Porter-Cable PCC640 Instruction Manual

20 volt max* 1/4” lithium-ion cordless impact driver
Hide thumbs Also See for PCC640:

Advertisement

Table of Contents

See also: Instruction Manual
20 Volt Max* 1/4" Lithium-Ion
Cordless Impact Driver
6.35mm visseuse à percussion sans fil á
block-piles au lithium-ion de 20v Max*
6.35mm destornillador de impacto
inalámbrico de iones de litio de 20v Max*
Instruction manual
Manuel d'instructions
Manual de'instrucciones
www.portercable.com
INSTRUCTIVO DE OPERACIÓN,
CENTROS DE SERVICIO Y PÓLIZA DE
GARANTÍA.
ADVERTENCIA: LÉASE ESTE
INSTRUCTIVO ANTES DE USAR EL
PRODUCTO.
*Maximum initial battery pack voltage
(measured without a workload) is 20
volts. The nominal voltage is 18.
CATALOG NUMBERS
PCC640

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCC640 and is the answer not in the manual?

Questions and answers

Related Manuals for Porter-Cable PCC640

Summary of Contents for Porter-Cable PCC640

  • Page 1 INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA DE GARANTÍA. ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO. *Maximum initial battery pack voltage (measured without a workload) is 20 CATALOG NUMBERS volts. The nominal voltage is 18. PCC640...

  • Page 2: General Safety Rules

    SAfETy GUIDELINES - DEfINITIONS It is important for you to read and understand this manual. The information it contains relates to protecting YOUR SAFETY and PREVENTING PROBLEMS. The symbols below are used to help you recognize this information. DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
  • Page 3 b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, nonskid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries. c) Prevent unintentional starting. Ensure the switch is in the off position before connecting to power source and/ or battery pack, picking up or carrying the tool.

  • Page 4: Specific Safety Rules

    SPECIfIC SAfETy RULES • Hold power tool by insulated gripping surfaces, when performing an operation where fastener may contact hidden wiring. Fasteners contacting a “live” wire may make exposed metal parts of the power tool “live” and could give the operator an electric shock.

  • Page 5: Functional Description

    Symbols • The label on your tool may include the following symbols. The symbols and their definitions are as follows: V ......volts A ....amperes Hz ....hertz W ....watts min ....minutes or AC ..alternating current n o ....no load speed or DC ..direct current .....Class I Construction ....earthing terminal (grounded)
  • Page 6 • Shock hazard. Do not allow any liquid to get inside charger. • Burn hazard. To reduce the risk of injury, charge only designated PORTER-CABLE batteries. Other types of batteries may burst causing personal injury and damage.
  • Page 7 2. Long storage will not harm the battery pack or charger. CHARGING PROCEDURE PORTER-CABLE chargers are designed to charge PORTER-CABLE battery packs. Charge times are: PCC690L in 40-80 mins., PCC691L in 70-140 mins. and PCC695L in 180-360 mins. depending on the pack being charged.

  • Page 8: Operating Instructions

    BAD BATTERy The charger can detect a weak or damaged battery. The LED flashes in the pattern indicated on the label. If you see this bad battery blink pattern, do not continue to charge the battery. Return it to a service center or a collection site for recycling.
  • Page 9 TO REMOVE BATTERY PACk: Depress the battery release button (7) as shown in figure C and pull battery pack out of tool. VARIABLE SPEED TRIGGER SWITCH - fIGURE D To turn the tool on, squeeze the trigger switch (1). To turn the tool off, release the trigger switch. Your tool is equipped with a brake.

  • Page 10: Troubleshooting

    LED WORk LIGHT When impact driver is activated by pulling the trigger switch (1), the integrated LED work light (9) will automatically illuminate the work area. NOTE: The work light is for lighting the immediate work surface and is not intended to be used as a flashlight. Bit Tip Storage Two magnetic bit storage slots (5) are built into the area on the top of the tool.

  • Page 11: Maintenance

    We cannot guarantee repairs made or attempted by others. You can also write to us for information at PORTER-CABLE, 4825 Highway 45 North, Jackson, Tennessee 38305, (888) 848-5175 - Attention: Product Service. Be sure to include all of the information shown on the nameplate of your tool (model number, type, serial number, etc.).
  • Page 12 90 DAy MONEy BACk GUARANTEE: If you are not completely satisfied with the performance of your PORTER-CABLE Power Tool for any reason, you can return it within 90 days from the date of purchase with a receipt for a full refund – no questions asked.
