Model : IH680P-U
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProLine IH680P-U and is the answer not in the manual?

Questions and answers

Related Manuals for Proline ProLine IH680P-U

Summary of Contents for Proline ProLine IH680P-U

  • Page 1 Model : IH680P-U INSTRUCTION MANUAL...
  • Page 2 Dear Customer, Thank you for purchasing a Prestige Ceramic Hob. The safety precautions and recommendations in these instructions are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance.
  • Page 3 BEFORE USING FOR THE FIRST TIME • Read the instructions carefully before installing and using the appliance • After unpacking the appliance, make sure it is not damaged. In case of doubt, do not use the appliance and contact your supplier or a qualified engineer. •...

  • Page 4: Advice For The Installer

    ADVICE INSTALLER FOR THE IMPORTANT Appliance installation and maintenance must only be carried out by QUALIFIED TECHNICIANS and in compliance with the local safety standards. Failure to observe this rule will invalidate the warranty. This induction hob caters for all kind of cooking, with its electromagnetic cooking zones, and its micro-computerised controls and multi-functions.
  • Page 5 1. Protection from over-heating A sensor monitors the temperature in the cooking zones. When the temperature exceeds a safe level, the cooking zone is automatically switched off. 2. Detection of small or non-magnetic items When a unsuitable size or non-magnetic pan (e.g. aluminium), or some other small item (e.g.
  • Page 6 Installation 1. Cut a hole in the worktop of the dimension shown in the diagram below. A minimum of 50 mm space should be left around the hole. The worktop should be at least 30 mm thick and made of heat-resistant material. As shown in Figure (1) Figure (1) 2.
  • Page 7 3. Fix the hob to the worktop using the four brackets on the base of the hob. The position of the brackets can be adjusted according to the thickness of the top. Cautions 1.The induction hob must be installed by a properly qualified person. Never try to install the appliance yourself.
