- Page 1 AR-B5230 Series User’s Manual AR-B5230 Series CPU Board EPIC form factor, onboard VGA, LVDS with DDR2-SODIMM Built in two LAN, CF type-II Edition: 1.4 Book Number: AR-B5230 Series-09.07.02...
- Page 2 AR-B5230 Series User’s Manual © Copyright 2006 All Rights Reserved. Manual’s first edition: October 31, 2006 For the purpose of improving reliability, design and function, the information in this document is subject to change without prior notice, which does not represent a commitment on the part of the manufacturer.
-
Page 3: Table Of Contents
AR-B5230 Series User’s Manual Contents INTRODUCTION .............. 4 ................4 PECIFICATIONS ................6 ................7 LOCK IAGRAM INSTALLATION ..............8 ..................8 OCATIONS ........ 10 IST OF ONNECTORS AND UMPER ETTINGS BIOS SETTING............... 15 MAIN SETUP ................16 ............17... -
Page 4: Introduction
AR-B5230 Series User’s Manual INTRODUCTION Welcome to the AR-B5230 Series (5230/5231) EPIC board. The AR-B5230 Series (5230/5231) ® incorporates the advanced Intel 915GME(5230)/910GMLE(5231) Chipset. It supports the Pentium M and Celeron M processors, while coming with a 400MHz Front Side Bus. - Page 5 AR-B5230 Series User’s Manual PCI-104 slot: PS/2: One PS/2 connector for keyboard and mouse GPIO: 8 bit GPIO Watch dog: Software programmable 1~63 Seconds Hardware monitor: CPU voltage CPU and System temperature CPU/System Fan speed control: AT : 12V single voltage input (BIOS default)
-
Page 6: What You Have
AR-B5230 Series User’s Manual 1.2 What You Have Before you begin to install your AR-B5230 Series (5230/5231) board, please make sure that the following items are inside the AR-B5230 Series (5230/5231) package. The quick manual AR-B5230 Series (5230/5231) board Software utility CD... -
Page 7: Block Diagram
AR-B5230 Series User’s Manual 1.3 Block Diagram... -
Page 8: Installation
AR-B5230 Series User’s Manual INSTALLATION This chapter describes the installation of AR-B5230 Series (5230/5231). At first, it shows the Function diagram and the layout of AR-B5230 Series (5230/5231). It then describes the unpacking information which you should be careful with, as well as the jumper/switch settings for the AR-B5230 Series (5230/5231) configuration 2.1 Locations... - Page 9 AR-B5230 Series User’s Manual Buttom Side 36. JP8,JP9...
-
Page 10: List Of Connectors And Jumper Settings
AR-B5230 Series User’s Manual 2.2 List of Connectors and Jumper Settings 2.2.1 Power input (CN4) SIGNAL +12V 2.2.2 ATX function connector (CN5) SIGNAL PS_ON +5V_SUS 2.2.3 CPU fan (FAN1) 2.2.4 CPU select jumper (JP7) SIGNAL SHORT DOTHAN OPEN BANINES 2.2.5 PCI-104 support SERIRQ (JP6) Note: Short this jumper in order to support SERIRQ function. - Page 11 AR-B5230 Series User’s Manual SIGNAL SIGNAL USB0- USB1- USB0+ USB1+ 2.2.10 CF card Master/Slave select jumper (JP4) SIGNAL SHORT MASTER OPEN SLAVE 2.2.11 CMOS clear jumper (JP1) 2.2.12 Keyboard lock (J3) 2.2.13 RTC battery connector (CN1) 2.2.14 Keyboard/Mouse connector (KM1)
- Page 12 AR-B5230 Series User’s Manual SIGNAL SIGNAL TD0+ TD0- TD1+ TD1- TD2+ TD2- TCK+ TCK- SCL1 SDATA1 GREEN BLUE VSYNC SCL2 HSYNC SDATA2 2.2.20 V-out connector (TVCON1) SIGNAL SIGNAL CVBS/Pb-G C/Pr-G 2.2.21 Internal COM2 connector (COM2) SIGNAL SIGNAL /DCDB /DSRB RXDB...
- Page 13 AR-B5230 Series User’s Manual SIGNAL SIGNAL /DCDB /DSRB RXDB /RTSB TXDB /CTSB /DTRB /RIB 2.2.25 System FAN (FAN2) Note: The FAN will start to work when temperature over 67ºC and stop when temperature below 53ºC. 2.2.26 Switch button (J1) SIGNAL...
- Page 14 AR-B5230 Series User’s Manual SIGNAL 2.2.31 LVDS voltage select jumper (JP5) SIGNAL 3.3V 2.2.32 Interver connector (CN3) SIGNAL SIGNAL +12V +12V 2.2.33 LVDS connector (LVDS1) 2.2.34 DDR2 connector (DDR2SODIMM1) 2.2.35 Type II CF card connector (CN2) 2.2.36 FSB select jumper (JP8/JP9)
-
Page 15: Bios Setting
AR-B5230 Series User’s Manual BIOS SETTING This chapter describes the BIOS menu displays and explains how to perform common tasks needed to get up and running. It also gives detailed explanation of the elements found in each of the BIOS menus. The following topics are covered:... -
Page 16: Main Setup
AR-B5230 Series User’s Manual 3.1 MAIN SETUP Once you enter the AwardBIOS™ CMOS Setup Utility, the Main Menu will appear on the screen. Use the arrow keys to highlight the item and then use the <Pg Up> <Pg Dn> keys to select the value you want in each item. -
Page 17: Advanced Chipset Setup
AR-B5230 Series User’s Manual 3.2 Advanced Chipset Setup Option Choice Description This category speeds up Power On Self Test (POST) after Quick Power On Enabled you have powered up the computer. If it is set to Enable, Disabled Self Test BIOS will shorten or skip some check items during POST. -
Page 18: Power Setup
AR-B5230 Series User’s Manual 3.3 Power setup Option Choice Description This item sets Advanced Configurtion and Power Enabled Interface.When ATX mode is enabled and AT mode is ACPI Function Disabled disabled. S1&S3 This item sets Advanced Configurtion and Power S1(POS) ACPI Suspend Type Interface mode.It is asserted ACPI Function is enable. - Page 19 AR-B5230 Series User’s Manual 3.4 PnP/PCI setup Option Choice Description Normally, you leave this field Disabled. Select Enabled to reset Extended System Configuration Data (ESCD) Reset Configuration Enabled when you exit Setup. If you have installed a new add-on Disabled...
-
Page 20: Peripherals Setup
AR-B5230 Series User’s Manual 3.5 Peripherals Setup Option Choice Description Onboard Serial Port 1 Serial Port 1: 3F8 / IRQ4 Select an address and the Onboard Serial Port 2 Serial Port 2: 2F8 / IRQ3 corresponding interrupt for each Serial Port 3: 3E8 / IRQ11... -
Page 21: Pc Health Setup
AR-B5230 Series User’s Manual 3.6 PC Health Setup This section shows the parameters in determining the PC Health Status. These parameters include temperatures, fan speeds, and voltages. 21/21... -
Page 22: Boot Setup
AR-B5230 Series User’s Manual 3.7 Boot setup Option Choice Description Hard Disk CDROM First / Second / Third The BIOS attempts to load the USB-FDD operating system from the devices in Boot Device/Other Boot USB-CDROM the sequence selected in these items. -
Page 23: Exit Setup
AR-B5230 Series User’s Manual 3.8 Exit SETUP Option Choice Description Press “Y” to store the selections made in the menus in CMOS – a special Pressing <Enter> on this section of memory that stays on after item for confirmation: you turn your system off. The next time you boot your computer, the BIOS Save &... - Page 24 AR-B5230 Series User’s Manual Type the password, up to eight characters in length, and press <Enter>. The password typed now will clear any previous password from the CMOS memory. You will be asked to confirm the password. Type the password again and press <Enter>.
- Page 25 AR-B5230 Series User’s Manual ATX and AT POWER CONFIGURATION J1 (SPEAKER, RESET, and POWER BUTTON JUMPER Setting) When using an AT power supply in your system, the pin5-6 of header J1 must be shorted. If using an ATX power supply in the system, the pin5-6 of header J1 should connect to a Push-Button-Switch.
