- Page 1 Arecont Vision D4SO Outdoor Dome Series Installation Manual 0 | P a g e...
- Page 2 Arecont Vision D4SO Outdoor Dome Series Installation Manual D4SO Outdoor Dome Installation Manual Inside the box: Remove camera and hardware from the box. Arecont Vision D4SO Dome Camera Using the Mounting Template, prepare Mounting template the mounting provisions for camera C.
- Page 3 Arecont Vision D4SO Outdoor Dome Series Installation Manual Run Ethernet cable through the hole on the bottom of D4SO and plug it into the RJ45 port ® on Arecont Vision’s compact MegaVideo camera. (Image 3) . NOTE: If the camera will be powered via PoE, please skip to step 5.
- Page 4 Arecont Vision D4SO Outdoor Dome Series Installation Manual If you are using the side conduit opening, Adjust lens tilt as required and tighten the remove the conduit plug by first removing the screw. CAUTION: To properly install camera, socket set screw using one of provided Allen the U bracket needs to be installed between keys (Image 5).
- Page 5 Arecont Vision D4SO Outdoor Dome Series Installation Manual Adjusting the Focus: To focus the lens, loosen the three set screws as shown in Image 9 and adjust each as needed. A adjusts the zoom, B adjusts the iris, C adjusts the focus.
- Page 6 Arecont Vision D4SO Outdoor Dome Series Installation Manual D4SO Pendant Mount (MD-CMT) Installation Instructions Inside the box: Top shield Pendant Mount C. Mounting template D. Pack of four (4) machine screws Pack of four (4) small machine screws Pack of four (4) wood screws and four (4)
- Page 7 Arecont Vision D4SO Outdoor Dome Series Installation Manual D4SO Wall Mount (MD-WMT2) Installation Instructions Caution: Remove Wall Mount and hardware from the box. MD-WMT2 only fits with SV-JBA and SV-EBA but not with MD-JBA and MD-EBA! Inside the box: Wall mount ( Fit 1.5 NPT Standard) Top shield C.
- Page 8 Arecont Vision D4SO Outdoor Dome Series Installation Manual D4SO Wall Mount Cap (MD-CAP) Installation Instructions Inside the box: Wall Mount Cap (MD-CAP) Pack of four (4) machine screws MD-CAP Not included but needed: • 1½” NPT Pipe 1 ½” Coupling •...
- Page 9 Arecont Vision D4SO Outdoor Dome Series Installation Manual D4SO Junction Box Adapter (MD-JBA) Installation Instruction Caution: Remove Junction Box and hardware from the MD-JBA only fits with D4SO and MD-CMT but not with MD-WMT2! Inside the box: Junction Box Adapter Large round rubber gasket C.
- Page 10 Arecont Vision D4SO Outdoor Dome Series Installation Manual D4SO Junction Box Adapter (SV-JBA) for MD-WMT2 Installation Instruction Caution: SV-JBA only fits with MD-WMT2 but not with D4SO and MD-CMT! Inside the box: Junction Box Adapter Pack of four (4) machine screws C.
- Page 11 Arecont Vision D4SO Outdoor Dome Series Installation Manual D4SO Flush Mount Adapter (MD-FMA) Installation Instructions Inside the box: Screw the “lever screws” until the FMA is snuggly installed, as shown in Image 23. The White Trim Ring “Support Arm” will ride down the screw to Flush Mount Adapter compress the mounting surface.
- Page 12 Arecont Vision D4SO Outdoor Dome Series Installation Manual D4SO Electrical Box Adapter (MD-EBA) Installation Instructions Caution: Attach Electrical Box Adapter to Electrical Box as shown in Image 26. MD-EBA fits with D4SO and MD-CMT but not with MD-WMT2! Attach Dome to Electrical Box Adapter as shown in Image 27.
- Page 13 Arecont Vision D4SO Outdoor Dome Series Installation Manual D4SO Electrical Box Adapter (SV-EBA) for SV-WMT2 Installation Instructions Caution: Attach Electrical Box Adapter to Electrical Box. SV-EBA fits with MD-WMT2 but not with D4SO and Attach Dome to Electrical Box Adapter as MD-CMT! shown in Image 29.
- Page 14 Arecont Vision D4SO Outdoor Dome Series Installation Manual D4SO Pole Mount Adapter (MD-PMA) Installation Instructions Inside the box: Run Ethernet Cable and outside power cable (if necessary) through the Compress Fittings Pole Mount Adapter and D4SO Wall Mount. 2x Compress Fittings C.
- Page 15 Arecont Vision D4SO Outdoor Dome Series Installation Manual D4SO Corner Mount Adapter (MD-CRMA) Installation Instructions Inside the box: Corner Mount Adapter 2x Compression Fittings C. Pack of four (4) machine screws D. 2x Packs of four (4) wood screws and four...
- Page 16 Arecont Vision D4SO Outdoor Dome Series Installation Manual D4SO I/O Cable Connection Not included but needed: • Run the I/O cable through the hole in the Flat head screw driver bottom of the camera and plug it into the “J7”...
- Page 17 Arecont Vision D4SO Outdoor Dome Series Installation Manual D4SO Heater (MD-1HK) Accessory Inside the box: Heater Screw the heater board to the standoffs as shown in Image 40. Two (2) screws Not included but needed: • #1 Phillips head screw driver...
- Page 18 Arecont Vision D4SO Outdoor Dome Series Installation Manual 17 | P a g e...
