High Efficiency Water Heaters and Boilers
Installation, Commissioning, User & Maintenance Instructions
Direct Gas Fired Floor Standing Water Heater
with Automatic Pilot Ignition
These instructions must be read and understood before installing, commissioning, operating or maintaining the equipment.
Charger
IMPORTANT INFORMATION
Models:
CHA 100 G CE and PG CE
CHA 155
G CE and PG CE
CHA
200 G CE and PG CE
CHA 300 G CE and PG CE
CHA 400 G CE and PG CE
CHA 500 G CE and PG CE
CHA 600 G CE and PG CE
CHA 700 G CE and PG CE
0310569
March 2012
