.
  • Page 95 Note: The "sip vmail" and "sip lineN vmail" parameters are configurable using the configuration files only. To configure voicemail see Chapter 5, the section, “Voicemail (480i/480i CT only)” page 5-84. Specific sets of SIP parameters are inter-dependent with each other. To prevent conflicting parameter values from being applied, per-line values always take precedence over the corresponding set of global values.
  • Page 96 IP Phone Administrator Guide Advanced Network Settings SIP Precedence Example The following example shows the SIP proxy feature and example schema for storage and parsing of the SIP configuration parameters. The following SIP configuration is assumed: # SIP network block sip proxy ip: 10.30.11.154 sip proxy port: 5060...
  • Page 97 The IP phone performs an SRV lookup when the IP address of the server is FQDN and the corresponding port is 0. For example, if the phone is configured with sip proxy ip of "ana.aastra.com", and sip proxy port of "0", the SRV lookup may return multilple servers, based on the priorities if one is selected as primary and others are selected as secondary.
  • Page 98 You can configure SIP settings using the configuration files, the IP Phone UI, or the Aastra Web UI. Note: To configure the SIP settings per-line, use the configuration files or the Aastra Web UI. (The 9112i has only one line available to configure SIP settings.) Configuration Files For specific parameters you can set in the configuration files, see Appendix A, the section, “SIP Basic,...
  • Page 99 Press % on the phone to enter the Options List. Select SIP Settings. Select Proxy Server (or Proxy IP for 480i/480i CT) and enter an IP address or fully qualified host name for the SIP proxy server. Select Proxy Port and enter a port for accessing the SIP proxy server.
  • Page 100 IP Phone Administrator Guide Advanced Network Settings Aastra Web UI Step Action For global configuration, click on Advanced Settings->Global SIP->Basic SIP Settings. 4-44 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...
  • Page 101 Configuring the IP Phones Advanced Network Settings Aastra Web UI Step Action Or, for per-line configuration, click on Advanced Settings->Line N (1-9). To configure SIP authentication settings: In the "Screen Name" field, enter the screen name that displays on the idle screen.
  • Page 102 IP Phone Administrator Guide Advanced Network Settings Aastra Web UI Step Action To configure SIP network settings: In the "Proxy Server" field, enter an IP address or fully qualified host name of the SIP proxy server. In the "Proxy Port" field, enter a port number for accessing the SIP proxy server.
  • Page 103 Configuring the IP Phones Advanced Network Settings Configuring Advanced SIP Settings (optional) Using the configuration files or the Aastra Web UI, you can set more advanced SIP settings on the IP phone such as: Configuration File Parameters Aastra Web UI Parameters...
  • Page 104 IP Phone Administrator Guide Advanced Network Settings Aastra Web UI Step Action Click on Advanced Settings->Global SIP->Advanced SIP Settings. Enable the "Explicit MWI Subscription" field by checking the check box. (Disable this field by unchecking the check box). If the IP phone has a message waiting subscription with the Service Provider, a Message Waiting Indicator (MWI) (LED or display icon) tells the user there is a message on the IP Phone.
  • Page 105 Configuring the IP Phones Advanced Network Settings Aastra Web UI Step Action In the "Timer 1 and Timer 2" fields, enter a time, in milliseconds, that will apply to an IP phone session. These timers are SIP transaction layer timers defined in RFC 3261.

  • Page 106: Real-Time Transport Protocol (Rtp) Settings

    RTCP control is on the next port up. A phone call therefore uses one pair of ports for each media stream. On the Aastra IP phone, the initial port used as the starting point for RTP/RTCP port allocation can be configured using "RTP Port Base". The default RTP base port on the IP phones is 3000.
  • Page 107 Configuring the IP Phones Advanced Network Settings Aastra IP phones support the International Telecommunications Union (ITU) transmission standards for the following CODECs: • Waveform CODECs: G.711 pulse code modulation (PCM) with a-Law or u-Law companding • Parametric CODEC: G.729a conjugate structure - algebraic code excited linear prediction (CS_ACELP).
  • Page 108 18 for G.729a ptime (in milliseconds) 5, 10, 15, 20..90 silsupp You can specify a customized Codec preference list on a global-basis using the configuration files or the Aastra Web UI. 4-52 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...
  • Page 109 Out-of-Band DTMF The IP phones support out-of-band Dual-Tone Multifrequency (DTMF) mode according to RFC2833. In the Aastra Web UI, you can enable or disable this feature as required. The "out-of-band DTMF" is enabled by default. In out-of-band mode, the DTMF audio is automatically clamped (muted) and DTMF digits are not sent in the RTP packets.
  • Page 110 For 9112i/9133i: Press on the phone to enter the Options List. For 480i/480i CT: Press % on the phone to enter the Options List. Select SIP Settings. Select RTP Port Base to change the RTP port base setting. Default is 3000.
  • Page 111 Configuring the IP Phones Advanced Network Settings Aastra Web UI Step Action Click on Advanced Settings->Global SIP->RTP Settings. Enter an RTP Port Base in the RTP Port field. Default is 3000. Enable the "Basic Codecs (G.711 u-Law, G.711 a-Law, G.729)" field by checking the check box.
  • Page 112 IP Phone Administrator Guide Advanced Network Settings Aastra Web UI Step Action Enter a "Customized Codec Preference List" which all payload=8;ptime=10; silsupp=on; payload=0;ptime=10; silsupp=off Valid values are: Attribute Value payload 0 for G.711 u-Law 8 for G.711 a-Law 18 for G.729a ptime (in milliseconds) 5, 10, 15, 20..90...

  • Page 113: Operational Features

    Softkeys/Programmable Keys page 5-12 Suppressing DTMF Playback page 5-24 Busy Lamp Field (BLF) (480i/480i CT/9133i only) page 5-26 Directed Call Pickup (BLF Call Interception) (480i/480i CT/9133i) page 5-32 BLF Subscription Period (480i/480i CT/9133i) page 5-35 Do Not Disturb (DND) page 5-37...
  • Page 114 5-63 Callers List page 5-70 Missed Calls Indicator page 5-74 Directory List page 5-76 Voicemail (480i/480i CT only) page 5-84 XML Customized Services page 5-87 SIP Local Dial Plan page 5-107 Incoming/Outgoing Intercom with Auto-Answer (Intercom applicable to page 5-112...

  • Page 115: Description

    Also allows you to se the Redial and Conf keys as speeddials. Softkeys/Programmable Keys Allows you to configure softkeys (480i/480i CT) or programmable keys (9112i/9133i) with specific settings such as speeddial, do not disturb, or BLF. Suppressing DTMF Playback...
  • Page 116 Allows you to press the Icom button and enter the number you Auto-Answer want to call to initiate an Intercom call. The call can be (Intercom applicable to 480i/480i CT controlled either locally (phone-side) or by the SIP server only) (server-side).
  • Page 117 Allows you to set the language to display on the IP phone UI. For the 480i/9133i/9112i, valid languages are English (default), French, Spanish, German, and Italian. For the 480i CT, valid languages are English (default), French, and Spanish. The following paragraphs describe each of these features.

  • Page 118: User Passwords

    Operational Features User Passwords A user or an administrator can change the user passwords on the phone using the configuration files, the IP phone UI, or the Aastra Web UI. Use the following procedures to change the user password. Procedures...
  • Page 119 Operational Features Operational Features Aastra Web UI Click on Operation->User Password. In the "Current Password" field, enter the current user password. In the "New Password" field, enter the new user password. In the "Confirm Password" field, enter the new user password again.

  • Page 120: Administrator Passwords

    IP Phone Administrator Guide Operational Features Administrator Passwords An administrator can change the administrator passwords on the phone using the configuration files only. An administrator can also assign a password for using the Options key on the IP phone. You turn this feature on and off by entering the "options password enabled"...

  • Page 121: Hard Keys

    Operational Features Operational Features Hard Keys There are hard keys on your phone, such as Hold, Redial, Xfer, Icom and Conf (Hold and Icom not available on the 9112i and 9133i) that are configured for specific call-handling features. (See the product-specific User Guide for more information about the hard key functions).
  • Page 122 You can configure this feature using the configuration files or the Aastra Web UI. Note: If you configure the Redial and Conf keys for speeddialing on the 480i CT Base Station, the Redial and Conf keys on the 480i CT handset retain their original functionality. The Redial and Conf keys on the handset are not configured for speeddial.
  • Page 123 Operational Features Operational Features Aastra Web UI Click on Basic Settings->Preferences. In the Key Mapping section, enter a number in the "Map Redial Key To" field, that the IP phone will use to speedial when the Redial key is pressed.

  • Page 124: Softkeys/Programmable Keys

    480i and 480i CT, when a programmable key is pressed on the 9112i and 9133i, or a feature key is pressed on the 480i CT handset. The IP phone generates flash events only when a call is connected and there is an active RTP stream (for example, when the call is not on hold).
  • Page 125 5-58.) • empty (480i, 480i CT) - Indicates the softkey is configured to force a blank entry on the IP phone display for a specific softkey. The soft keys are added in order (from softkey1 to softkey20) after any hard-coded keys have been added.
  • Page 126 You can enable or disable the softkey states using the configuration files or the Aastra Web UI. In the Aastra Web UI, the operational states for each softkey display enabled. To disable a state, you uncheck the box for that operational state.

  • Page 127: Configuration Example

    (not used) Key 5 Speeddial displays for softkey6. Connected displays as applicable. Softkeys and programmable keys are configurable using the Aastra Web UI or the configuration files. 41-001129-00 Rev 09, Release 1.4.1 5-15 DFW Phone 972-992-4600...
  • Page 128 Handset IP Phone Softkeys Programmable Lines Keys Model Available Keys Available Available Available 480i 480i CT 9112i 9133i 5-16 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...
  • Page 129 For specific parameters you can set in the configuration files, see Appendix A, the section, “Softkey/Programmable Key Parameters” page A-93. Aastra Web UI For the 480i/480i CT: Click on Operation->Softkeys and XML. 41-001129-00 Rev 09, Release 1.4.1 5-17 DFW Phone 972-992-4600...
  • Page 130 IP Phone Administrator Guide Operational Features Aastra Web UI For the 9112i/9133i: Click on Operation->Programmable Keys. 9112i Screen Note: Only two programmable keys are available on the 9112i. 9133i Screen In the "Type" field, select the type of softkey or programmable key you want to configure.
  • Page 131 In the "Value" field, enter a value to associate with the softkey or programmable key. For example, for a speeddial value, you can enter *1. For the 480i/480i CT and 9133i, in the "Line" field, select the line for which you want to associate the softkey or programmable key.
  • Page 132 Operational Features 480i Cordless (CT) Feature Keys In addition to the softkeys on the 480i CT, this phone also has handset keys you can configure with specific features. You can use the Aastra Web UI to configure the handset keys.
  • Page 133 Operational Features Operational Features Feature Key Programming Guidelines The following are guidelines to use when programming the feature keys on the handset: • All handsets paired with the same Base Station have the same programmed functions since the web interface applies the functions to all the handsets paired with that base.
  • Page 134 Operational Features Programming Feature Keys You can program up to 15 feature keys on the 480i CT IP phone using the Aastra Web UI. Use the following procedure to program the feature keys on your 480i CT Base Station and all paired handsets.
  • Page 135 The key programming information is sent to the 480i Base Station and to all the cordless handsets associated with that Base Station. Any key programmed to "None" does not appear in the handset’s list.

  • Page 136: Suppressing Dtmf Playback

    DTMF playback suppression is disabled by default. Suppressing DTMF playback can be configured using the Aastra Web UI and the configuration files. Configuring Suppression of DTMF Playback Use the following procedures to configure the suppression of DTMF playback on the IP phone.
  • Page 137 Operational Features Operational Features Aastra Web UI Click on Basic Settings->Preferences->General. Enable the "Suppress DTMF Playback" field by checking the check box. (Disable this field by unchecking the box). Default is disabled. Click to save your settings. You must restart your IP phone for the changes to take affect.

  • Page 138: Busy Lamp Field (Blf) (480I/480I Ct/9133I Only)

    BLF Setting (For use with Asterisk) On the 480i and 480i CT, the busy and idle indicators show on the IP phone screen display next to the softkey programmed for BLF functionality. When the monitored user is idle, an icon with the handset on-hook shows next to the BLF softkey.
  • Page 139 A receptionist has a 480i running Broadsoft firmware that subscribes to a list of extensions from the BroadWorks Application Server. Each monitored extension in the list shows up individually on the 480i screen next to a softkey button. The softkey icons on the screen change depending on the state of the extensions.
  • Page 140 “Monitored Users List” on the Busy Lamp Field service page and also enter in a list name for the monitored users BLF list on the same page. Changes to the “Monitored Users List” are dynamic and the Aastra IP phones are automatically updated without requiring a restart.
  • Page 141 To set BLF or BLF\List in the configuration files, see Appendix A, the section, “Softkey/Programmable Key Parameters” page A-93. Aastra Web UI On the 480i/480iCT: Click on Operation->Softkeys and XML. Note: You can configure up to 20 softkeys on the 480i/480i CT. 41-001129-00 Rev 09, Release 1.4.1 5-29 DFW Phone 972-992-4600...
  • Page 142 For the 480i, 480i CT, or 9133i, in the "Type" field, select "BLF" (Asterisk) or "BLF\List" (BroadSoft BroadWorks). For the 480i/480i CT, in the "Label" field, enter the name of the person who’s extension you are monitoring (Asterisk only). Note: If BLF\List type is selected, no label value is required. The BroadWorks BLF List name is configured in the "BLF List URI"...
  • Page 143 Busy Lamp field page for your particular user. For example, my480i-blf-list@as.broadworks.com. Note: The value of the BLF\List URI parameter must match the list name configured. Otherwise, no values display on the 480i screen and the feature is disabled. Click to save your changes.

  • Page 144: Directed Call Pickup (Blf Call Interception) (480I/480I Ct/9133I)

    Directed Call Pickup (BLF Call Interception) (480i/480i CT/9133i) Directed call pickup is an enhancement to the existing BLF feature found in 480i/ 480i CT and 9133i. The existing BLF feature allows a softkey/programmable key to monitor the states of an extension. The extension states can be one of three states: "busy", "ringing"...
  • Page 145 Use the following procedure to enable or disable the Directed Call Pickup feature on the IP phone. Configuration Files To enable/disable Directed Call Pickup on the IP phone (480i/480i CT/9133i) using the configuration files, see Appendix A, the section, “Directed Call Pickup (BLF Call Interception) Settings”...
  • Page 146 IP Phone Administrator Guide Operational Features Aastra Web UI Enable the "Play a Ring Splash" field by checking the check box. (Disable this field by unchecking the box). Default is disabled. The IP phone plays a short "call waiting tone" when there is an incoming call on the BLF monitored extension.

  • Page 147: Blf Subscription Period (480I/480I Ct/9133I)

    IP phone. If you enter a value lower than 120 for this parameter, the default value (3600) will be used by the IP phone. You can configure this feature using the configuration files or the Aastra Web UI. Configuring BLF Subscription Period Use the following procedures to configure the BLF subscription period on the IP phone.
  • Page 148 IP Phone Administrator Guide Operational Features Aastra Web UI Click on Advanced Settings->Global SIP->Advanced SIP Settings. Enter a value, in seconds, from 120 (2 min) to 3600 (1 hour) in the "BLF Subscription Period" field. Click to save your changes.

  • Page 149: Do Not Disturb (Dnd)

    Do Not Disturb (DND) The IP phones have a feature you can enable called "Do not Disturb (DND). You can configure DND on softkeys and programmable keys using the Aastra Web UI or the configuration files. If DND is configured on the phone, the softkey or programmable key switches DND ON and OFF.
  • Page 150 IP Phone Administrator Guide Operational Features Aastra Web UI Click on Operation->Programmable Keys. Select a hard key to configure. In the "Type" field, select "do not disturb". Note: You do not need to set the "Value" for DND. DND is applied to the hard key only.

  • Page 151: Bridged Line Appearance (Bla) (480I/480I Ct/9133I Only)

    NOTIFY messages to report the status of a dialog. BLA DA can be configured on a global basis or on a per-line basis on the IP phones using the Aastra Web UI or the configuration files. 41-001129-00 Rev 09, Release 1.4.1...
  • Page 152 You configure BLA on a global basis in the configuration files using the following parameters: sip mode sip user name sip bla number You configure BLA on a global basis in the Aastra Web UI using the following fields at Advanced Settings->Global SIP->Basic SIP Settings: • Line Mode •...
  • Page 153 You configure BLA on a per-line basis in the configuration files using the following parameters: sip lineN mode sip lineN username sip lineN bla number You configure BLA on a per-line basis in the Aastra Web UI using the following fields at Advanced Settings->Line 1 thru Line 9: • Line Mode •...
  • Page 154 IP Phone Administrator Guide Operational Features For ININ Server When configuring the BLA feature on an ININ server, the value set for the sip lineN bla number parameter shall be the same value set for the sip lineN user name parameter without the incremented digit added to the phone #. For example, if the sip lineN user name for the first phone is 10101, and the sip lineN user name for the second phone is 10102, etc., you would configure BLA on a per-line basis for the ININ server as follows:...
  • Page 155 Operational Features Operational Features Aastra Web UI For global configuration of BLA: Click on Advanced Settings->Global SIP->Basic SIP Authentication Settings. 41-001129-00 Rev 09, Release 1.4.1 5-43 DFW Phone 972-992-4600...
  • Page 156 IP Phone Administrator Guide Operational Features Aastra Web UI For per-line configuration of BLA: Click on Advanced Settings->Line N (1-9). In the "Line Mode" field, select the BLA option. In the "Phone Number" field, enter the phone number of the IP phone.

  • Page 157: Park Calls/Pick Up Parked Calls

    BLA group. Park Calls/Pick Up Parked Calls The IP phones (including the 480i CT handset) have a park and pickup call feature that allows you to park a call and pickup a call when required. There are two ways a user or adminstrator can configure this feature: •...
  • Page 158 Note: On the 480i CT handset, pressing Ï displays the "Park" and "Pickup" labels. The values you enter in the Aastra Web UI for the Park/Pickup call feature are dependant on your type of server. The following table provides the values you enter for the "Park Call"...
  • Page 159 (480i/480i CT only) Use the following procedure to configure the Park/Pickup call feature using the static configuration method. Note: Aastra recommends you configure either the static or the programmable configuration, but not both. Aastra Web UI Click on Basic Settings->Preferences->General.
  • Page 160 The programmable method of configuration creates park and pickup softkeys or programmable keys that you can configure on the IP phones (480i/480i CT/9112i/ 9133i). For the 480i/480i CT you can set a softkey as "Park" or "Pickup" and then: • specify a customized label to display on the Phone UI •...
  • Page 161 Operational Features Operational Features • On the 480i CT, the customized labels apply to the base unit only. On the 480i CT handset, pressing Ï displays the default labels of "Park" and "Pickup". Notes: On the 480i CT, the customized labels apply to the base unit only. On the 480i CT handset, pressing Ï...
  • Page 162 In the configuration files, you configure Park/Pickup using the softkey parameters. You must specify the"softkeyN value" and "prgkeyN value" as <server type;server-specific value>. The following examples show Park/Pickup configurations using specific servers. Model 480i/480 CT Examples Server Park Configuration Pickup Configuration...
  • Page 163 Operational Features Operational Features Model 9133i Examples Server Park Configuration Pickup Configuration Asterisk prgkeyN type: park prgkeyN type: pickup prgkeyN value: asterisk;700 prgkeyN value: asterisk;700 prgkeyN line: 1 prgkeyN line: 1 Sylantro prgkeyN type: park prgkeyN type: pickup prgkeyN value: sylantro;*98 prgkeyN value: sylantro;*99 prgkeyN line: 1 prgkeyN line: 1...
  • Page 164 480i handset uses the first programmable configuration. For example, if line 1 and line 6 are configured for park, the 480i CT handset uses the configuration set for line 1 to park a call.
  • Page 165 Operational Features Operational Features Aastra Web UI For the 480i/480i CT: Click on Operation->Softkeys and XML. Pick a softkey to configure for Parking a call. In the "Type" field, select Park. In the "Label" field, enter a label for the Park softkey.
  • Page 166 Click on Operation->Reset. In the "Restart Phone" field click to restart the IP phone and apply the changes. For the 480i CT Handset: Click on Operation->Handset Keys. Pick a handset key to configure for parking a call. In the "Key Function" field, select Park.
  • Page 167 Operational Features Operational Features Aastra Web UI Pick another handset key to configure for picking up a call. In the "Key Function" field, select Pickup. Click to save your changes. You must restart your IP phone for the changes to take affect.
  • Page 168 IP Phone Administrator Guide Operational Features Aastra Web UI In the "Type" field, select Park. In the "Value" field, enter the approriate value based on the server in your network. Note: For values to enter in this field, see the table “Park/Pickup Call Server Configuration Values”...
  • Page 169 Operational Features Operational Features Using the Park Call/Pickup Parked Call Feature Use the following procedures on the IP phones to park a call and pick up a parked call. IP Phone UI Step Action Parking a Call While on a live call, press the "Park" softkey. Perform the following for your specific server: For Asterisk Server: - Server announces the...

  • Page 170: Last Call Return (Lcr) (Sylantro Servers Only)

    This feature is for Sylantro servers only. You can configure the “lcr” softkey feature via the configuration files or the Aastra Web UI. How it works you configure "lcr" on a softkey or programmable key, and a call comes...
  • Page 171 Operational Features Operational Features Aastra Web UI For the 480i/480i CT: Click on Operation->Softkeys and XML. Pick a softkey to configure for Last Call Return. In the "Type" field, select lcr. In the "Line" field, select a line for which to apply the last call return configuration.
  • Page 172 IP Phone Administrator Guide Operational Features Aastra Web UI For the 480i CT Handset: Click on Operation->Handset Keys. Pick a handset key to configure for Last Call Return. In the "Key Function" field, select lcr. Click to save your changes.
  • Page 173 Operational Features Operational Features Aastra Web UI For the 9112i/9133i: Click on Operation->Programmable Keys. 9112i Screen 9133i Screen Pick a hard key to configure for Last Call Return. In the "Type" field, select lcr. For the 9133i: In the "Line" field, select a line for which to apply the lcr configuration.
  • Page 174 IP Phone Administrator Guide Operational Features Aastra Web UI Click on Operation->Reset. In the "Restart Phone" field click to restart the IP phone and apply the changes. 5-62 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...

  • Page 175: Call Forwarding

    Call forwarding is disabled by default. You can configure call forwarding on a phone-wide basis or on multi-line phones (480i/480i CT/9133i), on a per-line basis. If you have configured call forwarding on an individual line, then the settings for this line are used;...
  • Page 176 Enabling/Disabling the Ability to Configure Call Forwarding Using the configuration files, you can enable or disable the ability to configure Call Forwarding in the Aastra Web UI and the IP Phone UI. You use the following parameter to enable/disable this feature: •...

  • Page 177: Configuring Call Forwarding

    You can set the phone-wide call forward settings using the IP phone UI or the Aastra Web UI. However, you must use the Aastra Web UI to set the per-line call forward settings. The per-line settings override the settings for global call forwarding.
  • Page 178 Action For 9112i/9133i: In the “Cfwd Mode” field, enter the mode that you want to set on your phones. For 480i/480i CT: In the “Mode” field, enter the mode that you want to set on your phones. Valid modes are: •...
  • Page 179 Operational Features Operational Features Aastra Web UI Click on Basic Settings->Call Forward. 480i/480i CT/9133i Screens 9112i Screen 41-001129-00 Rev 09, Release 1.4.1 5-67 DFW Phone 972-992-4600...
  • Page 180 • Busy No Answer Note: To disable call forwarding in the Aastra Web UI, set the mode to OFF and remove the phone number in the "Number" field. In the "Number" field, enter the destination number for which you want your calls to be call forwarded.
  • Page 181 Operational Features Operational Features Aastra Web UI In the "Forward Number" field, enter the destination number for which you want your calls on this line to be call forwarded. In the "Number of Rings" field, select the number of rings you want this line to ring before the call is forwarded.

  • Page 182: Callers List

    IP phone UI. You can also directly dial from a displayed line item in the Callers List. You can download the Callers List to your PC for viewing using the Aastra Web UI. When you download the Callers List, the phone stores the callerlist.csv file to your computer in comma-separated value (CSV) format.

  • Page 183: Using The Callers List

    0, the Callers List can be accessed by all users. If this parameter is set to 1, the IP phone does not save any caller information to the Caller List. For 480i and 480i CT phones, the "Caller List" option on the IP phone is removed from the Services menu, and the Caller List key is ignored if pressed by the user.
  • Page 184 IP Phone Administrator Guide Operational Features IP Phone UI Step Action To delete all entries in the Callers list, press the 3 Delete softkey at the "Callers List" header. To delete a line item from the Callers List, select the line item you want to delete and press the 3 Delete softkey.
  • Page 185 Operational Features Operational Features Downloading the Callers List Use the following procedure to download the Callers List using the Aastra Web Aastra Web UI Click on Operation->Directory. In the Callers List field, click on A “File Download” message displays. Click Enter the location on your computer where you want to download the Callers List and click The callerslist.csv file downloads to your computer.

  • Page 186: Missed Calls Indicator

    IP Phone Administrator Guide Operational Features Missed Calls Indicator The IP phone has a "missed calls" indicator that increments the number of missed calls to the phone. This feature is accessible from the IP phone UI only. You can enable and disable the Missed Calls Indicator feature using the configuration files.
  • Page 187 Once you display the Callers List, the "<number> New Calls" indicator clears. IP Phone UI Step Action For the 480i/480i CT: Press on the phone to display the Services menu. Press the key to enter the Callers List directly. (skip to step 3) From the Services menu, select "Callers List".

  • Page 188: Directory List

    Directory List using the IP phone UI. You can also directly dial a number from the Directory List. For the 480i CT, a public and private softkey can be used at a Directory List line item. The Private key toggles a number in the Directory List to private. The Public key allows a number in the Directory List to be sent to the handsets.
  • Page 189 0, the Directory List can be accessed by all users. If this parameter is set to 1, the Directory List does not display on the IP phone and the Directory key is disabled. On the 480i and 480i CT the "Directory" option is also removed from the "Services" menu.
  • Page 190 IP Phone Administrator Guide Operational Features Server to IP Phone Download You can populate your IP phone Directory List with server directory files. To activate this feature, you need to add the following parameters to the configuration files: • directory 1: company_directory •...
  • Page 191 Maximum length of a URI 45 characters Maximum number directory entries in the NVRAM 200 entries Maximum number directory entries in the NVRAM 50 entries with the "public" attribute (480i CT only) 41-001129-00 Rev 09, Release 1.4.1 5-79 DFW Phone 972-992-4600...
  • Page 192 Note: The entry is set to Private by default. If the entry is made Public, the entry is sent to the handsets. A 480i CT accepts a maximum of 50 entries with the public attribute. To edit an entry, use the Change softkey.
  • Page 193 Operational Features Operational Features IP Phone UI Step Action To exit the Directory List, press the Quit softkey. For the 9112i/9133i: Press 3 Directory on the phone to enter the Directory List. Note: If no key is pressed within 3 seconds, the phone prompts you to press the first letter in the name of the required directory entry.
  • Page 194 A-63. Downloading from the IP Phone to the Server You can use the Aastra Web UI to download the Directory List from the IP phone to the configuration server. Note: You must use TFTP to download the Directory List.
  • Page 195 Operational Features Operational Features Use the following procedure to configure the download. Aastra Web UI Click on Operation->Directory. In the Directory List field, click on A “File Download” message displays. Click Enter the location on your computer where you want to download the Directory List and click The directorylist.csv file downloads to your computer.

  • Page 196: Voicemail (480I/480I Ct Only)

    Operational Features Voicemail (480i/480i CT only) The Voicemail feature on the 480i/480i CT IP phones allow you to configure lines with phone numbers so the phone can dial out to connect to a voicemail server. You associcate the Voicemail numbers with the phone numbers configured on each line (1 - 9 lines).
  • Page 197 Operational Features Operational Features You can enter up to 9 Voicemail numbers associated with each of the 9 lines on the phone. For example: sip line1 vmail: *97 sip line2 vmail: *95 Note: In the above example, the user would dial *97 to access the voicemail account for line 1, and *95 to access the voicemail account for line 2.
  • Page 198 Using Voicemail (480i480i CT only) Use the following procedure to access and use voicemail. IP Phone UI Step Action For the 480i/480i CT: Press on the phone to display the Services menu. From the Services menu, select "Voicemail". Use the to scroll through the line items in the Voicemail List.

  • Page 199: Xml Customized Services

    Operational Features Operational Features XML Customized Services Extensible Markup Language (XML) is a markup language much like HTML. HTML was designed to display data and to focus on how data looks. XML was designed to describe data and to focus on what data is. The following are characteristics of XML: •...
  • Page 200 AastraIPPhoneStatus object appears in the status message, then the default behavior is no beep is heard when the object arrives to the phone. The value set in the configuration files and Aastra Web UI override the attribute you specify for the AastraIPPhoneStatus object.
  • Page 201 Users can access XML applications via the "Services" menu on the 480i/480i CT and via a programmable key on the 9112i/9133i IP phones. The phone performs an HTTP GET on the URI configured in the Aastra Web UI or configuation files. You configure the following parameters for object requests: •...
  • Page 202 It does so by checking the IP address or host name of the requesting host against a list of trusted hosts (or domain names) configured via the Aastra Web UI (parameter called XML Push Server List) or the configuration files (parameter called xml application post list).
  • Page 203 Configuring for XML on the IP Phone After creating an XML application, an administrator can configure the IP phone to use the application using the configuration files or the Aastra Web UI. Configuration Files For specific parameters you can set in the configuration files, see Appendix A, the section, “XML Settings”...
  • Page 204 " in the applicable field. http://172.16.96.63/aastra/internet.php In the "XML Application Title" field, enter the name of the XML application that you want to display on the IP phone Services Menu. In the illustration above, the XML Application Title is "Aastra Telecom". 5-92 41-001129-00 Rev 09, Release 1.4.1...
  • Page 205 Operational Features Operational Features Aastra Web UI Click to save your changes. The XML application is applied to the IP phone immediately. When the XML application is pushed to the phone via an HTTP POST, a host IP address or domain name server is required.
  • Page 206 IP Phone Administrator Guide Operational Features Aastra Web UI For the 9112i/9133i Click on Operation->Programmable Keys. 9112i Screen. 9133i Screen For the 9112i, select a key from keys 1 through2. For the 9133i, select a key from keys 1 through 7..
  • Page 207 Operational Features Operational Features Aastra Web UI In the "Type" field, select XML from the list box. In the "Value" field, enter the IP address or qualified domain name of the XML application. Click to save your changes. The XML application is applied to the IP phone immediately.
  • Page 208 Use the following procedure to use the XML feature on the IP phone. IP Phone UI Step Action For the 480i/480i CT: Press on the phone to display the Services menu. Select "Custom Features". Use the to scroll through the line items in a menu-driven and directory "Custom...
  • Page 209 Operational Features Operational Features IP Phone UI Step Action For the 9112i/9133i Press the programmable key configured on the phone for XML.. A "Custom Features" screen displays. Use the to scroll through the customized features. For menu and directory services, select a service to display the information for that customized service.
  • Page 210 IP Phone Administrator Guide Operational Features The following table identifies the configurable action URI parameters in the configuration files and the Aastra Web UI. This table also identifies the variables that apply to specific parameters. Configuration File Aastra Web UI Parameters at...
  • Page 211 Note: If the phone can’t find the Action URI you specify, it returns a “NULL” response. For example, http://10.50.10.140/outgoing.pl?number= You can configure this feature via the configuration files or the Aastra Web UI. Configuring XML Action URIs Use the following procedures to configure XML Action URIs using the configuration files or the Aastra Web UI.
  • Page 212 IP Phone Administrator Guide Operational Features Aastra Web UI Click on Advanced Settings->Action URI. Enter an XML URI for a startup event in the “Startup” field. For example: http://10.50.10.140/startup This parameter pecifies the URI for which the phone executes a GET on when a startup event occurs.
  • Page 213 Operational Features Operational Features Aastra Web UI Enter an XML URI for an incoming call event in the “Incoming Call” field. For example: http://10.50.10.140/incoming.php?number=$$REMOTENUMBER$$ This parameter pecifies the URI for which the phone executes a GET on when an incoming call event occurs.
  • Page 214 XML softkey URIs that are bound when the key is pressed. These variables are the same as those used in the Action URIs. When an administrator enters an XML softkey URI either via the Aastra Web UI or the configuration files, they can specify the following variables: •...
  • Page 215 Operational Features Configuring XML Softkey URIs Use the following procedures to configure XML Softkey URIs using the configuration files or the Aastra Web UI. Configuration Files For specific parameters you can set in the configuration files, see Appendix A, the section, “Softkey/Programmable Key Parameters”...
  • Page 216 IP Phone Administrator Guide Operational Features Aastra Web UI In the "Type" field, select XML from the list box. In the "Label" field, enter a label that displays on the IP phone for the XML softkey. For example, "aastra". In the "Value" field, enter the URI that the phone performs a GET on when the key is pressed. For example: http://10.50.10.140/script.pl?name=$$SIPUSERNAME$$...
  • Page 217 Operational Features Operational Features Aastra Web UI For the 9112i/9133i: Click on Operation->Programmable Keys. 9112i Screen. 9133i Screen 41-001129-00 Rev 09, Release 1.4.1 5-105 DFW Phone 972-992-4600...
  • Page 218 IP Phone Administrator Guide Operational Features Aastra Web UI On the 9112i, select a key from keys 1 through 2. On the 9133i, select a key from keys 1 through 7. In the "Type" field, select XML from the list box.

  • Page 219: Sip Local Dial Plan

    The IP phones have local dial plan capacity. You configure the SIP Local Dial Plan using the Aastra Web UI or the configuration files. The IP phone SIP local dial plan available symbols are as follows: Symbol...

  • Page 220: Prefix Dialing

    You can enable this feature by adding a prepend digit(s) to the end of the Local Dial Plan parameter string in the configuration files or the Aastra Web UI at Basic Settings->Preferences->General. For example, if you add a prepend map of “[2-9]XXXXXXXXX,91”, the IP phone adds the digits “91”...
  • Page 221 (#)) the phone waits 4 or 5 seconds after you pick up the handset or press a key to make a call. You can configure the dial plan terminator using Aastra Web UI or the configuration files. 41-001129-00 Rev 09, Release 1.4.1...
  • Page 222 Configuring the SIP Local Dial Plan Use the following procedures to configure the SIP Local Dial Plan using the configuration files or the Aastra Web UI. Configuration Files For specific parameters you can set in the configuration files, see Appendix A, the section, “SIP Local Dial...
  • Page 223 Operational Features Operational Features Aastra Web UI Click on Operation->Reset. In the "Restart Phone" field click to restart the IP phone and apply the dial plan to the IP phone. Optional for all models: In addition to configuring the dial plan and dial plan terminator above, you can also configure names that are displayed on the idle screen rather than the user name and phone number, respectively.

  • Page 224: Incoming/Outgoing Intercom With Auto-Answer (Intercom Applicable To 480I/480I Ct Only)

    (server-side). Note: Auto-answer is applicable to all IP phone models, but the Intercom feature is applicable to the 480i and 480i CT only. Outgoing Intercom Calls On outgoing intercom calls, an available unused line is found when the Icom button is pressed.
  • Page 225 Configuring Intercom Calls and Auto-Answer You can configure the Intercom feature and auto-anaswer using the configuration files or the Aastra Web UI. Note: An administrator can configure the incoming and outgoing Intercom feature. A user can configure the incoming Intercom feature only.
  • Page 226 IP Phone Administrator Guide Operational Features Aastra Web UI Select an Intercom type for outgoing Intercom calls from the Type list box. Valid values are Phone-Side, Server-Side, Off. Default is Off. If Server-Side is selected, enter a prefix to add to the phone number in the "Prefix Code" field.
  • Page 227 Operational Features Operational Features Aastra Web UI The "Microphone Mute" field is enabled by default. The microphone is muted on the IP phone for Intercom calls made by the originating caller. To disable this field, uncheck the box. The "Auto-Answer" field is enabled by default. The automatic answering feature is turned on for the IP phone for answering Intercom calls.

  • Page 228: Audio Transmit And Receive Gain Adjustments

    • audio mode The default setting for these parameters is 0 (zero). Note: Aastra Telecom recommends you leave the default of 0 (zero) as the settings for these parameters. The following table describes each parameter. Parameter Description...
  • Page 229 Operational Features Operational Features Parameter Description Handsfree tx gain The increased (+db) or decreased (-db) amount of signal transmitted from the base microphone to the far-end party. Audio mode Allows you to configure how the d/f key (handsfree key) works. Audio mode has 4 options: 0 (Speaker) - Calls can be made or received using the handset or handsfree speakerphone and can be switched between the two modes by...

  • Page 230: Ring Tones And Tone Sets

    IP Phone Administrator Guide Operational Features Ring Tones and Tone Sets You can configure ring tones and ring tone sets on the IP phones. Ring Tones There are several distinct ring tones a user or administrator can select from to set on the IP phones.
  • Page 231 Operational Features Operational Features Aastra Web UI Global: Global: Tone 1 Tone 1 Tone 2 Tone 3 Tone 4 Tone 5 Silent Per-Line: Per-Line: Global Global Tone 1 Tone 2 41-001129-00 Rev 09, Release 1.4.1 5-119 DFW Phone 972-992-4600...
  • Page 232 - congestion tones - call waiting tone - ring cadence pattern You configure ring tones and tone sets using the Aastra Web UI, IP Phone UI, or configuration files. However, when using the IP phone UI, you can set global configuration only.
  • Page 233 For global configuration only: For 9112i/9133i: Press on the phone to enter the Options List. For 480i/480i CT: Press % on the phone to enter the Options List. Select Tones. Select Set Ring Tone. Select the type of ring tone (Tone 1 through Tone 5, or Silent).
  • Page 234 Valid values are Australia, Europe, France, Germany, Italy, UK, and US. Default is US. For 9112i/9133i: Press Set. For 480i/480i CT: Press Done. The ring tone and tone set you select is immediately applied to the IP phone. Aastra Web UI Click on Basic Settings->Preferences.
  • Page 235 Operational Features Operational Features Aastra Web UI For per-line configuration: In the "Ring Tone" section, select a line for which you want to set ring tone. Select a value from the "LineN" field Note: See the “Ring Tone Settings Table”...

  • Page 236: Priority Alerting

    You can enable or disable priority alerting on the IP phone for the Asterisk, Broadworks, and Sylantro servers using the configuration files and the Aastra Web UI. Configuration of priority alerting is on a global-basis only.
  • Page 237 When the ring tone keywords appear in an "Alert-Info" header from a Sylantro server, the keyword is mapped to the ring tone pattern based on the configuration you set in the Aastra Web UI or the configuration files. Ring Tone Patterns In IP Telephony, different ringing patterns have different frequencies and cadences.
  • Page 238 IP Phone Administrator Guide Operational Features If you enable priority alerting when using a Sylantro server, you can specify the Bellcore tone to be used for the following configurable criteria: Ring Tone Pattern (Sylantro Servers) Call criteria Bellcore tones for each call criteria alert-acd (auto call distribution) Normal ringing (default) alert-community-1...
  • Page 239 Operational Features Operational Features The following table identifies the different Bellcore ring tone patterns and cadences. Minimum Nominal Maximum Pattern Duration Duration Duration Bellcore Tone Pattern Cadence (ms) (ms) (ms) (Standard) Ringing 2s On 1800 2000 2200 Silent 4s Off 3600 4000 4400...
  • Page 240 Ring Tone Pattern (Asterisk/ Broadworks Servers) page 125. For Sylantro servers, call waiting tones are specified by the Bellcore tones you configure in the Aastra Web UI or the configuration files. See the table Ring Tone Pattern (Sylantro Servers) page 126.
  • Page 241 For specific parameters you can set in the configuration files for priority alerting, see Appendix A, the section, “Priority Alert Settings” page A-75. Aastra Web UI Click on Basic Settings->Preferences. In the "Priority Alerting Settings" section, enable the "Enable Priority Alerting" field by checking the check box. (Disable this field by unchecking the box).
  • Page 242 IP Phone Administrator Guide Operational Features Aastra Web UI Select a ring tone pattern for each of the following fields: • Group • Internal • External • Emergency • Priority • auto call distribution • community-1 • community-2 • community-3 •...

  • Page 243: Stuttered Dial Tone

    You can enable or disable the playing of a stuttered dial tone when there is a message waiting on the IP phone. You can configure this feature using the configuration files and the Aastra Web Configuring Stuttered Dial Tone Use the folllowing procedures to configure stuttered dial tone on the IP phones.
  • Page 244 IP Phone Administrator Guide Operational Features Aastra Web UI Click to save your changes. You must restart your IP phone for the changes to take affect. Click on Operation->Reset. In the "Restart Phone" field click to restart the IP phone.

  • Page 245: Call Waiting Tone

    You can enable or disable the playing of a call waiting tone when a caller is on an active call and a new call comes into the phone. You can configure this feature using the configuration files and the Aastra Web Configuring Call Waiting Tone Use the folllowing procedures to configure a call waiting tone on the IP phones.
  • Page 246 IP Phone Administrator Guide Operational Features Aastra Web UI Click to save your changes. You must restart your IP phone for the changes to take affect. Click on Operation->Reset. In the "Restart Phone" field click to restart the IP phone.

  • Page 247: Language

    Valid languages for the 480i/9112i/9133i include English, French, Spanish, German, and Italian. Valid languages for the 480i CT include English, French, and Spanish. Default language for all model phones is English. Configuring Language You configure the language on the IP phone using the Options key on the IP phone.
  • Page 248 Select In English (English), En francais (French), En espanol (Spanish), In Deutsch (German), or In italiano (Italian). Note: Valid values for the 480i CT are English, French, and Spanish only. For 9112i/9133i: Press Enter and then press Set to confirm the change.

  • Page 249: About This Chapter

    Advanced Operational Features About this chapter Introduction The IP phones have advanced operational features you can configure using the configuration files and/or the Aastra Web UI. This chapter describes each of these features and provides procedures for configuring each feature. Topics...

  • Page 250: Advanced Operational Features

    TFTP server, it is automatically configured by that TFTP server. Single Call Restriction (480i CT only) Allows you to enable or disable a single call restriction between the 480i CT base unit and a call server. 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...

  • Page 251: Mac Address/Line Number In Register Messages

    The IP phones can send the MAC address and line number in the REGISTER packets making it easier for the call server when a user configures the phones via the Aastra Web UI or the IP Phone UI. The following two configurable headers send this information to the call server: Aastra-Mac: <mac address>...
  • Page 252 IP Phone Administrator Guide Advanced Operational Features Aastra Web UI Step Action Click on Advanced Settings->Global SIP->Advanced SIP Setting. Enable the "Send MAC Address in REGISTER Message" field by checking the check box. (Disable this field by unchecking the box).

  • Page 253: Sip Message Sequence For Blind Transfer

    Advanced Operational Features Advanced Operational Features SIP Message Sequence for Blind Transfer The SIP message sequence for Blind Transfer avoids the transfer target having two simultaneous calls. Prior to release 1.4, a CANCEL message was sent to the transfer target (if it was in a ringing state) after sending a REFER to the transferee to complete the transfer.

  • Page 254: Update Caller Id During A Call

    IP Phone Administrator Guide Advanced Operational Features Update Caller ID During a Call It is possible for a proxy or call server to update the Caller ID information that displays on the phone during a call, by modifying the SIP Contact header in the 200 OK message and/or in a re-INVITE message.

  • Page 255: Boot Sequence Recovery Mode

    Advanced Operational Features Advanced Operational Features Boot Sequence Recovery Mode You can force the IP phone into recovery mode by pressing the 1 and # keys during boot up when the logo displays. This feature is enabled by default on the IP phone.

  • Page 256: Auto-Discovery Using Mdns

    IP Phone Administrator Guide Advanced Operational Features Auto-discovery Using mDNS The IP phones can perform an auto-discovery of all servers on a network using mDNS. When the IP phone discovers a TFTP server, it is automatically configured by that TFTP server. An unconfigured phone (phone right out of the box) added to a network, attempts to auto-discover a configuration server on the network without any end-user intervention.

  • Page 257: Single Call Restriction (480I Ct Only)

    You can configure this feature via the configuration files or the Aastra Web UI. Configuring Single Call Restriction. Configuration Files For the specific parameters you can set in the configuration files for single call restriction on the 480i CT, see Appendix A, the section, “Single Call Restriction”...
  • Page 258 IP Phone Administrator Guide Advanced Operational Features Aastra Web UI Step Action Click on Advanced Settings->Global SIP->RTP Settings. Enable the "Two Call Support" field by checking the check box. (Disable this field by unchecking the box). Click to save your settings.

  • Page 259: About This Chapter

    Chapter 7 Encryption and the IP Phone About this chapter Introduction This chapter provides information about encryption on the IP phones and provides methods an administrator can use to store encryped files to a server. Topics This chapter covers the following topics: Topic Page Encryption and the IP Phone...

  • Page 260: Configuration File Encryption Method

    IP phones. If security.tuz is present on the TFTP/FTP/HTTP server, the IP phones download it and use it locally to decrypt the configuration information from the aastra.tuz and <mac>.tuz files. Because only the encrypted versions of the configuration files need to be stored on the server, no plain-text configuration or passwords are sent across the network, thereby ensuring security of the configuration data.

  • Page 261: Procedure To Encrypt/Decrypt Configuration Files

    IP phones again. Note: If the use of encrypted configuration files is enabled (via security.tuz or pre-provisioned on the IP phone) the aastra.cfg and <mac>.cfg files are ignored, and only the encrypted equivalent files aastra.tuz and <mac>.tuz are read.
  • Page 262 Example 1 Encrypt aastra.cfg into aastra.tuz using password 1234abcd: C:\> anacrypt aastra.cfg -p 1234abcd Example 2 Decrypt aastra.tuz into aastra.cfg prompting user for password: C:\> anacrypt aastra.tuz Example 3 Decrypt mac.tuz using password 1234abcd, display plaintext on console: C:\> anacrypt aastra.tuz -o CON: -p 1234abcd...
  • Page 263 Encryption and the IP Phone Encryption and the IP Phone Example 7 Use the "-v" variable to display version number. C:\> anacrypt -v The encryption tag format supported by this anacrypt is: Tuzo v1.3 rev1 The corresponding IP phone firmware build is: 20051017 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...
  • Page 264 DFW Phone 972-992-4600...

  • Page 265: Firmware Upgrade

    Chapter 8 Firmware Upgrade About this chapter Introduction This chapter provides information about upgrading the IP phone firmware. Topics This chapter covers the following topics: Topic Page Upgrading the Firmware page 8-2 Manual Firmware Update (TFTP only) page 8-2 Manual Firmware and Configuration File Update page 8-4 Automatic Update (auto-resync) page 8-6...

  • Page 266: Upgrading The Firmware

    • Automatic update of firmware, configuration files, or both at a specific time in a 24-hour period (via the configuration files or the Aastra Web UI). Manual Firmware Update (TFTP only) Use the following procedure to activate a firmware download using TFTP.
  • Page 267 Firmware Upgrade Upgrading the Firmware Aastra Web UI Step Action Click on Advanced Settings->Firmware Update. Enter the TFTP server IP address or qualified domain name in the "TFTP Server IP" field. Enter the firmware file name (<phone model>.st) that you want to download to your IP phone in the "File Name"...

  • Page 268: Manual Firmware And Configuration File Update

    Step Action For 9112i/9133i: Press on the phone to enter the Options List. For 480i/480i CT: Press % on the phone to enter the Options List. Select Phone Status. Select Restart Phone. For 9112i/9133i: Press # to restart the phone.
  • Page 269 Firmware Upgrade Upgrading the Firmware Aastra Web UI Step Action Click on Operation->Reset. Click Click OK at the confirmation prompt. The firmware and configuration files download from the configuration server. 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...

  • Page 270: Automatic Update (Auto-Resync)

    24-hour period if the files on the server have changed. This feature works with TFTP, FTP, and HTTP servers. An administrator can enable this feature using the Aastra Web UI or using the configuration files (aastra.cfg and <mac>.cfg).
  • Page 271 Use the following procedures to configure automatic update of the IP phone firmware, configuration files, or both. Notes: If a user is accessing the Aastra Web UI, they are not informed of an auto-reboot. Any changes made using the Aastra Web UI or the IP phone UI are not overwritten by an auto-resync update.
  • Page 272 IP Phone Administrator Guide Upgrading the Firmware Aastra Web UI Step Action Click on Advanced Settings->Configuration Server->Auto-Resync. Select the auto-resync mode from the Mode field. Valid values are None, Configuration Files, Firmware, Both. Default is None. Select the time from the Time (24-hour) field that you want the update to take place.
  • Page 273 Firmware Upgrade Upgrading the Firmware Reference For more information about setting automatic update on the IP phone, see the "auto resync mode" and "auto resync time" parameters, see Appendix A, the section, “Configuration Server Settings” page A-10. 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...
  • Page 274 DFW Phone 972-992-4600...

  • Page 275: Troubleshooting

    Chapter 9 Troubleshooting About this chapter Introduction This chapter describes tasks that a system administrator can perform on the IP phones for troubleshooting purposes. It also includes answers to questions you may have while using the IP phones. Topics This chapter covers the following topics: Topic Page Troubleshooting...

  • Page 276: Troubleshooting

    Aastra Technical Support can then use the information gathered to perform troubleshooting tasks. Log Settings Using the configuration files or the Aastra Web UI, you can specify the location for which to save files for troubleshooting purposes. In the configuration files, you use the following parameters to configure log settings: •...
  • Page 277 Performing this task allows Aastra Technical Support to view the current configuration of the IP phone and troubleshoot as necessary. You can also display task and stack status information about the IP phone. Aastra Technical Support uses this information for troubleshooting the IP phone when required.
  • Page 278 For specific parameters you can set in the configuration files, see Appendix A, the section, “Troubleshooting Parameters” page A-107. Aastra Web UI Step Action Click on Advanced Settings->Troubleshooting. To set log settings: In the "Log IP" field, enter the IP address of where you want log files to be stored.
  • Page 279 Stack Status" field. Note: The local and server configuration file information and the task and stack status information is for use by Aastra Technical Support for troubleshooting purposes. Reference For information that describes solutions to most common problems using the IP phones, see the next section, “Troubleshooting Solutions”...

  • Page 280: Troubleshooting Solutions

    Note: Your computer needs to be on the same network as your IP Phone. In the URL, type: “http://<IP Address>” (where IP Address is the IP Address displayed on the phone). Your browser launches the Aastra IP Phone Firmware Recovery page.

  • Page 281: Why Does My Phone Display The "No Service" Message

    "No Service" message does not display, and the message waiting indicator (MWI) does not come on. Check that the "Registrar Server" IP address in the Aastra Web UI at Advanced Settings->Global SIP is correct. Check the "sip registrar ip" parameter in the configuration files is correct.

  • Page 282: Why Is My Phone Not Receiving The Tftp Ip Address From The Dhcp Server

    IP Phone Administrator Guide Troubleshooting Solutions Reason: Neither of the <mac>.tuz and aastra.tuz files are present on the configuration server (TFTP/FTP/HTTP). Fix: Create the encrypted files using anacrypt.exe and copy them to the configuration server. Reason: The encrypted <mac>.tuz or aastra.tuz file is encrypted using a different version of anacrypt.exe than the phone firmware.

  • Page 283: How Do I Restart The Ip Phone

    Step Action For 9112i/9133i: Press on the phone to enter the Options List. For 480i/480i CT: Press % on the phone to enter the Options List. Select Phone Status. Select Restart Phone. For 9112i/9133i: Press #=Confirm to restart the phone.
  • Page 284 IP Phone Administrator Guide Troubleshooting Solutions Aastra Web UI Step Action Click Click OK at the confirmation prompt. 9-10 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...

  • Page 285: How Do I Set The Ip Phone To Factory Default

    To restore the local configuration file factory defaults only: Select Config only to restore all factory defaults to the local configuration file. This option removes the configuration file that contains saved parameters set from the Aastra Web UI or the IP phone UI.
  • Page 286 IP Phone Administrator Guide Troubleshooting Solutions IP Phone UI Step Action For 9112i/9133i: Press #=Confirm. For 480i/480i CT: Press Default. Note: Press Cancel to cancel the operaiton. Press Restart when the phone prompts you to restart the phone. Aastra Web UI Step Action Click on Operation->Reset.
  • Page 287 In the "Remove Local Configuration Settings" field, click This restores all factory defaults to the local configuration file. It removes the configuration file that contains saved parameters set from the Aastra Web UI or the IP phone UI.. Press to restart the phone.

  • Page 288: How To Reset A User's Password

    Step Action For 9112i/9133i: Press on the phone to enter the Options List. For 480i/480i CT: Press % on the phone to enter the Options List. Select User Password. Enter the current user password. Enter the new user password. Re-enter the new user password.
  • Page 289 Troubleshooting Troubleshooting Solutions Aastra Web UI Step Action In the "New Password" field, enter the new user password. In the "Confirm Password" field, enter the new user password again. Click to save your changes. 41-001129-00 Rev 09, Release 1.4.1 9-15...
  • Page 290 DFW Phone 972-992-4600...

  • Page 291: Configuration Parameters About This Appendix

    A-4 Operational, Basic, and Advanced Parameters page A-5 Network Settings page A-5 Password Settings page A-8 Aastra Web UI Settings page A-10 Configuration Server Settings page A-10 Type of Service (ToS)/DSCP Settings page A-17 Virtual Local Area Network (VLAN) Settings...
  • Page 292 BLF Subscription Period Settings page A-89 Hard Key Parameters page A-90 Softkey/Programmable Key Parameters page A-93 Softkey Settings for 480i and 480i CT page A-94 Programmable Key Settings for 9112i and 9133i page A-100 Advanced Operational Parameters page A-103 MAC Address/Line Number page A-103 Blind Transfer Setting.
  • Page 293 Configuration Parameters About this appendix Topic Page Update Caller ID Setting. page A-105 Boot Sequence Recovery Mode. page A-105 Single Call Restriction page A-106 Troubleshooting Parameters page A-107 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...

  • Page 294: Setting Parameters In Configuration Files

    Setting Parameters in Configuration Files You can set specific configuration parameters in the configuration files for configuring you IP phone. The aastra.cfg and <mac>.cfg files are stored on the server. The aastra.cfg file stores global IP phone configuration settings. The <mac>.cfg file stores configuration settings specific to the IP phone with that...

  • Page 295: Operational, Basic, And Advanced Parameters

    IP phone. Each parameter table includes the name of the parameter, a description, the format, default value, range, and example. The table also provides the method for which the parameters can be configured (IP phone UI, Aastra Web UI, or configuration files).
  • Page 296 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – IP phone UI Options->Network Settings subnet mask Aastra Web UI Advanced Settings->Network Configuration Files aastra.cfg, <mac>.cfg Subnet Mask (in Web UI) Description Subnet mask defines the IP address range local to the IP phone.
  • Page 297 Configuration Parameters Operational, Basic, and Advanced Parameters Parameter – IP phone UI Options->Network Settings default gateway Aastra Web UI Advanced Settings->Network Configuration Files aastra.cfg, <mac>.cfg Gateway (in Web UI) Description The IP address of the network’s gateway or default router IP address.

  • Page 298: Password Settings

    Up to 63 alphanumeric characters Example admin password: 123456 Parameter – IP phone UI Options->User Password user password Aastra Web UI Operation->User Password Configuration Files aastra.cfg, <mac>.cfg Current Password (in Web UI) Description Allows you to set a new user password for the IP phone.
  • Page 299 Configuration Parameters Operational, Basic, and Advanced Parameters Parameter – Configuration Files aastra.cfg, <mac>.cfg options password enabled Description Enables or disables password protection of the Options key on the IP phone. If enabled, upon pressing the Options key, a user has to enter a password at the IP phone UI.

  • Page 300: Aastra Web Ui Settings

    Configuration Filesaastra.cfg, <mac>.cfg web interface enabled Description Enables or disables the Aastra Web UI for a single IP phone when placed in the <mac>.cfg file. Enables or disables the Aastra Web UI for all phones when placed in the aastra.cfg file.
  • Page 301 Configuration Parameters Operational, Basic, and Advanced Parameters Parameter – IP phone UI Options->Network->TFTP Server-> tftp server Primary TFTP Aastra Web UI Advanced Settings->Configuration Server TFTP Server Configuration Files aastra.cfg, <mac>.cfg (in Web UI) Description The TFTP server’s IP address or qualified domain name. If DHCP is enabled and the DHCP server provides the information, this field is automatically populated.
  • Page 302 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – IP phone UI Options->Network->TFTP Server->Select TFTP use alternative tftp server Aastra Web UI Advanced Settings->Configuration Server Configuration Files aastra.cfg, <mac>.cfg Use Alternate TFTP (in Web UI) Description Enables or disables the alternate TFTP server. Valid values are "0"...
  • Page 303 Configuration Parameters Operational, Basic, and Advanced Parameters Parameter – IP phone UI Options->Network->FTP Server ftp username Aastra Web UI Advanced Settings->Configuration Server Configuration Files aastra.cfg, <mac>.cfg FTP User Name (in Web UI) Description The username to enter for accessing the FTP server. This will become effective after this configuration file has been downloaded into the phone.
  • Page 304 HTTP root directory, the relative path to that sub-directory should be entered in this field. Format dir/dir/dir Default Value Not Applicable Range Up to 63 alphanumeric characters Example http path: ipphones/480i A-14 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...
  • Page 305 Notes: 1. If a user is accessing the Aastra Web UI, they are not informed of an auto-reboot. 2. Any changes made using the Aastra Web UI or the IP phone UI are not overwritten by an auto-resync update.
  • Page 306 1. The resync time is based on the local time of the IP phone. 2. The value of 00:00 is 12:00 A.M. 3. When selecting a value for this parameter in the Aastra Web UI, the values are in 30-minute increments only.

  • Page 307: Type Of Service (Tos)/Dscp Settings

    Operational, Basic, and Advanced Parameters Type of Service (ToS)/DSCP Settings Parameter – IP phone UI Options->Network->Type of Service->SIP tos sip Aastra Web UI Advanced Settings->Network-> Type of Service,DSCP Configuration Files aastra.cfg, <mac>.cfg Description The Differentiated Services Code Point (DSCP) for SIP packets.

  • Page 308: Virtual Local Area Network (Vlan) Settings

    IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Virtual Local Area Network (VLAN) Settings Parameter – IP phone UI Options->Network->VLAN->VLAN Enable tagging enabled Aastra Web UI Advanced Settings->Network->VLAN->Global Configuration Files aastra.cfg, <mac>.cfg VLAN Enable (in Web UI) Description Enables or disables VLAN on the IP phones.
  • Page 309 RTP Priority Options->Network->VLAN->Phone-> RTCP Priority Priority->RTCP (for Port 0 in Web UI) Aastra Web UI Advanced Settings->Network->VLAN->Port 0 Configuration Files aastra.cfg, <mac>.cfg Description This parameter is based on the Type of Service (ToS), Differentiated Services Code Point (DSCP) setting for SIP (tos sip parameter), RTP (tos rtp parameter) and RTCP (tos rtcp parameter).
  • Page 310 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – IP phone UI Options->Network->VLAN->Phone-> priority non-ip Priority->Other Aastra Web UI Advanced Settings->Network->VLAN->Global Priority, Non-IP Packet Configuration Files aastra.cfg, <mac>.cfg (in Web UI) Description Specifies the priority value for non-IP packets.

  • Page 311: Network Address Translation (Nat) Settings

    Configuration Parameters Operational, Basic, and Advanced Parameters Network Address Translation (NAT) Settings Parameter – IP phone UI Options->SIP Settings sip nat ip Aastra Web UI Advanced Settings->Network Configuration Files aastra.cfg, <mac>.cfg NAT IP (in Web UI) Description IP address the network device that enforces NAT.
  • Page 312 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Advanced Settings->Network sip nortel nat timer Configuration Files aastra.cfg, <mac>.cfg Nortel NAT Timer (in Web UI) Description The interval, in seconds, that the phone sends SIP ping requests to the Nortel proxy.

  • Page 313: Time Server Settings

    Configuration Parameters Operational, Basic, and Advanced Parameters Time Server Settings Parameter – Aastra Web UI Advanced Settings->Network-> time server disabled Advanced Network Settings Configuration Files aastra.cfg, <mac>.cfg NTP Time Servers (in Web UI) Description This parameter enables or disables the time server. This parameter affects the time server1, time server2, and time server3 parameters.
  • Page 314 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Advanced Settings->Network-> time server2 Advanced Network Settings Configuration Files aastra.cfg, <mac>.cfg Time Server 2 (in Web UI) Description The secondary time server's IP address or qualified domain name. If the...

  • Page 315: Time And Date Settings

    Parameter – IP phone UI Options->Time and Date->Time Format time format Configuration Files aastra.cfg, <mac>.cfg Time Format (in Phone UI) Description This parameter changes the time to 12 hour or 24 hour format. Use “0” for the 12 hour format and “1” for the 24 hour format.
  • Page 316 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – IP phone UI Options->Time and Date->Daylight Savings dst config Configuration Files aastra.cfg, <mac>.cfg Daylight Savings (in Phone UI) Description Enables/disables the use of daylight savings time. Format Integer Default Value...
  • Page 317 Configuration Parameters Operational, Basic, and Advanced Parameters Time Zone Name/Time Zone Code Table Time Zone Name Time Zone Code AD-Andorra AG-Antigua AI-Anguilla AL-Tirane AN-Curacao AR-Buenos Aires AS-Pago Pago AT-Vienna AU-Lord Howe AU-Tasmania AU-Melbourne AU-Sydney AU-Broken Hill AU-Brisbane AU-Lindeman AU-Adelaide AU-Darwin AU-Perth AW-Aruba BA-Sarajevo...
  • Page 318 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Time Zone Name Time Zone Code CA-Newfoundland CA-Atlantic CA-Eastern CA-Saskatchewan CA-Central CA-Mountain CA-Pacific CA-Yukon CH-Zurich CK-Rarotonga CL-Santiago CL-Easter CN-China CO-Bogota CR-Costa Rica CU-Havana CY-Nicosia CZ-Prague DE-Berlin DK-Copenhagen DM-Dominica DO-Santo Domingo EE-Tallinn ES-Madrid ES-Canary FI-Helsinki...
  • Page 319 Configuration Parameters Operational, Basic, and Advanced Parameters Time Zone Name Time Zone Code HK-Hong Kong HN-Tegucigalpa HR-Zagreb HT-Port-au-Prince HU-Budapest IE-Dublin IS-Reykjavik IT-Rome JM-Jamaica JP-Tokyo KY-Cayman LC-St Lucia LI-Vaduz LT-Vilnius LU-Luxembourg LV-Riga MC-Monaco MD-Chisinau MK-Skopje MQ-Martinique MS-Montserrat MT-Malta MX-Mexico City MX-Cancun MX-Merida MX-Monterrey MX-Mazatlan...
  • Page 320 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Time Zone Name Time Zone Code PA-Panama PE-Lima PL-Warsaw PR-Puerto Rico PT-Lisbon PT-Madeira PT-Azores PY-Asuncion RO-Bucharest RU-Kaliningrad RU-Moscow RU-Samara RU-Yekaterinburg RU-Omsk RU-Novosibirsk RU-Krasnoyarsk RU-Irkutsk RU-Yakutsk RU-Vladivostok RU-Sakhalin RU-Magadan RU-Kamchatka RU-Anadyr SE-Stockholm SG-Singapore SI-Ljubljana SK-Bratislava...
  • Page 321 Configuration Parameters Operational, Basic, and Advanced Parameters Time Zone Name Time Zone Code VA-Vatican YU-Belgrade 41-001129-00 Rev 09, Release 1.4.1 A-31 DFW Phone 972-992-4600...

  • Page 322: Sip Local Dial Plan Settings

    The name displayed on the idle screen rather than the user name and phone number. Format Alphanumeric characters Default Value Not Applicable Range For 480i/480i CT: Up to 21 characters (width of LCD) For 9112i/9133i: Up to 16 characters (width of LCD) Example displayName1: SIPphone1 Parameter –...
  • Page 323 Configuration Parameters Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Basic Settings->Preferences sip dial plan Configuration Files aastra.cfg, <mac>.cfg Local Dial Plan (in Web UI) Description A dial plan describes the number and pattern of digits that a user dials to reach a particular telephone number.
  • Page 324 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Basic Settings->Preferences sip dial plan terminator Configuration Files aastra.cfg, <mac>.cfg Send Dial Plan Terminator (in Web UI) Description The IP phone allows the configuration of a dial plan terminator. When...

  • Page 325: Sip Basic, Global Settings

    Operational, Basic, and Advanced Parameters SIP Basic, Global Settings SIP Global Authentication Settings Parameter – IP Phone UI Options->SIP Settings sip screen name Aastra Web UI Advanced Settings->Global SIP-> Basic SIP Settings Screen Name Configuration Files aastra.cfg, <mac>.cfg (in Web UI) Description Used to display text on the screen of the phone.
  • Page 326 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – IP Phone UI Options->SIP Settings sip display name Aastra Web UI Advanced Settings->Global SIP-> Basic SIP Settings Caller ID Configuration Files aastra.cfg, <mac>.cfg (in Web UI) Description Used in the display name field of the From SIP header field. Some IP PBX systems use this as the caller’s ID and some may overwrite this...
  • Page 327 Configuration Parameters Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Advanced Settings->Global SIP-> sip bla number Basic SIP Settings Configuration Files aastra.cfg, <mac>.cfg BLA Number (in Web UI) Description Allows you to assign a phone number that is shared across all IP phones.
  • Page 328 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters SIP Global Network Settings. Parameter – IP Phone UI Options->SIP Settings sip proxy ip Aastra Web UI Advanced Settings->Global SIP-> Basic SIP Settings Proxy Server Configuration Files aastra.cfg, <mac>.cfg (in Web UI)
  • Page 329 Configuration Parameters Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Advanced Settings->Global SIP-> sip backup proxy ip Basic SIP Network Settings Configuration Files aastra.cfg, <mac>.cfg Backup Proxy Server (in Web UI) Description The IP address of the backup SIP proxy server for which the IP phone uses when the primary SIP proxy is unavailable.
  • Page 330 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Advanced Settings->Global SIP-> sip outbound proxy port Advanced SIP Settings Configuration Files aastra.cfg, <mac>.cfg outbound proxy port (in Web UI) Description The proxy port on the proxy server to which the IP phone sends all SIP messages.
  • Page 331 Configuration Parameters Operational, Basic, and Advanced Parameters Parameter – IP Phone UI Options->SIP Settings sip registrar port Aastra Web UI Advanced Settings->Global SIP-> Basic SIP Settings Registrar Port Configuration Files aastra.cfg, <mac>.cfg (in Web UI) Description The registrar's port number.
  • Page 332 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Advanced Settings->Global SIP-> sip backup registrar port Basic SIP Network Settings Configuration Files aastra.cfg, <mac>.cfg Backup Registrar Port (in Web UI) Description The backup registrar's (typically the backup SIP proxy) port number.

  • Page 333: Sip Basic, Per-Line Settings

    Operational, Basic, and Advanced Parameters SIP Basic, Per-Line Settings The following parameters are SIP per-line settings. The value of "N" is 1 - 9 for 480i, 480i CT, and 9133i. The value of "N" is 1 for 9112i.. SIP Per-Line Authentication Settings Parameter –...
  • Page 334 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Advanced Settings->Line 1 thru 9 sip lineN display name (480i/480i CT/9133i) Aastra Web UI Advanced Settings->Global SIP (9112i) Caller ID Configuration Files aastra.cfg, <mac>.cfg (in Web UI) Description Used in the display name field of the From SIP header field.
  • Page 335 Configuration Parameters Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Advanced Settings->Line 1 thru 9 sip lineN password (480i/480i CT/9133i) Aastra Web UI Advanced Settings->Global SIP (9112i) Password Configuration Files aastra.cfg, <mac>.cfg (in Web UI) Description The password that will be used to register at the registrar.
  • Page 336 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Advanced Settings->Line 1 thru 9 sip lineN bla number (480i/480i CT/9133i) Aastra Web UI Advanced Settings->Global SIP (9112i) BLA Number Configuration Files aastra.cfg, <mac>.cfg (in Web UI)
  • Page 337 BLA - Bridged Line Appearance (BLA) line. • If the softkeys on the 480i/480i CT or the programmable keys on the 9133i are set as line keys, and you configure that line key for BLA, the key is configured to use BLA.
  • Page 338 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters SIP Per-Line Network Settings. Parameter – Aastra Web UI Advanced Settings->Line 1 thru 9 sip lineN proxy ip (480i/480i CT/9133i) Aastra Web UI Advanced Settings->Global SIP (9112i) Proxy Server Configuration Files aastra.cfg, <mac>.cfg...
  • Page 339 Configuration Parameters Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Advanced Settings->Line 1 thru 9 sip linex backup proxy ip (480i/480i CT/9133i) Aastra Web UI Advanced Settings->Global SIP (9112i) Backup Proxy Server Configuration Files aastra.cfg, <mac>.cfg (in Web UI)
  • Page 340 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Advanced Settings->Line 1 thru 9 sip lineN outbound proxy port (480i/480i CT/9133i) Aastra Web UI Advanced Settings->Global SIP (9112i) Outbound Proxy Port Configuration Files aastra.cfg, <mac>.cfg...
  • Page 341 Configuration Parameters Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Advanced Settings->Line 1 thru 9 sip lineN registrar port (480i/480i CT/9133i) Aastra Web UI Advanced Settings->Global SIP (9112i) Registrar Port Configuration Files aastra.cfg, <mac>.cfg (in Web UI) Description...
  • Page 342 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Advanced Settings->LineN-> sip linex backup registrar port Basic SIP Network Settings Configuration Files aastra.cfg, <mac>.cfg Backup Registrar Port (in Web UI) Description The backup registrar's (typically the backup SIP proxy) port number.

  • Page 343: Advanced Sip Settings

    Parameter – Aastra Web UI Advanced Settings->Global SIP-> sip explicit mwi subscription Advanced SIP Settings Configuration Files aastra.cfg, <mac>.cfg Explicit MWI Subscription (in Web UI) Description If the IP phone has a message waiting subscription with the Service Provider, a Message Waiting Indicator (MWI) (LED or display icon) tells the user there is a message on the IP Phone.
  • Page 344 Parameter – Aastra Web UI Advanced Settings->Global SIP-> sip session timer Advanced SIP Settings Configuration Files aastra.cfg, <mac>.cfg Session Timer (in Web UI) Description The time, in seconds, that the IP phone uses to send periodic re-INVITE requests to keep a session alive. The proxy uses these re-INVITE requests to maintain the status' of the connected sessions.
  • Page 345 Parameter – Aastra Web UI Advanced Settings->Global SIP-> sip T2 timer Advanced SIP Settings Configuration Files aastra.cfg, <mac>.cfg T2 Timer (in Web UI) Description This timer is a SIP transaction layer timer defined in RFC 3261. Timer 2 represents the amount of time, in milliseconds, a non-INVITE server transaction takes to respond to a request.
  • Page 346 Parameter – Aastra Web UI Advanced Settings->Global SIP-> sip transport protocol Advanced SIP Settings Configuration Files aastra.cfg, <mac>.cfg Transport Protocol (in Web UI) Description The protocol that the RTP port on the IP phone uses to send out RTP packets.
  • Page 347 Parameter – Aastra Web UI Advanced Settings->Global SIP-> sip registration timeout retry Advanced SIP Settings timer Configuration Files aastra.cfg, <mac>.cfg Registration Timeout Retry Timer (in Web UI) Description Specifies the length of time, in seconds, that the phone waits until it re-attempts to register after a REGISTER message times out.

  • Page 348: Rtp, Codec, Dtmf Global Settings

    Operational, Basic, and Advanced Parameters RTP, Codec, DTMF Global Settings Parameter – IP Phone UI Options->SIP Settings->RTP Port Base sip rtp port Aastra Web UI Advanced Settings->Global SIP->RTP Settings Configuration Files aastra.cfg, <mac>.cfg RTP Port Base (in IP Phone UI)
  • Page 349 Configuration Parameters Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Advanced Settings->Global SIP->RTP Settings sip out-of-band dtmf Configuration Files aastra.cfg, <mac>.cfg Force RFC2833 Out-of-Band DTMF (in Web UI) Description Enables or disables out-of-band DTMF. Enabling this parameter forces the IP phone to use out-of-band DTMF according to RFC2833.

  • Page 350: Dtmf Per-Line Settings

    IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Advanced Settings->Global SIP->RTP Settings sip dtmf method Configuration Files aastra.cfg, <mac>.cfg DTMF Method (in Web UI) Description Sets the Dual-tone multifrequency (DTMF) method to use on the IP phone.

  • Page 351: Silence Suppression Settings

    Configuration Parameters Operational, Basic, and Advanced Parameters Silence Suppression Settings Parameter – Aastra Web UI Advanced Settings->Global SIP->RTP Settings sip silence suppression Configuration Files aastra.cfg, <mac>.cfg Silence Suppression (in Web UI) Description Silence suppression is enabled by default on the IP phones. The phone negotiates whether or not to use silence suppression.

  • Page 352: Voicemail Settings

    <mac>.cfg sip lineN vmail Note: The value of "N" is 1 - 9 for 480i, 480i CT, and 9133i. The value of "N" is 1 for 9112i. Description Use this parameter in the <mac>.cfg file to configure the phone to dial a specific number to access an existing voicemail account on a Service Provider’s server.

  • Page 353: Directory Settings

    UI. If this parameter is set to 1, the Directory List does not display on the IP phone and the Directory key is disabled. On the 480i and 480i CT the "Directory" option is also removed from the "Services" menu.

  • Page 354: Callers List Settings

    If this parameter is set to 1, the IP phone does not save any caller information to the Caller List. For 480i and 480i CT phones, the "Caller List" option on the IP phone is removed from the Services menu, and the...

  • Page 355: Missed Calls Indicator Settings

    Configuration Parameters Operational, Basic, and Advanced Parameters Missed Calls Indicator Settings Parameter – Configuration Files aastra.cfg, <mac>.cfg missed calls indicator disabled Description Enables or disables the Missed Calls Indicator. If the "missed calls indicator disabled" parame.ter is set to 0, the indicator increments as unanswered calls come into the IP phone.

  • Page 356: Xml Settings

    This is the XML application you are loading into the IP phone configuration. Format HTTP server path or fully qualified Domain Name Default Value Not Applicable Range Not Applicable Example xml application URI: http://172.16.96.63/aastra/internet.php Parameter – Aastra Web UI Operation->Softkeys and XML->Services xml application title Configuration Files aastra.cfg, <mac>.cfg XML Application Title...
  • Page 357 Parameter – Aastra Web UI Basic Settings->Preferences xml beep notification Configuration Files aastra.cfg, <mac>.cfg XML Beep Support (in Web UI) Description Enables or disables a BEEP notification on the phone when a status message object (AastraIPPhoneStatus) containing a “beep” attribute arrives to the phone.
  • Page 358 Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Basic Settings->Preferences xml status scroll delay Configuration Files aastra.cfg, <mac>.cfg Status Scroll Delay (seconds) (in Web UI) Description Specifies the length of time, in seconds, that each XML status message displays on the phone.

  • Page 359: Action Uri Settings

    Configuration Parameters Operational, Basic, and Advanced Parameters Action URI Settings Parameter – Aastra Web UI Advanced Settings->Action URI action uri startup Configuration Files aastra.cfg, <mac>.cfg Startup (in Web UI) Description Specifies the URI for which the phone executes a GET on when a startup event occurs.
  • Page 360 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Advanced Settings->Action URI action uri incoming Configuration Files aastra.cfg, <mac>.cfg Incoming Call (in Web UI) Description Specifies the URI for which the phone executes a GET on when an incoming call event occurs.
  • Page 361 Configuration Parameters Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Advanced Settings->Action URI action uri offhook Configuration Files aastra.cfg, <mac>.cfg Offhook (in Web UI) Description Specifies the URI for which the phone executes a GET on when an offhook event occurs.

  • Page 362: Ring Tone And Tone Set Global Settings

    Integer Default Value Aastra Web UI : Tone 1 IP Phone UI: Tone 1 Configuration Files: 0 (Tone 1) Range Aastra Web UI & IP Phone UI Tone 1 Tone 2 Tone 3 Tone 4 Tone 5 Silent Configuration Files...

  • Page 363: Ring Tone Per-Line Settings

    Sets the type of ring tone on the IP phone on a per-line basis. Ring tone can be set to one of six distinct rings. Format Integer Default Value Aastra Web UI :Global Configuration Files:-1 (Global) Range Aastra Web UI Global...

  • Page 364: Stuttered Dial Tone Setting

    IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Stuttered Dial Tone Setting Parameter – Aastra Web UI: Basic Settings->Preferences->General stutter disabled Configuration Files aastra.cfg, <mac>.cfg Stuttered Dial Tone (in Web UI) Description Enable or disables the playing of a stuttered dial tone when there is a message waiting on the IP phone.

  • Page 365: Priority Alert Settings

    Configuration Parameters Operational, Basic, and Advanced Parameters Priority Alert Settings Parameter – Aastra Web UI: Basic Settings->Preferences-> prioity alerting enabled Priority Alerting Settings Configuration Files aastra.cfg, <mac>.cfg Enable Priority Alerting (in Web UI) Description Enables and disables distinctive ringing on the IP phone for incoming calls and call-waiting calls.
  • Page 366 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI: Basic Settings->Preferences-> alert community 1 Priority Alerting Settings Configuration Files aastra.cfg, <mac>.cfg community-1 (in Web UI) Description When an "alert community-1” keyword appears in the header of the INVITE request, the configured Bellcore ring tone is applied to the IP phone.
  • Page 367 Configuration Parameters Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI: Basic Settings->Preferences-> alert community 3 Priority Alerting Settings Configuration Files aastra.cfg, <mac>.cfg community-3 (in Web UI) Description When an "alert community-3” keyword appears in the header of the INVITE request, the configured Bellcore ring tone is applied to the IP phone.
  • Page 368 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI: Basic Settings->Preferences-> alert external Priority Alerting Settings Configuration Files aastra.cfg, <mac>.cfg alert external (in Web UI) Description When an "alert external" keyword appears in the header of the INVITE request, the configured Bellcore ring tone is applied to the IP phone.
  • Page 369 Configuration Parameters Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI: Basic Settings->Preferences-> alert group Priority Alerting Settings Configuration Files aastra.cfg, <mac>.cfg alert group (in Web UI) Description When an "alert group" keyword appears in the header of the INVITE request, the configured Bellcore ring tone is applied to the IP phone.

  • Page 370: Language Settings

    Used to set the language that the phone uses to display messages, etc. Valid values for 480i/9112i/9133i are: 0 (English) 1 (French) 2 (Spanish) 3 (German) 4 (Italian) Valid values for 480i CT are: 0 (English) 1 (French) 2 (Spanish) Format Integer Default Value...

  • Page 371: Suppress Dtmf Playback Settings

    Configuration Parameters Operational, Basic, and Advanced Parameters Suppress DTMF Playback Settings Parameter – Aastra Web UI Basic Settings->Preferences suppress dtmf playback Configuration Files aastra.cfg, <mac>.cfg Suppress DTMF Playback (in Web UI) Description Enables and disables suppression of DTMF playback when a number is dialed from the softkeys or programmable keys.

  • Page 372: Intercom And Auto-Answer Settings

    Format Integer Default Value For Aastra Web UI: Off (480i, 480i CT and handsets) For Configuration Files: 3 Off (480i, 480i CT and handsets) Range For Aastra Web UI: Phone-Side Server-Side Off (480i and 480i CT handsets) For Configuration Files:...
  • Page 373 Configuration Parameters Operational, Basic, and Advanced Parameters Parameter – Aastra Web UI Basic Settings->Preferences-> sip intercom prefix code Outgoing Intercom Settings Configuration Files aastra.cfg, <mac>.cfg Prefix Code (in Web UI) Description The prefix to add to the phone number for server-side outgoing Intercom calls.
  • Page 374 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Incoming Intercom Settings Parameter – Aastra Web UI Basic Settings->Preferences-> sip intercom mute mic Incoming Intercom Settings Configuration Files aastra.cfg, <mac>.cfg Microphone Mute (in Web UI) Description Enables or disables the microphone on the IP phone for Intercom calls made by the originating caller.

  • Page 375: Audio Transmit And Receive Gain Adjustment Settings

    Operational, Basic, and Advanced Parameters Audio Transmit and Receive Gain Adjustment Settings Parameter – Configuration Files aastra.cfg, <mac>.cfg headset tx gain Description This is the increased (+db) or decreased (-db) amount of signal transmitted from the headset microphone to t he far-end party. The amount of Tx gain in the IP phone firmware has been reduced to avoid side-tone and echo on the local and far-end equipment.
  • Page 376 IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Parameter – Configuration Files aastra.cfg, <mac>.cfg handset tx gain Description This is the increased (+db) or decreased (-db) amount of signal transmitted from the handset microphone to the far-end party. The amount of Tx gain in the IP phone firmware has been reduced to avoid side-tone and echo on the local and far-end equipment.
  • Page 377 Configuration Parameters Operational, Basic, and Advanced Parameters Parameter – Configuration Files aastra.cfg, <mac>.cfg handsfree tx gain Description This is the increased (+db) or decreased (-db) amount of signal transmitted from the base microphone to the far-end party. The amount of Tx gain in the IP phone firmware has been reduced to avoid side-tone and echo on the local and far-end equipment.

  • Page 378: Directed Call Pickup (Blf Call Interception) Settings

    IP Phone Administrator Guide Operational, Basic, and Advanced Parameters Directed Call Pickup (BLF Call Interception) Settings Parameter – Aastra Web UI Basic Settings->Preferences directed call pickup ->Directed Call Pickup Settings Configuration Files aastra.cfg, <mac>.cfg Directed Call Pickup (in Web UI) Description Enables or disables the use of "directed call pickup"...

  • Page 379: Blf Subscription Period Settings

    Configuration Parameters Operational, Basic, and Advanced Parameters BLF Subscription Period Settings Parameter – Aastra Web UI Advanced Settings->Global SIP sip blf subscription period ->Advanced SIP Settings Configuration Files aastra.cfg, <mac>.cfg BLF Subscription Period (in Web UI) Description Specifies the time period, in seconds, that the IP phone resubscribes the BLF subscription service after a software/firmware upgrade or after a reboot of the IP phone.

  • Page 380: Hard Key Parameters

    This section provides the hard key settings you can use to enable and disable the Redial, Conf, and Xfer keys on the IP phone. Parameter – Configuration Files aastra.cfg, <mac>.cfg redial disabled Description Enables or disables the Redial key on the IP phone. If this parameter is set to 0, the key is active and can be pressed by the user.
  • Page 381 If you leave this parameter blank, the Redial key returns to its original functionality. Note: If you configure the Redial key for speeddialing on the 480i CT Base Station, the Redial key on the 480i CT handset retains its original functionality.
  • Page 382 If you leave this parameter blank, the Conf key returns to its original functionality. Note: If you configure the Conf key for speeddialing on the 480i CT Base Station, the Conf key on the 480i CT handset retains its original functionality.

  • Page 383: Softkey/Programmable Key Parameters

    Programmable Feature Keys Available Model Available Keys Available Available Lines 480i 480i CT 480i CT Handset 9112i 9133i Note: When entering definitions for softkeys, the “#” sign must be enclosed in quotes. 41-001129-00 Rev 09, Release 1.4.1 A-93 DFW Phone 972-992-4600...

  • Page 384: Softkey Settings For 480I And 480I Ct

    URL for this option. • flash - Indicates the softkey is set to generate a flash event when it is pressed on the 480i and 480i CT, or a feature key is pressed on the 480i CT handset. •...
  • Page 385 Configuration Parameters Softkey/Programmable Key Parameters Default Value none Range line speeddial list ("BLF\List" in the Aastra Web UI) flash park pickup empty Example softkey1 type: line softkey2 type: speeddial softkey3 type: lcr softkey 4 type: xml 41-001129-00 Rev 09, Release 1.4.1...
  • Page 386 • Pickup Notes: For the 480i and 480i CT phones, an icon appears beside the soft key label that indicates the status of the line. If the softkeyN type parameter is set to "flash", and no label value is entered for the softkeyN label parameter, the label of "Flash" is used.
  • Page 387 Configuration Parameters Softkey/Programmable Key Parameters Parameter – Aastra Web UI Operation->Softkeys and XML softkeyN value Configuration Files aastra.cfg, <mac>.cfg Value (In WEb UI) Description This is the value you assign to the softkey. The “softkeyN value” parameter can be set for the following softkey types only: •...
  • Page 388 • speeddial • • BLF/List • Park • Pickup • Format Integer Default Value Range 1 through 9 (for 480i and 480i CT) Example softkey1 line: 1 softkey2 line: 5 A-98 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...
  • Page 389 Configuration Parameters Softkey/Programmable Key Parameters Parameter – Aastra Web UI Operation->Softkeys and XML softkeyN states Configuration Files aastra.cfg, <mac>.cfg Idle, Connected, Incoming, Outgoing (in Web UI) Description Displays the status of the phone when a softkey is pressed. You can enter multiple values (idle, connected, incoming, outgoing) for the "softkeyN state"...

  • Page 390: Programmable Key Settings For 9112I And 9133I

    - Indicates programmable key is configured for speeddial • dnd - Indicates programmable key is configured for do not disturb on the phone. This option is "do not disturb" in the Aastra Web UI). • blf (9133i only) - Indicates programmable key is configured for Busy Lamp Field (BLF) use.
  • Page 391 Configuration Parameters Softkey/Programmable Key Parameters Range line (9133i only) speeddial dnd ("do not disturb" in the Aastra Web UI) blf (9133i only) list (9133i only; Aastra Web UI only) flash park pickup Example prgkey1 type: speeddial Parameter – Aastra Web UI Operation->Programmable Keys...
  • Page 392 IP Phone Administrator Guide Softkey/Programmable Key Parameters Parameter Aastra Web UI Operation->Programmable Keys (9133i only) – Configuration Files aastra.cfg, <mac>.cfg prgkeyN line Line (in Web UI) Description This is the line associated with the programmable key you are configuring. This parameter is for the 9133i only.

  • Page 393: Advanced Operational Parameters

    <mac>.cfg Send MAC Address in REGISTER Message (in Web UI) Description Adds an "Aastra-Mac:" header to the SIP REGISTER messages sent from the phone to the call server, where the value is the MAC address of the phone. Format Boolean...

  • Page 394: Blind Transfer Setting

    <mac>.cfg Send Line Number in REGISTER Message (in Web UI) Description Adds an "Aastra-Line:" header to the SIP REGISTER messages sent from the phone to the call server, where the value is the MAC address of the phone. Format Boolean...

  • Page 395: Update Caller Id Setting

    Configuration Parameters Advanced Operational Parameters Update Caller ID Setting. Parameter – Configuration Files aastra.cfg, <mac>.cfg sip update callerid Description Enables or disables the updating of the Caller ID information during a call. Format Boolean Default Value 0 (disabled) Range 0 (disabled)

  • Page 396: Single Call Restriction

    When this feature is enabled (set to 1), you can make separate active calls from the 480i CT base unit and from the cordless handset. If this feature is disabled (set to 0), only one call can be active at a time either from the base unit or from the handset.

  • Page 397: Troubleshooting Parameters

    Configuration Parameters Troubleshooting Parameters Troubleshooting Parameters The following parameters in this section allow the system admininstrator to set logging and support settings for troubleshooting purposes. Parameter – Aastra Web UI Advanced Settings->Troubleshooting log ip Configuration Files aastra.cfg, <mac>.cfg Description Specifies the IP address for which to save log files for troubleshooting purposes.
  • Page 398 IP Phone Administrator Guide Troubleshooting Parameters Parameter – Aastra Web UI Advanced Settings->Troubleshooting log level Configuration Files aastra.cfg, <mac>.cfg Log Level (in Web UI) Description Specifies the severity level of the logs to be reported to a log file. When this parameter is set to a specific value, only the logs with characteristics of this value and higher are reported to the log file.
  • Page 399 Configuration Parameters Troubleshooting Parameters 41-001129-00 Rev 09, Release 1.4.1 A-109 DFW Phone 972-992-4600...
  • Page 400 IP Phone Administrator Guide Troubleshooting Parameters Time Zone Name Time Zone Code AD-Andorra AG-Antigua AI-Anguilla AL-Tirane AN-Curacao AR-Buenos Aires AS-Pago Pago AT-Vienna AU-Lord Howe AU-Tasmania AU-Melbourne AU-Sydney AU-Broken Hill AU-Brisbane AU-Lindeman AU-Adelaide AU-Darwin AU-Perth AW-Aruba BA-Sarajevo BB-Barbados BE-Brussels BG-Sofia BM-Bermuda BO-La Paz BR-Noronha BR-Belem...
  • Page 401 Configuration Parameters Troubleshooting Parameters Time Zone Name Time Zone Code CA-Newfoundland CA-Atlantic CA-Eastern CA-Saskatchewan CA-Central CA-Mountain CA-Pacific CA-Yukon CH-Zurich CK-Rarotonga CL-Santiago CL-Easter CN-China CO-Bogota CR-Costa Rica CU-Havana CY-Nicosia CZ-Prague DE-Berlin DK-Copenhagen DM-Dominica DO-Santo Domingo EE-Tallinn ES-Madrid ES-Canary FI-Helsinki FJ-Fiji FK-Stanley FO-Faeroe FR-Paris GB-London...
  • Page 402 IP Phone Administrator Guide Troubleshooting Parameters Time Zone Name Time Zone Code HK-Hong Kong HN-Tegucigalpa HR-Zagreb HT-Port-au-Prince HU-Budapest IE-Dublin IS-Reykjavik IT-Rome JM-Jamaica JP-Tokyo KY-Cayman LC-St Lucia LI-Vaduz LT-Vilnius LU-Luxembourg LV-Riga MC-Monaco MD-Chisinau MK-Skopje MQ-Martinique MS-Montserrat MT-Malta MX-Mexico City MX-Cancun MX-Merida MX-Monterrey MX-Mazatlan MX-Chihuahua...
  • Page 403 Configuration Parameters Troubleshooting Parameters Time Zone Name Time Zone Code PA-Panama PE-Lima PL-Warsaw PR-Puerto Rico PT-Lisbon PT-Madeira PT-Azores PY-Asuncion RO-Bucharest RU-Kaliningrad RU-Moscow RU-Samara RU-Yekaterinburg RU-Omsk RU-Novosibirsk RU-Krasnoyarsk RU-Irkutsk RU-Yakutsk RU-Vladivostok RU-Sakhalin RU-Magadan RU-Kamchatka RU-Anadyr SE-Stockholm SG-Singapore SI-Ljubljana SK-Bratislava SM-San Marino SR-Paramaribo SV-El Salvador TR-Istanbul...
  • Page 404 IP Phone Administrator Guide Troubleshooting Parameters Time Zone Name Time Zone Code VA-Vatican YU-Belgrade A-114 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...

  • Page 405: Configuration Server Setup

    Appendix B Configuration Server Setup About this appendix Introduction This appendix describes how to setup the TFTP protocol configuration server in your network. Topics This appendix covers the following topics: Topic Page Configuration Server Protocol Setup page B-2 TFTP Server Set-up page B-2 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...

  • Page 406: Configuration Server Protocol Setup

    IP Phone Administrator Guide Configuration Server Protocol Setup Configuration Server Protocol Setup TFTP Server Set-up There are a number of TFTP servers available. PumpKIN is one of such TFTP servers. Use the keywords “pumpkin TFTP server” on Google and you should get the web site where you can download the software from.
  • Page 407 Configuration Server Setup Configuration Server Protocol Setup If you want to prevent users from writing files to the directory select the “Deny all requests” in the “Write Request Behavior” category. Click the OK button after you have entered all the required information. All the firmware files should be in the file system root directory.
  • Page 408 DFW Phone 972-992-4600...

  • Page 409: Appendix C Configuring The Ip Phone At The Asterisk Ip Pbx

    Appendix C Configuring the IP Phone at the Asterisk IP PBX About this appendix Introduction This appendix describes how to setup a user’s phone with an extension to make and receive calls using the Asterisk as the PBX. Topics This appendix covers the following topics: Topic Page IP Phone at the Asterisk IP PBX...

  • Page 410: Ip Phone At The Asterisk Ip Pbx

    ;This is used in the “extensions.conf” file to identify this ;physical phone when issuing Dial commands. [phone1] ;The type to use for the 480i is “friend”. ;”Peer” is used when the Asterisk is contacting a proxy, ;”user” is used for phones that can only make calls ;and “friend”...
  • Page 411 (D) 255.255.255.255 5060 Unmonitored This completes the basic set-up for the 480i phone with 1234 extension at the Asterisk IP PBX system. Refer to Asterisk documentation for set-up on extended or advanced features such as voice mail and call forwarding, etc.
  • Page 412 DFW Phone 972-992-4600...
  • Page 413 Appendix D Sample Configuration Files About this appendix Introduction This appendix provides sample configuration files for the 480i, 480i CT, 9112i, and 9133i. Topics This appendix covers the following topics: Topic Page Sample Configuration Files page D-2 480i Sample Configuration File...

  • Page 414: Sample Configuration Files

    # a pound. For Boolean fields, 0 = false, 1 = true. # Comments: # This file contains sample configurations for the "aastra.cfg" or # "<mac>.cfg" file. The settings included here are examples only. # You should change/comment the values to suit your requirements.
  • Page 415 Sample Configuration Files Sample Configuration Files # The Aastra 480i, 480iCT, 9112i and 9133i phones will download 2 # configuration files from the TFTP server while restarting, the # "aastra.cfg" file and the "<mac>.cfg" file. These two configuration # files can be used to configure all of the settings of the phone with # the exception of assigning a static IP address to a phone and line # settings, which should only be set in the "<mac>.cfg"...
  • Page 416 IP Phone Administrator Guide Sample Configuration Files # Network Settings ## = = = = = = = = # Notes: If DHCP is enabled, you do not need to set these network # settings. Although depending on you DHCP server configuration you # may still have to set the dns address.
  • Page 417 # Option 2: # If you are using a session border controller, you should set the # outbound proxy to the session border controller address #sip outbound proxy: sbc.aastra.com #sip outbound proxy port: 0 # a value of 0 enables SRV # lookups for the address of # the proxy.
  • Page 418 ## FTP server settings #ftp server: 192.168.0.131 # can be IP or FQDN #ftp username: aastra #ftp password: 480iaastra ## HTTP server settings (for http://bogus.aastra.com/firmware/) #http server: bogus.aastra.com # can be IP or FQDN #http path: firmware #------------------------------------------------------------------- # Dial Plan Settings...
  • Page 419 Sample Configuration Files Sample Configuration Files (1) The entered number is an exact match in the dial plan (2) The "#" symbol has been pressed (3) A timeout occurs # The dial plan is a regular expression that supports the following # syntax: 0,1,2,3,4,5,6,7,8,9,*,# : matches the keypad symbols : matches any digit (0...9)
  • Page 420 # Notes: These settings are used as the default configuration for the hard key lines on the phone. That is: L1 to L4 on the 480i and 480iCT L1 to L3 on the 9133i L1 on the 9112i These can be over-ridden on a per-line basis using the per-line settings.
  • Page 421 0 - generic, 1 - BroadSoft SCA line 2 - Nortel line sip proxy ip: proxy.aastra.com # IP address or FQDN of proxy sip proxy port: 5060 # port used for SIP messages on the # proxy. Set to 0 to enable SRV # lookups sip registrar ip: aastra.com...
  • Page 422 # There are a maximum of 18 softkeys that can be configured on the # 480i or 480iCT phone. These can be set up through either of the 2 # configuration files, depending on whether this is to be server wide # ("aastra.cfg") or phone specific ("<mac>.cfg").
  • Page 423 Sample Configuration Files Sample Configuration Files # call/line appearances and have a type, label and value associated # with it as seen here in the default softkey settings. # SOFTKEY TYPES: "line", "speeddial", "blf", "list", "dnd" # SOFTKEY LABEL: Alpha numeric name for the softkey. The maximum number of characters for this value is 10 for speeddials and dnd, 9 chars for lines, blf # SOFTKEY VALUE: If softkey type is a speeddial, any DTMFs (from...

  • Page 424: 480I Ct Sample Configuration File

    # Not all possible paramters are shown, refer to the admin guide for # the full list of supported parameters, their defaults and valid # ranges. # The Aastra 480i, 480iCT, 9112i and 9133i phones will download 2 D-12 41-001129-00 Rev 09, Release 1.4.1...
  • Page 425 # the exception of assigning a static IP address to a phone and line # settings, which should only be set in the "<mac>.cfg" file. # The "aastra.cfg" file configures the settings server wide, while the # "<mac>.cfg" file configures only the phone with the MAC address for # which the file is named (for example, "00085d0304f4.cfg").
  • Page 426 IP Phone Administrator Guide Sample Configuration Files # Network Settings # ================ # Notes: If DHCP is enabled, you do not need to set these network # settings. Although depending on you DHCP server configuration you # may still have to set the dns address. D-14 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...
  • Page 427 Sample Configuration Files Sample Configuration Files #ip: # This value is unique to each phone on a server # and should be set in the "<mac>.cfg" file if # setting this manually. #subnet mask: #default gateway: #dns1: #dns2: # Time Server Settings # ==================== #time server disabled: 1 # Time server disabled.
  • Page 428 # Option 2: # If you are using a session border controller, you should set the # outbound proxy to the session border controller address #sip outbound proxy: sbc.aastra.com #sip outbound proxy port: 0 # a value of 0 enables SRV # lookups for the address of # the proxy.
  • Page 429 ## FTP server settings #ftp server: 192.168.0.131 # can be IP or FQDN #ftp username: aastra #ftp password: 480iaastra ## HTTP server settings (for http://bogus.aastra.com/firmware/) #http server: bogus.aastra.com # can be IP or FQDN #http path: firmware #------------------------------------------------------------------ # Dial Plan Settings...
  • Page 430 IP Phone Administrator Guide Sample Configuration Files # As you dial a number on the phone, the phone will initiate a call # when one of the following conditions are meet: (1) The entered number is an exact match in the dial plan (2) The "#"...
  • Page 431 Sample Configuration Files Sample Configuration Files # with a 0 or 1, any 5 digit number # beginning with a number between 2 and 8 # (inclusive) or a 12 digit number # beginning with 91 #sip dial plan terminator: 1 # enable sending of the "#"...
  • Page 432 0 - generic, 1 - BroadSoft SCA line 2 - Nortel line sip proxy ip: proxy.aastra.com # IP address or FQDN of proxy sip proxy port: 5060 # port used for SIP messages on the # proxy. Set to 0 to enable SRV # lookups sip registrar ip: aastra.com...
  • Page 433 - the proxy and registrar settings are taken from the global settings above sip line3 screen name: Support sip line3 user name: 4000 sip line3 display name: Aastra Support sip line3 auth name: support sip line3 password: 54321 sip line3 mode: 1...
  • Page 434 # There are a maximum of 18 softkeys that can be configured on the # 480i or 480iCT phone. These can be set up through either of the 2 # configuration files, depending on whether this is to be server wide # ("aastra.cfg") or phone specific ("<mac>.cfg").
  • Page 435 #------------------------------------------------------------------- # Cordless Handset Feature Keys # ============================= # Notes: # In addition to the configuration parameters that exist on the 480i # phone, following are the parameters specific to the 480i Cordless 41-001129-00 Rev 09, Release 1.4.1 D-23 DFW Phone 972-992-4600...
  • Page 436 Sample Configuration Files # phones' handset. These parameters can be defined either int the # aastra.cfg or the <mac>.cfg files. # The feature keys are displayed when the user presses the F button # on the cordless phone's hand set. If any changes to the features # keys are made using these parameters the feature keys that exist on # the hand set have to be refreshed.
  • Page 437 Sample Configuration Files Sample Configuration Files # is set to use Spanish Feature key 0 Gr label: "Gr-Line 1" # German label for the key. Displayed when the phone's language # is set to use German Feature key 0 It label: "It-Line 1" # Italian label for the key.
  • Page 438 IP Phone Administrator Guide Sample Configuration Files 58 - Menu (Options) 59 - Feature Key 60 - Redial 61 - Directory 62 - Callers' list 63 - Services 86 - Icom #Feature key 0 base event: 1 # Indicates a corresponding action to perform on the base set when # the "Feature key N hs event"...
  • Page 439 Sample Configuration Files Sample Configuration Files Feature key 0 control: 0 Feature key 0 hs event: 7 Feature key 0 base event: 1 Feature key 1 En label: "Conf." Feature key 1 Fr label: "Fr-Conf." Feature key 1 Sp label: "Sp-Conf." Feature key 1 control: 1 Feature key 1 hs event: 8 Feature key 1 base event: 12...
  • Page 440 IP Phone Administrator Guide Sample Configuration Files Feature key 5 Sp label: "Sp-Callers" Feature key 5 hs event: 62 Feature key 5 control: 1 Feature key 5 base event: 13 Feature key 6 En label: "Top" Feature key 6 Fr label: "Fr-Top" Feature key 6 Sp label: "Sp-Top"...

  • Page 441: 9112I Sample Configuration File

    # the full list of supported parameters, their defaults and valid # ranges. # The Aastra 480i, 480iCT, 9112i and 9133i phones will download 2 # configuration files from the TFTP server while restarting, the # "aastra.cfg" file and the "<mac>.cfg" file. These two configuration...
  • Page 442 IP Phone Administrator Guide Sample Configuration Files # DHCP Setting # ============ #dhcp: 1 # DHCP enabled. # DHCP: # 0 = false, means DHCP is disabled. # 1 = true, means DHCP is enabled. # Notes: # DHCP is normally set from the Options list on the phone or # the web interface # If DHCP is disabled, the following network settings will # have to be configured manually either through the configuration...
  • Page 443 # Option 2: # If you are using a session border controller, you should set the # outbound proxy to the session border controller address #sip outbound proxy: sbc.aastra.com #sip outbound proxy port: 0 # a value of 0 enables SRV # lookups for the address of # the proxy.
  • Page 444 # the alternative tftp server. ## FTP server settings #ftp server: 192.168.0.131 # can be IP or FQDN #ftp username: aastra #ftp password: 480iaastra ## HTTP server settings (for http://bogus.aastra.com/firmware/) #http server: bogus.aastra.com # can be IP or FQDN #http path: firmware -------------------------------------------------------------------- D-32 41-001129-00 Rev 09, Release 1.4.1...
  • Page 445 Sample Configuration Files Sample Configuration Files # Dial Plan Settings # ================== # Notes: # As you dial a number on the phone, the phone will initiate a call # when one of the following conditions are meet: (1) The entered number is an exact match in the dial plan (2) The "#"...
  • Page 446 # line type: 0 - generic, 1 - BroadSoft SCA line 2 - Nortel line sip proxy ip: proxy.aastra.com # IP address or FQDN of proxy sip proxy port: 5060 # port used for SIP messages on the D-34 41-001129-00 Rev 09, Release 1.4.1...
  • Page 447 # on the 9133i phone, and only 2 on the 9112i phone. These can be set # up through either of the 2 configuration files, depending on # whether this is to be server wide ("aastra.cfg") or phone specific # ("<mac>.cfg"). Each prgkey needs to be numbered from 1 - 7 (or 1 - # 2 on the 9112i), for example "prgkey2 type: speeddial".

  • Page 448: 9133I Sample Configuration File

    # a pound. For Boolean fields, 0 = false, 1 = true. # Comments: # This file contains sample configurations for the "aastra.cfg" or # "<mac>.cfg" file. The settings included here are examples only. # You should change/comment the values to suit your requirements.
  • Page 449 # for the full list of supported parameters, their defaults and # valid ranges. # The Aastra 480i, 480iCT, 9112i and 9133i phones will download 2 # configuration files from the TFTP server while restarting, the # "aastra.cfg" file and the "<mac>.cfg" file. These two...
  • Page 450 IP Phone Administrator Guide Sample Configuration Files # The "aastra.cfg" file configures the settings server wide, while # the "<mac>.cfg" file configures only the phone with the MAC # address for which the file is named (for example, # "00085d0304f4.cfg"). The settings in the "aastra.cfg" file will # be overridden by settings which also appear in the "<mac>.cfg"...
  • Page 451 Sample Configuration Files Sample Configuration Files #ip: # This value is unique to each phone on a server # and should be set in the "<mac>.cfg" file if # setting this manually. #subnet mask: #default gateway: #dns1: #dns2: # Time Server Settings # ===================== #time server disabled: 1 # Time server disabled.
  • Page 452 IP Phone Administrator Guide Sample Configuration Files #sip nortel nat timer: 60 # seconds between keep alive messages D-40 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...
  • Page 453 # Option 2: # If you are using a session border controller, you should set the # outbound proxy to the session border controller address #sip outbound proxy: sbc.aastra.com #sip outbound proxy port: 0 # a value of 0 enables SRV # lookups for the address of # the proxy.
  • Page 454 IP Phone Administrator Guide Sample Configuration Files D-42 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...
  • Page 455 ## FTP server settings #ftp server: 192.168.0.131 # can be IP or FQDN #ftp username: aastra #ftp password: 480iaastra ## HTTP server settings (for http://bogus.aastra.com/firmware/) #http server: bogus.aastra.com # can be IP or FQDN #http path: firmware #---------------------------------------------------------------- # Dial Plan Settings...
  • Page 456 IP Phone Administrator Guide Sample Configuration Files D-44 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...
  • Page 457 Sample Configuration Files Sample Configuration Files 0,1,2,3,4,5,6,7,8,9,*,# : matches the keypad symbols : matches any digit (0...9) : matches 0 or more repetitions of the : previous expression : matches any number inside the brackets : can be used with a "-" to represent a : range : expression grouping : either or...
  • Page 458 # Notes: These settings are used as the default configuration for the hard key lines on the phone. That is: L1 to L4 on the 480i and 480iCT L1 to L3 on the 9133i L1 on the 9112i These can be over-ridden on a per-line basis using the per-line settings.
  • Page 459 0 - generic, 1 - BroadSoft SCA line 2 - Nortel line sip proxy ip: proxy.aastra.com # IP address or FQDN of proxy sip proxy port: 5060 # port used for SIP messages on the # proxy. Set to 0 to enable SRV # lookups sip registrar ip: aastra.com...
  • Page 460 # on the 9133i phone, and only 2 on the 9112i phone. These can be # set up through either of the 2 configuration files, depending on # whether this is to be server wide ("aastra.cfg") or phone # specific ("<mac>.cfg"). Each prgkey needs to be numbered from # 1 - 7 (or 1 -2 on the 9112i), for example "prgkey2 type:...
  • Page 461 Sample Configuration Files Sample Configuration Files # PRGKEY TYPES: "line", "speeddial", "blf", "list", "dnd" # PRGKEY VALUE: If prgkey type is a speeddial, any DTMFs (from 0 - 9, *, "#") or a comma (,) for 500ms pause and 'E' for On-hook can be set for the value. If prgkey type is blf it is the extension you want to monitor.
  • Page 462 DFW Phone 972-992-4600...

  • Page 463: Sample Blf Softkey Settings

    Appendix E Sample BLF Softkey Settings About this appendix Introduction This appendix provides sample BLF softkey settings for both the Asterisk server and the BroadSoft BroadWorks server. Topics This appendix covers the following topics: Topic Page Sample BLF Softkey Settings page E-2 Asterisk BLF page E-2...

  • Page 464: Asterisk Blf

    Sample BLF Softkey Settings Asterisk BLF The following are sample softkey and programmable key configurations to enable Asterisk BLF support on Aastra IP phones. 480i and 480i CT Configuration Parameters for Asterisk BLF softkey1 type: blf softkey1 value: 9995551212 softkey1 label: John...

  • Page 465: Broadsoft Broadworks Blf

    The following are sample softkey and programmable key configurations to enable Broadsoft BroadWorks Busy Lamp Field support on Aastra IP phones. 480i and 480i CT Configuration Parameters for Broadsoft BroadWorks BLF Note: One softkey must be defined of type “list” for EACH monitored user.
  • Page 466 DFW Phone 972-992-4600...

  • Page 467: Sample Multiple Proxy Server Configuration

    Appendix F Sample Multiple Proxy Server Configuration About this appendix Introduction This appendix provides a sample multiple proxy server configuration. Topics This appendix covers the following topics: Topic Page Multiple Proxy Server Configuration page F-2 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...

  • Page 468: Multiple Proxy Server Configuration

    Multiple Proxy Server Configuration Multiple Proxy Server Configuration Multiple proxy servers can be configured in the aastra.cfg file or the <mac>.cfg file. In the example below, the default proxy setting is used if no specific setting is specified in the line configuration. Line2 and line3 are used for the global proxy configurations, while line1 and line4 use their own specific settings.
  • Page 469 Sample Multiple Proxy Server Configuration Multiple Proxy Server Configuration Continued..#line 2 sip line2 auth name: sip line2 password: sip line2 mode: 0 sip line2 user name: sip line2 display name: sip line2 screen name: #line 3 sip line3 auth name: sip line3 password: sip line3 mode: 0 sip line3 user name:...
  • Page 470 DFW Phone 972-992-4600...

  • Page 471: Creating An Xml Application

    G-4 Text Screen Object (Message Screens) page G-6 UserInput Object (User Input Screens) page G-7 Directory Object (Directory List Screen) (480i only) page G-12 Status Message Object (Idle Screen) page G-14 Execute Commands Object (for executing XML commands) page G-17...

  • Page 472: How To Create An Xml Application

    &gt; Creating XML Objects This section describes how to create XML objects. The Aastra IP phone XML API supports four proprietary objects that allow the creation of menu screens, message screens, input screens, and directory screens: • Text Menu Object (Menu Screens) •...

  • Page 473: Creating Custom Softkeys

    XML screen type (Text Menu, Text Screen, User Input, Directory). A developer can define up to six softkeys before the closing tag of any object on the 480i/480i CT. The following softkey functionality is available to the developer for the purpose of reordering or preserving the default functionality of the XML screens.

  • Page 474: Text Menu Object (Menu Screens

    Text Menu Object Implementation The following is how you would implement the Text Menu object. Note: For all available parameters you can use for the Text Menu object, and for an explanation of each parameter, see Aastra Telecom’s "XML Developer’s Guide". Softkeys: •...
  • Page 475 Creating an XML Application How to Create an XML Application XML example: <AastraIPPhoneTextMenu> <Title>Phone Services</Title> <MenuItem base = "http://10.50.10.53/"> <Prompt>Traffic Reports</Prompt> <URI> rss_to_xml.pl</URI> </MenuItem> <MenuItem> <Prompt>Employee List</Prompt> <URI>employees.xml</URI> </MenuItem> <MenuItem base =""> <Prompt>Weather</Prompt> <URI>http://10.50.10.52/weather.pl</URI> </MenuItem> </AastraIPPhoneTextMenu> XML Screen Example: Phone Services 1.Traffic Reports 2.Employee List 3.Weather...

  • Page 476: Text Screen Object (Message Screens

    Note: For all available parameters you can use for the Text Screen object, and for an explanation of each parameter, see Aastra Telecom’s "XML Developer’s Guide". Text Screen Object Implementation The following is how you would implement the Text Screen object.

  • Page 477: Userinput Object (User Input Screens

    The following is how you would implement the UserInput object using an IP Address. Note: For all available parameters you can use for the UserInput object, and for an explanation of each parameter, see Aastra Telecom’s "XML Developer’s Guide". Softkeys: •...
  • Page 478 IP Phone Administrator Guide How to Create an XML Application XML Description: <AastraIPPhoneInputScreen type = "IP/string/number" password = "yes/no" destroyOnExit = "yes/no"> <!-password attribute is optional and set to "no" by defaultà <!-destroyOnExit is optional and "no" by default à <Title>Title string, usually same as menu title</Title>...
  • Page 479 Creating an XML Application How to Create an XML Application XML Example: <AastraIPPhoneInputScreen type = "IP"> <Title>Proxy Server</Title> <Prompt>Server IP:</Prompt> <URL>http://10.50.10.53/script.pl</URL> <Parameter>proxy</Parameter> <Default></Default> <AastraIPPhoneInputScreen> XML Screen Example: Proxy Server Server IP: Backspace Cancel Done 41-001129-00 Rev 09, Release 1.4.1 DFW Phone 972-992-4600...
  • Page 480 IP Phone Administrator Guide How to Create an XML Application UserInput Object Implementation (Number) The following is how you would implement the UserInput object using Numbers. Softkeys: • 1=Backspace, • 5=Cancel, • 6=Done XML Example: <AastraIPPhoneInputScreen type = "number"> <Title>Proxy Port</Title> <Prompt>Port:</Prompt>...
  • Page 481 Creating an XML Application How to Create an XML Application UserInput Object Implementation (String) The following is how you would implement the UserInput object using Strings in XML. Softkeys: • 1=Backspace, • 2=Dot, • 3=Tri-Mode key, • 4=Nextspace, • 5=Cancel, •...

  • Page 482: Directory Object (Directory List Screen) (480I Only

    The following is how you would implement the Directory object in XML. Note: For all available parameters you can use for the Directory object, and for an explanation of each parameter, see Aastra Telecom’s "XML Developer’s Guide". If the URI entry contains a "?" the phone appends an "&" instead.
  • Page 483 <Prompt>480i - John Doe 1</Prompt> <URI> 10.50.10.49</URI> </MenuItem> <MenuItem> <Prompt>9133i - John Doe 2</Prompt> <URI>4326</URI> </MenuItem> <MenuItem> <Prompt>480i CT - John Doe 3</Prompt> <URI>9982691234</URI> </MenuItem> </AastraIPPhoneDirectory XML Screen Example:: My Directory (1/6) 1. 480i John Doe 1 2. 9133i John Doe 2 3.

  • Page 484: Status Message Object (Idle Screen

    The messages display when the server pushes XML information to the phone. The 480i/480i CT phones display messages on the second line in the phone window. (where “No Service” would display if there was no service. If there is no service on the phone, the “No Service”...
  • Page 485 Creating an XML Application How to Create an XML Application Examples Example 1: The following is an example of using the AastraIPPhoneStatus object: <AastraIPPhoneStatus> <Session>abc12345</Session> <Message index="3">Server side call forwarding disabled</Message> <AastraIPPhoneStatus/> In this example, the AastraIPPhoneStatus object sends the default behavior with the status message (i.e., the status message is added to the scroll list).
  • Page 486 The default time is 5 seconds for each message to display before scrolling to the next message. You can configure this option via the configuration files or the Aastra Web UI. Changes are dynamic and apply to the phone immediately.

  • Page 487: Execute Commands Object (For Executing Xml Commands

    Creating an XML Application How to Create an XML Application Execute Commands Object (for executing XML commands) An AastraIPPhoneExecute object on the IP phones allows the phone to execute commands using XML. The phones support the following execute object commands: •...
  • Page 488 IP Phone Administrator Guide How to Create an XML Application The following example shows an AastraIPPhoneExecute object using the Reset command: <AastraIPPhoneExecute> <ExecuteItem URI="Command: Reset"/> </AastraIPPhoneExecute> Note: If you specify a command as a URI attribute (instead of a URL), the keyword "Command"...

  • Page 489: Http Post

    Creating an XML Application How to Create an XML Application HTTP Post In addition to initiating a request to an XML application from the Services menu, an HTTP server can push an XML object to the phone via HTTP Post. The phone parses this object immediately upon receipt and displays the information to the screen.
  • Page 490 IP Phone Administrator Guide How to Create an XML Application Example 2: Below is a sample php source code which sends an XML object to an Aastra phone. <?php function push2phone($server,$phone,$data) # url-encode the xml object $xml = "xml=".urlencode($data); $post = "POST / HTTP/1.1\r\n";...
  • Page 491 Creating an XML Application How to Create an XML Application HTTP Refresh Header An HTTP refresh header feature can be used with the XML screen objects on the IP phones. This feature includes the following: • All current XML screen objects have the ability to be refreshed by adding a Refresh and URL setting to the HTTP headers.

  • Page 492: Xml Schema File

    Schema file provided in this section. This helps you find any parsing errors that may exist, and verify that your XML objects conform to the Aastra API. Note: Aastra IP phonees do not contain validating XML parsers. There are many free XML validators available on the Web (i.e., http://apps.gotdotnet.com/xmltools/xsdvalidator/Default.aspx) that can perform validation using the schema file.
  • Page 493 Creating an XML Application How to Create an XML Application <xs:element name="Prompt" type="xs:string" /> <xs:element name="URI" type="xs:string" /> </xs:sequence> <xs:attribute name="base" type="xs:string" /> </xs:complexType> </xs:element> </xs:sequence> <xs:attribute name="destroyOnExit" default="no"> <xs:simpleType> <xs:restriction base="xs:string"> <xs:pattern value="yes|no" /> </xs:restriction> </xs:simpleType> </xs:attribute> </xs:complexType> </xs:element> <xs:element name="AastraIPPhoneInputScreen">...
  • Page 494 IP Phone Administrator Guide How to Create an XML Application </xs:attribute> <xs:attribute name="destroyOnExit" default="no"> <xs:simpleType> <xs:restriction base="xs:string"> <xs:pattern value="yes|no" /> </xs:restriction> </xs:simpleType> </xs:attribute> </xs:complexType> </xs:element> <xs:element name="AastraIPPhoneDirectory"> <xs:complexType> <xs:sequence> <xs:element name="Title" type="xs:string" /> <xs:element name="MenuItem" minOccurs="1" maxOccurs="15"> <xs:complexType> <xs:sequence> <xs:element name="Prompt" type="xs:string" /> <xs:element name="URI"...

  • Page 495: Limited Warranty

    Exclusions Aastra Telecom does not warrant its telephone sets to be compatible with the equipment of any particular telephone company. This warranty does not extend to damage to products resulting from improper installation or operation, alteration, accident, neglect, abuse, misuse, fire or natural causes such as storms or floods, after the telephone is in your possession.
  • Page 496 After Warranty Service Aastra Telecom offers ongoing repair and support for this product. This service provides repair or replacement of your Aastra Telecom product, at Aastra Telecom's option, for a fixed charge. You are responsible for all shipping charges.
  • Page 497 Index Aastra Web UI advanced settings description call forwarding basic settings description configuraton method for enabling and disabling configuring operation description enabling/disabling status description call waiting tone Administration Guide, for IP phone configuring administrator options call waiting tones auto-answer callers list...
  • Page 498 configuration server settings encryption methods for configuring network overview cordless keys procedure for configuring factory default settings DHCP firmware configuring configuration server requirement for not using description of using installation considerations dial plan installation methods configuring installing dial plan terminator flash key overview dial plans...
  • Page 499 480i and 480iCT softkey enabling/disabling 9112i and 9133i programmable key overview Aastra Web UI Action URIs advanced SIP audio transmit and receive adjustment settings auto-answer settings BLF subscription period configuring blind transfer setting...
  • Page 500 parameters, setting in configuration files configuring park key ring tones configuring park/pickup about parked/pickup calls configuring a static configuration configuring configuring programmable configuration using silenace suppression config files RTP port configuring programmable configuration using Web RTP settings Basic Codecs programmable configuration of customizing Codec preference list static configuration of DTMF method...
  • Page 501 Softkey settings for 480i, 480iCT, 480i BroadSoft warranty for 9112i and 9133i warranty exclusions softkeys configuring softkeys, state-based speeddial key Xfer key, enabling/disabling spre key SRV lookup, configuring...
  • Page 502 DFW Phone 972-992-4600...
  • Page 503 DFW Phone 972-992-4600...
  • Page 504 Models 480i, 480i CT, 9112i, 9133i © 2006 Aastra Telecom Inc. If you’ve read this owner’s manual and consulted the Troubleshooting section and still have problems, please visit our website at www.aastra.com or call 1-800-574-1611 for technical assistance. 41-001129-00 Rev 09 Release 1.4.1...

This manual is also suitable for:

480i ct9112i9133i

Table of Contents
