Summary of Contents for CTC Union FSW-2104W

  • Page 1 FSW-2104W 4-Port Media Streaming Plus 1 Fiber Port Switch...
  • Page 3 CTC Union Technologies makes no warranty, representation, or guarantee regarding the suitability of its products for any particular purpose, nor does CTC Union assume any liability arising out of the application or use of any product and specifically disclaims any and all liability, including without limitation any consequential or incidental damages.
  • Page 4 This manual supports the following models: FSW-2104W This document is the current official release manual. Please check CTC Union's website for any updated manual or contact us by E-mail at info@ctcu.com. Please address any comments for improving this manual or to point out omissions or errors to marketing@ctcu.com.
  • Page 5: Table Of Contents

    Contents Chapter 1: About This Guide ....................7 Chapter 2: Introduction ......................7 2.1 Product Description...................... 7 2.2 Product Features......................7 Chapter 3: Connecting to Router..................... 9 3.1 System Requirements....................9 3.2 Installation Environment Requirements..............9 3.3 Connecting the Router....................9 Chapter 4: Fast Installation and Configuration..............
  • Page 7: Chapter 1: About This Guide

    Chapter 2: Introduction 2.1 Product Description The FSW-2104W is a 4-port Web Smart switch with 1-port wire speed NAT-router. Its designed is dedicated to IPTV Home Gateway network solutions. The FSW-2104W is intended for Multimedia applications in the Digital Home, it supports the IGMP proxy,IGMP Snooping V1/V2 function, QoS function and wire speed NAT function.
  • Page 8 FSW-2104W Multimedia Residential Gateway 2.3 Product Specifications IEEE802.3 10Base-T, Standards IEEE802.3u 100Base-TX, 100Base-FX Topology Star CSMA/CD,DHCP, TCP/IP、 PPPoE、 DHCP、 NAT、 ICMP、 SNTP、 Protocol IGMP Ethernet: 10Mbps (Half Duplex), 20Mbps (Full Duplex) Data Transfer Rate Fast Ethernet: 100Mbps (Half Duplex), 200Mbps (Full Duplex) 10Base-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ù...
  • Page 9: Chapter 3: Connecting To Router

    5. Power on your PC(s) and Cable/DSL modem. Chapter 4: Fast Installation and Configuration This chapter describes how to configure the basic functions of your FSW-2104W Cable/DSL router. You may access the Internet via the router immediately after it has been successfully configured.
  • Page 10 FSW-2104W Multimedia Residential Gateway Figure 4-1 Successful result of Ping command If the result displayed is same as to what is shown in figure 4-1, the connection between your PC and the router has been established. Figure 4-2 Fail result of ping command If the result displayed is similar to what shown in figure 4-2, it means that your PC has not connected to the router.
  • Page 11: Chapter 5: Configuring The Router

    FSW-2104W Multimedia Residential Gateway Chapter 5: Configuring the Router 5.1 login Enter the User name and password correctly and click OK button (shown in figure 5-1). After your successful login, you can configure and manage the router. There are fourteen main menus are: Status, LAN, WAN, NAT, Firewall, Qos, IGMP, SNMP, SNTP, VLAN config, Port config, Storm Control, Tool, System Logs.
  • Page 12: Lan

    FSW-2104W Multimedia Residential Gateway 5.2.1.2 LAN Status This field displays the current settings or information for the LAN, including the MAC address, IP address and Subnet Mask. Figure 5-2 Router Status 5.3 LAN Figure 5-3 the LAN menu There are two submenus under the LAN menu (shown in figure 5-3): LAN, DHCP Clients. Click any of them,...
  • Page 13 FSW-2104W Multimedia Residential Gateway 5.3.1 LAN Please configure the IP parameters of the LAN on this page. Figure 5-4 LAN Setup and DHCP Setup • IP Address - Enter the IP address of your router in dotted-decimal notation (factory default: 192.168.123.252).
  • Page 14: Wan

    FSW-2104W Multimedia Residential Gateway 5.3.2 DHCP Clients This page shows Host IP Address, Host IP Address for each DHCP Client attached to the router (figure 5-5): Figure 5-5 DHCP Clients • NO. - The index of the DHCP Client •...
  • Page 15 FSW-2104W Multimedia Residential Gateway 5.4.1 WAN Connection You can configure the WAN port parameters on this page. First, please choose the WAN Connection Type (Dynamic IP/Static IP / PPPoE ) to the Internet. The default type is PPPoE. If you aren’t given any login parameters (fixed IP address, logging ID, etc), please select Dynamic IP.
  • Page 16 FSW-2104W Multimedia Residential Gateway 2. If you choose Static IP, you should have fixed IP parameters specified by your ISP. The Static IP settings page will appear, shown in figure 5-8: Figure 5-8 WAN - Static IP Please type the following parameters into the spaces provided: •...
  • Page 17 There are two choices you can select. The system default is NAT Mode, In this Mode, you can use FSW-2104W as a router. If you select Bridge Mode, the FSW-2104W will be used as a switch. After you select the Bridge...
  • Page 18: Nat

    FSW-2104W Multimedia Residential Gateway 5.5 NAT Figure 5-11 The NAT menus There is one submenu under the NAT menu (shown in figure 5-11): Virtual Server. Click it, and you will be able to configure the corresponding function. The detailed explanations for each submenu are provided below : 5.5.1 Virtual Server...
  • Page 19: Firewall

    FSW-2104W Multimedia Residential Gateway 5.6 Firewall Figure 5-13 Firewalls There are two submenus under the Firewall menu (shown in figure 5-13): WAN IP Filter and LAN MAC Filter. 5.6.1 WAN IP Filter Using The Wan IP Filtering feature allows you to control Internet Access by WAN IP addresses. The IP Address...
  • Page 20: Qos

    FSW-2104W Multimedia Residential Gateway 5.7 QoS Figure 5-16 QoS There are two submenus under the Tools menu (shown in figure 5-16): Qos Priority, Qos(DSCP) Configuration. Click any of them, and you will be able to configure the corresponding function. 5.7.1 QoS Priority Configuration Figure 5-17 QoS Priority Configuration •...
  • Page 21: Igmp

    FSW-2104W Multimedia Residential Gateway 5.8 IGMP Figure 5-19 IGMP Multicast forwarding enables transmitting packets from either a specific multicast group to a source or from a nonspecific source to a multicast group. There are two submenus under the Tools menu (shown in figure 5-19): IGMP Configuration, IGMP Status.
  • Page 22: Snmp

    FSW-2104W Multimedia Residential Gateway 5.8.2 IGMP Status You can see the IGMP status on this page, shown in figure 5-21: Figure 5-21 IGMP Status • NO.:The number of the IGMP entries. • IP Multicast Group ID:The ID of IP Multicast Group. Each IP Multicast Group have only one ID.
  • Page 23: Sntp

    FSW-2104W Multimedia Residential Gateway • SNMP Mode.:Enable or Disable the SNMP mode • SNMP Community:the SNMP Community, include public or private. • SNMP SERVER: the IP of SNMP SERVER. • SNMP SERVER Port: the port of SNMP SERVER. • SNMP Available IP: the Available IP of SNMP.
  • Page 24: Vlan Configuration

    FSW-2104W Multimedia Residential Gateway 5.11 VLAN Configuration There is only one submenu under the Tools menu (shown in figure 5-27): Tag VLAN Configuration. Click it, and you will be able to configure the corresponding function. Figure 5-27VLAN configuration 5.11.1 Tag VLAN Configuration Figure 5-28 802.1Q VLAN...
  • Page 25: Storm Control

    FSW-2104W Multimedia Residential Gateway 5.12.1 Port Para Figure 5-30 Port Para Configuration • Port : There are five ports you can select to modify(WAN, LAN-1, LAN-2, LAN-3, LAN-4). • Speed:Here you can select the speed of the port . •...
  • Page 26: Tool

    FSW-2104W Multimedia Residential Gateway 5.13.1 Storm Control Figure 5-33 Storm Control • Broadcast Strom:select enable if you want control the speed of Broadcast packets... • Multicast Strom control:select enable if you want control the speed of Multicast packets... • UL Strom:select enable if you want control the speed of UL packets..
  • Page 27 FSW-2104W Multimedia Residential Gateway 5.14.2 Restart This page (shown in figure 5-36) allows you to reboot the router: Figure 5-36 Reboot Click the Reboot button to restart the router. Some settings of the router will take effect only after rebooting, which include: •...
  • Page 28: System Logs

    FSW-2104W Multimedia Residential Gateway Figure 5-38 User Name/Password Management It is strongly recommended that you change the factory default user name and password of the router. All users who try to access the router's web-based utility will be prompted for the router's user name and password.
  • Page 29 FSW-2104W Multimedia Residential Gateway 5.15.1 Log This page (shown in figure 5-40) allows you to query the Logs of the router. Figure 5-40 System Logs The router can keep logs of all traffic. You can query the logs to find what happened to the router.
  • Page 30: Appendix A: Glossary

    FSW-2104W Multimedia Residential Gateway Appendix A: Glossary • DDNS (Dynamic Domain Name System) – The capability of assigning a fixed host and domain name to a dynamic Internet IP address. • DHCP (Dynamic Host Configuration Protocol) - A protocol that automatically configure the TCP/IP parameters for the all the PCs that are connected to a DHCP server.
