HDMI ARC CONTROL BOX
HDMI ARC & Audio Extractor
INSTRUCTION MANUAL
MODEL : SB-5610
HDMI ARC BOX & AUDIO EXTRACTOR
ARC BOX WITH HDMI TO SPDIF & AUDIO EXTRACTOR
HDMI HIGH QUALITY ARC/SPDIF/AUDIO Series
Thank you for purchasing the SB-5610 HDMI To HDMI-ARC-SPDIF-AUDIO Extractor Control Box. You will find
this unit easy to install and highly reliable but it is essential that you read this manual thoroughly before attempting
to use ARC Control Box & Extractor.
Part No.: ENCL005610000A1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Shinybow USA SB-5610
Summary of Contents for Shinybow USA SB-5610
- Page 1 HDMI HIGH QUALITY ARC/SPDIF/AUDIO Series Thank you for purchasing the SB-5610 HDMI To HDMI-ARC-SPDIF-AUDIO Extractor Control Box. You will find this unit easy to install and highly reliable but it is essential that you read this manual thoroughly before attempting to use ARC Control Box &...
-
Page 2: Safety Information
SAFETY INFORMATION Save the carton and packing material even if the equipment has arrived in good condition. Should you ever need to ship the unit, use only the original factory packing. Read all documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. -
Page 3: Safety Notice
INTRODUCTION The SB-5610 is the high quality HDMI ARC Control Box with HDMI Audio Extractor. Audio are ARC, DVD Source SPDIF and Analog stereo, This control Box can link audio (ARC or Source SPDIF) to TV or Audio Amplifier and turn ON or turn OFF the TV or Audio Amplifier speaker. -
Page 4: Features And Specifications
FEATURES & SPECIFICATIONS FEATURES • HDMI ARC Control Box with Source SPDIF and analog Audio Extractor • HDMI 1.3a, HDMI 1.3c (CTS), DVI 1.0 and HDCP compliant • Support HDMI in/out Repeater with Equalizer • Support 3D Video Format in HDMI 1.4 •... -
Page 5: Command Code
RS-232 PROTOCOL COMMAND RS-232 TRANSMISSION FORMAT • Baud Rate: 9600 • Date Bit : 8 • Parity: None • Stop Bit: 1 Bit COMMAND CODE RESPONSE DESCRIPTION ARC 00 Switch to SOURCE UN-Know Command ARC 01 Switch to ARC UN-Know Command HDMIADO 00 UN-Know Command HDMIADO 01... -
Page 6: Typical Hookup And Operation
TYPICAL HOOKUP AND OPERATION SB-5610: FRONT AND REAR PANEL INSTRUCTIONS FRONT & REAR PANEL CONTROL BUTTON 1. DC Input: 12VDC 1. EDID: 2. HDMI Input: Signal from HDMI player source - TV: Passing EDID source to TV 3. RS-232 Input: RS-232 interface series - Bitstream: Multi Audio formats 4. -
Page 7: Limited Warranty
LIMITED WARRANTY LIMITED WARRANTY SHINYBOWUSA WARRANTY SHINYBOWUSA Technology warrants this product against defects in materials and workman ship for a period of 3 years from the date of purchase. Should this product, in SHINYBOWUSA Technology’s opinion, Prove defective within this warranty period, SHINYBOWUSA Technology, at its option, will repair this product without charge, to whatever extent it shall deem necessary to restore said product to proper operation condition. - Page 8 M ULT IM EDI A A UDIO A ND V I SU A L 1399 Wildfire Lane | Frisco, TX 75034 1-877-SHINY-USA 1-877-744-6987 1-972-377-2508 sales@shinybowusa.com www.shinybowusa.com...
