Summary of Contents for Ganz Digimaster Series DR8HRD

  • Page 2: Table Of Contents

    S p e c i f i c a t i o n & O r g a n i z a t i o n - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - S p e c i f i c a t i o n s - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1 2 P r o d u c t C o n t e n t s L i s t...
  • Page 3 U s e r - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - U s e r M a n a g e m e n t - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 0...
  • Page 4 R e c o r d i n g - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7 5 U s e r - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7 6 N e t w o r k...
  • Page 5 It is important to note here that some features, figures, pictures and references can only be applied to just one model. • GANZ cannot be held responsible if the DVR is damaged due to the use of non-compatible devices with this product. If you have any doubts, please check.
  • Page 6 All copyrights of this manual are reserved by CBC (America) Corp., CBC Group, and CBC Co., Ltd. © Copyright 2010 Any reproduction or republishing of this manual for commercial purposes is prohibited. It is prohibited to transfer this manual via online media such as, but not limited to, the Internet. It is also prohibited to post, distribute or translate this manual without permission from CBC.
  • Page 7 The following are warnings and precautions to ensure user safety and prevention of property damage. Please read the information below thoroughly.

  • Page 11: Important Safety Instructions

    Important Safety Instructions 1) Read all instructions contained in this manual. 2) Keep a copy of these instructions for future reference. 3) Read all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a dry cloth. 7) Do not block any of the ventilation openings.

  • Page 12: S P E C I F I C A T I O N

    Specifications & Organization 1. Device Specifications DR8HRD/DR16HRD Video Standard NTSC/PAL Audio Bi-Directional Audio Monitor Display Real Time: 30ips (NTSC) or 25ips (PAL), per camera Covert Camera Operation Programmable Up to 1,000,000 event log entries for user login/out, configuration changes, Event/Log Search remote access, connects/disconnects.
  • Page 13 Specifications & Organization 1. Device Specifications Pre-Alarm Recording Up to 5 seconds, programmable per camera OSD Languages English, Spanish, Portuguese, French, Russian, Polish, German, Italian Ethernet/LAN Network Interface Gigabit Ethernet, RJ-45 Live View, Search, Playback, Configuration, Archiving Remote Function Support for CMS Software, Web R/A and Smart Phone Watermarked Video &...

  • Page 14: P R O D U C T C O N T E N T S L I S

    Specifications & Organization 2. Product Contents List Please check to make sure that all of the product contents are present after opening the product packaging. ① Basic Contents...
  • Page 15 12V DC Adapter DR8HRD / 16HRD Unit AC Power Cable Instruction Manual Remote Controller Installation CD AAA Battery x 2 ② Optional Contents Internal Hard Disk Drive...

  • Page 16: S Y S T E M O R G A N I Z A T I O

    Specifications & Organization 3. System Organization VGA Monitor...

  • Page 17: Product Description

    Product Description 1. Front Panel ① POWER : System Power On / Shutdown ② DISPLAY : Switch Screen Division Modes (and Screen Rotation Mode) ③ SEQUENCE : Toggle Sequence Mode ④ PANIC : Trigger Panic Recording Mode and Panic Relay Output ⑤...
  • Page 18 Product Description 2. Rear panel description. CAMERA INPUTS and LOOP OUTPUTS: Connect up to 16 camera inputs. Loop outputs can be used for connection to other equipment. COMPOSITE AND S-VIDEO MAIN: MONITOR CONNECTIONS Both outputs can be used at the same time if more than one main monitor connection is required.
  • Page 19 Selectable Video outputs are HD, VGA, SD. Video output selection to choose only one. If user selects the video output to two or more duplicate, the video may not be output normally. If monitor spec doesn’t support DDC, the monitor can’t be recognized. 1) If you select HD output, 2) If you select VGA output, 3) If you select SD output,...

  • Page 20: R E M O T E C O N T R O L L E R D E S C R I P T I O

    – – 3. Remote Controller description. POWER SETUP : Go to Main Setup Menu ON/OFF Channel Selection Buttons (also used for Password Digit Entry) ID Button Select DVR Unit ID ENTER : Confirm / Select / Next Screen RETURN Cancel / Deselect Navigation Buttons Used for Playback Control, Previous Screen...
  • Page 21 & & • Connect up to 16 CAMERA INPUTS as necessary. • Connect one or more monitors to the DVR using the COMPOSITE, VGA, S-Video and HD MONITOR connections. • Connect power to the DVR, using the provided AC power cord or DC 12V Power Adapter (depending on model). The DVR will check for proper power connection and emits two beeps if system power test is OK.

  • Page 22: L I V E D I S P L A

    MENU CONTROL All menus can be controlled from this ‘Status Bar’ with either the USB mouse or Front Panel buttons. SCREEN DIVISION Select the ‘DISPLAY’ button and the screen division menu will appear. Select the screen type (1, 4, 6, 8, 9, 16 and rotation sequence). SEQUENCE MODE (User can select a sequence as one of the options within the screen division menu.) Press the ‘SEQ’...

  • Page 23: D I G I T A L Z O O

    1) CAM: Select the Channel of the PTZ device which you are controlling. 2) Preset: Select the number of the preset you are working with (1 ~ 254). 3) Set: Sets the current PTZ position as the selected Preset number. 4) GOTO: Tells the PTZ device to move to the position of the selected Preset.

  • Page 24: P A N I C R E C O R D I N

    LOG SEARCH User can see a live event log window, which shows each new event as it occurs. Caution) When POS function is activated, user can’t use Live LOG function. PANIC RECORDING - This function button is used to toggle the Panic Recording mode On/Off. - When Panic Recording mode is enabled, you will see a red recording icon with “P”...

  • Page 25: Q U I C K M E N

    QUICK MENU You may access the ‘Quick Menu’ by right-clicking on any channel which you would like to control. 1. Freeze On/Off: User can freeze the live display of any channel. While the other channels will continue to show live view video, the frozen channel display is stopped. Click once more to return to live view video. 2.

  • Page 26: S Y S T E M S E T U

    SYSTEM SETUP Click the ‘MENU’ button and choose the ‘SYSTEM SETUP’ menu. - To navigate around any items in the setup menu, use the CURSOR KEYS and the ‘ENTER’ and ‘RETURN’ buttons. - In general, the ‘ENTER’ button is used to select a particular field to edit, and then is pressed again to confirm changes. - The ‘RETURN’...

  • Page 27: Camera

    SYSTEM SETUP CAMERA From the ‘System Setup’ menu, click on the ‘CAMERA’ submenu. CAMERA: CAMERA SETUP Left-click on the CAMERA SETUP menu. Double-click on the ‘TITLE’ field to change the camera name. Click the ‘COVERT’ or ‘AUDIO’ fields for the desired channel. Then, use the button to modify each value.
  • Page 28 SYSTEM SETUP Modify each value using the button. The selected channel is displayed in full screen mode. BRIGHTNESS, CONTRAST, TINT and COLOR can be changed as necessary. To modify a different channel, highlight the CAMERA field, and choose the desired channel. Press RETURN when all changes are completed.
  • Page 29 SYSTEM SETUP Advanced PTZ properties can be adjusted for each channel using the ‘DETAIL’ button. Some settings, such as Auto Focus, may not be compatible with all PTZ devices. If this is the case, changing this value will have no effect on PTZ control. Click the “TOUR”...
  • Page 30 SYSTEM SETUP CAMERA : MOTION SENSOR Click on the MOTION SENSOR menu. Click on a SENSITIVITY value for the desired channel. Then use the button to increase or decrease the sensitivity. SENSITIVITY: Determines the degree of motion required before recording is activated. (1: Least Sensitive to Motion - 10: Most Sensitive to Motion) Click the button to edit the motion detection area.

  • Page 31: M O T I O N S E N S O

    SYSTEM SETUP DISPLAY From the ‘System Setup’ menu, click on the ‘DISPLAY’ submenu. DISPLAY - OSD Click on the ‘OSD’ submenu and then click on any field. Then, click on the button to modify the value. STATUS BAR TIMEOUT: Toggles the status bar at the bottom of screen in Live View mode ON / OFF. CAMERA TITLE: Determines whether the camera title is displayed for each channel.

  • Page 32: Monitor

    SYSTEM SETUP DISPLAY - MONITOR Click the MONITOR menu, then click on any field. Use the button to modify the value. SEQUENCE DWELL: The amount of time that each screen is displayed in a sequence. SPOT-OUT DWELL: The amount of time that each screen is displayed on each of the spot monitor outputs. DE-INTERLACE MODE: When recording any channels in D1 resolution (704 x 480), this may be set to ON, to prevent interlaced motion distortion during playback.

  • Page 33: S E Q U E N C

    SYSTEM SETUP DISPLAY - SEQUENCE Click the ‘SEQUENCE’ menu. - When the ‘SEQ’ button is pressed, the default sequence will cycle through all 16 channels, one by one, in full screen. - Sequence setup allows the user to define a custom sequence pattern, using either full screen or mixed multi-screen views, which can be comprised of any number of channels in any order.
  • Page 34 SYSTEM SETUP Click ‘ADD’. The “Sequence Setup” submenu appears. - Determine the Screen Division mode under the “VIEW TYPE” section. - Assign the desired channel under the “CONFIGURE” section. - When all sequence settings have been entered correctly, click ‘CONFIRM’. - To add an additional mode, click ‘ADD’...
  • Page 35 SYSTEM SETUP DISPLAY – SPOT OUT Click on the ‘SPOT-OUT’ menu and click the camera channel for ON/OFF. The DVR has 4 SPOT MONITOR OUTPUT (Digital Spot) and user can assign the SPOT OUT display for each channel Spot monitor displays a full screen sequence of particular channels, depending on the settings within this menu. For spot monitor, the operator can decide which channels are to be displayed in the sequence.

  • Page 36: Audio

    SYSTEM SETUP SOUND From the ‘System Setup’ menu, click on the ‘SOUND’ menu. SOUND - AUDIO Click on the ‘AUDIO’ menu, and click on any field. Use the button to modify each value. LIVE AUDIO: When enabled, the selected audio channel can be monitored from the AUDIO OUTPUT. DEFAULT AUDIO CHANNEL: Specify which one of the 4 AUDIO INPUTS is routed to the AUDIO OUTPUT.

  • Page 37: Date / Time

    SYSTEM SETUP SYSTEM From the ‘System Setup’ menu, click the SYSTEM menu. SYSTEM - DATE / TIME Click the DATE / TIME menu, and click on any field. Use the button to modify any value. DATE TIME: Allows the operator to set or modify the current system date & time. DATE FORMAT: Determines the format in which the date is displayed.

  • Page 38: D D N

    SYSTEM SETUP SYSTEM-SYSTEM MANAGEMENT Click on the ‘SYSTEM MANAGEMENT’ menu. SYSTEM INFORMATION: User can see the system information as below. S/W version: Shows the firmware version of the DVR. H/W version: Shows the hardware version of the DVR. VIDEO SIGNAL TYPE: The DVR automatically switches between PAL and NTSC depending on the video format of the Channel 1 input signal at the time of power on.

  • Page 39: Control Device

    SYSTEM SETUP F/W UPDATE: Firmware updates may be released periodically to enhance system performance and add extra features. The user can upgrade the DVR firmware locally, using a USB memory stick. Select the Device where the Firmware Update files are located. After selecting the F/W version from F/W list, press ‘UPGRADE’.
  • Page 40 SYSTEM SETUP SYSTEM: POS SETUP POS ENABLE: This determine POS enable / disable. BAUDRATE: Must be set to match the baud rate of the POS device. PROTOCOL: Must be set by POS device.. ADDRESS: This determine POS device address of each channel. Caution) When POS function is activated, user can’t use Live LOG function and Control device..

  • Page 41: E - M A I

    USER From the ‘System Setup’ menu, click on the ‘USER’ menu. USER - USER MANAGEMENT By default, the DVR is configured with a user ID of ‘ADMIN’, belonging to the ADMIN group, with a password of ‘1234’. Within this menu, you have the ability to add new users, or modify the details for existing users. To modify user details, click or highlight the user with the green cursor square, and press ‘ENTER’.
  • Page 42 SYSTEM SETUP For ADD, double click on the each tap after clicking ADD. After changing, click OK. USER ID: Edit the user ID using the virtual keyboard. PASSWORD: Change the password using the virtual keyboard. GROUP: Users can be assigned to one of three groups - ADMIN, MANAGER or USER. E-MAIL: Enter the user’s email address if email notification is required.
  • Page 43 SYSTEM SETUP NETWORK From the ‘System Setup’ menu, click on the ‘NETWORK’ menu. NETWORK- IP SETUP Click on the ‘IP SETUP’ menu. DHCP: When enabled, the DVR will obtain an IP address automatically from a router or DHCP server, upon reboot. WEB SERVICE: When enabled, allows remote connections using Internet Explorer or other compatible web browsers.

  • Page 44: E-Mail

    SYSTEM SETUP NETWORK-DDNS DDNS: When enabled, the DVR can be accessed through a Dynamic DNS server. (This is commonly used if a particular broadband connection does not have a Static IP address.) CAUTION: To use the DDNS function, the user must configure port forwarding. a.

  • Page 45: Event / Sensor

    SYSTEM SETUP EVENT / SENSOR From the ‘System Setup’ menu, click on the ‘EVENT / SENSOR’ menu. EVENT / SENSOR - HDD EVENT Click on the ‘HDD EVENT’ menu, and choose any field. . Use the button to modify the value. The DVR will continually monitor the health of the hard drives in the system and detect problems that may be developing.

  • Page 46: H D D E V E N

    SYSTEM SETUP EVENT / SENSOR - ALARM OUT Click on the ALARM OUTPUT menu, and click on a field. Use the button to modify the value. This menu will determine the behavior and actions that will trigger each of the 1 alarm output. Behavior settings ALARM OUT: Choose which alarm output to configure.

  • Page 47: Buzzer Out

    SYSTEM SETUP EVENT / SENSOR - BUZZER OUT Click on the BUZZER OUTPUT menu, and click on a field. Use the button to modify the value. This menu will determine the behavior and actions that will trigger the internal buzzer. Behavior settings OPERATION: The internal buzzer can be enabled or disabled.

  • Page 48: E-Mail Notification

    SYSTEM SETUP EVENT / SENSOR - E-MAIL NOTIFICATION Click on the EMAIL NOTIFICATION menu, and click on a field. Use the button to modify the value. This menu will determine the behavior and actions that will send an e-mail notification to a remote user. Behavior settings NOTIFICATION: E-mail notification can be enabled or disabled.

  • Page 49: D I S K M A N A G

    SYSTEM SETUP DISK MANAGEMENT Click on the DISK MANAGEMENT menu. To manage the internal hard drives, from the ‘System Setup’ menu, highlight ‘DISK MANAGE’ and press ENTER. RECORD TIME LIMIT: In certain circumstances, it may be necessary to limit the amount of footage stored. on the DVR (to comply with data protection laws, for example).

  • Page 50: Record Setup

    RECORD SETUP From the Main Menu, click on the ‘RECORD’ menu. To configure the recording behavior of the DVR, highlight ‘RECORD MENU’ and press ‘ENTER’. RECORDING OPERATIONS Click on the ‘RECORDING OPERATIONS’ menu. Click on any field, and use the button to modify the value.

  • Page 51: C O N T I N U O U S / M O T I O N R E C O R D I N G S E T U

    RECORD SETUP CONTINUOUS / MOTION RECORDING SETUP Click on the ‘CONTINUOUS / MOTION RECORDING’ menu. This menu allows the operator to configure continuous and motion-activated recording, based on a schedule. There are 2 sections to this menu: SIZE / FPS / QUALITY: Recording settings for each channel can be defined across a 24-hour period, in blocks (for example between 09:00 and 18:00) or by each individual hour.
  • Page 52 RECORD SETUP SIZE / FPS / QUALITY (continued) Click on the TIMELINE to select a block of time. Press ‘ENTER’ to display the green cursor. The green cursor square shown represents one hour. (In this case between 00:00 and 01:00). The table below the time bar shows the recording settings for this time period.
  • Page 53 RECORD SETUP SIZE / FPS / QUALITY (continued) Click on the SIZE, FPS, QUALITY or AUDIO fields. Use the button to modify the value. Press ENTER. Recording settings for the selected time period are displayed. Maximum recording frame rate is 480FPS at resolution of D1. SIZE: Recording resolutions of CIF (352x240), 2CIF (704x240) or D1 (704x480) can be selected for each channel.
  • Page 54 RECORD SETUP SCHEDULE Click on the ‘ACTIVATION’ menu. To change ‘ACTIVATION’ settings, highlight ‘CONTINUOUS / MOTION RECORDING’ and press ‘ENTER’. Use the CURSOR KEYS to highlight ‘ACTIVATION’ and press ‘ENTER’. The schedule box is highlighted in green. Press ‘ENTER’ to display the green cursor square. Example: To set all channels to motion detection recording only between 18:00 and 00:00.

  • Page 55: A L A R M R E C O R D I N G S E T U

    RECORD SETUP ALARM RECORDING SETUP Click on the ‘ALARM RECORDING’ submenu. The layout of this menu is very similar to the ‘CONTINUOUS / MOTION RECORDING’ menu. This menu screen allows the user to configure alarm-activated recording. There are 2 sections to this menu: SIZE / FPS / QUALITY: Recording settings for each channel can be defined across a 24-hour period, in blocks (for example between 09:00 and 18:00) or for each individual hour.
  • Page 56 RECORD SETUP RECORD: NETWORK STREAMING SETUP Click the NETWORK STREAMING menu. Select the Size, FPS, Quality and audio. During Network Streaming mode, the DVR is possible to set remotely uploaded video, audio stream with using client program like Web RA. Maximum recording frame rate is 120FPS at resolution of 1CIF (352x240).

  • Page 57: S E A R C

    SEARCH SEARCH To search for a particular section of recorded footage, click or press the ‘SEARCH’ button. To protect unauthorized viewing of footage, only ADMIN and MANAGER user groups can playback footage (by default). To login as ADMIN, enter the default password of ‘1234’ and press ‘ENTER’. SEARCH –...
  • Page 58 SEARCH Click and drag the time bar across the timeline. Press ENTER to select the calendar and use the CURSOR KEYS to move the purple square to the desired day. As different days are selected, the timeline display also changes to show the timeline of recorded footage for that day. Press ENTER to choose the date and move to the timeline.
  • Page 59 SEARCH MODE: MULTI PLAYBACK PLAY (Multi view): The default playback mode is 16 screen display. pressing DISPLAY using CHANNEL SELECTION buttons, it is possible to display single screen or other multi screen formats in a similar way to the live display mode. When playback is paused, the <<, >>...
  • Page 60 SEARCH During playback, user can put a bookmark on the recorded data that needs to be archived later. Click the button at the time the archive is to be started. Then playback will halt and menu below will appear. After inputting the “TAG” name, press START. Then the system will return to playback mode. Click the button again at the end point of the archive.
  • Page 61 SEARCH To exit playback mode and return to the search screen in order to choose another time and date, press ‘RETURN’. To exit the search screen and return to Live View mode, repeatedly press the ‘RETURN’ button. SEARCH – SEARCH BY EVENT The DVR event log stores events such as motion and alarm activated recording, video loss etc.
  • Page 62 SEARCH Click the ‘SEARCH’ button to search for events. Highlight ‘SEARCH’ and press ‘ENTER’ to display the event log for the criteria selected. To playback footage for a particular event, select the event from the list using the CURSOR KEYS and press ‘ENTER’. Playback resumes from the moment the selected event occurred and continues until stopped by the user.
  • Page 63 SEARCH : POS EVENT SEARCH The DVR POS event log stores events such as price, quantity, item keyword, date, etc. On SEARCH BY POS EVENT menu, it can search log price, quantity, item keyword, date, etc, and playback recorded video. Click the SEARCH BY POS EVENT menu and select each...
  • Page 64 To playback footage for a particular event, select the event from the list using the CURSOR KEYS and press ENTER. Playback resumes from the moment when the selected event occurred and continues until stopped by the operator. During event search playback, the playback buttons can be used as normal. To stop playback and return to live view mode, repeatedly press RETURN.
  • Page 65 ARCHIVING NEW ARCHIVING To archive recorded footage to a USB Memory Stick or CD/DVD, press the ARCHIVE button. To protect unauthorized viewing and distribution of footage, only the ADMIN user level can archive footage (by default). To login as ADMIN, enter the default password of ‘1234’ and press ‘ENTER’. CREATE A NEW ARCHIVE Click on a field to configure each of the archive settings.

  • Page 66: Reserved Data Management

    ARCHIVING RESERVED DATA MANAGEMENT AVI ARCHIVING LIST: User can see the list of data that has been reserved from the ‘Create New Archive’ menu INFORMATION: The detailed information of each clip that has been reserved. DELETE: Delete the selected clip from the list of reserved data. BURN: Perform an archiving operation using the selected clip.
  • Page 67 FTP SETUP FTP Archiving is possible if setting up the HOST Name, Port number, User Name, and Password having become setting to FTP server. FTP Archiving is possible on New Archiving or Reserved Data Management.. Archiving data is appeared in Directory of the name that they set up to 'DIRECTORY' if got from FTP backup. FTP TEST normally uses it to purposes to test Archiving possible to the FTP server which a user set up.

  • Page 68: How To Connect

    PRELIMINARY BEFORE CONNECTING When configuring for a web or remote connection to the DVR, Ports 554 and 8080 should be forwarded within the router. Refer to the user’s manual of your specific model of router for information on port forwarding configuration. WEB / REMOTE CLIENT - MINIMUM PC REQUIREMENTS P4 (3.0GHz or higher) 512MB (or higher)
  • Page 69 The default User ID and Password are ‘ADMIN’ & ’1234’, respectively. User will need to install the ActiveX control, click Run Add-on. In case of not being able to install ActiveX, the user needs to enable ActiveX within the IE security menu. Select ‘Enable’...

  • Page 70: Live Mode

    LIVE MODE Icons and corresponding functions within LIVE mode: - Select Live View Screen Division (1, 4, 8, 9, 16-channel modes) - Sequence Mode - Move to Next Camera - Full Screen - Select Live View Channel Manually. - Activate Microphone to send audio to the DVR audio out jack. - Toggle Network Audio Receive (from DVR).

  • Page 71: Recording -

    - Status : Shows active status indicators of all channels on the DVR. Alarm - indicator will be marked when system detects Alarm Input. Motion - indicator will be marked when system detects Motion. Video Loss - indicator will be marked when system detects Video Loss. Recording - Display current recording mode.

  • Page 72: S E A R C H B Y T I M

    1. Pattern – move a camera to a sequence of several preset camera positions in order. 2. Preset – set a position of the camera to be recalled later. 3. Swing – move a camera between two or more preset points. SEARCH BY TIME - Select a position on the timeline or set an exact time.

  • Page 73: S E A R C H B Y E V E N

    SEARCH BY EVENT 1. Event : Select the types of events to search for within the recorded data. 2. Period : Set the date/time range to search for events within the recorded data. 3. Search : Begin query, and list all events found within selected range and type. 4.

  • Page 74: R E M O T E S E T U

    REMOTE SETUP 1. CAMERA : User can configure all camera attributes, such as title, covert channel, PTZ, or motion. - Motion Area Setup for individually configuring motion areas and sensitivity.
  • Page 75 1. CAMERA (continued) 1) Select the ‘Motion’ submenu. 2) Select a channel and the motion sensitivity level. 3) Click and drag the mouse across the image grid to select motion areas. 4) Click OK. 2. DISPLAY 1) OSD - Configure properties for the on-screen display (OSD) of the DVR. 2) Monitor - Set dwell time for sequence, spot monitor output, and pop-up functions.
  • Page 76 3. Sound 1) Audio Setting - Enable live audio, and select a live audio channel. 2) Buzzer Setting - Activate DVR internal buzzer, based on keypress. 4. System Configure Date and Time Formats, NTP Time Server, Time Zone and DST properties. 5.

  • Page 77: Network

    6. User Add new users, configure existing users, authority level and log out time. 7. Network User can check the DVR network information and adjust the network bandwidth throttle. All other IP settings are not allowed to be changed remotely. These settings can only be changed locally. For setting up e-mail notification, user can configure the SMTP server details remotely.
  • Page 78 8. Sensor Configure all options for Alarm Input, Alarm Output, Buzzer Out, and E-Mail Notification. The menu structure is very similar to the local DVR system setup for Event / Sensor. INFORMATION - Displays the DVR Model and WEB Remote Software Version.
  • Page 79 1. Open the archive data, and Run the file [bplayer.exe], which is included within the backup folder. 2. Click the [Open File] button and choose the backup file you wish to open and verify.
  • Page 80 3. After selecting the file, you will be asked to confirm whether or not you would like to check the watermark. 4. Click the [Yes] button to verify the embedded watermark. 5. If the archived AVI file has been modified, a [Verification Failed] message will appear.
  • Page 81 • iPhone 1. Select the Safari browser. 2. Enter the IP address or URL to connect. Click the [GO] button. 3. Enter the User ID and Password. (Default: ADMIN / 1234)
  • Page 82 • BlackBerry 1. Select the Web browser. 2. Enter the IP address or URL to connect, and press the Enter button. 3. Enter the User ID and Password. (Default: ADMIN / 1234)
