Operation
This unit is designed to operate only with the specified voltage on page 4. For
conversion to a different voltage of operation contact SDI.
To operate the unit, locate the AC power entry module on the rear of the enclosure and
connect the power cord. Plug the unit into an appropriate power outlet. A green LED
on the front panel labeled POWER will turn on. Attach the signal to be distributed to the
SMA input connector on the back panel. Any HPDA-15RM-A output may be used to
drive the input of another distribution module.
Absolute Maximum Ratings
Input power
Reverse Power
Input DC Voltage
Output DC Voltage
Storage Temperature
Operation Environment
Rack Mount Chassis
+20dBm Maximum
+20dBm Maximum
10 VDC Maximum
50 VDC Maximum
-10 to +75 ºC
0 to +50 ºC
1U H, 19" W, 14" D
Copyright © SpectraDynamics, Inc. 2010
SDI
5
