  • Page 1 AMB-N280S1 Board User Manual...
  • Page 2 Trademarks AMB-N280S1 is a registered trademarks of Acrosser; IBM PC is a registered trademark of the International Business Machines Corporation; Pentium is a registered trademark of Intel Technologies Inc; AMI is a registered trademark of AMI Software International Inc; other product names mentioned herein are used for identification purposes only and may be trademarks and/or registered trademarks of their respective companies.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 Introduction ...........................4 1.1. Specifications........................4 1.2. Package Contents ......................5 Chapter 2 H/W Information ........................6 Mainboard illustration (Top Side)..................6 Location & Definition of Jumpers and Headers ............... 8 Chapter 3 BIOS Settings........................15 3.1. Main Setup ........................16 3.2.

  • Page 4: Chapter 1 Introduction

    Chapter 1 Introduction AMB-N280S1 Series with Intel Atom N2800 processor is a multi-function Industrial Main-board, which is suitable for using in all kind of applications. Besides basic I/O ports like VGA, HDMI, USB, COM. LAN, and GPIO. It also compliant with most industry standards for computing usage including CE and FCC.

  • Page 5: Package Contents

    1.2. Package Contents 　 Check if the following items are included in the package. Quick Manual AMB-N280S1 board 1 x Driver CD 1 x COM port cable with four DB9 connectors 1 x SATA Cable 1 x SATA Power Cable...

  • Page 6: Chapter 2 H/W Information

    This chapter describes the installation of AMB-N280S1. At first, it shows the Function diagram and the layout of AMB-N280S1. It then describes the unpacking information that you should read carefully, as well as the jumper/switch settings for the AMB-N280S1 configuration.

  • Page 7: Bottom Side

    Bottom Side Mini PCI-E1* Intel N2800 CPU 1.86GHz Mini-PCIe Socket DIMM 1 Intel NM10 PCH 204-Pin DDR3 Socket Mini PCI-E2* SIM Card slot Mini-PCIe Socket * The Mini-PCIE1 supports 3G module but cannot supports mSATA module. And Mini-PCIe2 supports mSATA module only.

  • Page 8: Location & Definition Of Jumpers And Headers

    2.2 Location & Definition of Jumpers and Headers 17 21 ATX1 LVDS_P1 J485_1 Power Input Header Pin Header for LVDS backlight Pin Header for RS485 signal LVDS1 SYS_FAN1 JCMOS1 Pin Header for CMOS Pin Header for LVDS Pin Header for System Fan1 F_PANEL1 SATA_P1 SYS_FAN2...
  • Page 9 [1] Power Input Header（4*1 Pin 2.54mm） Definition Definition +12V IN +12V IN ATX1 * Please use the DC Power Cable in accessory to avoid the System damage. [2] CMOS Control Jumper (3*1 Pin 2.54mm) Setting Function Normal (Default) JCMOS1 Clear CMOS [3] Front Panel Header（5*2 Pin 2.54mm）...

  • Page 10: 7] Lpt Header (13*2 Pin 2.0Mm

    [6] GPIO Header（5*2 Pin 2.00mm） Definition Definition GPIO6 (0500 Bit6) GPIO22(0502 Bit6) GPIO15 (0501 Bit7) GPIO38(0x504 Bit6) GPIO7(0500 Bit7) J_GPIO1 GPIO33(0504 Bit1) GPIO36(0x504 Bit4) GPIO39(0x504 Bit7) [7] LPT Header (13*2 Pin 2.0mm) Definition Definition LPT1 LPT14 LPT2 -ERR LPT3 LPT16 LPT4 LPT17 LPT5...
  • Page 11 [9] LVDS Header（20*2 Pin 1.25mm） Definition Definition VDD_PANEL VDD_PANEL VDD_PANEL VDD_PANEL LVDS_A_DATA0- LVDS_A_DATA0+ LVDS_A_DATA1- LVDS_A_DATA1+ LVDS_A_DATA2- LVDS1 LVDS_A_DATA2+ LVDS_A_CLK- LVDS_A_CLK+ LDDC_DATA LDDC_CLK ， *Attention: The output default value of VDD_PANEL is 3.3V it also can be 5V or 12V by changing the hardware! [10]SATA Power Supply Header (4*1 Pin 2.00mm) Definition...
  • Page 12 [11] Serial Port 1-4 Header（20*2 Pin 2.0 mm） Definition Definition J_COM1-4 [12] Serial Port 5 Header（3*1 Pin 2.54mm） Definition Definition J_COM5 [13] Serial Port 6 Header（3*1 Pin 2.54mm） Definition Definition J_COM6 *Workable in RS-232 mode only...
  • Page 13 [14] Serial Port 6 Working Mode selection Header（two 3*1 Pin 2.54mm） Header Settings Working Mode RS-485 JP3、JP4 RS-232（Default） [15] RS485 Header（2*1 Pin 2.54mm） Definition Definition RS485+ RS485- J485_1 *Workable in RS-485 mode only [16] System Fan1 Header (3*1 Pin 2.54 mm) Definition Definition + 12V...
  • Page 14 [19] VGA Header（12*1 Pin 2.00 mm）(Reserve for Test) Definition Definition CRT_ON VSYNC HSYNC GREEN J_VGA1 BLUE DDCDAT DDCCLK [20] ATX2 Power Output Header （4*1 Pin 2.54mm） Definition Definition +12V ATX2 [1] The Mini-PCIe1 supports 3G module but cannot supports mSATA module. And Mini-PCIe2 supports mSATA module only.

  • Page 15: Chapter 3 Bios Settings

    Chapter 3 BIOS Settings This chapter describes the BIOS menu displays and explains how to perform common tasks needed to get the system up and running. It also gives detailed explanation of the elements found in each of the BIOS menus. The following topics are covered: Main Setup Advanced Setup Chipset Setup...

  • Page 16: Main Setup

    3.1. Main Setup Once you enter the AMI BIOS™ CMOS Setup Utility, the Main Menu will appear on the screen. Use the arrow keys to highlight the item and then use the <Pg Up> <Pg Dn> keys to select the value you want in each item.
  • Page 17 Project Version This item displays the Project Information. Motherboard Version This item displays the Mother Board Model. This item displays the Built information Built Data & Time System Date Set the date. Use Tab to switch between Date elements System Time Set the time.

  • Page 18: Advanced Setup

    3.2. Advanced Setup Option Choice Description ACPI Settings ACPI Options Settings Power On Power Fail settings CPU Configuration This item displays the CPU and Parameters. IDE Configuration SATA and IDE port configuration. USB Configuration Monitor hardware status SMART Settings Power Sub System System Super IO Chip Parameters.

  • Page 19: Acpi Settings

    3.2.1 ACPI Settings Option Choice Description Enable ACPI Auto Enabled / Disabled Enable or disable APCI Settings Configuration Enable Hibernation Enabled / Disabled Enable or disable Hibernation Disable / S1 Only / ACPI Sleep State Define ACPI State while Suspend button pressed S3 Only...

  • Page 20: Power On Configuration

    3.2.2 Power On Configuration Option Choice Description PowerOn After Power On/ Power Define the system Power status after Power Fail. Power Fail Off / Last Status...

  • Page 21: Cpu Configuration

    3.2.3 CPU Configuration Option Choice Description Enabled / Disabled Enabled or Disabled the Hyper-Threading Technology. Hyper-Threading Execute Disable Bit Enabled / Disabled Enabled or Disabled the Execute Disable Bit Function...

  • Page 22: Ide Configuration

    3.2.4 IDE Configuration Option Choice Description SATA Controller(s) Enabled / Disabled Enable or Disable SATA Device. SATA Mode IDE / AHCI Determines how SATA controller(s) operate. Selection Enabled / Disabled Enable or Disable SATA Port SATA Port 0 SATA Port 0 Hot Plug Enabled / Disabled Designates this port as hot Pluggable SATA Port 1 Enabled / Disabled Enable or Disable SATA Port SATA Port 1 Hot Plug Enabled / Disabled Designates this port as hot Pluggable...

  • Page 23: Usb Configuration

    3.2.5 USB Configuration Option Choice Description Enables Legacy USB support. AUTO option disables legacy Legacy USB Enabled / Disabled support if no USB devices are connected. DISABLE option Support will keep USB devices available only for EFI applications. Enable or Disable the EHCI Hand-Off Function. It Could Enabled / Disabled EHCI Hand-Off Disable if driver of OS is not supported.
  • Page 24 3.2.6 SAMRT Configuration Option Choice Description Enabled / Disabled Enable or Disable the SMART Self Test SMART Self Test...

  • Page 25: Super Io Configuration

    3.2.7 Super IO Configuration Option Choice Description COM1 Set Parameters of COM1 Port COM2 Set Parameters of COM2 Port COM3 Set Parameters of COM3 Port COM4 Set Parameters of COM4 Port Set Parameters of COM5 Port COM5 Set Parameters of COM6 Port COM6 Set Parameters of LPT Port...
  • Page 26 3.2.7.1 COM Port Configuration COM Port 1~6 Configurations Option Choice Description Serial Port Enabled / Disabled Enable or Disable this Serial Port (1~6) Device Settings Show the Parameters of Serial Port (1~6)
  • Page 27 3.2.7.2 LPT Port Configuration Option Choice Description Parallel Port Enabled / Disabled Enable or Disable this Parallel Port Device Settings Show the Parameters of Parallel Port STD / SPP / EPP / Device Mode Change the Printer Port Mode...
  • Page 28 3.2.8 HW Monitor...

  • Page 29: Chipset Setup

    3.3. Chipset Setup Option Choice Description HOST Bridge Options and Settings HOST Bridge South Bridge Options and Settings South Bridge...

  • Page 30: Host Bridge

    3.3.1 HOST Bridge Option Choice Description Intel IGD Intel IGD Options and Settings Configuration Display the memory Information Memory Information...

  • Page 31: Intel Igd Configuration

    3.3.1.1 Intel IGD Configuration Option Choice Description IGFX – Boot Type VGA /LVDS / HDMI HOST Bridge Options and Settings LCD Panel Type VBIOS Default/LCD Select Panel Type Used Auto / Force / Off / Panel Scaling Select LCD Panel Scaling Options used Maintain Disable / Internal / Select Active LVDS Configuration...

  • Page 32: South Bridge

    3.3.2 South Bridge Option Choice Description Enable /Disable Intel IO Controller Hub devices TPT Devices...
  • Page 33 3.3.2.1 TPT Device Option Choice Description Azalia Controller Disable / HD Audio Enable or Disable the Azalia Audio Controller By Ports / By By Port or By Controller to setting the USB Mode Select USB Mode Controller USB Functions X USB Ports Enable or Disable the USB Ports (x : 0~8) USB 2.0(EHCI) Enable / Disable...

  • Page 34: Boot Setup

    3.4. Boot Setup Option Choice Description Bootup Number On / Off Enable or Disable the Azalia Audio Controller Lock Fullscreen Logo Enable / Disable By Port or By Controller to setting the USB Mode CSM Parameters Enable or Disable the USB Ports (x : 0~8)

  • Page 35: Csm Parameters

    3.4.1 CSM Parameters Option Choice Description Launch PXE OpROM Do not Launch / Controls the execution of UEFI and Legacy PXE OpROM Policy UEFI / Legacy Launch Storage Do not Launch / Controls the execution of UEFI and Legacy Storage OpROM OpROM Policy UEFI / Legacy Launch Video...

  • Page 36: Security Setup

    3.5. Security setup Option Choice Description Administrator Set Administrator Password Password User Password Set User Password...

  • Page 37: Save & Exit Setup

    3.6. Save & Exit Setup Option Choice Description Save Changes and Yes / No Reset System after Save the Changes Exit Discard Changes Yes / No Reset System but not Saving the Changes and Exit Save Changes Yes / No Saving the changes done so far Discard Changes Yes / No...

  • Page 38: Chapter 4 Function Description

    User Manual. 4.5. Serial ATA (SATA) There is one SATA port on the AMB-N280S1. There is also one SATA power connectors for the SATA hard disks and it has 1pcs SATA power cable in Accessory. If you need more SATA power cable, please contact your Acrosser sales representative for the quotation 4.6.
