  • Page 1 Stand Alone Type DVR SYSTEM U S E R M A N U A L DR16NRT...

  • Page 2: Table Of Contents

    Specification & Organization -------------------------------------------------- 4 Specifications --------------------------------------------------------- 4 Product Contents List --------------------------------------------------- 6 System Organization ---------------------------------------------------- 7 Product Description -------------------------------------------------------- 8 Front panel description --------------------------------------------------- 8 Rear panel description --------------------------------------------------- 9 Remote Controller description --------------------------------------------- 10 HDD , CD/DVD-RW Connect -------------------------------------------------- 11 Power On ---------------------------------------------------------------- 12 Live Display --------------------------------------------------------------- 13 Configuring the live display ---------------------------------------------- 13...
  • Page 3 Configuration-Record -------------------------------------------------- Record mode --------------------------------------------------------- 46 Normal record ---------------------------------------------------- Intensive record ----------------------------------------------------- 50 Panic record ----------------------------------------------------- Sequence -------------------------------------------------------- 53 Digital Zoom ------------------------------------------------------- 54 Keylock ---------------------------------------------------------------- 55 Panic Start/Stop ----------------------------------------------------------- 56 Shutdown ---------------------------------------------------------------- 57 RemoteSW installation ------------------------------------------------------- 58 System Requirement ---------------------------------------------------- 58 Introduce ------------------------------------------------------------ 59 RemoteSW Local Setup ----------------------------------------------------- 60 local setup ---------------------------------------------------- 60...

  • Page 4: Specification & Organization

    SPECIFICATION&ORIGANIZATION SPECIFICATION&ORIGANIZATION Specifications MODEL DR16NRT Operation PENTAPLEX PENTAPLEX performance ( Simultaneous Live Display/Recording/Playback/Archiving/ Networking effectively without interfering each other operations) Video in Channels Connection BNC, 1.0Vpp composite 75ohm balanced Loop through BNC,1.0Vpp composite 75ohm unbalanced, auto termination Audio in Channels...
  • Page 5 SPECIFICATION&ORIGANIZATION SPECIFICATION&ORIGANIZATION Model XVR - 1648 Playback Speed Forward / reverse. 1x, 2x, 3x, 4x, 8x, 16x, 32x, 64x, 128x Control Front panel buttons and Jog / Shuttle ring/USB Mouse Search method Calendar / timeline, event log, Sequence, Thumbnail, Smart Search Split screen display modes 1,4,16 Audio synchronization...

  • Page 6: Product Contents List

    SPECIFICATION&ORIGANIZATION SPECIFICATION&ORIGANIZATION Product Contents List Please confirm that all product contents are present after opening the package. ① Basic Contents DR16NRT Unit AC Power Cable Instruction Manual Remote Controller Remote Agent AAA Battery x 2 Installation CD ② Optional Contents...

  • Page 7: System Organization

    SPECIFICATION&ORIGANIZATION SPECIFICATION&ORIGANIZATION System Organization Alarm Sensor #1-16 Relay Out Remote Client PC Image Printer Camera #1-16 Alarm Input/Out NETWORK AVI Backup TCP/IP Video In WEB Client Backup Video Out Remote Controller USB Mouse A/V Monitor CD-RW Monitor...

  • Page 8: Product Description

    PRODUCT DESCRIPTION PRODUCT DESCRIPTION Front Panel ① Power : System Power On/Off ② DISPLAY : Select Screen Division Mode or Rotation Mode ③ SEQUENCE : Select Sequence Screen Mode ④ PANIC : Trigger Panic Recording Mode and Panic Relay Output ⑤...

  • Page 9: Rear Panel Description

    PRODUCT DESCRIPTION PRODUCT DESCRIPTION Rear Panel ① Video IN / Loop : BNC Video Input Port, BNC Video Loop Output ② Monitor out : BNC Main Monitor Output SVHS : Output Video by Connected SVHS. ③ Spot #1 ~ #4 : 4 x BNC Output to Individually-Sequenced Spot Monitors ④...

  • Page 10: Remote Controller Description

    REMOTE CONTROLLER REMOTE CONTROLLER POWER MENU : Open System Setup Menu System ON/OFF Channel Selection Buttons ID Button Select DVR ID ENTER : Apply / Select /Go to Next Screen RETURN Cancel / Deselect Navigation Buttons : Used for Playback Control, Previous Screen Menu Navigation, and PTZ/Focus Control ※...

  • Page 11: Hdd , Cd/Dvd-Rw Connect

    HDD, CD/DVD RW CONNECTION HDD, CD/DVD RW CONNECTION Above is mainboard picture after opening the top cover. The connection board is in red box (1) is the port for system disk(master disk) so you must install the first HDD at this port .(HDD jumper location should be “Master”)..

  • Page 12: Power On

    POWER ON POWER ON Press the power button. After startup process is complete, the “logon” display appears and input the Password. The DVR startup screen detects and checks the HDD and CD-RW/DVD-RW. (Default password is none. So click the “Logon” button.) The DVR start the normal operation and show default display of all 16channels.

  • Page 13: Live Display

    LIVE DISPLAY LIVE DISPLAY Press the mouse right button from live display. It shows the menu screen. In case of pressing the “setup” button from front panel, it will enter “system setup menu of configuration” directly. Configuring the Live Display Click the right mouse button on the Live Display screen and Click the DISPLAY...

  • Page 14: Ptz

    Click the right mouse button on the Live Display screen and Click the menu. • PTZ controls appear like above. 1) Select the camera. 2) Control the camera direction. Press this button. The operator can control the PTZ detailed configuration with pop-up screen. 4) Control the Zoom, Focus, Iris.

  • Page 15: Search

    SEARCH SEARCH The operator can search the recorded data as Normal, Sequence, Thumbnail and Smart search Normal Search Click the right mouse button on the Live Display screen and Click the SEARCH menu. Select the “SEARCH” icon and press the “SEARCH” button. Logon display shows and input the password.
  • Page 16 SEARCH SEARCH : Click the button for snapshot backup, Then it shows below screen. During the playback, the operator can save the image that want to save. Input the snapshot tag. Select the channel. Select the screen. Input the Memo. For saving the image, click the “reserve”...
  • Page 17 SEARCH SEARCH It shows left screen with backup data information. How to burning and reserve is same with how to save the snapshot. (The operator can check the saved image from backup Date Management of backup menu). : Click the button for full screen from (D). Then it shows below screen. For returning, drag the mouse to the bottom of screen.
  • Page 18 SEARCH SEARCH : Click the button for viewing the log from (D). Then it shows left screen. Current log is appeared. For returning, click the same button again. : Click the button for changing the playback display from (D). The operator can select the playback display mode. The display color about the recorded data at Timeline from (E) appear differently each type like above.
  • Page 19 SEARCH SEARCH • Playback-> Log Click the “log”. Then it shows left screen. Select the date that want to see the log from calendar. Select the event section that want to see. Click to start the “search”. Click the button with viewing with timeline. The option that want to search each channel can be selected.

  • Page 20: Sequence Search

    SEARCH SEARCH Sequence Search - The operator can search frame by frame. • Select the channel. • Select the date. • Select the time. • The operator can select the time from timer or by drag the timeline bar. • How to search is almost the same as normal search.

  • Page 21: Thumbnail Search

    SEARCH SEARCH Thumbnail Search - The operator can search with divided screens each time range. Channel selection Snapshot backup Start time selection Total time Range selection The operator can select the playback location by Drag and drop Timeline bar. • Select the channel.

  • Page 22: Smart Search

    SEARCH SEARCH Smart Search -The operator can search by Museum search or Motion search. - Select the camera. - Select the area that want to search by mouse drag. - Select the search method.(Museum or Motion) - Museum search This search indicates or generates event(consistent/inconsistency) when search is compare with the starting image and the image continuous to occur more than Designated Time on the Designated Accuracy of the Selected Area.

  • Page 23: Backup

    BACKUP BACKUP Backup Click the right mouse button on the Live Display screen and Click the BACKUP menu. • Select the “BACKUP” icon and press the “BACKUP” button. • Logon display shows and input the password. It shows the backup display. •...

  • Page 24: Backup Date Management

    BACKUP BACKUP Backup Data Management • The operator can see the saved snapshot image and AVI file form Backup menu and search menu. : Detailed information : Delete : Burning...

  • Page 25: Configuration-System

    CONFIGURATION SYSTEM CONFIGURATION SYSTEM Click the right mouse button on the Live Display screen and Click the CONFIGURATION menu and Click the “SYSTEM”. Camera -> Title • Camera Title: Input the Title and description by virtual keyboard.
  • Page 26 CONFIGURATION SYSTEM CONFIGURATION SYSTEM Camera -> Color • Camera color setup: Select the Brightness, Contrast, Tint, Color. The operator can control the color with live display when clicking the button. Camera -> PTZ • Select the address, protocol and Baud rate each camera. The operator can control PTZ detailed setup when clicking the button.
  • Page 27 CONFIGURATION SYSTEM CONFIGURATION SYSTEM Camera -> OSD • Select the covert each channel and main display, spot OSD setup. ※ How to use the virtual keyboard Double Click the left mouse button where you want to enter data. Then it shows the virtual keyboard. Select each character from virtual keyboard. For using the small character.

  • Page 28: Alarm/Event

    CONFIGURATION SYSTEM CONFIGURATION SYSTEM Alarm/Event -> Sensor Select the Activation, Normal State (High/Low-It is related with sensor type) and input the description. Alarm/Event -> Video Loss Select the video loss Activation.
  • Page 29 CONFIGURATION SYSTEM CONFIGURATION SYSTEM Alarm/Event -> Motion Detection Select the Motion Detection Activation,Sensitivity(1~10) and Motion Area. The operator can select the motion area from above screen after clicking the button. After selecting the motion area with mouse drag, click the mouse right button, Then it shows pop-up menu that related with selection.
  • Page 30 CONFIGURATION SYSTEM CONFIGURATION SYSTEM Alarm/Event -> Storage • File system Event - Disk Full When disk full, Activation On/Off. • Smart Event - Smart Warning When HDD has trouble, Activation On/Off. - Smart Check Period Select from 1 hour to 24 hour.
  • Page 31 CONFIGURATION SYSTEM CONFIGURATION SYSTEM Alarm/Event -> User Defined The operator can make the User Defined Event with current event’s mixing. When happen the over two events at the same time, the operator can setup how it work. (Mixing condition is “AND” not “OR”) Select the Activation each channel.
  • Page 32 CONFIGURATION SYSTEM CONFIGURATION SYSTEM Alarm/Event -> Event Action -> Digital Out -Linked Event: Select the event that want to assign the action. (Alarm, Motion, Video loss and User defined) - Select the Activation on/off. -Normal state: Select the operation type. (High / Low) -Dwell Type: use/ Not use Time: 5- 300 second and until...
  • Page 33 CONFIGURATION SYSTEM CONFIGURATION SYSTEM Alarm/Event -> Event Action -> Remote Client Notification - When happen the selected event, it notify the event to Remote client. - Select the Activation on/off. - Select the Sensor, Video loss, Motion, Storage(Smart alarm, HDD full) and user defined event). - Input the memo.
  • Page 34 CONFIGURATION SYSTEM CONFIGURATION SYSTEM Alarm/Event -> Event Action -> Buzzer - When happen the selected event, select buzzer on/off. After selecting the event (Alarm, motion, Video loss, User Defined Event) that want to buzzer, select the activation on/off. - Dwell Type: use/ Not use Time: 5- 300 second and until pressing the any key.

  • Page 35: Display

    CONFIGURATION SYSTEM CONFIGURATION SYSTEM Display -> Screen Template Setup the display configuration. When operator want to see live display with sequence mode, it is used. This menu should be setup before setup the Main Display Sequence. The operator can select the screen mode with 1,4,8,9,16 division with clicking above icon. ADD button: Please add the item that want to be pop-up.
  • Page 36 CONFIGURATION SYSTEM CONFIGURATION SYSTEM Display -> Main Display Sequence • Main Display Sequence When start the sequence, the operator select and make the working sequence type. - Press the ADD button. - Select the new list (It show blue square) - Input the name with virtual keyboard and select the dwell time(5-100 sec).
  • Page 37 CONFIGURATION SYSTEM CONFIGURATION SYSTEM Display -> Spot#1-4 Display Sequence In case of advance spot, setup method is almost same with main display sequence. The different thing is only one. The screen template that can select is only two types.(1,4 division) - Press the ADD button.

  • Page 38: Audio

    CONFIGURATION SYSTEM CONFIGURATION SYSTEM Audio • Setup the audio configuration. - Live Audio: Select the Live audio channel. Network Audio: Select the audio transmitter and receiver. - Buzzer ; when pressing the key of front board and Remote controller. Sound on/ off.

  • Page 39: User

    CONFIGURATION SYSTEM CONFIGURATION SYSTEM User -> User group Default user group (administrator, manager, user) can not be delete or edit. After selecting “ADD” button, the operator can make the new user group with new authority. When selecting “ ADD” button, it show “add group” screen. It shows the virtual keyboard when click mouse left button double for inputting the text.
  • Page 40 CONFIGURATION SYSTEM CONFIGURATION SYSTEM User -> User : ADD The operator can add, delete or edit the new user. : DELETE When selecting the “ADD” button, it shows “add user” screen. : EDIT After inputting the ID, PW and E-mail by virtual keyboard, click the “OK”.

  • Page 41: Network

    CONFIGURATION SYSTEM CONFIGURATION SYSTEM Network -> Configuration DHCP: In case of “Dynamic IP”, select the “DHCP” When clicking the “apply” button, DVR get the IP address automatically after selecting the “DHCP”. In case of using the” Static IP”, input the IP address and other information manually. DDNS (Dynamic DNS): This is used with a Dynamic IP address, which may be changed by the ISP at any time.
  • Page 42 CONFIGURATION SYSTEM CONFIGURATION SYSTEM Network -> E-Mail Server USER Account : Enter a username to identify the DVR in email messages. PASSWORD : If SECURITY is set to ON, enter the password here. SMTP SERVER : The SMTP outbound email server that should be used to send email notifications. SMTP SERVER PORT : The outbound email port number.

  • Page 43: System

    CONFIGURATION SYSTEM CONFIGURATION SYSTEM System -> Information Information Site Description: Input the name by virtual keyboard - H/W version: DVR’s H/W version - S/W version: DVR’s FW version Mac address; DVR’s Mac address Controller connecting - Setup to control by the keyboard controller.
  • Page 44 CONFIGURATION SYSTEM CONFIGURATION SYSTEM System -> Update Firmware Upgrade The operator can update the F/W by USB device and CD. After inserting the F/W at USB and CD, connect it at the DVR. Select the F/W upgrade button then it shows the above screen. After selecting the F/W from list, select the “upgrade”...

  • Page 45: Storage

    CONFIGURATION SYSTEM CONFIGURATION SYSTEM Storage -> Operation - Operation mode: Select the overwrite /write once (no overwrite) - Internal recording: It shows the internal HDD recording information that installed - CD/DVD Media: It shows the internal CD-RW/DVD-RW that installed. Storage -> Utility - Format When clicking the “START”...

  • Page 46: Configuration-Record

    CONFIGURATION RECORD CONFIGURATION RECORD Click the right mouse button on the Live Display screen and Click the CONFIGURATION menu and Click the “RECORD”. Record Mode...
  • Page 47 CONFIGURATION RECORD CONFIGURATION RECORD Record Mode In case of selecting the “Normal Record” from record mode, The operator can not enter “Intensive Record” setup. Oppositely in case of selecting the “Intensive Record”, The operator can not enter “Normal Record” setup. - Weekly/Daily The operator can select the ‘Weekly”...

  • Page 48: Normal Record

    CONFIGURATION RECORD CONFIGURATION RECORD Normal Record Parameter -Drag the time that want to setup by mouse. In case of setup differently each time, the color is different. In case of recording setup, the operator should setup as 4 divided parts. The operator can setup Max.CIF,120FPS each divided part.
  • Page 49 CONFIGURATION RECORD CONFIGURATION RECORD Schedule The operator can select recording type (Timer, Motion, Alarm, User Defined, Alarm or Motion and Record off) each time, channel. Drag the section that want to select and then click the mouse right button. Then recording option will be appeared. The operator can select the recording option each time and channel. Recording setup Save, Load and Delete The operator can make the various recording setup in DVR.

  • Page 50: Intensive Record

    CONFIGURATION RECORD CONFIGURATION RECORD Intensive Record In case of this record, record will be centralized at channel that event is happened as event priority. Parameter -Drag the time that want to setup by mouse. In case of setup differently each time, the color is different.
  • Page 51 CONFIGURATION RECORD CONFIGURATION RECORD Schedule The operator can select the record on/ off each time, channel. Drag the section that want to select and then click the mouse right button. Then recording option will be appeared. The operator can select the recording on/off each time and channel. Recording setup Save, Load and Delete The operator can make the various recording setup in DVR.

  • Page 52: Panic Record

    CONFIGURATION RECORD CONFIGURATION RECORD Panic Record When pressing the panic button or detecting the panic alarm, recording condition is changed as panic record setup. In case of recording setup, the operator should setup as 4 divided parts. The default setup is CIF, 30FPS. Setup method is same with normal record setup.

  • Page 53: Sequence

    SEQUENCE SEQUENCE Click the right mouse button on the Live Display screen and Click the “SEQUENCE PLAY” “SEQUENCE STOP”. • Select the “SEQUENCE PLAY” icon and press the “SEQ” button. Then it shows installed sequence display. (Sequence Play/Stop). It is related with “Display -> Main Display Sequence“. Please setup the Main Display Sequence firstly.

  • Page 54: Digital Zoom

    DIGITAL ZOOM DIGITAL ZOOM Click the right mouse button on the Live Display screen and Click the “DIGITIAL ZOOM”. Click button for returning to live display. Click the mouse right button for changing the channel. Then it shows the channel list. Select the channel that want to change.

  • Page 55: Keylock

    KEYLOCK KEYLOCK Click the right mouse button on the Live Display screen and Click the “KEYLOCK”. When selecting the “Keylock” by menu or pressing “Lock” button from Remote controller or Front panel, System is locked. If pressing any button under keylock condition, below is appeared. - Input the Password.

  • Page 56: Panic Start/Stop

    PANIC PANIC Click the right mouse button on the Live Display screen and Click the “PANIC START/STOP”. When Pressing the “PANIC START”, it start panic record. Please press the “PANIC STOP” after stopping the panic record.

  • Page 57: Shutdown

    SHUTDOWN SHUTDOWN Click the right mouse button on the Live Display screen and Click the “SHUTDOWN”. When Pressing the SHUTDOWN”, below is appeared. If pressing “OK” after inputting the Password, system is power off.

  • Page 58: Remotesw Installation

    REMOTE SW INSTALLATION System Requirement ① Main Board (CPU): Pentium-500(Minimum), Pentium 4 recommend ② OS: Higher than Windows 2000,DirectX 7.0A ③ Memory (RAM): More than 128 M ④ VGA: Graphic card that support the DIRECT-X ※IMM4 Codec (When Playback Backup File) ①...

  • Page 59: Introduce

    REMOTE SW INSTALLATION Introduction ③ ① ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑭ ⑬ ① Main Display : Shows single or multi-channel view of cameras connected to the DVR. ② Camera Selection Buttons : Indicates Camera #; click button to display a selected camera. ③...

  • Page 60: Remotesw Local Setup

    REMOTE SW LOCAL SETUP Local Setup ② ① Group & DVR list. ① ② DVR Information. ③ Camera Assign : Setup camera. ③ ④ Option Check.(Event-system, alarm, video, record & In/Out) ⑤ Add, modify, delete group. ④ ⑤ Add Group ①...
  • Page 61 REMOTE SW LOCAL SETUP ③ Input DVR information.(name, IP, port, ID, PW) ④ Set camera position, check option and press ‘ADD’. ⑤ New DVR list is shown on the left upper side. Configuration ① Video OSD : Select screen information. (title, name, date, time) ②...
  • Page 62 REMOTE SW LOCAL SETUP Selection Network ID • Select I/D to Connect Server. • I/D can be Add, Change, and Delete at Setup. TIP ※ Multi DVR Client 4EA DVRs can be control the live view, search the data, backup data and setup about each channel at the same time.
  • Page 63 REMOTE SW LOCAL SETUP AVI File Conversion • Click AVI Conversion Button to Start AVI File Conversion. • During AVI Conversion Showing a Message and before Click ‘Stop” Save AVI File continuously . • ‘Press ‘Stop’ to Open Designate File Name & Saving Location, and Save AVI File.

  • Page 64: Remotesw Search

    REMOTE SW SEARCH Search Function Introduce ① ③ ④ ⑤ ⑥ ⑦ ② ⑧ ① Search Screen Playing Selected Video. ② Search Bar Search & Indicate Camera Recording Situation by Time Bar . ③ LIVE Return to Watch Mode. SETUP Open Setup to Change Network Setup or Option. ④...

  • Page 65: Search Method

    REMOTE SW SEARCH Search Method ⑥ ⑤ ④ ③ ② ⑦ ① Indicates the Time of Day (0 ~ 24 hours) on Search Timeline. ② Indicates Recording Mode (Blue : No Recording, Red: Recorded Images Present) ③ Search Bar : Drag bar with the mouse to search through recorded video on the timeline. ④...

  • Page 66: Search Option

    REMOTE SW SEARCH Search Option ③Save Image ①Archive ⑤Log Viewer ②Backup ⑥Event Play Viewer ④Print - Archive – Backup Image from Server to Remote PC. • Time Range - Enter the Starting and Ending Date/Time. • Channel : Check each channel to include in the Archive. •...
  • Page 67 REMOTE SW SEARCH - Backup Play (DVR Player) – Transfer to DVR Player ① ② ④ ③ ⑤ ① Showing Image (Possible to Only 1*1View Mode). ② Backup File Open to Play First Video. Ex. : ch02_04131730_04131735.rec ( Backup File for # 2 ch. Apr.13, 17H30M ~17H35M ) ③...
  • Page 68 REMOTE SW SEARCH - Save Image – Capture Image and Save to Local PC • Click ‘Save Image’ Icon During Playing Video. • Designate File name, File Type (JPG,BMP), and Location and Press Saving. • Conversion and Saving Image from Remote Viewer. - Print Image –...
  • Page 69 REMOTE SW SEARCH - Log Viewer – Find Video from the DVR Event Log. ② ① ③ ④ ⑤ ⑥ ⑧ ⑨ ⑩ ⑪ ⑦ ① Select Starting Date/Time and Ending Date/Time from which to search for Event Log events. - Press Search Button to Search and View Search Results.
  • Page 70 REMOTE SW SEARCH - Event Viewer - Showing Present Event in Server & Find Image ① Indicates the order in which events occurred. ② Indicates the DVR # on which an event occurred. ③ Indicates the Camera # on which an event occurred. ④...

  • Page 71: Remotesw Dvr System Setup

    REMOTE SW DVR SYSTEM SETUP Press button and it shows left screen. Select the System setup or Record setup. Click the “System” icon. Input the Password. ( Current default password is none. So click the “OK” w/o inputting the password )

  • Page 72: Camera

    REMOTE SW DVR SYSTEM SETUP Camera Title: Input the name and description after Color: Select the Brightness, Contrast, Tint, Color each channel. selecting the channel with mouse. PTZ: Select the address, protocol, Baud rate Covert/OSD: Select the covert and main display, each channel.

  • Page 73: Alarm/Event

    REMOTE SW DVR SYSTEM SETUP Alarm/Event VideoLoss Event: Select the video loss Sensor Event: Select the Activation, Active Activation. State (N/C, N/O-It is related with sensor type) and input the description. Motion Detection Event: Select the Motion Select the “AREA” icon. It shows above screen. Detection Activation and Select the motion area by Mouse drag then choose Sensitivity(1~10) and...
  • Page 74 REMOTE SW DVR SYSTEM SETUP Storage Event - User Event Disk Full: When disk full, Activation On/Off. Select the user event Activation Click the “Edit” then it shows above screen. The operator can make the User Defined Event with current event’s mixing. When happen the over two events at the same time, the operator can setup how it work.
  • Page 75 REMOTE SW DVR SYSTEM SETUP - Event Action * Relay out - Select the event that want to assign the action. - Select the Activation on/off. - Active state: Select the operation type(High / Low) - Dwell: Select the type and Action Time. Transparent : It work from Event start time to Event end time.

  • Page 76: Display

    REMOTE SW DVR SYSTEM SETUP * Buzzer - When happen the selected event, select buzzer on/off. - After selecting the event(Alarm, motion, video loss,User Defined Event) that want to buzzer, select the activation on/off. - Select the buzzer type (Latched, Transparent) DISPLAY - Screen Template Select the screen division(typeA,B,C,D,E)
  • Page 77 REMOTE SW DVR SYSTEM SETUP - Main Display Setup - Press the ADD button or select the current list. - Select the name and dwell time. - Select the new list. - Select the screen template that want to do the sequence each channel.

  • Page 78: Audio

    REMOTE SW DVR SYSTEM SETUP AUDIO - Live Audio Select the Live audio channel. - Network Audio Select the audio transmitter and receiver USER - User group Default user group(ADMINISTRATOR, MANAGER, USER) can not be deleted. After selecting “ADD” button, the operator can make the new user group with new authority.

  • Page 79: Remotesw Dvr Record Setup

    REMOTE SW DVR RECORD SETUP Input the Password. (Current default password is non. So click the “OK” w/o inputting the password) Record Mode - Select the “record mode” and “weekly/daily”. In case of selecting the “Normal Record” from record mode, The operator can not enter “Intensive Record”...
  • Page 80 REMOTE SW DVR RECORD SETUP - Weekly/Daily The operator can select the ‘Weekly” and “Daily” record setup from ‘Normal Record” and ‘Intensive Record” setup. So the DVR will record as daily and weekly setup configuration of “Normal and Intensive record” setup mode. Pre-Event Recording Time: When the DVR is not in continuous recording mode, this setting determines the amount of footage that is always recorded before an event occurs.

  • Page 81: Normal Record

    REMOTE SW DVR RECORD SETUP Normal Record - Select the Daily/Weekly. - Select the Parameter/Schedule - Parameter - Drag the time that want to setup by mouse. In case of setup differently each time, the color is different - Click the “SET” icon. Then it shows above screen. In case of recording setup, the operator should setup as 4 divided parts.
  • Page 82 REMOTE SW DVR RECORD SETUP - Schedule The operator can select recording type (Timer, Motion, Alarm, User Defined, Alarm or Motion and Record off) each time, channel. Drag the section that want to select and then click the mouse right button. Then recording option will be appeared.

  • Page 83: Intensive Record

    REMOTE SW DVR RECORD SETUP Intensive Record - In case of this record, record will be centralized at channel that event is happened as event priority. - Parameter - Drag the time that want to setup by mouse. In case of setup differently each time, the color is different The setup is same with normal recording setup.

  • Page 84: Panic Record

    REMOTE SW DVR RECORD SETUP - Schedule The operator can select the record on/ off each time, channel. Drag the section that want to select and then click the mouse right button. Then recording option will be appeared. The operator can select the recording on/off each time and channel.
