- Page 1 WINE CELLAR Models SWC525L & SWC525LBI CM405M421BL Owner's Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS FELIX STORCH, INC. Write the Serial Number here: 770 Garrison Avenue _________________________ Bronx, NY 10474 www.summitappliance.com...
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. This symbol alerts you to potential hazards that can kill or injure you and others. - Page 3 Use two or more people to move and install the wine cellar. Failure to do so can result in back or other injury. To ensure proper ventilation for your appliance, the front of the unit must be completely °...
-
Page 4: Table Of Contents
Table of Contents Important Safeguards ......................1 - 2 Location of Parts ........................3 Technical Information ......................4 Installation Instructions ....................... 4 - 6 Before Using Your Wine Cellar ................... 4 Installing the Wine Cellar ..................4 - 5 Electrical Connection / Extension Cord ............... 5 Reversing the Door Swing ................... -
Page 5: Technical Information
(fully recessed). On the other hand, model SWC525LBI is specifically designed to be built in. Model SWC525L: Allow 5 inches of space at the back, sides and top of the unit, which will allow the proper air circulation to cool the compressor. ... -
Page 6: Electrical Connection / Extension Cord
and 1/16” at the top. Be sure that airflow under the appliance is not blocked. If the appliance is going to be placed against a wall, if possible, leave extra space on the hinge side so the door can open wider than its width (to make it easier to remove wire racks). -
Page 7: Reversing The Door Swing
Reversing the Door Swing: Figure 1 (Default position) Figure 2 (After door reversal) 1. Upper hinge cover 6. Screws 2. Screws 7. Hole cover 3. Upper hinge 8. Cabinet 4. Door 9. Pin cap 5. Lower door hinge This wine cellar can be opened from either the right side or the left. By default, the door hinge is on the right side. -
Page 8: Operating Your Wine Cellar
Operating Your Wine Cellar Setting the Temperature Control: You can adjust the temperature by pressing the ADJUST (SET) switch. Each press increases the temperature setting by 1° (either °F or °C). The temperature range is 45° to 65°F (7°C to 18°C). The default temperature is 45°F (7°C). Interior light Recommended storage Type of wine... -
Page 9: Care And Maintenance
Care and Maintenance Cleaning your wine cellar: 1. Unplug the wine cellar and remove all items, including shelves and racks. 2. Wash the inside surfaces with a solution of warm water and baking soda. The solution should contain about 2 tablespoons of baking soda to a quart of water. -
Page 10: Problems With Your Refrigerator? (Troubleshooting)
Problems with Your Wine Cellar? You can easily solve many common problems with your wine cellar, saving you the cost of a possible service call. Try the suggestions below to see if you can correct the problem before calling the service provider. TROUBLESHOOTING GUIDE Problem Possible Cause... - Page 11 Notes...
-
Page 12: Limited Warranty
Limited Warranty ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company.
