SDI
Operation
To operate the unit, plug the module into a NIM pre-wired bin with the power turned off.
Turn on the power to the NIM bin. A red LED located on the bottom of the front panel
will turn on when power is applied to the unit. The signal to be distributed should be
connected to the SMA bulkhead on the front panel labeled "input". Any output can be
used to drive another HPDA distribution amplifier. The red LED located on the top of
the front panel labeled STATUS monitors the input level to the module. When a signal
is present that exceeds +7 +/- 1 dBm the LED will be on.
Copyright © SpectraDynamics, Inc. 2012
5
