Short user guide
innovaphone IP 200
Display
Symbol
Description
Loudspeaker
Microphone
Call diversion
Telephone locked
Handset
Headset
Connection down
Connection up
Keys
Key
Function...
Enter main menu, leave menu and save changes
Leave menu without saving the changes
Shift key to enter an uppercase letter
Alt key to enter a special character
Backspace, deletes one character on the left
Space, to enter spaces
Enter to complete entries or confirm selection
Leave the menu without saving
Do not disturb, ring tone off
Displays in-bound call list
Displays out-bound call list
Starts hands-free calling
Name
Symbols
Date
...during connection
Setup a conference
Terminate active call
On hook / off hook using headset
Terminate active call
Mute, microphone off
Consultation call
Forward active call
Speaker on, change to hands-free mode
Number
Time
Symbols

Advertisement

loading
Need help?

Need help?

Do you have a question about the IP 200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Innovaphone IP 200

Summary of Contents for Innovaphone IP 200

  • Page 1 Short user guide innovaphone IP 200 Display Symbol Description Name Number Loudspeaker Microphone Call diversion Telephone locked Handset Headset Connection down Connection up Symbols Date Time Symbols Keys Function..during connection Enter main menu, leave menu and save changes Setup a conference...
  • Page 2 Actions Action Status Keys Description Accept call pick up The display shows caller and called party Reject call Caller gets a busy tone Terminate call hang up, The active call is terminated Make call 0...9, then All numbers can be entered after picking up the handset Dial via phonebook a...Z, dann...

  • Page 3: Function Key Configuration

    Function key configuration Key function Display Description Dial Dials the configured number Call Forwarding Configuration of automatic call forwarding Up to 4 different destinations can be configured Call forwarding unconditional on busy or on no reply 3: Aus shows call forwarding on busy or no reply, Call forwarding unconditional shows the complete number in display Lock Locks the phone, only out-bound calls using dial pad are possible...

  • Page 4: Menu Structure

    VLAN registration reset configuration All described functions are related to the IP200 phone connected to an innovaphone PBX. The configuration of the phone has to be done over Web interface. Use this key to enter the menu, select administration and confirm with , select information and confirm again.
