The Front Panel
AC Power LED
The POWER LED is on when power is applied to unit and the unit is operating properly.
Monitor LED
The Monitor LED labeled 1 will be on if all outputs on the first HPDA module have
signal levels greater than +7 dBm. The Monitor LED labeled 2 will be on if all outputs
on the second HPDA module have signal levels greater than +7dBm. The Monitor LED
labeled 3 will be on if all outputs on the third HPDA module have signal levels greater
than +7dBm.
