4. Parts Identification & Accessories
4-1 Receiver //
US-902D Pro / US-9216 Series
Dual Channel PLL Diversity Receiver
Power Switch
1
Channel Selector (Up/Down)
2
LCD panel
3
Volume control
4
Antenna
5
Squelch level adjustor
6
DCV Input (12-18V DC/300mA)
7
Unbalanced Ø6.3mm jack socket
8
Balanced XLR socket
9
US-903DC Pro / US-9364 Series
Dual Channel PLL Diversity Receiver
Power Switch
10
Channel Selector (Up/Down)
11
LCD panel
12
Volume control
13
Antenna
14
Charger
15
Squelch level adjustor
16
DCV Input (12-18V DC/900mA)
17
Unbalanced Ø6.3mm jack socket
18
Balanced XLR socket
19
5
4
RX2
RX2
RX1
9
14
15
13
16
RX2
RX2
RX1
19
3
4
1
2
6
RX1
Mixed
300
8
7
12
11
13
RX1
Mixed
900
18
17
10
6
