Page 3
Local programming requires the use of a 2-line alpha keypad connected to the keypad terminals on the control. Field Function ] = Default Value Programmed Values Field Function ] = Default Value Programmed Values SYSTEM SETUP ( 20 – 30) 20 INSTALLER CODE 27 X–10 HOUSE CODE Enter 4 digits, 0–9...
46 REPORT FORMAT † † Primary Secondary 0 = 3+1, 4+1 ADEMCO L/S STANDARD 1 = 3+1, 4+1 RADIONICS STANDARD 2 = 4+2 ADEMCO L/S STANDARD 3 = 4+2 RADIONICS STANDARD 6 or undefined = 4+2 ADEMCO EXPRESS 7 = ADEMCO CONTACT ID REPORTING...
Page 5
56 / 58 ZONE ASSIGNMENT/ALARM REPORT CODES This field is an interactive mode. Fill in the required data on the worksheet below (and on next page) and follow the programming procedure in the installation manual. Zone Types are shown on page 6 of this manual. →...
65 OPEN REPORT CODE † A 0 ( not #+10) in both boxes will disable the report. With Ademco Contact ID Reporting: Enter any digit (other 66 ARM AWAY/STAY RPT CODE [00] †† than 0) in the first box, to enable zone to report (entries in the AWAY STAY second boxes will be ignored).
RESTORE REPORT CODES ( 70 – 76) † 70 ALARM RESTORE RPT CODE 73 AC RESTORE RPT CODE [00] 2nd digit is automatically sent as the 2nd digit of 74 LOW BAT RESTORE RPT CODE [00] the zone alarm report code programmed in 56, if expanded or 4+2 reporting is selected.
DOWNLOAD INFORMATION ( 94, 95) DOWNLOAD PHONE NO. RING DET COUNT FOR DWNLDING 0 = Disable Station Initiated Download; 1–14 = number of rings (1–9, # +10 =10, # +11 =11, # +12 =12, # +13 =13, # +14 =14); 15 = answering machine defeat (# +15 =15) Enter up to 20 digits, 0–9;...
Page 9
OUTPUT RELAYS/POWERLINE CARRIER DEVICES WORKSHEET FOR 80 and 81. Applicable only if Relays and/or Powerline Carrier devices are to be used. 80 OUTPUT DEVICES – This is an Interactive Menu mode. Fill in the required data on the worksheet below and follow the programming procedure in the installation manual as you enter the data in response to the displays and prompts that appear in sequence.
Page 10
ZONE LISTS FOR OUTPUT DEVICES (01 - 03); Cross Zones (04); and Night-Stay Zones (05). This is an interactive mode. Fill in the required data on the worksheet below and follow the procedure in the installation manual as you enter the data in response to the displays and prompts that appear in sequence. Record desired zone numbers below.
SPECIAL MESSAGES OC = OPEN CIRCUIT (no communication between console and control). EE or ENTRY ERROR = ERROR (invalid field number entered; re-enter valid field number). After powering up, " AC, dI " (disabled) or " Busy Standby " and " NOT READY " will be displayed after approximately 4 seconds. This will revert to READY in approximately.
ENROLLED TRANSMITTERS ZONE SERIAL No. (If applicable) INPUT Stick Serial No. Label from Transmitter ZONE ZONE LOOP TYPE Here TYPE DEVICE LOCATION – 13 –...
Page 14
ENROLLED TRANSMITTERS (cont'd) ZONE SERIAL No. (If applicable) ZONE ZONE INPUT Stick Serial No. Label from Transmitter LOOP TYPE TYPE Here DEVICE LOCATION – 14 –...
Page 15
AND/OR ACCORDANCE WITH THE NATIONAL FIRE PRO- BE DONE WITH A 6160 CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL SOUNDING FOR FIRE (e.g. USE ADEMCO No. 702 AUX CURRENT 4285/4286 VOICE MODULE (160mA) CONNECTED TO KEYPAD TECTION ASSOCIATION’S STANDARD 72, CHAP- INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT SIREN, OR 12V BELL).
