Inverter Setup
Displays the various data for the specific inverter. This information is set during the
manufacturer process. The information is used by service and maintenance personnel.
Model
Serial Number
THEIA Part Number
THEIA Version
GUI Software Part No
GUI Software Version
GUI Hardware Part No
GUI Hardware Version
SW1 Part No
SW1 Version
Control Board Part No
Control Board Version
Main Board Part Number
Main Board Hardware
Version
SW2 Part No
SW2 Version
Grid Setup
Displays grid settings based on the selected country. The settings can be changed using the
password within 5 hours of feeding in power to the grid after installation. Thereafter it is only
accessible by using the Installer password, which may only be obtained by contacting Eltek
Valere.
Country
Country code
Grid nom voltage
Grid nom frequency
Voltage limit min
Voltage limit max
Voltage time limits min
Voltage time limits max
Frequency limits min
Frequency limits max
Frequency time limits min
Frequency time limits max
54
Inverter model
Unique identifier for each inverter. Also to be found on the product
label
Identifier for each inverter hardware configuration within Eltek Valere
Unique version name for keeping track of the development of different
inverter versions within Eltek Valere
The GUI (Graphical User Interface) software part number. GUI allows
interaction with the inverter through the display
Version number for the GUI software
Identifier for the GUI-card hardware
Version number for the GUI hardware
The DSP1 (Digital Signal Processing) software part number. DSP is a
microprocessor controlling the power conversion in the inverter
Version number for the DSP1 software
DSP-card hardware part number
Version name for the DSP control card hardware
Identifier for the PCB (Printed Circuit Board) hardware. PCB hosts all
the components and subsystems of the inverter
Unique version number for keeping track of the development of
different main board versions
The DSP2 software part number
Version number for the DSP2 software
Country of the installation
Name of the grid protection standards
Nominal voltage of the grid on site
Nominal frequency of the grid on site
Lower disconnection limit of the grid voltage on site
Upper disconnection limit of the grid voltage on site
Minimum disconnection time limit
Maximum disconnection time limit
Lower disconnection limit of the grid frequency on site
Upper disconnection limit of the grid frequency on site
Minimum disconnection time limit
Maximum disconnection time limit
