VISTA-48D

Security System

Installation and Set-Up Guide
K0749-4EN 1/03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISTA-48D and is the answer not in the manual?

Questions and answers

Related Manuals for ADEMCO VISTA-48D

Summary of Contents for ADEMCO VISTA-48D

  • Page 1: Security System

    VISTA-48D Security System Installation and Set-Up Guide K0749-4EN 1/03...

  • Page 3: Table Of Contents

    Table Of Contents                                      Features and Installation Highlights .......................
  • Page 4 System Communication and Operation ....................6-1 Panel Communication with Central Station ....................6-1 Report Code Formats ..........................6-1 Robofon 8 Format ............................6-3 ADEMCO Contact ID ® ..........................6-4 Security Codes ............................6-5 Keypad Functions ............................6-6 Panic Keys ..............................6-6 Follow-Me Feature .............................

  • Page 5: Features And Installation Highlights

     Event Logging records up to 250 selected events in a history log; control and readout from the log is done via Ademco Compass Downloader software or using an installer/master code at an alpha display keypad for local display.

  • Page 6: Compatible Devices

     Backup Battery: Rechargeable (sealed lead-acid type) 12VDC, 6AH minimum.  Audio Alarm Verification (using AAV module, such as ADEMCO UVS); can be used in conjunction with an output trigger to permit voice dialog between an operator at the central station and a person at the premises.

  • Page 7: Mounting And Wiring The Control

    S E C T I O N Mounting and Wiring the Control                                        This section describes the procedures for mounting and wiring this control and its peripheral devices.

  • Page 8: Mounting Board With Rf Receiver

    Installation Instructions Notes Mounting Board with RF Receiver  Do not mount the cabinet on or near metal a. Remove the receiver board from its case, then objects. This will decrease RF range and/or block insert the top of the board into the slots at the top RF transmissions from wireless transmitters.

  • Page 9: Wiring To Keypads

    Mounting and Wiring the Control Notes Wiring to Keypads  Typical Fixed-Word Display: Connect keypads to the control’s keypad terminals as 6128RF/6148/6150/6150RF/6150V shown on the Summary of Connections diagram.  Typical Alpha Display: 6160/6160V/6160RF/6164 Determine wire size using the Wiring Run Chart ...

  • Page 10: Sounder (Siren) Connections

    Installation Instructions Notes Sounder (Siren) Connections  The 12VDC sounder output activates when an 1. Make sounder connections to alarm output terminals 3 alarm occurs. (+) and 4 (–).  Total current drain from this output cannot For supervised output, continue with steps 2 and 3. exceed 2 amps (going beyond 2 amps will 2.

  • Page 11: Backup Battery

    Mounting and Wiring the Control Notes Backup Battery IMPORTANT: The panel will not power up 1. Place the 12-volt backup battery in the cabinet. initially on battery power only. You must plug the 2. After all connections to the control are completed and transformer in first, and then connect the battery.

  • Page 12: Basic Wired Zones

    Installation Instructions Notes Basic Wired Zones  EOLR: If the EOLR is not at the end of the loop, Normally Open Zones/Normally Open EOLR Zones the zone is not properly supervised and the system 1. Connect open circuit devices in parallel across the may not respond to an “open”...

  • Page 13: 4219/4229 Expansion Zones

    Mounting and Wiring the Control Figure 7. 4-Wire Smoke Detector Connections 4-Wire Smoke Detector Using Relay for Power Reset 4-Wire Smoke Detector Using Output 17 for Power Reset Notes 4219/4229 Expansion Zones  Supports up to 40 expansion zones (NO or NC) 1.

  • Page 14: 6164 Keypad Expansion Zones

    Installation Instructions Notes 6164 Keypad Expansion Zones  Each 6164 keypad supports up to 4 wired 1. Connect each keypad to the control’s keypad expansion EOLR or double-balanced zones and terminals. one relay output. 2. Using the keypad’s program mode, assign each ...

  • Page 15: Installing The Rf Receiver

    Mounting and Wiring the Control Notes Installing the RF Receiver  The receiver is supervised and a trouble report is Use one of the following receivers: sent (“CHECK 100” displayed) if communication RF Receiver Number of Zones between the panel and receiver is interrupted, or 5881ENL up to 8 (including keyfob buttons) if no valid RF signals from at least one supervised...

  • Page 16: Installing A Keyswitch

    Installation Instructions Transmitter Battery Life • See Wireless Transmitter paragraph in the Limitations of This Alarm System statement located at the end of this manual for information on transmitter battery life. • Some transmitters (e.g., 5802 and 5802CP) contain long-life but non-replaceable batteries, and no battery installation is required.

  • Page 17: Connecting Relay Modules

    Mounting and Wiring the Control Notes Connecting Relay Modules  Use 4204/4229 modules or 6164 keypad. 1. Mount either remotely or in the control panel.  Supervision: 4204/4229 modules and 6164 2. Connect to control’s keypad terminals using the keypad are supervised against removal. The connector harness supplied with the module.

  • Page 18: Powerline Carrier Devices

    Installation Instructions Notes Powerline Carrier Devices  When using Powerline Carrier devices, you must 1. Install up to 16 powerline carrier devices (if no relays use a Powerline Carrier Device Modulator. It are used) according to the instructions included with supplies signals from the control panel through each.

  • Page 19: On-Board Triggers

    Mounting and Wiring the Control Notes On-Board Triggers  There are two on-board triggers that can be Connect field wiring to the desired trigger pin on the used to activate output devices. 8-pin trigger connector centrally located above the  These outputs are normally high, and go low terminal strip.

  • Page 20: Phone Line Connections

     For voice session monitoring, connect an EOLR Suggested AAV Module: zone to UVCM module terminals 6 & 7, and ADEMCO UVS (shown) or Eagle 1250 program the zone as zone type 81 (*56 Menu mode). E.g., Using output 18 for the trigger, program an...

  • Page 21: Programming Overview

    S E C T I O N Programming Overview                                        About Programming You can program the system at any time, even at the installer's premises prior to the actual installation.

  • Page 22: Keypads

    Installation Instructions Keypads Keypads are identified by predefined addresses (starting at address 16) as follows: Address Keypad Program Field  always enabled for partition 1, all sounds enabled. keypad 1 NOTE: First keypad is address 16.  data field *190 keypad 2 ...

  • Page 23: Function Keys

    4. If using child-not-home pager report, define the report schedule using Scheduling mode (master code + [#] [6] [4] then select event type “03”). 5. If using a function key to manually send a message to a pager, see Function Keys paragraph below. 6.
  • Page 24 Installation Instructions  Assign to a zone covering a sensitive area such as a stock room, drug supply Type 05 room, emergency exit door, etc. Trouble when  Can also be used with a sensor or contact for an area where immediate Disarmed/ Alarm when Armed notification of an entry is desired.
  • Page 25  Usually assigned to all sensors or contacts on windows and infrequently used Type 24 exterior doors where siren sounding is NOT desired for alarms. Silent Burglary  Provides an instant alarm, with NO audible indication at any keypad or external sounder, if the zone is faulted when the system is armed in the Away, Stay, Instant, or Maximum modes.

  • Page 26: Mechanics Of Programming

    Installation Instructions Mechanics of Programming To program the system from a keypad:  You must use a 2-line Alpha display keypad.  All partitions must be disarmed. Data Field Programming Procedures Task Procedure A) Press both [  ] and [#] at the same time within 50 seconds after power is applied Entering Program Mode to the control, B) After power-up, enter [Installer code (4-1-1-2)] + 8 0 0 (long beep indicates one...
  • Page 27 Table of Device Addresses †† Enabled By… This Device Uses Address Reports as RF Receiver *56 zone programming: input device type entry Alternative Communication automatic if output to ACM field *29 enabled † Media (ACM) Telecommand Voice Module 17-23 117-123 same as keypad enables;...
  • Page 28 Installation Instructions...

  • Page 29: Data Field Programming

    S E C T I O N Data Field Programming                                        About Data Field Programming The following pages list this control’s data fields in numerical order.

  • Page 30: Zone Sounds & Timing

    Installation Instructions FIELD TITLE and DATA ENTRIES EXPLANATION Powerline Carrier devices require a House ID, identified in this field. Powerline Carrier Device (X-10) Program Powerline Carrier devices in interactive modes 79, *80 and House ID *81. 0 = A 6 = G # + 11 = L 1 = B 7 = H...

  • Page 31: Dialer Programming (  40 -  50)

    Entry 1 for each partition selects whether arming from wired Confirmation Of Arming Ding keypads causes siren ding. Confirmation of arming is 1/2 second Entry 1: 0 = no; 1 = yes, 1-second ding external sounder “ding.” Ding occurs when closing reports is sent, or (ding if armed from wired keypad) when exit delay expires.
  • Page 32 Select report format for primary and secondary phone numbers. Report Format (Primary/Secondary) * ADEMCO Contact ID format 0 = 3+1, 4+1 ADEMCO L/S STANDARD 1 = 3+1, 4+1 RADIONICS STANDARD 2 = 4+2 ADEMCO L/S STANDARD NOTE: To enable the audio “beeps” format (Follow-Me feature), refer...

  • Page 33: System Status Report Codes

    An entry of “0” in the second entry eliminates the expanded message for that report. ADEMCO or Robofon Contact ID® Reporting: Enter a digit in the first entry to enable the zone to report. Use a different digit for each zone until you have used up available digits. If the number of zones ex ceeds the number of available digits, begin with digit 1 again.

  • Page 34: Miscellaneous System Fields

    Installation Instructions Alarm restore message will be sent upon condition selected. Alarm Restores Send restore code (if fault cleared): 0 = at siren timeout (if restored) or at disarm (whether restored or not) 1 = dynamically as the fault clears 2 = only after a disarm Sent when an alarm zone is restored to its non-faulted condition or at Alarm Restore Report Code...
  • Page 35 FIELD TITLE and DATA ENTRIES EXPLANATION When enabled (1 = yes), this feature causes a “CANCELED Cancel Verify Keypad Display ALARM” display on the LCD keypad under the following conditions: 0 = no  After the kissoff of the cancel message to the Central Station, 1 = yes indicating a successful transmission.
  • Page 36 Installation Instructions FIELD TITLE and DATA ENTRIES EXPLANATION Entry 1: Sets the length of time a phone line fault must remain after Telecom Monitor Enable detected before the second digit option is activated. Entry 1–Timeout: 0 = disabled Entry 2: Selects the desired phone line fault response. 1-15 = 1 minute to 15 minutes respectively Option 2 may be used even if a relay unit or Powerline carrier device (2 = 2 min, 3 = 3 min, etc.;...

  • Page 37: Pager Programming Fields

    Pager Programming Fields FIELD TITLE and DATA ENTRIES EXPLANATION If you enter fewer than 20 digits, exit by pressing [] and next field Pager 1 Phone No. *160 number. To clear entries from this field, press 160. Enter up to 20 digits Up to 16 optional characters may be sent as a prefix to the 7-digit Pager 1 Characters *161...

  • Page 38: Miscellaneous System Fields

    Installation Instructions Miscellaneous System Fields Select desired option. *173 RF REPORTING OPTIONS 0 = none 1 = RF Tamper reports during disarm 2 = RF keyfobs send low battery 3 = RF Tamper reports during disarm and RF keyfobs send low battery Select desired options.
  • Page 39 FIELD TITLE and DATA ENTRIES EXPLANATION Select the maximum number of zones that can be bypassed. Zone Bypass Limit *180 Each partition individually uses this entry. 0 = unlimited zone bypasses in each partition 1-7 = number of zone bypasses allowed in each partition Select the method of Real-Time Clock synchronization used by the 50/60 Hz AC Operation...

  • Page 40: Keypad Programming Fields

    Installation Instructions Keypad Programming Fields NOTE: Each keypad must be assigned a unique address. Keypads programmed with the same address will give unpredictable results. FIELD TITLE and DATA ENTRIES EXPLANATION Keypad 2 Keypad 2 Device Address 17 *190 Entry 1: enter the partition in which the keypad is located Entry 1 –...

  • Page 41: Menu Mode Programming

    S E C T I O N Menu Mode Programming                                                  ...
  • Page 42 Installation Instructions PROMPT VALID ENTRIES EXPLANATION Each zone must be assigned to a zone type, which defines the way in Zone Type (ZT) 10 Zone Type which the system responds to faults in that zone. 00-24, 77, 82, 90-93 = zone Enter the Zone Type code from the list below: Perimeter type (see table at right)
  • Page 43 PROMPT VALID ENTRIES EXPLANATION Used only when enrolling wireless transmitters. Serial number Entry 10 INPUT S/N: a. Transmit two open/close sequences. If using a button-type and Loop Number Entry transmitter, press and release the button twice, but wait about 4 A 0 2 2 - 4 0 6 4 see explanation seconds before pressing the button the second time.

  • Page 44: Completing Zone Programming

    (zone number, zone type, loop number, etc.) relevant to that device. 58 Expert Programming Mode Procedures This method is designed for use by installers with previous experience in programming ADEMCO control panels. This mode is also used to program wireless keys using pre -defined templates.
  • Page 45 PROMPT VALID ENTRIES EXPLANATION Manually enter the serial number (found on the transmitter label), by Serial number 10 INPUT S/N: typing digits in the “X” locations, using the [A] (advance) or [B] (back) S/N = serial number – keys as required. You can also perform two open and close sequences; A X X X - X X X L = loop number for button-type transmitters that means pressing and releasing the...

  • Page 46: Wireless Key Programming Templates

    Installation Instructions Wireless Key Programming Templates This procedure programs the wireless keys, but a key is not active until it is assigned to a user number (see System Operation section, assigning attributes command). If the D key was previously pressed (from *58 Menu mode) to enter and duplicate 5804 and/or 5804BD wireless keys, the following screens appear.
  • Page 47 If the serial number transmitted does not match the serial number Not Confirmed Entd A022-4063 entered, a display similar to the one shown will appear. If the loop [] to continue number does not match, it will also be displayed. Rcvd A022-4064 If so, activate the button on the wireless key once again.

  • Page 48: About Output Device Programming (*79/*80 Menu Mode)

    Installation Instructions About Output Device Programming (*79/*80 Menu Mode) Output Devices: The system supports up to 16 relays and/or Powerline Carrier devices (X -10 devices) plus 2 built-in trigger outputs in any combination. These 18 “outputs” are assigned to system-wide output numbers (01-18). Use *79 Menu Mode to assign output numbers and map them to device addresses.
  • Page 49 Start Output Device Mapping by pressing *79 while in Data Programming Mode. The following prompts are displayed: 79 Menu Mode PROMPT VALID ENTRIES EXPLANATION This is the logical (or reference) relay number as used in the system. Device Output Number ENTER OUTPUT NO.

  • Page 50: *80 Menu Mode: Defining Output Functions

    Installation Instructions *80 Menu Mode: Defining Output Functions Use this mode to program output function definitions (up to 48 functions) that provide automated control of any of the output devices, based on events occurring on individual zones or zones with certain zone types.
  • Page 51 Select where the initiating event for this output definition is to occur Activated By 01 Activated By: as follows: 0 = delete 0 = delete (deletes the output function and any previous Zone List 1 = zone list programming;-see prompt below) 2 = zone type 3 = zone number 1 = zone list (go to “A”...
  • Page 52 Installation Instructions “C” If zone number was selected, this screen appears. Zone Number 01 Enter Zn No. Enter the desired zone number associated with this output number. Press [  ] to continue. Enter the zone event that will activate this output. 0 = restore;...

  • Page 53: About Zone Lists (81 Menu Mode)

    About Zone Lists (81 Menu Mode) Zone lists let you group individual zones for use with certain system actions. The following table shows the available zone lists and their purposes: Used for… List No. 1, 2 general purpose chime-by-zone linked zones night stay zones 6, 7 general purpose...

  • Page 54: About Function Key Programming (57 Menu Mode)

    Installation Instructions About Function Key Programming (57 Menu Mode) The system provides the ability to program each of the four keypad function keys to perform one of 12 system operations. The end user can then activate the function by simply pressing and holding the programmed key for 2 seconds.

  • Page 55: About Descriptor Programming (*82 Menu Mode)

    About Descriptor Programming (*82 Menu Mode) The system lets you directly enter zone descriptors for each protection zone so when an alarm or trouble occurs in a zone, an appropriate description for that zone's location can be displayed at the keypad. Each description is composed of up to 16 characters.

  • Page 56: Configurable Zone Type Programming (*83 Menu Mode)

    Installation Instructions Configurable Zone Type Programming (*83 Menu Mode) Start Configurable Zone Type Programming Mode by pressing  83 while in Data Programming mode. Enter the configurable zone type number being programmed. Zone Type Number E nt e r Z o n e T y p e 90-93 = zone type ( 0 0 = q ui t ) [] to continue...
  • Page 57 Select whether faults on zones assigned to this zone type are Display Options 9 0 D i s p O p t i o n displayed at the keypad and/or cause a chime sound. 0 = no display 1 = display only 2 = chime only 3 = chime &...

  • Page 58: Programming Installer And User Schedules

    Installation Instructions Programming Installer and User Schedules The system provides up to 32 schedules, which can be used to control 11 types of system events at pre - defined times. 24 schedules are intended for use by the end-user, and 8 are reserved for the installer. In addition, some events are also reserved for the installer only (listed in the “Enter Event”...
  • Page 59 Enter the event’s start time and days of the week to occur. Start Time S T A R T S M TW T F S To select days, position the cursor under the desired days using the † 01-12 (00-23) = hour 0 0 1 0 0 0 0 [] key to move forward, then press “1”...
  • Page 60 Installation Instructions 5-20...

  • Page 61: System Communication And Operation

    Comprises a 6-digit subscriber number and a 2-digit report code. 4+2 Format Comprises a 4-digit subscriber number and 2-digit report code. ADEMCO and Robofon Comprises a 4-digit or 10-digit subscriber number, 1-digit event qualifier (“new” or “restore”), 3-digit event code, 2-digit partition number, and 3-digit...
  • Page 62 Installation Instructions The following table lists codes for reports sent in different formats: Code for Code for Type of 3+1/4+1 3+1/4+1 Code for Report Standard Expanded 4+2/Robofon 8** Alarm SSS(S) A SSS(S) A SSSS (SS) AZ AAA(A) Z Trouble SSS(S) T SSS(S) T SSSS (SS) Tt TTT(T) t...

  • Page 63: Robofon 8 Format

    Robofon 8 Format send data in a pulsed frequency format in the following protocol: Robofon 8 format First bit Last Tone = 0, No tone = 1 Freq = 1000Hz ± 5Hz ‘U’ First Byte Last Byte 50 baud (20ms / bit) 200ms / char, 11 chars / message (‘U’...

  • Page 64: Ademco Contact Id

    Installation Instructions ® ADEMCO Contact ID ® ADEMCO and Robofon Contact ID Reporting takes the following format: CCCC(CCCCCC) Q EEE GG ZZZ where: CCCC(CCCCCC) = 4-digit or 10-digit Customer (subscriber) ID Q = 1-digit Event qualifier, where: E = new event , and R = restore...

  • Page 65: Security Codes

    Security Codes The system supports up to 48 security codes, which can each be assigned one of 5 authority levels. The authority level determines the functions each code can perform as follows: Authority Levels (authority levels can be assigned to users 3-49 only; users 1 and 2 cannot be changed) Level User No.

  • Page 66: Keypad Functions

    Installation Instructions Keypad Functions The following is a brief list of system commands. For detailed information concerning system functions, refer to the User's Manual. Keypad Commands Function Description Silence alarms Pressing any key will silence the keypad sounder for 10 seconds. Disarming the system will silence both keypad and external sounders.

  • Page 67: Follow-Me Feature

    Follow-Me Feature  This feature lets users of each partition enter a phone number that the system will call in the event of an alarm at the protected premises, thus alerting the user to the alarm.  The message sent consists of a series of multi-frequency (DTMF) tones (beeps). ...

  • Page 68: Various System Trouble Displays

    Installation Instructions Various System Trouble Displays Alpha Display Fixed Disp. Meaning Appears if an exit or interior zone contained a fault during closing at the time the CANCELED ALARM Exit Delay ended (e.g., exit door left open and the zone was not auto-bypassed), but the system was disarmed during the Entry Delay time.

  • Page 69: Testing The System

    S E C T I O N Testing the System                                        About Test Procedures After the installation is complete, you should perform the following tests: System Test:...

  • Page 70: Go/No Go Test Mode

    Installation Instructions NOTES: • All BR type RF units (e.g., 5804) must physically be activated to clear the display. • When one button of a transmitter (RF, UR, or BR) is activated, all zones assigned to other buttons on that transmitter are cleared. This also applies to multiple-loop transmitters (e.g. 5816 and 5817). •...

  • Page 71: Specifications & Accessories

    3. Communication: FORMAT SUPPORTED: ADEMCO Express: 10 characters/sec, DTMF (multi-frequency) Data Tones, 1400/2300Hz ACK, 1400Hz KISSOFF. ADEMCO Low Speed: 10 pulses/sec, 1900Hz Data Tone, 1400Hz ACK/KISSOFF. Radionics/SESCOA: 20 pulses/sec, 1800Hz Data Tone, 2300Hz ACK/KISSOFF. Can report 0-9, B-F Robofon 8 See description in Communication section.
  • Page 72 Low-profile, Ionization type, direct wire 1100 Transformers: 1321 or 16.5VAC, 25VA wired-in transformer Sounders: Ademco AB-12M 25cm Motorized Bell & Box Ademco 1011BE12M 25cm Motorized Bell & Box Ademco 702 Outdoor Siren Ademco 719 2-Channel Siren Ademco 747 Indoor Siren...

  • Page 73: 5800 Series Transmitter Input Loop Identification

    5800 Series Transmitter Input Loop Identification All of the transmitters illustrated below have one or more unique factory assigned input (loop) ID codes. Each of the input loops requires its own programming zone (e.g., a 5804's four inputs require four programming zones). NOTE: For information on any transmitter not shown, refer to the instructions accompanying that...
  • Page 74 Installation Instructions Compatible 5800 Series Transmitters Table (continued) Model Product Input Type Description Transmits a fault condition when temperature drops below 45°F. 5816TEMP Low-Temp. Sensor Has three unique input (loop) codes: one for a “Primary” contact 5817 Multi-Point Universal loop with programmable options; the others for two “auxiliary” Transmitter closed circuit contact loops.
  • Page 75 – NOTES –...
  • Page 76 Installation Instructions – NOTES –...

  • Page 77: Limitations And Warranty

    S E C T I O N Limitations and Warranty                                        WARNING THE LIMITATIONS OF THIS ALARM SYSTEM While this System is an advanced design security system, it does not offer guaranteed protection against burglary, fire or ot her emergency.
  • Page 78 Installation Instructions – INDEX – 1321 AC Transformer ..1-2, 2-42-11 DIP Switches........2-8 Perimeter Burglary ......3-3 1321X10 ....1-2, 2-4, 2-11, 9-2 Disarming ......3-4 5-11, 7-2 Phone Line ........2-12 24-Hour Audible Alarm ..... 3-4 Double-Balanced ......2-6 Power Failure ......
  • Page 79 Figure 17. Summary of Connections...
  • Page 80 24 months from the date stamp con trol on the product or, for products not having an Ademco date stamp, for 12 months from date of origina l purchase unless the installation instructions or catalog sets forth a shorter period, in which case the shorter period shall apply.
