ECOWATER
S Y S T E M S
INSTALLATION USING ECOWATER BYPASS VALVE
Filtered
Water OUT
120V AC
Outlet
1" Sweat
Adaptor
(not included)
1"
Copper
Tube*
Drain
Fitting
Valve
Drain
Hose
Valve
Drain
Hose
Unfiltered
Water IN
Unfiltered Water
to Outside Faucets
1" NPT Male Adaptor
(not included)
1" NPT Inlet
Check Valve*
1" NPT Installation Adaptor*
O-Ring Seal (2)*
#7214383
Bypass
* Included with filter - Pipe and
Valve
fittings supplied by installer.
Clip (2)*
Valve
INLET
FIG. 2
Pull out for
To adapt a copper tube to the filter, buy a compression fitting (garden hose thread to
filtered water
5/8" I.D. minimum tube and necessary tubing from your local hardware store.
"Service"
Push in for
Bypass
To standpipe, sump, laundry
tub or other suitable drain.
1-1/2"
Air Gap
FLOOR
DRAIN

Typical Installation Illustrations

Use if water supply flows from the left.
Include single or 3-valve bypass.
UNFILTERED
WATER
FROM FILTER
OUTLET
INSTALLATION USING 3-VALVE BYPASS
For filtered water SERVICE:
-Open the inlet and outlet
valves
For unfiltered BYPASS:
-Close the inlet and outlet
valves
-Open the bypass valve
(not included)
Clip (2)*
CONNECTING A RIGID VALVE DRAIN TUBE
Clip
Drain Fitting
1-1/2""
SUMP
Air Gap
LAUNDRY
TUB
1-1/2" Air Gap
6
CROSS-OVER
FILTERED
WATER
TO FILTER
INLET
BYPASS
Valve
OUTLET
INLET
Valve
Valve
1" Sweat
Adaptor
1" NPT
Male Adaptor
(not included)
1" NPT Inlet
Check Valve*
1" NPT Installation
Adaptor*
O-Ring Seal (2)*
Valve
INLET
Adaptor, garden hose
thread to compression
5/8" I.D.
(minimum)
copper tube
1-1/2"
Air Gap
STAND
PIPE
FIG. 3
FIG. 4
