VISTA-40
2-Partition
Security System
Programming Guide
Single Partition and 2-Partition
Programming Forms
®
N7001PRV4 7/98

Advertisement

loading
Need help?

Need help?

Do you have a question about the VISTA-40 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADEMCO VISTA-40

Summary of Contents for ADEMCO VISTA-40

  • Page 1 VISTA-40 2-Partition Security System Programming Guide Single Partition and 2-Partition Programming Forms ® N7001PRV4 7/98...

  • Page 2: Table Of Contents

    PARTITION-SPECIFIC DATA FIELDS ..................... 11 PROGRAMMING WITH #93 MENU MODE (Overview)).............. 13 CHANGING ZONE RESPONSE TYPE & REPORT CODES (EXPERT MODE) ....... 14 SYSTEM LAYOUT WORKSHEETS ....................16 Other Documents Provided With The VISTA-40 Document Purpose and Content Installation Use the Installation Instructions portion of this manual when installing the hard-ware...

  • Page 3: Single Partition Programming Form

    • To enter program mode, enter installer code + [8] + [0] + [0] • To set standard defaults, press 9 7 • To set communication defaults, press 94 + one of the following: 80=low speed; 81=Ademco Express; 82=Ademco High Speed; 83=Ademco's Contact ID •...
  • Page 4 01 if VIM module is used. 2 2 KEYPAD PANIC ENABLES [0-0-1] PRIMARY FORMAT 1=enable; 0=disable 0=Low Speed; 1=Contact ID; 2=Ademco High Speed; 3=Ademco Express 2 3 MULTIPLE ALARMS LOW SPEED FORMAT (Primary) 1=yes; 0=no 0=Ademco Low Speed;...
  • Page 5 VISTA-40 SINGLE PARTITION PROGRAMMING FORM SYSTEM NON ALARM CODES 54 - 57 ALARM REPORT CODE & ID DIGITS FOR ZONES 1-16. Skip these fields. Use #93 Menu Mode, First Digit Second Digit Zone Programming to assign report codes. Close Second digit of each 58 SUPV.
  • Page 6 VISTA-40 SINGLE PARTITION PROGRAMMING FORM 1 3 4 COMM. SPLIT REPORT SELECTION 1 7 0 EVENT LOG TYPES 0=no; 1=alarms primary, others secondary; 1=enable logging; 0=disable Alrm Chck Byps O/C Systm 2=open/close, test secondary, others primary; See 51 for notes.

  • Page 7: Two-Partition Programming Form

    • To enter program mode, enter installer code + [8] + [0] + [0] • To set standard defaults, press • To set communication defaults, press 94 + one of the following: 80=low speed; 81=Ademco Express; 82=Ademco High Speed; 83=Ademco's Contact ID •...

  • Page 8: System-Wide Data Fields

    1 7 AC LOSS KEYPAD SOUNDING 1=yes; 0=no PRIMARY FORMAT 1 9 RANDOMIZE AC LOSS REPORT 0=Low Speed; 1=Contact ID; 2=Ademco High Speed; 3=Ademco Express 1=randomize 10-40 min.; 0=no 4 6 LOW SPEED FORMAT (Primary) 2 0 4285 PHONE MODULE ACCESS CODE 0=Ademco Low Speed;...
  • Page 9 VISTA-40 TWO-PARTITION PROGRAMMING FORM SUPV. & RESTORE CODES 1 3 2 RF RECEIVER TYPE (zones 87-99) 1=4281; 2=5881; 0=NONE 1 3 3 TOUCH-TONE W/ROTARY BACKUP ENABLE Alrm Rst. 1=enable; 0=disable Trouble 1 3 4 COMM. SPLIT REPORT SELECTION Trble Rst.
  • Page 10 VISTA-40 TWO-PARTITION PROGRAMMING FORM 3rd Page Programming Fields (press 2 0 0 NUMBER OF PARTITIONS Enter 2 for two partition systems. 2 0 1 DAYLIGHT SAVINGS TIME START/END MONTH Start 00-12; if no daylight savings time, enter 00,00; default=04,10] 2 0 2 DAYLIGHT SAVINGS TIME...

  • Page 11: Partition-Specific Data Fields

    VISTA-40 TWO-PARTITION PROGRAMMING FORM PARTITION-SPECIFIC FIELDS (PARTITION #1) To program these fields, 1. Press 91 to select a partition. 2. Enter a partition-specific field number (ex. 09). 3. Repeat steps 1 & 2 for each partition in the system. 4. To return to the global program fields, enter a global field number.
  • Page 12 VISTA-40 TWO-PARTITION PROGRAMMING FORM PARTITION-SPECIFIC FIELDS (PARTITION #2) To program these fields, 1. Press 91 to select a partition. 2. Enter a partition-specific field number (ex. 09). 3. Repeat steps 1 & 2 for each partition in the system. 4. To return to the global program fields, enter a global field number.

  • Page 13: Programming With #93 Menu Mode (Overview))

    PROGRAMMING WITH #93 MENU MODE (Overview*) N O T E : The following fields should be preset before beginning: 2 00 Number of Partitions; 1 32 Receiver Type. In addition, receivers should be programmed via Device programming. * Refer to the #93 Menu Mode section of the separate INSTALLATION INSTRUCTIONS document for detailed programming procedures with this mode.

  • Page 14: Changing Zone Response Type & Report Codes (Expert Mode)

    REPORT CODE DATA FIELDS (Expert Mode) • Because the VISTA-40 supports various types of input devices (such as button type transmitters, serial number polling loop devices, etc.), zone characteristics, including zone response types and report codes, must be initially programmed using #93 Menu Mode. However, once a zone has been programmed, changes in response type or report code can be made using the respective data fields.
  • Page 15 CHANGING ZONE RESPONSE TYPE AND REPORT CODE DATA FIELDS REPORT CODE FIELDS ALARM REPORT CODE & ID DIGITS FOR ZONES 81-87, RF ALARM REPORT CODE & ID DIGITS FOR ZONES 1-32 & RCVRs & PANICS, & THEIR SUPV. & RESTORE CODES SUPV.

  • Page 16: System Layout Worksheets

    SYSTEM LAYOUT WORKSHEETS As with any security system, you should first define the installation. This includes determining how many partitions will be used, how many zones per partition, and how many users per partition. You will also need to determine what peripheral devices will be needed, and basic system options such as exit/entry delays, etc.
  • Page 17 DEVICES (Keypads, 4204, etc.) ADDRESSABLE DEVICE OPTIONS † Device Type Home Sounder Address Partition Option † Device type 1, and 2 only. Keypad Sounder Options: 00 = no suppression 01 = suppress arm/disarm and entry/exit beeps 02 = suppress chime mode beeps only 03 = suppress arm/disarm, entry/exit, chime mode beeps D e v i c e...
  • Page 18 ZONE DEFINITIONS FOR ZONES 1–24 † Enter loop number on module † Parti- Ser. Hard RPM RPM RF Trans. Type Loop number must be “1” for hardwire and DIP devices) † Zone Zone tion RF UR BR Report Zone Information (part numbers) & left lp rght lp Wired Type (1-2)
  • Page 19 ZONE DEFINITIONS FOR ZONES 25–48 † Enter loop number on module RF Trans. Type † Parti- Ser. Hard RPM RPM Loop number must be “1” for hardwire and DIP devices) † Zone Zone tion RF UR BR Report Zone Information (part numbers) & left lp rght lp Wired Type (1-2)
  • Page 20 ZONE DEFINITIONS FOR ZONES 49–64 † Enter loop number on module RF Trans. Type † Parti- Ser. Hard RPM RPM Loop number must be 1 for hardwire and DIP devices) † Zone Zone tion RF UR BR Report Zone Information (part numbers) & left lp rght lp Wired Type (1-2)
  • Page 21 ALPHA VOCABULARY (For Entering Alpha Descriptors. To select a word, press [#] followed by the word's 3-digit number.) Bulleted words in bold face type are those that are also available for use by the 4285 phone module. If using a phone module, and words other than these are selected for alpha descriptors, the phone module will not provide annunciation of those words.
  • Page 22 5800 Series Transmitter Input Loop Identification • All of the transmitters illustrated below have one or more unique factory assigned input (loop) ID codes. Each of the inputs requires its own programming zone (e.g., a 5803's three inputs require three programming zones).
  • Page 23 NATIONAL FIRE PROTECTION ASSOCIATION'S STANDARD 72, (NATIONAL Normal: 350mSec-500mSec, or 720mSec FIRE PROTECTION ASSOC., BATTERYMARCH PARK, QUINCY, MA. 02269). (default response) PRINTED INFORMATION DESCRIBING PROPER INSTALLATION, OPERATION, TESTING, MAINTENANCE, EVACUATION PLANNING AND REPAIR SERVICE IS TO BE PROVIDED WITH THIS EQUIPMENT. VISTA-40 SUMMARY OF CONNECTIONS...
