SDI

The Front Panel

AC Power LED
The LED labeled POWER is on when power is applied to unit and the unit is operating
properly.
Signal LED
The LED labeled SIGNAL will turn on when you apply an input signal to the SMA input
connector greater than +7 dBm.
Copyright © SpectraDynamics, Inc. 2010
3
