Summit SWC1987T Owner's Manual

Three-zone wine cooler
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
THREE-ZONE WINE COOLER
Models SWC1987T
Owner's Manual
BEFORE USE, PLEASE READ AND FOLLOW
ALL SAFETY RULES AND OPERATING INSTRUCTIONS
Felix Storch, Inc.
Write Serial Number here:
Summit Appliance Division
_________________________
An ISO9001:2015 registered company
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWC1987T and is the answer not in the manual?

Questions and answers

Related Manuals for Summit SWC1987T

Summary of Contents for Summit SWC1987T

  • Page 1 THREE-ZONE WINE COOLER Models SWC1987T Owner’s Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS Felix Storch, Inc. Write Serial Number here: Summit Appliance Division _________________________ An ISO9001:2015 registered company 770 Garrison Avenue Bronx, NY 10474...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNINGTo reduce the risk of fire, electrical shock or injury when using your appliance, follow these basic precautions  Read all instructions before using the wine cooler.  Plug into a grounded 3-prong outlet. Do not remove grounding prong, do not use an adapter, and do not use an extension cord.
  • Page 3  Although the unit has been tested at the factory, due to transit and storage, you should clean the appliance before use.  Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may damageor discolor the interior. ...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Important Safety Instructions ..............1 – 2 Location of Parts ....................4 Installation Instructions ................5 - 7 Before using your wine cooler ..............5 Installation of your wine cooler ..............5 Reversing the door swing of your appliance ........5 - 7 Operating Your Wine Cooler ..............

  • Page 5: Location Of Parts

    LOCATION OF PARTS Upper hinge Uppermost zone Upper control panel Glass door Full-size wooden shelves Middle zone Baffle plate and lower control panel Handle Baffle plate Lowermost zone Short wooden shelf Key lock Ventilationgrille Door seal (gasket) (kickplate) Adjustable legs NOTE: Each zone has a Ventilation fan and a Sensor located on the rear wall.

  • Page 6: Installation Instructions

    INSTALLATION INSTRUCTIONS Before Using Your Wine Cooler Remove the exterior and interior packing. Before connecting the wine cooler to the power source, let it stand upright for approximately 2 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation.
  • Page 8 NOTE: All parts removed must be saved to allow the door swing to be reversed. 1. Carefully use a sharp tool to pry up the decorative cap at the top of the cabinet and also the cap of the door hinge (Fig.1). 2.

  • Page 9: Operating Your Wine Cooler

    OPERATING YOUR WINE COOLER The wine cooler should be placed where the ambient temperature is between 61 ° and 95 degrees Fahrenheit (16-35 C).If the ambient temperature is above or below this range, the performance of the unit may be affected. For example, placing your unit in extremely cold or hot conditions may cause interior temperatures to fluctuate.

  • Page 10: Operation Of The Buttons

    ● LOWER CHAMBER: This displays the actual temperature of the lower chamber. It can display temperatures from 0°C to 37°C (32°F to 99°F). ● °C/°F light: When the °C light is on, the temperature displayed is in Celsius. When the °F light is on, the temperature is in Fahrenheit. Operation of the Buttons ●...

  • Page 11: Defrosting

    bottom of the door and turn it counter-clockwise to lock the door, making sure the metal pin is engaged completely. To unlock the door, do the reverse. Remove the key and put it in a secure location. Defrosting The wine cooler defrosts automatically during its operating cycle. The water resulting from the defrosting is collected in a drip tray near the compressor at the back where it is automatically evaporated.

  • Page 12: Storage Of Wine Bottles

    Storage of Wine Bottles Your wine cooler was designed to store wine bottles in total security. It can hold up to 133 standard wine bottles. We recommend that you observe the following tips to optimize loading:  Spread your bottles out as evenly as possible over the shelves, so that weight is not concentrated in one spot.

  • Page 13: Care And Maintenance

    CARE AND MAINTENANCE Cleaning Your Wine Cooler 1. Turn off the power, unplug the appliance, and remove all items including shelves and racks. 2. Wash the inside surfaces with a warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda to a quart of water. 3.

  • Page 14: Problems With Your Wine Cooler

    PROBLEMS WITH YOUR WINE COOLER You can solve many common wine cooler problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling a service technician. TROUBLESHOOTING GUIDE Problem Possible Cause...
  • Page 15 NOTES...

  • Page 16: Limited Warranty

    LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship.
