SDI
The Front Panel
Power LED
The LED at the bottom of the front panel is on when power is applied to unit and the
unit is operating properly.
Signal LED
The LED labeled STATUS will turn on when all outputs are active and the signal levels
are greater than +7 dBm.
SMA INPUT
The signal to be distributed should be connected to the SMA jack labeled input.
SMA OUTPUTS
The five outputs of each amplifier module are DC isolated from the chassis ground to
prevent ground loops. Make sure that the amplifier ground does not float to a potential
greater than 50 VDC from the chassis ground. An output ground potential greater than
50 VDC will damage the amplifier and could cause injury or death to personnel.
Copyright © SpectraDynamics, Inc. 2012
3
