Page 1 Features Q.E.D. programming for quick enrollment of devices. 2-Partitioned Security System VISTA-40 This Control Supports the Ademco 2-Way Voice Interface Module (VIM) For Audio Alarm Verification (AAV) Installation Instructions • Installation Instructions • Installation Instructions N7001–INSTV2 6/97, Part of N7001V2 downloaded from: http://www.guardianalarms.net...
Page 2 RECOMMENDATIONS FOR PROPER PROTECTION The Following Recommendations For The Location Of Fire And Burglary Detection Devices Help Provide Proper Coverage For The Protected Premises. Recommendations For Smoke And Heat Detectors With regard to the number and placement of smoke/heat detectors, we subscribe to the recommendations contained in the National Fire Protection Association's (NFPA) Standard #72 noted below.
Page 3: Table Of Contents
PART 1. INSTALLATION INSTRUCTIONS Use Part 1 when installing the hardware components of the installation. Section 1. GENERAL INFORMATION... 7 SUMMARY OF SYSTEM FEATURES... 7 INTRODUCTION TO THE PARTITIONED SYSTEM ... 9 Section 2. INSTALLING THE CONTROL... 10 MOUNTING THE CABINET ... 10 PHONE LINE CONNECTIONS...
Page 4 Section 6. RELAY OUTPUTS & POWERLINE CARRIER DEVICES... 31 General Information... 31 4204 Relay Module... 31 4300 Transformer & X-10 Devices... 31 Section 7. THE 4285 PHONE MODULE... 32 General Information... 32 Mounting The Phone Module... 32 Wiring Connections ... 33 Programming The Control For Phone Access ...
Page 5 VIM Voice Interface Module Prompts... 64 Relay Programming... 65 Zone List Programming ... 68 Programming Relays for Silencing of External Sounders When Using the VIM ... 68 Programming the VIM for Relay Triggering on Supervision Fault... 69 Relay Voice Descriptors ... 69 Relay Voice Descriptors and Custom Word Substitute Vocabulary ...
Page 6: Part 1. Installation Instructions
PART 1 INSTALLATION INSTRUCTIONS Ð 6 Ð...
Page 7: General Information
Section 1. GENERAL INFORMATION SUMMARY OF SYSTEM FEATURES The VISTA-40 Control is a microprocessor based, programmable, partitioned system, and features EEROM memory technology (power loss does not result in the loss of programmed data). Before installing this partitioned system, become completely familiar with the partitioning concepts, including zone distribution (each zone can be assigned to only one partition), output relay features, user code usage and authority levels, and the user-friendly menu mode of programming.
Page 8 Descriptors ¥ All programmed descriptors can be displayed (one at a time) by pressing and holding the READY key for 5 seconds, then releasing the key. This serves as a check for installers to be sure all descriptors are entered properly. Event Logging ¥...
Page 9: Introduction To The Partitioned System
INTRODUCTION TO THE PARTITIONED SYSTEM Basic Partitioning Features The following lists the partitioning features of the VISTA-40 system. Simple, Secure, Reliable ¥ Easy to use and program as the simplest alarm system. ¥ Integrity of security is not compromised for any users of the system.
Page 10: Section 2. Installing The Control
Section 2. INSTALLING THE CONTROL MOUNTING THE CABINET General The VISTA-40 is supplied with a 12.5"W x 14.5"H x 3"D cabinet suitable for use in residential and non-certified commercial burglary installations. Mount the Control cabinet to a sturdy wall using fasteners or anchors (not supplied) in a clean, dry area which is not readily accessible to the general public.
Page 11: Phone Line Connections
PHONE LINE CONNECTIONS Standard Phone Line IMPORTANT!: If using a 4285 Phone Module, phone connections must be Connections made exactly as shown in the PHONE MODULE section, even if the system is not programmed to communicate with a monitoring station. The 4285 Phone Module will not function unless the system is wired exactly as described.
Page 12: Section 3. Powering The System
Section 3. POWERING THE SYSTEM Primary Power Power to the Control panel is supplied by model No. 1361* Plug-in Transformer which is rated at 16.5VAC, 40VA. Caution must be taken when wiring this transformer to the panel to guard against blowing the fuse inside the transformer (non-replaceable).
Page 13: Power-Up Procedure
Power-Up Procedure POLLING LOOP CURRENT DRAW WORKSHEET RPM DEVICE 998MX PIR 4191SN Contact 4194 Contact 4192SD Photo Smoke 4192SDT Smoke w/Heat 4192CP Ionization Detector 4275 Dual Element PIR 4278 Quad Element PIR 4190WH 2-Zone RPM 4208 8-Zone RPM 4278EX-SN PIR 4939SN Contact 4959SN Contact * If the total current draw exceeds 64 mA, a 4197 Loop Extender module must be used.
Page 14: Section 4. Installing Remote Keypads
Section 4. INSTALLING REMOTE KEYPADS General The Control supplies up to 750 mA of auxiliary power for remote keypads, polling loop devices and/or other auxiliary devices such as motion detectors or 4-wire smoke detectors*. The Control supports, independent of auxiliary power considerations, up to 16 addressable remote keypads (6128, 6137, 6139, 6139AV ).
Page 15: Setting The Keypad Address
Wire Gauge Maximum Length #22 gauge #20 gauge #18 gauge #16 gauge Setting the To set the keypad's address, do the following: Keypad Address 1. Enter the address mode: Power-up (plug-in) the keypad. Within 60 seconds of system power-up, press and hold down the [1] and [3] keys at the same time for 3 seconds.
Page 16: Av 2-Way Voice Keypads
6139AV 2-Way Voice The control supports the VIM Voice Interface Module, which can support up to six Keypads 6139AV 2-way voice keypads. These keypads feature a built-in microphone and speaker that allows a central station operator to "listen-in" and/or speak to persons at the protected premises after an alarm has occurred.
Page 17: Basic 9 Hard-Wired Zones
Section 5. ZONE CONFIGURATIONS BASIC 9 HARD-WIRED ZONES General Information Zones 1-9 are reserved for traditional hard-wired devices. The following table summarizes zone usage. Zone 1 Zones 2, 3, 4, 6 Zone 5 Zone 7 Zone 8 Zone 9 Programmable Response Time For Zone 9: Zone response time for zone 9 can be set to either 350mS (normal) or 10mS (fast) via program field *14.
Page 18: Compatible Smoke Detectors
Photoelectric Photoelectric w/ 135° heat Photoelectric w/heat sensor, direct wire Photoelectric, direct wire Photoelectric w/heat sensor, direct wire Photoelectric w/B401B base Photoelectric w/heat sensor & B401B base Ionization Ionization, direct wire Ionization w/B401B base Photoelectric duct detector w/DH400 base Ionization duct detect. w/DH400 base Zone 1 Advisories If the EOLR is not at the end of the loop, the zone is not properly supervised.
Page 19: Compatible Glass Break Detectors
Use detectors which are compatible with the following ratings: Standby Voltage:... 5VDC-Ð13.8VDC Standby Resistance: Alarm Resistance:... Less than 1.1k ohms (see note below) Alarm Current: ... 2 mA -Ð10 mA Reset Time:... Less than 6 seconds The IEI 735L series detectors have been tested and found to be compatible with these ratings.
Page 20: 2-Wire Polling Loop Expansion (Zones 10 Through 64)
2-WIRE POLLING LOOP EXPANSION (Zones 10 through 64) General Information The following table summarizes polling loop expansion characteristics. Applications RPM Address (ID) Connections Maximum Polling Loop Wire Runs Important: When in a star configuration, no individual run can be longer than the table indicates, and the total length of all the sensor star runs, combined, cannot exceed 4000'.
Page 21: Compatible Polling Loop Devices
Important! Since the phone module, RF receiver(s), VIM and the polling loop are shared Fault Annunciation among the 2 partitions, the scheme for annunciating their failure follows: Respective faults (for zones 87, 88Ð91, 93 & 97) will report as trouble conditions only, and as such, should be assigned either zone type 00 if no annunciation is desired, or zone type 05 if annunciation as trouble condition is desired.
Page 22: Wireless Expansion (Zones 1Ð63)
WIRELESS EXPANSION (Zones 1Ð63) General Information 4281 Series R e c e i v e r s 4281H 4281M 4281L The following table summarizes wireless expansion characteristics. Zones Supported RF Receivers (General) Receiver Supervision ¥ If the connection is broken between the receiver and the control House Identification Sniffer Mode For House ID...
Page 23: 4281 Series Receiver
The following table highlights the features of each receiver. Feature Wiring House ID Receiver Address Cover Removal Go/No Go Mode Spatial Diversity (2 antennas) Transmitter ID 4281 Series Receiver ¥ Set field 1*32 to 1. ¥ Using #93 Menu modeÐDevice Programming, select as RF device type (type 3). ¥...
Page 24: Transmitters
Transmitters NOTE: After replacing a low or dead battery, activate the transmitter and enter the security code + OFF to clear its memory of the "Low Battery" signal. Ð 24 Ð The following table summarizes wireless transmitter characteristics. Transmitters ¥ Supports 5700 or 5800 series transmitters. (General) ¥...
Page 25: Arming/Disarming With Rf Keys (5801, Etc.)
Arming/Disarming 5800 series RF keys can be used to arm and disarm the system. These With RF Keys transmitters include the 5801, 5802, 5804 and any other 5800 series transmitter ( 5 8 0 1 , 5 8 0 2 , e t c . ) (except 5827 wireless keypad) if programmed for one of zone type responses 20-22.
Page 26: Fault Annunciation
Fault Annunciation Important Battery Notice Compatible 5700 Series Wireless Devices Ð 26 Ð Since the phone module, RF receiver(s), VIM and the polling loop are shared among the 2 partitions, the scheme for annunciating their failure follows: Respective faults (for zones 87, 88Ð91, 93 & 97) will report as trouble conditions only, and as such, should be assigned either zone type 00 if no annunciation is desired, or zone type 05 if annunciation as trouble condition is desired.
Page 27: Compatible 5800 Series Wireless Devices
Compatible 5800 Series Wireless Devices (Refer to the installation instructions provided with each transmitter) VOLTAGE TRIGGERS (Connector J7) (Ground St art Module, Keyswit ch, Remot e Keypad Sounder, or a non-Ademco AAV Unit requiring a Volt age t rigger) General Information Output 1: Operates, by default, as a trigger for the 675 ground start module.
Page 28: Ground Start Module
Output 2, 3, & 4 Rating: Ground Start Module Not intended for use in UL Listed applications. Remote Keyswitch Ð 28 Ð Outputs 2 & 4: Operate, by default, as Fire and Silent Panic/Duress triggers respectively. These triggers may optionally be programmed to act as Arm and Ready status indicators when it is desired to use the 4146 keyswitch.
Page 29 A momentary short across this zone will arm the system in the "AWAY" mode. If the short is held for more than 3 seconds, the system will arm in the "STAY" mode. After the system has been armed, the next time zone 7 is shorted, the system will disarm.
Page 30: Remote Keypad Sounder Operation And Wiring
Remote Keypad Sounder Operation & Wiring TO AUX POWER + TERMINAL 6 (10mA CURRENT DRAW) Using A Trigger To Activate Another ManufacturerÕs AAV Unit (if necessary) Ð 30 Ð An optional Amseco PAL 328N can be used for installations where it is desired to remote the sounds produced by the keypad's built-in piezo sounder for one partition.
Page 31: Section 6. Relay Outputs & Powerline Carrier Devices
RELAY OUTPUTS & POWERLINE CARRIER DEVICES General Information The VISTA-40 supports up to 8 relay outputs. These outputs may consist of relay outputs from the 4204 output relay module (4 relay outputs per module) or X-10 device outputs. Outputs can be activated and deactivated by predetermined events such as turning on lights in the event of an alarm condition and/or closing a fire door in the event of a fire alarm condition.
Page 32: Section 7. The 4285 Phone Module
Section 7. THE 4285 PHONE MODULE General The 4285 Phone Module is an add-on accessory for the VISTA-40 that will permit Information access to the security system via a Touch-tone phone (either on premises or by a call-in when away). Only one Phone Module can be used in this security system and it must be assigned as device address 04 only and assigned to partition 1 using #93 Menu Mode, Device Programming.
Page 33: Wiring Connections
Wiring Connections General The 4285 is wired between the control panel and the premises handset(s). It listens for touch tones on the phone line and reports them to the control panel. During on-premises phone access, it powers the premises phones; during off- premises phone access, it seizes the line from the premises phones and any answering machines.
Page 34: Installation When The Telephone System Includes An Answering Machine
WIRING NOTES: 1. Wire the 4285 Phone Module exactly as shown, using a direct-connect cord and RJ31X jack. CALLER ID 2. If Touch-tones are not present following phone access to the security @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ h ? @ @ @ @ @ @ @ @ e ?
Page 35: 2-Way Voice Keypads & Audio Alarm Verification (Aav)
Section 8. 2-WAY VOICE KEYPADS & AUDIO ALARM VERIFICATION (AAV) General Information The VISTA-40 features 2-way voice capability when used with the Ademco Voice Interface Module (VIM) and 6139AV 2-way voice keypads. IMPORTANT: Audio alarm verification reports only on the primary phone number.
Page 36: 6139Av Audio Connections To The Vim Module
6139AV Audio Connections To The VIM Module Programming Information For the VIM Module 2-WAY † 2-WAY † 2-WAY † VOICE VOICE VOICE KEYPAD KEYPAD KEYPAD TO J5 AUDIO OUTPUT PHONE MODULE IMPORTANT: ADDRESS 4 RESERVED FOR VISTA INTERACTIVE PHONE MODULE SET DIP SWITCHES BEFORE CONNECTING SWITCH...
Page 37: Programming Information For The 6139Av Keypad
¥ Chime option for other partition during 2-way voice session. ¥ VIM text option for displaying voice mode text at the keypad. ¥ VIM AC loss option, when enabled, allows 2-way voice communication after AC ¥ The AUTO CALLBACK option, when enabled, allows callback to initiate 2-way Programming ¥...
Page 38: Using A Non-Ademco Audio Alarm Verification (Aav) Unit
Using A Non-Ademco Audio Alarm Verification (AAV) Unit Ð 38 Ð If you prefer to use another manufacturerÕs AAV unit in place of the Ademco VIM unit, contact the manufacturer for information regarding the wiring of their unit to the VISTA-40. When using another manufacturerÕs AAV unit, see Notes below. Some AAV modules allow remote triggering by ring detection at the alarm installation.
Page 39: Section 9. External Sounders
Section 9. EXTERNAL SOUNDERS Relay Output The Control provides a wet bell relay output which is used to power external alarm sounders. Connections are made to terminals 4 (positive output) and 5 (negative return). See SUMMARY OF CONNECTIONS Diagram. UL Household Installations For installations which must provide UL Listed protection, the total current drawn from this output and the auxiliary power output, combined, must not exceed 750mA in order to comply with the battery independence requirements.
Page 40: Part 2. Programming Procedures
PART 2 PROGRAMMING PROCEDURES Ð 40 Ð...
Page 41: General Programming Procedures
GENERAL PROGRAMMING PROCEDURES GENERAL INFORMATION The system is shipped with a set of pre-programmed default values that are Review the global and designed to meet the needs of many installations. These can be changed by the specific partitioning features installer to suit specific needs if desired, by using a 6139 (AV) alpha keypad*. In listed in the GENERAL INFORMATION section of addition, four sets of pre-programmed communication default values can also be...
Page 42: Programming Steps
Programming Steps IMPORTANT: The programming scheme is different than other Ademco controls and from previous versions of the VISTA-40. Be sure to review these steps before attempting to program this system. Ð 42 Ð Set the keypads to the appropriate addresses. Set factory defaults by pressing *97.
Page 43: Section 2. Zone Types
Zone Types & Applicable Sensors Type 00 Zone Not Used Type 01 Entry/Exit #1 Burglary. Type 02 Entry/Exit #2 Burglary. Type 03 Perimeter Burglary. Type 04 Interior, Follower. Section 2. ZONE TYPES The VISTA-40 supports up to 64 zones of hard-wire, polling loop and/or wireless protection, distributed among up to 2 partitions.
Page 44 Type 05 Trouble by Day/Alarm by Night. Type 06 24-hour Silent Alarm. Type 07 24-hour Audible Alarm. Type 08 24-hour Auxiliary Alarm. Type 09 Supervised Fire. (No Verification) Type 1 0 Interior w/Delay. Type 20 Arm-Stay* Type 21 Arm-Away* Type 22 Disarm* Type 23 No Alarm Response...
Page 45: Section 3. Data Field Programming
Section 3. DATA FIELD PROGRAMMING PROGRAMMING SYSTEM-WIDE (GLOBAL) DATA FIELDS General Procedure The global (i.e. non partition-specific) programming fields are grouped into three sets (referred to as "pages"), as represented in the diagram below. The first page of fields is accessed automatically after entering a field number. To access the other pages of fields (indicated on the programming form by a "1"...
Page 46: Index To Programming Fields
INDEX TO PROGRAMMING FIELDS In the following pages, the programming fields have been arranged by functional group. Use this index to cross reference the numerical ordered fields on the programming form with the text. Field Group *0 0 Control *0 2 #93 Menu Mode *0 3 #93 Menu Mode...
Page 47: Data Field Descriptions
DATA FIELD DESCRIPTIONS Control Options * 0 0 Installer Code * 1 4 Zone 9 Response Time * 1 5 Keyswitch Assignment * 1 7 AC Loss Keypad Sounding * 1 8 UL AC Loss S ir e n * 1 9 Randomize AC Loss Report * 2 0...
Page 48 Control Options (continued) * 2 7 Test Report Enter the test reporting interval in hours, 001-199. Enter 000 if no test Interval reporting is desired. If a test report is desired, enter a test code in fields *81 & *82, location 7. Max. 024 for UL. * 2 8 Power Up In Enter 1 if it is desired that upon power-up, the system will assume the system...
Page 49: Downloader Options
Downloader Options Download Phone No. * 3 6 Download ID No. * 3 7 Download Command Enables 2nd PAGE FIELD 1*53 Download Callback Dialer Options Touch-Tone Or Rotary Dial * 3 1 P A B X Access Code Primary Phone Number Secondary Phone Number * 4 0...
Page 50 Dialer Options (continued) * 4 3 Dial Tone Determines whether the control will wait for a true dial tone before dialing, or if it Detection will wait for a predetermined delay before dialing (delay is programmed in Dial Tone Pause field *42). The latter may be necessary in high-noise environment Telco networks where noise can be confused with dial tone, resulting in premature dialing.
Page 51: Wireless Options
Dialer Options (continued) * 8 0 Zone Type Enter 1 to enable restore reporting for individual zone types. Enter 0 if no Restores restore report is desired for a zone type. For Types 9-10 * 8 1 - * 8 2 Non-Alarm Enter the appropriate report codes as indicated on the programming form.
Page 52: Partitioning Options
Wireless Options (cont.) 1 * 5 7 Enable 5800 Enter 1 to have the system arm/disarm in accordance with the button's user's RF Button global arming settings. Enter 0 if the button is not to be used to global arm the Global Arm system (however, home partition arming will still occur).
Page 53: Programming Partition-Specific Data Fields
PROGRAMMING PARTITION-SPECIFIC DATA FIELDS General Procedure Partition-Specific Field Descriptions * 0 9 Entry Delay #1 * 1 0 Exit Delay #1 * 1 1 Entry Delay #2 * 1 2 Exit Delay #2 * 1 3 Alarm Sounder Duration * 1 6 Confirmation Of Arming Ding * 2 2...
Page 54 Quick Arm * 3 2 Primary Subscriber Acct # * 3 8 Prevent Zone XX Bypass * 3 9 Open/Close Report For Installer Code * 8 4 Swinger Suppression * 8 5 Enable Dialer For Panics & Duress * 8 7 Entry Warning * 8 8 Burg.
Page 55: Programming With #93 Menu Mode
PROGRAMMING WITH #93 MENU MODE General Information NOTE: The following fields should be preset before beginning: 2*00 (Number of Partitions); 1*32 (receiver type). In addition, receivers should be programmed via Device programming. After programming all system-related programming fields in the usual way, press #93 while still in programming mode to display the first choice of the menu driven programming functions, which are as follows: ZONE PROG?
Page 56: Zone Programming
Zone Programming Important!: Note that before programming zone characteristics, field 2*00 (number of partitions) and field 1*32 (receiver type) must be programmed. This identifies the use of RF Receivers and the number of partitions being used in the system. Enter Programming mode, then press #93 to display "ZONE PROG?". ZONE PROG? 1=YES 0=NO ENTER ZN NO.
Page 57 Zone Programming 20 INPUT TYPE (continued) RF TRANS. RF: Note that input types 4 & 5 are valid for certain 5800 series transmitters only (ex. 5801, 5802, 5802CP). When using 5700 series transmitters, always set the input type to type 3. The zone number of the transmitter identifies whether or not supervision...
Page 58: Serial Number Enrolling/Deleting
Serial Number SERIAL # PROG? Enrolling/Deleting 0=NO 1=YES ENTER ZONE NO. 00=QUIT 10 PROG AS RF: 2 DELETE S/N? 0=NO, 1=YES INPUT TYPE INPUT = 0 OR 3Ð6 LEARN S/N? 0=NO, 1=YES INPUT S/N:L 10 PROG AS RF:2 10 ZT P RC IN:L Ð...
Page 59: Entering Zone Descriptors
Alpha Programming If using an alpha keypad in the system, a user friendly English language description/location of all protection zones, partitions' keypad panics, polling loop short and RF receiver supervision faults can be programmed into the system. Each description can be composed of a combination of words (up to a maximum of 3) that are selected from a vocabulary of 244 words stored in memory, and any word can have an "s"...
Page 60: Adding Custom Words
Entering Zone Descriptors (continued) Adding Custom Words Ð 60 Ð 5. When all desired words have been entered, press key [8] to store the description in memory. 6. To review the zone descriptions, key [#] plus zone number (e.g., #01). To edit zone descriptions, key [*] plus zone number (e.g., *01) 7.
Page 61: Creating Partition Descriptors
Creating Partition 1. Select "Part DESCRIPT." mode. The system will ask for the partition number Descriptors 2. Follow the same procedure as for CUSTOM WORDS, except that partition Creating A Custom Normally, when the system is in the disarmed state, the following display is Message Display (Installer's present on the Keypad.
Page 62: Alpha Vocabulary
(For Entering Alpha Descriptors. To select a word, press [#] followed by the word's 3-digit number.) Bulleted words in bold face type are those that are also available for use by the 4285 phone module. If using a phone module, and words other than these are selected for alpha descriptors, the phone module will not provide annunciation of those words.
Page 63: Device Programming
Device Programming Ð 63 Ð This menu is used to program keypads, receivers and relay modules. From Data Field Programming mode, press #93 to display "ZONE PROG?". Press 0 repeatedly to display "DEVICE PROG?". Press 1 to enter DEVICE PROGRAMMING mode. DEVICE PROG? 1=YES 0=NO Enter the 2-digit device number as set by the...
Page 64: Vim Voice Interface Module Prompts
VIM Voice Interface Module Prompts NOTE: The VIM reports supervisory faults as zone 93. Make sure to program a response type (trouble = response type 05) and report code to zone 93 using #93 Menu Mode - ZONE PROGRAMMING. Ð 64 Ð If device type 7 (VIM) is selected, the following prompts will appear.
Page 65: Relay Programming
Relay Programming The VISTA-40 supports up to eight (8) X-10 and/or relay outputs. The X-10 interface is made via a 4300 plug-in transformer. Relay and X-10 devices are interchangeable in functionality. Once a device is programmed into the system, there is no distinction between an X-10 or a relay output device. These relay output actions Relays can be used to perform many different function and actions.
Page 66 Relay Programming M e n u s Ð 66 Ð The following is a list of choices for (ZT): CHOICES FOR ZONE T Y P E S : 00 = No Response (Not Used) 01 = Entry/Exit #1 02 = Entry/exit #2 03 = Perimeter 04 = Interior Follower 05 = Trouble Day/Alarm Night...
Page 67 02 ÊÊA EV ZL ZT P STT Ê 0Ê 0 02 ÊÊA EV ZL ZT P STOP 0 0 0 00 NOTE: 4204 Relay Module 02 RELAY ACTION must be rev. "V3" or higher to NO RESPONSE activate temporal pulsing. 02 START EVENT NOT USED 02 START: ZN LIST...
Page 68: Zone List Programming
Zone List Programming Programming Relays for Silencing of External Sounders When Using the Ð 68 Ð After entering all relay menu items, up to four (4) zone lists can be entered by entering 00 at the ENTERÊRELAYÊNo. prompt. Enter the zone list number 1-4. Enter Zone LIST 00=QUIT 00 Enter each zone to be included in this zone list,...
Page 69: Programming The Vim For Relay Triggering On Supervision Fault
Programming The Vim For To program the system to trigger a relay upon an VIM fault, use the Relay Relay Triggering On Programming Menu (as described earlier) but enter the following values at the Supervision Fault appropriate prompts. When programmed, the relay activates upon VIM failure and deactivates when the operation of the VIM is restored.
Page 70: Relay Voice Descriptors And Custom Word Substitute Vocabulary
Relay Voice Descriptors and Custom Word Substitutes Vocabulary Word Index Word Air... 116 Daughter's ... 208 Alarm ... 255 Den ... 052 And ... 067 Detector... 128 Apartment... 117 Device ... 060 Appliances ... 161 Dim ... 163 Area... 118 Dining ...
Page 71: Section 5. System Communication
Section 5. SYSTEM COMMUNICATION COMMUNICATION FORMATS Split/Dual Reporting Dual reporting (*51) sends all reports to both primary and secondary phone numbers. Split reporting allows reports to be divided between the phone numbers according to the field's (1*34) selections. Split/Dual reporting can be selected by enabling dual reporting and enabling one of the split reporting options in field 1*34.
Page 72 4+2 Express Ademco High Speed Reporting High Speed Format Limitations Ð 72 Ð In 4+2 reporting a unique 2-digit code for each zone is reported. A 4-digit account number followed by a 2-digit code is sent, where the first digit is the actual event, such as in ALARM, RESTORE, or TROUBLE, etc., and the second digit of the code represents the "zone"...
Page 73: Table Of Contact Id Event Codes
Contact ID Reporting Code Definition Fire Alarm Duress Silent Panic Audible Panic Perimeter Burglary Interior Burglary 24 Hour Burglary (zone type 11 if supported) Entry/Exit Burglary Day/Night Burglary 24 Hour Auxiliary AC Loss Low System Battery System Reset Program Tamper Battery Test Fail Poll Loop Short-Trouble Addressable Device Failure...
Page 74: Communication Programming
COMMUNICATION PROGRAMMING General Information Loading Communication Defaults NOTE: Default communication commands are in second set of programming fields (fields 1*80, 1*81, 1*82 & 1*83). Making Changes To Communication Fields Swinger Suppression Enabling Of Dialer Reporting By Partition Ð 74 Ð To help expedite the installation, the system provides 4 different communication defaults (Low Speed, Ademco Express, Ademco High Speed &...
Page 75: Summary Of Default Consequences
Field # Low Speed *46, *48 Choose transmission speed and frequency *52, *53 Send as either 4+2 or expanded *79, *80 Enables alarm restores Add checksum digit *81, *82 Define codes and selects 4+1 or 4+2 *54, *56, *59, *61, Defines alarm event *64, *66, *69, *71, code...
Page 76 ¥ Disables reporting Troubles, Trouble Restores, Bypass, Bypass Restores for all zones. Ð 76 Ð...
Page 77: Communication Defaults For Low Speed Format ( Q 94 Then 80)
COMMUNICATION DEFAULTS for LOW SPEED FORMAT ( PRIMARY FORMAT LOW SPEED FORMAT (Primary) SECONDARY FORMAT LOW SPEED FORMAT (Sec.) CHECKSUM VERIFICATION No checksum SESCOA/RADIONICS SELECT ALARM REPORT CODE & ID DIGITS FOR ZONES 1-32 & SUPERVISORY & RESTORE CODES 54 CODE 55 ID 56 CODE 1 Ê...
Page 78: Communication Defaults For Ademco Express Format ( Q 94 Then 81)
COMMUNICATION DEFAULTS for ADEMCO EXPRESS FORMAT ( PRIMARY FORMAT LOW SPEED FORMAT (Primary) SECONDARY FORMAT LOW SPEED FORMAT (Sec.) CHECKSUM VERIFICATION No checksum SESCOA/RADIONICS SELECT ALARM REPORT CODE & ID DIGITS FOR ZONES 1-32 & SUPERVISORY & RESTORE CODES 54 CODE 55 ID 56 CODE 1 Ê...
Page 79 ARM STAY & TIME SET REPORT CODES First Digit Ê 0 | 0 Ê Armed STAY Ê 0 | 0 Ê ime/Date set or event log reset Second Digit Ê 0 | 0 Ê Ê 0 | 0 Ê...
Page 80: Communication Defaults For Ademco High Speed Format ( Q 94 Then 82)
COMMUNICATION DEFAULTS for ADEMCO HIGH SPEED FORMAT ( PRIMARY FORMAT LOW SPEED FORMAT (Primary) SECONDARY FORMAT LOW SPEED FORMAT (Sec.) CHECKSUM VERIFICATION No checksum SESCOA/RADIONICS SELECT ALARM REPORT CODE & ID DIGITS FOR ZONES 1-32 & SUPERVISORY & RESTORE CODES 54 CODE 55 ID 56 CODE...
Page 81 ARM STAY & TIME SET REPORT CODES First Digit Ê 0 | 0 Ê Armed STAY Ê 0 | 0 Ê ime/Date set or event log reset Second Digit Ê 0 | 0 Ê Ê 0 | 0 Ê...
Page 82: Communication Defaults For Ademco's Contact Id Format ( Q 94 Then 83)
COMMUNICATION DEFAULTS for ADEMCO's CONTACT ID FORMAT ( PRIMARY FORMAT LOW SPEED FORMAT (Primary) SECONDARY FORMAT LOW SPEED FORMAT (Sec.) CHECKSUM VERIFICATION No checksum SESCOA/RADIONICS SELECT ALARM REPORT CODE & ID DIGITS FOR ZONES 1-32 & SUPERVISORY & RESTORE CODES 54 CODE 55 ID 56 CODE...
Page 83 ARM STAY & TIME SET REPORT CODES First Digit Ê 0 | 0 Ê Armed STAY Ê 0 | 0 Ê ime/Date set or event log reset Second Digit Ê 0 | 0 Ê Ê 0 | 0 Ê Ð 83 Ð...
Page 84: Section 6. Downloading
Section 6. DOWNLOADING REMOTE DOWNLOADING What Is Downloading? How Does Downloading Work? Advisories: 1. Alarm and trouble responses and reports are disabled during on-line time. Should an event occur during this time, the response will take place and the report will go through as soon as the remote access sequence is completed.
Page 85 What Can Be Done Once ¥ Arm the System in the Away Mode; Disarm the System Panel Is "On-Line"? ¥ Bypass a Zone ¥ Force the System to Accept a New Program Download ¥ Shut Down Communication (dialer) Functions (non-payment of monitoring fees in an owned system) ¥...
Page 86: Direct Wire Downloading
DIRECT WIRE DOWNLOADING Direct Wire Downloading Connections Ð 86 Ð The VISTA-40 can be downloaded without using a modem or telephone line by using AdemcoÕs V-Link ¨ downloading software (Rev. 4 or higher) or AdemcoÕs Compass Windows downloading software, and a 4100SM Serial Module. The direct wire downloading connection is to be temporary, and is not part of the permanent installation.
Page 87: Section 7. Setting The Real-Time Clock
Section 7. SETTING THE REAL-TIME CLOCK PROCEDURE NOTE: A 6139 alpha keypad must be used to set the real-time clock, or the clock can be set via the Downloader software. Only users with installer or master authority level can set the real-time clock. IMPORTANT: This method...
Page 88: Section 1. System Operation
PART 3 SYSTEM OPERATION & TESTING Ð 88 Ð...
Page 89: System Operation
Section 1. SYSTEM OPERATION SECURITY ACCESS CODES General Information The System allows up to a total of 70 security access codes to be assigned (maximum of 69 in a given partition), each identified by a user ID number. In addition, the Quick Arm feature can also be programmed, which enables the [#] key to be pressed instead of entering the security code when arming the system.
Page 90 User Codes & Levels Of Manager Authority (cont.) Open/Close Reporting Note: When adding a user, the system will only prompt for Open/Close report capability if the user is being added by the Installer. When a Master or Manager adds a new user, the Operator new user's Open/Close report- (Levels 3-5)
Page 91 ¥ A user can only be DELETED or CHANGED from within the partition he is assigned. ¥ User numbers must be entered as 2-digit entries. Single digit user numbers must, therefore, always be preceded by a "0" (example, 03, 04, 05, etc.). Make sure the end user understands this requirement.
Page 92 To ADD a Master, Manager or Operator code Installer must program least Master c o d e . Or Master or Manager code, but must be code with higher level of authority than the code being changed. (i.e. Master code can add a Manager or Operator level code, cannot...
Page 93 Part. 2 Ð SHOP ? 0 = NO , 1 = YES Part. 1 S WHSE User 03 Auth=3G. To CHANGE a Master, Enter Installer code + [8] + User number (02-69) + new code for that user. Manager or Operator code The system will detect that the user number is already assigned and will prompt if this is a new user.
Page 94: Keypad Functions
KEYPAD FUNCTIONS General Information Phone Module Arming Functions Note that if QUICK ARM is enabled (field *29), the [#] key can be pressed instead of entering the security code, for any of the arming procedures (Away, Stay, Instant, Maximum, etc.). Global Arming Notes: 1.
Page 95: Access Control
Bypassing Zones Chime Mode Ê Ê M o d e ÊÊA W A Y ÊÊS T A Y ÊINSTANT ÊMAXIMUM Access Control If programmed, one relay may be used for access control. To activate this relay, the user enters his user code + [0]. The designated relay will pulse for 2 seconds. Each partition can have its own output device.
Page 96: Panic Keys
Panic Keys End User Relay Command Mode (#70 Mode) Trouble Conditions "Check" Messages Zones 88-91, 87, 93 and 97 can be assigned alpha descriptors Other Trouble Conditions Ð 96 Ð There are three panic keys (or panic key pairs) that, if programmed, can be used to manually initiate alarms and send a report to the central station.
Page 97: Power Failure
Power Failure VIM VOICE INTERFACE MODULE OPERATOR FUNCTIONS General Information N O T E S : ¥ "LO BAT" (alpha) or "BAT" (fixed-word) and a zone descriptor, and a once per minute beep at the Keypad indicates that a low battery condition exists in the wireless transmitter displayed.
Page 98: Event Logging
Operator Commands EVENT LOGGING Event Logging Procedures Programming Event Logging Display Ð 98 Ð Note: If the operator makes a mistake in entering the proper 4-digit ID code, the operator just needs to re-enter the correct code. If after 5 minutes have elapsed without the central station callback, only a new alarm will initiate a new 2-way voice session.
Page 99 SCAN LOG BY PART 0=NO 1-2=PART # Use the [3] & [1] keys to scroll to the next or previous category screens respectively: ALARM EVENT LOG TYPE CCC UUU CHECK EVENT LOG TYPE CCC UUU BYPASS EVENT LOG TYPE OP/CL EVENT LOG TYPE CCC UUU SYSTEM EVENT LOG TYPE CCC UUU...
Page 100: Section 2. Testing The System
Section 2. TESTING THE SYSTEM Using The Test Mode After the installation is completed, the Security System should be thoroughly tested on a partition by partition basis as follows: 1. With the System in the disarmed state, check that all zones are intact. If 2.
Page 101: 2-Way Voice Test Mode
At the Protected Premises: To test the VIM and 6139AV keypad 2-way voice operation, both the installer at the protected premises and the central station operator do the following. NOTE: The VIM has built-in LEDs which identify its operating mode. It can be helpful to view these LEDs when performing the following test.
Page 102: Turning The System Over To The User
Turning The System Over To The User Ð 102 Ð 1. Fully explain the operation of the system to the user by going over each of its functions as well as the User's Manual supplied. 2. In particular, explain the operation of each zone (entry/exit, perimeter, interior, fire, etc.).
Page 103: Section 3. Summary Of System Commands
Section 3. SUMMARY OF SYSTEM COMMANDS TYPES OF COMMANDS Arming, Disarming And Silencing Commands Bypassing Commands User Code Edit Commands Chime Mode Commands Real Time Clock Commands System Test Commands Event Logging Commands Program Mode And Download Commands Scheduling Related Commands Miscellaneous Relay Commands...
Page 104 Wireless System House Id Sniffer Mode = Code + [#] + [2] (installer only) Transmitter ID Test = Code + [#] + [3] (installer only) Go/No Go Test = Code + TEST [5] Key) Keypad Functions Arming Away: Arming Stay: Arming Instant: Arming Maximum: Quick Arm:...
Page 105: Section 4. Regulatory Agency Statements
Section 4. REGULATORY AGENCY STATEMENTS UL INSTALLATION REQUIREMENTS The following requirements apply to UL Residential Burglary installations: 1. All partitions must be owned and managed by the same person(s). 2. All partitions must be part of one building at one street address. 3.
Page 106 CANADIAN DEPARTMENT OF COMMUNICATIONS (DOC) STATEMENT NOTICE The Canadian Department of Communications label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. The Department does not guarantee the equipment will operate to the user's satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company.
Page 107 DIP SWITCH TABLES FOR ADDRESSABLE POLLING LOOP DEVICES DIP SWITCH TABLES FOR ADDRESSABLE POLLING LOOP DEVICES 4208 ZONE EXPANDER SHOWN SET FOR ID 10 (A) Ð 107 Ð...
Page 108 DIP SWITCH TABLES FOR POLLING LOOP DEVICES DIP SWITCH TABLES FOR POLLING LOOP DEVICES 4275 PIR MIRROR SHOWN SET FOR ID 10 (A) SIDE VIEW (UP) 1 2 3 4 5 6 7 POS 6: UP (A), DN (B) = INST. MODE DN (A), UP (B) = PULSE COUNT POS.
Page 109: Dip Switch Tables
DIP SWITCH TABLES FOR 5700 RF SYSTEM WIRELESS DEVICES DIP SWITCH TABLES FOR 5700 SERIES WIRELESS DEVICES HOUSE ID 5701 PANIC TRANSMITTER SWITCH SETTING FOR ALL DEVICES EXCEPT 5716 HOUSE ID (1 SHOWN) DIP SWITCH POSITION DEVICE 1 2 3 4 5 6 —...
Page 110: Section 5. Specifications
Section 5. SPECIFICATIONS VISTA-40 CONTROL Physical: 12-1/2"W X 14-1/2"H X 3"D Electrical: VOLTAGE INPUT: ALARM SOUNDER OUTPUT: AUXILIARY POWER OUTPUT: 9.6VDC-13.8VDC, 750mA max. For UL installations, the accessories BACK-UP BATTERY: STANDBY: CIRCUIT PROTECTORS: DIGITAL COMMUNICATOR FORMATS SUPPORTED: ADEMCO HIGH SPEED ADEMCO 4+2 EXPRESS ADEMCO LOW SPEED ADEMCO CONTACT ID...
Page 111: Contacting Technical Support
CONTACTING TECHNICAL SUPPORT PLEASE, Before you call Technical Support, be sure you: ¥ READ THE INSTRUCTIONS! ¥ Check all wiring connections. ¥ Determine that the power supply and/or backup battery are supplying proper voltages. ¥ Verify your programming information where applicable. ¥...
Page 112 THE LIMITATIONS OF THIS ALARM SYSTEM While this System is an advanced wireless security system, it does not offer guaranteed protection against burglary, fire or other emergency. Any alarm system, whether commercial or residential, is subject to compromise or failure to warn for a variety of reasons. For example: ¥...
Page 113 WARNING: OWNER'S INSTRUCTION NOTICE NOT TO BE REMOVED NOTES: 1. Zone 1 may be selected for EOLR supervised or normally closed (no EOLR) operation via cut jumper. (Cut red jumper for normally closed operation. Do not cut for Fire Usage). Zones 2-8 may be selected for either operation via program field * 41.
Page 114 ADEMCO LIMITED WARRANTY Alarm Device Manufacturing Company, a Division of Pittway Corporation, and its divisions, subsidiaries and affiliates ("Seller"), 165 Eileen Way, Syosset, New York 11791, warrants its products to be in conformance with its own plans and specifications and to be free from defects in materials and workmanship under normal use and service for 18 months from the date stamp control on the product or, for products not having an Ademco date stamp, for 12 months from date of original purchase unless the installation instructions or catalog sets forth a shorter...
Page 115 ADDENDUM TO: VISTA-40 and VISTA 50P/UL Installation Instructions NEW "QED" DEVICE ENROLLMENT PROCEDURE FOR 5800 SERIES TRANSMITTERS AND SERIAL NUMBER POLLING LOOP DEVICES This addendum describes the new procedure for "enrolling" 5800 series transmitters or serial number polling-loop devices into the system. •...
Page 116 4. Enter the zone number that you wish to program. As an example, zone E NTE R ZN NO . 0 0 = Q UIT Zone 10 entered 5. A display will appear, showing a summary of that zone's programming. If 1 0 ZT P RC IN: L 0 0 –...
Page 117 10. The cursor should now be flashing on the loop number. The default is 10 LOOP # 11. If the device’s serial number has not been previously “enrolled,” you may 10 LEARN S/N? 1 = YES, 0 = NO 12. This prompt is displayed if "1" (YES) is entered in response to the "Learn 10 INPUT S/N Axxx-xxxx 10 INPUT S/N...
Page 118 10 ZT P RC IN:L s 03 1 00 RF:1 ENROLLING THROUGH SEQUENTIAL MODE (#93) (Use this mode only after all other zone information has been programmed, including transmitter loop numbers). PROGRAM TOOL? 0 = NO, 1 = YES 0 00 INPUT S/N: L Axxx-xxxx At any time during this step, you may press the [ ] key on the keypad or the...
Page 119 00 PROG AS BR:3 A123-4567 4. Enter the type of device(s) to be enrolled as follows: TE CHNO L O GY TYP E WIRE L E S S Default 5. Enter the first zone number to be enrolled (e.g., zone 10). E NTE R ZN NO .
Page 120 If you do not wish to enroll the zone displayed, press the # key on the keypad or the upper right-hand button on the program tool (a long beep will be heard to verify). The following prompt will appear: 10 LEARN S/N? 0 = NO, 1 = YES 0 To enroll now, enter "1"...
Page 121 RF SERIAL NUMBER CLEAR MODE (#93) This mode may be used in the event that an undesired transmitter has been enrolled during sequential enrolling, causing each subsequent serial number to be assigned to an incorrect zone. Performing this operation will delete all RF serial numbers, leaving all other zone information intact. You may then return to Sequential mode to re-enroll wireless transmitters.
Page 122 • All of the transmitters illustrated below have one or more unique factory assigned input (loop) ID codes. Each of the inputs requires its own programming zone (e.g., a 5803's three inputs require three programming zones). • Transmitter inputs entered as: "RF"...

This manual is also suitable for:

Vista-40

ADEMCO N7001V2 Installation Instructions Manual

Quick Links

Related Manuals for ADEMCO Ademco N7001V2

Summary of Contents for ADEMCO Ademco N7001V2

This manual is also suitable for:

Table of Contents
